QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 1
Overview
What’s New
•Intel Mobile Pentium

III 800MHz
with Speedstep™ technology or
Intel Celeron 700MHz processor
•14.1-inch TFT XGA DisplayPanel
•10GB or 15GB Hard Drive
•Four Easy Access Internet
Buttons
At A Glance
•Intel Mobile Pentium

III 800MHz
with Speedstep™ technology
processor or Celeron 700MHz
processor
•14.1-inch TFT XGA DisplayPanel
•Configurations as light as
5.9 lbs/2.7 kg weight
•1.3 in/3.4 cm thin
•64MB SDRAM (100MHz),
Upgradeable to320 MB
•10GB or 15GB User Removable
Hard Drives
•Integrated Mini PCI modem/NIC
combo
•Full sized keyboard
•Windows Millennium
•2 USB port expansionoptions
available
•Lightweight/ExtendedCapacity
Lithium Ion batteryavailable
•Protected by a one-year,
worldwide limited warranty —
Certain restrictions and
exclusionsapply. Consult the
CompaqCustomerSupport
Center for details.

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 2
Standard Features
Processor 800 MHz on Intel

Mobile Pentium

III processor with SpeedStep™ technology
700 MHz on Intel

Celeron™ processor
Note: Mobile Pentium
®
III processors feature 256-KB integrated cache and Mobile Celeron Processors feature
128KB integrated cache.
Memory Standard
Maximum 64-MB 100 MHz SDRAM 320-MB 100 MHz SDRAM
Communications Type III Mini PCI
Compaq Global Mini PCI 56K (V.90) Modem or
Compaq 56K (V.90) Modem plus Intel PRO/100+ NIC
Note: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
Note: Modem availability is subject to country regulatory approval.
PC Card Slots Two Type I, II or one type III PC Card Slot which supports both 32-bit CardBus (Full support in Windows 9.x) and
16-bit PC Cards
Storage Hard Drives 10 GB (9.5 mm height)
15 GB
Multimedia Integrated 16-bit Sound Blaster Pro-compatible stereo audio
Integrated speakers and microphone
Software volume control
Headphone-out Jack
Microphone-in Jack
Hardware assisted MPEG2 support
Interfaces PC Card Slot Two Type I, II or one type III
Enhanced Parallel Port 1
PS/2 1 (Y-cable compatible)
Serial Port 1
External Monitor Port 1
Speaker Out (Headphone) Jack 1
Microphone In Jack 1
AC Power Connector 1
RJ-45 1 (with Mini PCI Nic option only)
RJ-11 Jack 1 (with Mini PCI modem option only)
Infrared Port 1 (”Fast IR” compliant, IR performance will vary
depending on performance of IR peripherals and
application used)
USB Port 2
Graphics Integrated Trident CyberBlade i1 with AGP 2X support
14.1-inch color TFT XGA with 1024 x 768 resolution up to 16.7M colors internalDisplay (Internal)-One of the
following:
16 Million colors supported
Display (External) 640x480, 800x600, 1024x768 or 1280x1024 up to 60,75,85 Hz refresh rate
Operating System Windows Millennium
Windows 98SE or Windows 2000 in select countries

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 3
Standard Features
Software Microsoft Office Small Business available on select models
Online Safety and Comfort Guide
Online Reference Guide
Norton AntiVirus 2000 available on select models
Security Cable lock support
Supervisor password
Boot password
Ability to disable serial port, parallel port
Power Supply External AC Adapter; 6-foot power cord included
Battery An 8-cell Lithium-Ion battery is standard
Note: Actual results may vary with individual usage. Standard configuration at time of announce is considered to be
one battery, a 1024x768 (High color – 16-bit color) panel set at 50percent brightness, 64 MB RAM, and no
drives other than the hard drive active.
Power Conservation Hibernation
Service and Support Compaq Services includes a one-year limited warranty, whole-unit replacement via second business day, pick-up
and delivery. (Eligibility depends on geographic location.) Optional services include a one-year warranty extension
CarePaq (FM-AMMAI-36 or 400514-002).
Note: Certain restrictions and exclusions apply. See the Limited Warranty Statement for details.

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 4
Standard Features
Naming Convention The Etymology of a Model name:

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 5
Standard Features
UNITED STATES Display 14.1-inch color TFT XGA
Processor Intel Pentium III 800 MHz
Cache Memory 256KB, L2 Cache
N15P800T4X15VC648LME
470013-661
720591808648
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 8X DVD-ROM
Hard Drive 15 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10DC648LME
470013-617
720591808099
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 15 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10DC648LME
GEM/NAFTA
470013-660
720591808631 Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 10 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 6
Standard Features
UNITED STATES (continued) Display 14.1-inchcolor TFT XGA
Processor Intel Pentium III 800 MHz
Cache Memory 256KB, L2 Cache
N15P800T4X15VC648LME
470013-726
720591810566
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 8X DVD-ROM
Hard Drive 15 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium + MS office SB
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10DC648LME
470013-730
720591810412
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 10 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium + MS Office SB
Battery 8 cell Lithium-Ion

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 7
Standard Features
FRENCH CANADA Display 14.1-inch color TFT XGA
Processor Intel Pentium III 800 MHz
Cache Memory 256KB, L2 Cache
N15P800T4X15VC648LME
470013-662
720591808655
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 8X DVD-ROM
Hard Drive 15 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10DC649HME
470013-618
720591808105
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 10 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 8
Standard Features
EURO Display 14.1-inch color TFT XGA
Processor Intel Pentium III 800 MHz
Cache Memory 256KB, L2 Cache
N15P800T4X15V648LME
470013-728
720591810689
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 8X DVD-ROM
Hard Drive 15 GB
Modem No Modem
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10D649HME
470013-724
720591810542
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 10 GB
Modem No Modem
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 9
Standard Features
ARABIA Display 14.1-inch color TFT XGA
Processor Intel Pentium III 800 MHz
Cache Memory 256KB, L2 Cache
N15P800T4X15VC648LME
470013-734
720591810436
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 8X DVD-ROM
Hard Drive 15 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10DC649HME
470013-700
720591810276
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 10 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion

QuickSpecs
Compaq Evo Notebook N150
DA-10837 World Wide — Version 4 — June 12,2001 10
Standard Features
BELGIUM Display 14.1-inch color TFT XGA
Processor Intel Pentium III 800 MHz
Cache Memory 256KB, L2 Cache
N15P800T4X15VC648LME
470013-663
720591808662
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 8X DVD-ROM
Hard Drive 15 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
Display 14.1-inch color TFT XGA
Processor Intel Celeron 700 MHz
Cache Memory 128KB, L2 Cache
N15C700T4X10DC648LME
470013-619
720591808112
Memory Standard 64 MB SDRAM
Maximum 320 MB SDRAM
Optical Drive 24X CD-ROM
Hard Drive 10 GB
Modem Mini-PCI V.90 modem/10/100 TX NIC Combo
Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)
Audio 16-bit SoundBlaster Pro compatible
Software Windows Millennium
Battery 8 cell Lithium-Ion
