Compaq Deskpro AP550 Manual

135618-001 1
Addenda #1, 2, and 3 to Compaq
Professional Workstation AP550
Maintenance & Service Guide
Compaq Professional Workstation AP550
Part number 135618-003
Spare part number 158279-001
The complete MSG follows these addenda.
These addenda contain changes to the original document.
2000 Compaq Computer Corporation. All rights reserved. Compaq is
registered in the U. S. Patent and Trademark Office. Product names
mentioned herein may be trademarks and/or registered trademarks of their
respective companies. First Edition (July 2000).

2Addenda to MSG 135618-001
Spare Part Numbers
Description Spare Part Number Warranty Tier
Intel Pentium III processor with heatsink (154293-001) and
clip (120891-001)
600 MHz/133-MHz 162996-001 A
800 MHz/133-MHz 174768-001 A
867 MHz/133-MHz 180221-001 A
Intel Pentium III processor with heatsink (210720-001), air
bafle (167373-001) and clip (120891-001)
1 GHz/133 MHz 210403-001 A
Memory Modules
64-MB ECC Direct Rambus Inline Memory Module
(RIMM) 800-MHz 157108-001 A
512-MB ECC (100-MHz SDRAM) 317748-001 A
Graphics Controllers
Matrox MGA-G400A, AGP 2x/4x 163361-001 A
Intense3D Wildcat 4110, AGP 2X, 166013-001 A
Intense3D Wildcat 4210, AGP Pro 202996-001 A
Nvidia TNT2 PRO, 16-MB SGRAM 179997-001 A
ELSA Gloria II AGP, 64 MB 174641-001 A
Matrox G200 MMS 171975-001 A
Graphics adapter, DVI-i to VGA 202997-001 A
Hard Drives
10-GB Ultra ATA Hard Drive, 7200 RPM 330520-001 A
20-GB Ultra ATA Hard Drive, 7200 RPM 157403-001 A
20-GB Ultra ATA Hard Drive, 7200 RPM 180475-001 A
30-GB Ultra ATA Hard Drive, 7200 RPM, Quiet Drive 180477-001 A
36.2-GB Wide-Ultra 160 SCSI Hard Drive 192197-001 A
Other Drives
48X Max CD-ROM Drive 187263-001 A
32X Max R-W CD-ROM Drive 173747-001 A
DVD-ROM Drive, 6x/32x, Opal 120417-001 B
DVD-ROM Drive, 10x/40x, Opal 161430-001 B
LS-120 SuperDisk 209938-001 AContinued

135618-001 3
Spare Part Numbers (continued)
Description Spare Part Number Warranty Tier
Fast Ethernet NIC PCI, 10/100, Wake-On-LAN 116188-001 A
NIC 10/100 PCI card with Wake-On/Alert-On LAN 118042-001 A
Miscellaneous Cable Kit
CD-ROM data, 12.5”(179048-001)
CD-ROM data, 12.5”(105876-001)
Diskette drive, 15.5”(179049-001)
CD-ROM audio, 12”(288489-001)
Thermal sensor (166785-001)
Hard drive/CD-ROM drive data, 14”(242947-001)
Hard drive data, 7”(247116-001)
Hard drive/CD-ROM drive data, 14.25”(242947-008)
Diskette drive data, 12”(247176-003)
Hard drive, CD-ROM drive data, 10”(247116-002)
Y-adapter, hard drive data (296563-001)
179182-001 D

4Addenda to MSG 135618-001
Specifications –Graphics Controllers
Matrox MGA-G400A Graphics Controller
Maximum display resolution
Graphics
memory Color palette* Double-buffering without Z-buffering
Double buffering
with 16-bit Z-
buffering
Double buffering
with 32-bit Z-
buffering
16 MB 64 K colors (16-bit) 2048 x 1536 1800 x 1440 1600 x 1200
16 M colors (32-bit) 1600 x 1200 1280 x 1024 1280 x 1024
32 MB 64 K colors (16-bit) 2048 x 1536 2048 x 1536 2048 x 1536
16 M colors (32-bit) 2048 x 1536 2048 x 1536 1800 x 1440
* 3D acceleration is only available with a 16- or 32-bit color palette.
Intense3D Wildcat 4110 Graphics Controller
Supported Resolutions Without Multisampling
bits per pixel
Aspect Ratio 96 128 160 192
4 x 3 1824x1368
(65 Hz) 1600x1200 (75 Hz) 1824x1368 (65 Hz) 1600x1200 (75 Hz)
5 x 4 1280x1024
(85 Hz) 1280x1024 (85 Hz) 1280x1024 (85 Hz) 1280x1024 (85 Hz)
16 x 9 2048x1152
(70 Hz) 1920x1080 (75 Hz) 2048x1152 (70 Hz) 1920x1080 (75 Hz)
16 x 10 1920x1200
(70 Hz) 1824x1128 (75 Hz) 1920x1200 (70 Hz) 1824x1128 (75 Hz)
5 x 4 Frame Sequential Stereo 1280x1024
(52 Hz) N/A 1280x1024 (52 Hz) N/A
4 x 3 Frame Sequential Stereo 1280x960
(60 Hz) 1152x864 (60 Hz) 1280x960 (60 Hz) 1152x864 (60 Hz)
Supported Resolutions with Multisampling
Aspect Ratio 128 bits per pixel 192 bits per pixel
4 x 3 1152x864 (85 Hz) 1024x768 (85 Hz)
5 x 4 N/A N/A
16 x 9 1360x766 (85 Hz) 1280x720 (85 Hz)
16 x 10 1280x800 N/A
4 x 3 Frame Sequential Stereo 800x600 (60 Hz) 800x600 (60 Hz)

135618-001 5
Specifications –Graphics Controllers (continued)
Intense3D Wildcat 4210 Graphics Controller
Supported Resolutions Without Multisampling
bits per pixel
Aspect Ratio 96 128 160 192
4 x 3 1920 x 1440
(60 Hz) 1920 x 1440 (60 Hz) 1920 x 1440 (60 Hz) 1920 x 1440 (60 Hz)
5 x 4 1600 x 1280
(76 Hz) 1600 x 1280 (76 Hz) 1600 x 1280 (76 Hz) 1600 x 1280 (76 Hz)
16 x 9 2048 x 1152
(75 Hz) 2048 x 1152 (75 Hz) 2048 x 1152 (75 Hz) 2048 x 1152 (75 Hz)
16 x 10 1920 x 1200
(75 Hz) 1920 x 1200 (75 Hz) 1920 x 1200 (75 Hz) 1920 x 1200 (75 Hz)
5 x 4 Frame Sequential Stereo 1280 x 1024
(60 Hz) 1280 x 1024 (60 Hz) 1280 x 1024 (60 Hz) 1280 x 1024 (60 Hz)
4 x 3 Frame Sequential Stereo 128 0x 960
(60 Hz) 1280 x 960 (60 Hz) 1280 x 960 (60 Hz) 1280 x 960 (60 Hz)
Supported Resolutions with Multisampling
Aspect Ratio 128 bits per pixel 192 bits per pixel
4 x 3 1600 x 1200 (85 Hz) 1360 x 1024 (85 Hz)
5 x 4 1600 x 1280 (76 Hz) 1280 x 1024 (94 Hz)
16 x 9 1920 x 1080 (85 Hz) 1600 x 900 (85 Hz)
16 x 10 1824 x 1128 (75 Hz) 1600 x 1024 (76 Hz)
4 x 3 Frame Sequential Stereo 1280 x 960 (60 Hz) 1280 x 960 (60 Hz)

6Addenda to MSG 135618-001
Specifications –Graphics Controllers (continued)
Matrox G200 Quad MMS Graphics Controller
Refresh Rate/Display
Graphics
Memory Aspect Ratio Resolution Vertical Horizontal
32 MB 4:3/5:4 640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 1024
1600 x 1200
1800 x 1440
60 - 200 Hz
60 - 200 Hz
30 - 140 Hz
60 - 120 Hz
60 - 100 Hz
60 - 90 Hz
60 - 70 Hz
31 –102 kHz
38 –114 Khz
48 - 113 kHz
54 - 110 kHz
64 - 107 kHz
75 - 13 kHz
89 - 1 04 kHz
32 MB 16:9/16:10 856 x 480
1280 x 720
1600 x 1024
1920 x 1080
1920 x 1200
60 –200 Hz
60 –100 Hz
60 - 100 Hz
60 - 80 Hz
60 - 76 Hz
30 –108 kHz
44 –76 kHz
64 –108 kHz
70 –94 kHz
75 –95 kHz
ELSA Gloria II AGP Graphics Controller
Graphics
Memory Maximum Colors Supported Resolution Maximum Refresh Rate Memory Dedicated to Texture Support
64 MB 16.7M 640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 800
1280 x 960
1280 x 1024
1600 x 1000
1600 x 1000
1600 x 1200
1600 x 1280
1600 x 1280
1900 x 1080
1920 x 1080
1920 x 1200
1900 x 1200
2048 x 1536
120 Hz
120 Hz
120 Hz
100 Hz
100 Hz
100 Hz
100 Hz
100 Hz*
85 Hz
85 Hz
85 Hz
75 Hz
85 Hz
75 Hz
85 Hz*
75 Hz
75 Hz
60 MB
58 Mb
54 MB
52 MB
52 MB
49 MB
48 MB
45 MB
45 MB
41 MB
40 MB
40 MB
39 MB
39 MB
37 MB
37 MB
27 MB
* Refresh rate may function but may not be officially supported by Compaq.

135618-001 7
Air Baffle Assembly

Compaq Professional Workstation AP550
Maintenance and Service Guide

Professional Workstation AP550
Maintenance and Service Guide
First Edition (October 1999)
Part Number 135618-001
Spare Part Number 158279-001
Compaq Computer Corporation

Notice
The information in this publication is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR
EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN, NOR FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE
OF THIS MATERIAL. THIS INFORMATION IS PROVIDED “AS IS” AND COMPAQ COMPUTER
CORPORATION DISCLAIMS ANY WARRANTIES, EXPRESS, IMPLIED OR STATUTORY AND
EXPRESSLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR
PARTICULAR PURPOSE, GOOD TITLE AND AGAINST INFRINGEMENT.
This publication contains information protected by copyright. No part of this publication may be
photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation.
© 1999 Compaq Computer Corporation.
All rights reserved. Printed in the U.S.A.
The software described in this guide is furnished under a license agreement or nondisclosure agreement.
The software may be used or copied only in accordance with the terms of the agreement.
Compaq, Compaq Insight Manager, ROMPaq, QVision, NetFlex, QuickFind, PaqFax, registered United
States Patent and Trademark Office.
Fastart, Netelligent and SoftPaq are trademarks and/or service marks of Compaq Computer Corporation.
Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Pentium is a registered trademark and Xeon is a trademark of Intel Corporation.
Other product names mentioned herein may be trademarks and/or registered trademarks of their respective
companies.
Compaq Professional Workstation AP550
Maintenance and Service Guide
First Edition (October 1999)
Part Number 135618-001
Spare Part Number 158279-001
