Compaq 5000 Series User manual

End-User Replaceable Parts Program
Replacing the 1394 Card
5 and 7 Series

Notice
© 2000 Compaq Computer Corporation
COMPAQ and the Compaq logo registered in U.S. Patent and Trademark
Office.
Microsoft and Windows are trademarks of Microsoft Corporation.
All other product names mentioned herein may be trademarks or registered
trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors or omissions
contained herein. The information in this document is subject to change
without notice.
The information in this publication is subject to change without notice and
is provided "AS IS" WITHOUT WARRANTY OF ANY KIND. THE
ENTIRE RISK ARISING OUT OF THE USE OF THIS INFORMATION
REMAINS WITH RECIPIENT. IN NO EVENT SHALL COMPAQ BE
LIABLE FOR ANY DIRECT, CONSEQUENTIAL, INCIDENTAL,
SPECIAL, PUNITIVE, OR OTHER DAMAGES WHATSOEVER
(INCLUDING WITHOUT LIMITATION DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
BUSINESS INFORMATION), EVEN IF COMPAQ HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE
FOREGOING SHALL APPLY REGARDLESS OF THE NEGLIGENCE
OR OTHER FAULT OF EITHER PARTY AND REGARDLESS OF
WHETHER SUCH LIABILITY SOUNDS IN CONTRACT,
NEGLIGENCE, TORT, OR ANY OTHER THEORY OF LEGAL
LIABILITY, AND NOTWITHSTANDING ANY FAILURE OF
ESSENTIAL PURPOSE OF ANY LIMITED REMEDY.
The limited warranties for Compaq products are exclusively set forth in the
documentation accompanying such products. Nothing herein should be
construed as constituting a further or additional warranty.
Compaq Presario
First Edition (September 2000)
Part Number 216695-001

REPLACING THE 1394 CARD 3
Replacing the
1394 Card
The 1394 card (also known
as IEEE 1394) has a high-
speed serial bus that allows
for simultaneously
connecting up to 63
devices. The 1394 card fits
into a Peripheral
Component Interconnect
(PCI) slot on the system
board.
It is widely used for
attaching video devices to
the computer.
Introduction
Your Compaq Internet PC has an Easy Access panel that
makes accessing the internal parts easy. This document
contains instructions for removing and replacing the 1394
card (see Figure 1-1).
Figure 1-1
Note: The view shown may vary slightly by model.

4REPLACING THE 1394 CARD
Tools Needed
A Phillips screwdriver is needed to remove and replace the
1394 card.
Warranty Statement
Compaq provides these detailed instructions to ensure your
safety and to keep your PC from being damaged. Following
these instructions also ensures that your PC remains
warranted by Compaq.
Your replacement part is warranted for the longer of 90 days
from the date the part was delivered to you, or the original
One Year Limited Warranty that came with your Compaq
Presario.
Preparing Your Computer for Disassembly
Before beginning the removal and replacement procedure,
complete the following procedure:
1. Remove any diskette or compact discs (CDs) from the
computer.
2. Turn off the computer and any peripheral devices
connected to your computer.
3. Disconnect the power cord from the electrical outlet, and
then from the computer (see Figure 1-2).
4. Disconnect all peripheral device cables from the computer.
Failure to disconnect the power from the computer may
result in personal injury.

REPLACING THE 1394 CARD 5
I. Disconnecting the Power
1. To shut down your computer, click the Start button, and
then click Shut Down. The Shut Down Windows dialog
box is displayed. Click OK to turn the computer off.
2. Disconnect the power cord from the electrical outlet 1
and 2computer (see Figure 1-2).
Failure to disconnect the power from the computer may
result in personal injury.
Figure 1-2

6REPLACING THE 1394 CARD
You do not have to replace the
screw securing the side access
panel. The screw securing the
side panel is used for shipping
purposes only.
Did you know ...
II. Opening the Side Access Panel
1. Remove the screw 1securing the side access panel.
Locate the latch 2directly below the screw, press the latch
down, and hold it in the down position (Figure 2-1).
Figure 2-1
Important: Some models may not have a screw 1. This screw is used
for shipping purposes only.
2. Grab the handle and slide the side panel from the chassis
(see Figure 2-2).
▲Caution: Before doing any work inside your computer, ground
yourself by touching a metal part of the chassis.
Figure 2-2

REPLACING THE 1394 CARD 7
Look at the replacement part
carefully to help you identify
and locate the component to
be replaced.
Tip
III. Identifying and Locating the 1394 Card
Use the illustration to identify and locate the following items:
the 1394 card 1, the PCI system board slot 2, and the rear
connector slot 3(see Figure 3-1).
Figure 3-1
Important: The number of PCI slots may vary by model. The replacement
1394 card may differ slightly from the original card.

8REPLACING THE 1394 CARD
IV. Removing the 1394 Card
1. Turn the computer on its side (open side facing up), and
locate the 1394 card.
2. Disconnect the Front I/O and the power cable (4 pin
connector) from the 1394 card (see Figure 4-1).
Figure 4-1

REPLACING THE 1394 CARD 9
3. Remove the screw 1securing the 1394 card, and save it
for your replacement card (see Figure 4-2).
Important: Keep the screw that secured the defective card to the
chassis. You will need it for your replacement card.
4. Pull the 1394 card using a gentle rocking (side-to-side)
motion from the PCI slot 2on the system board
(see Figure 4-2).
Figure 4-2

10 REPLACING THE 1394 CARD
V. Replacing the 1394 Card
Note: Save all the packing materials received with your replacement card.
You will need them to return the defective part.
1. Align the 1394 card with the PCI slot 1on the system
board and with the expansion card rear connector slot on
the chassis (see Figure 5-1).
Figure 5-1

REPLACING THE 1394 CARD 11
2. The 1394 card rear connector(s) 1must be inserted
properly into the expansion card rear connector slot 2to
ensure the card will seat properly into the PCI slot on the
system board (see Figure 5-2).
Note: Carefully insert the rear connector(s) on the 1394 card inside the
expansion card rear connector slot on the chassis.
Figure 5-2
Ensure that the card is
properly positioned into the
rear connector slot on the
chassis.
Tip

12 REPLACING THE 1394 CARD
3. Carefully and firmly press the 1394 card into the PCI slot.
4. Replace the screw 1to secure the 1394 card to the chassis
(see Figure 5-3).
Figure 5-3

REPLACING THE 1394 CARD 13
5. Reconnect the Front I/O 1and the power 2cable (4 pin
connector) to the 1394 card (see Figure 5-4).
Figure 5-4

14 REPLACING THE 1394 CARD
VI. Replacing the Side Access Panel
Align the tabs on the top and bottom of the side access panel
with the slots (located on the top and bottom edge) on the
chassis and slide the side access panel into place
(see Figure 6-1).
Figure 6-1
You do not have to replace the
screw securing the side access
panel. The screw securing the
side panel is used for shipping
purposes only.
Did you know ...

REPLACING THE 1394 CARD 15
VII. Checking To See If the Replacement Part Is
Installed Properly
1. Reconnect the power cord to the computer and then to the
electrical outlet.
2. Reconnect all peripheral device cables to the computer.
3. Turn on the computer using the power button and verify
that the replacement part is properly installed
(see Figure 7-1).
Figure 7-1
4. If the problem persists, repeat the Removing and
Replacing procedures.
5. If you are still experiencing problems, contact Compaq
Support: 1-800-984-9350
VIII. Returning the Defective Part
Please refer to the Compaq Part Return Instructions that came
with your replacement part for instructions on returning the
defective part.
