English
Installing the Wireless
Keyboard and Mouse Set
The wireless keyboard and mouse set consists
of a receiver (D) that plugs into the computer,
a wireless keyboard (K) and a wireless
mouse (M).
Note: This wireless set is compatible with
your model PC and not intended
for use with other computers.
D
K
M
Note: You can replace the batteries in the mouse
and keyboard without turning off the
computer. The computer must be on to
change the ID setting on the three units.

2Installing the Wireless Keyboard and Mouse Set
Filename: s3adwlpEU.doc Title: HP-Print2k.dot
Template: HP-Print2K.dot Author: kimt Last Saved By: kimt
Revision #: 103 Page: 2 of 100 Printed: 03/06/03 02:02 PM
Getting the Mouse Ready
M2 M1
M3
Note: Do not use rechargeable batteries
in the mouse. Alkaline batteries are
recommended.
Install the two AA alkaline batteries (provided)
in the wireless mouse:
1 Push in at M1, and lift the battery cover (M2)
from the bottom of the mouse.
2 Insert the batteries into the compartment.
Note the battery images on the inside of the
compartment, and make sure batteries are
placed in the correct direction.
3 Replace the cover.
Note: The red light (M3) turns on when the
batteries are installed correctly.

Installing the Wireless Keyboard and Mouse Set 3
Filename: s3adwlpEU.doc Title: HP-Print2k.dot
Template: HP-Print2K.dot Author: kimt Last Saved By: kimt
Revision #: 103 Page: 3 of 100 Printed: 03/06/03 02:02 PM
English
Getting the Keyboard Ready
K1 K3
K3 K2
K
Note: Do not use rechargeable batteries in
the keyboard. Alkaline batteries are
recommended.
Install the two AA alkaline batteries (provided) in
the wireless keyboard:
1 Place the keyboard (K) upside down with the
battery compartment (K2) away from you, as
shown in the illustration.
2 Remove the cover (K1) from the bottom of the
keyboard.
3 Insert a battery into the compartment (K2),
and slide the battery to the right. Insert the
second battery. Note the battery images on the
inside of the compartment, and make sure
batteries are placed in the correct direction.
4 Replace the cover.
5 Adjust the keyboard height by lifting the
adjustment legs (K3).
