Compaq 6720t - Mobile Thin Client User instructions

1. Volume Mute Button with LED 10. Left Touchpad Button
2. Volume Down Button 11. Internal Storage Activity LED
3. Volume Up Button 12. Battery Charging LED
4. Stereo Speakers 13. Power/Standby LED
5. Integrated Optical Drive (optional) 14. Wireless On/Off LED
6. 2 USB 2.0 Ports 15. Touchpad with scroll zone
7. Microphone Jack 16. Power Button with LED
8. Headphone Jack 17. Wireless On/Off Button with LED
9. Right Touchpad Button
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Overview
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 1

1. Kensington Lock Slot 5. PC Card Slot
2. RJ-45 Port (NIC) 6. PC Card Eject Button
3. RJ-11 Port (Modem) 7. VGA/External Monitor Port
4. USB 2.0 Port 8. Power Connector
At A Glance
Genuine Windows XP Embedded
Sleek light-weight design starting at 5.4 lb (2.45 kg) and 1.2 inch (30 mm) thin at front
15.4-inch wide screen display
Intel® Celeron® M processor
Mobile Intel 945GM Express Chipset
1GB of 667 MHz DDR2 SDRAM
Intel Graphics Media Accelerator 950
1 GB Flash Module
Optional DVD-ROM Drive
802.11 a/b/g wireless LAN module
Protected by a one-year standard parts and labor warranty – certain restrictions and exclusions apply.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Overview
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 2

Processors Intel Celeron M Processor 423* (1.06-GHz, 1-MB L2 cache, 533-MHz FSB)
* Intel's numbering is not a measurement of higher performance.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows XP Embedded
Chipset Mobile Intel 945GM Express Chipset
Graphics Intel Graphics Media Accelerator 950 with up to 224-MB shared system memory
Microsoft DirectX 9 capable
Display Internal 15.4-inch WXGA display with 1280 x 800 resolution
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and
lower resolutions at up to 100 Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory Standard 1024-MB 667-MHz DDR2 SDRAM SODIMM; one SODIMM slot
Maximum Supports up to 2048-MB maximum
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility.
Communications Integrated Broadcom 10/100 Ethernet PCI Controller
56K V.92 modem* with digital line guard
* Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability
is subject to country regulatory approval.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 3

Integrated wireless LAN Broadcom 4311AG WiFi
Adapter
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Wi-Fi certified for WPA2, WMM
Cisco Compatible Extensions support (Version 4.0)
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support s
Dual antennas integrated in the display enclosure
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, comfort-dished
keycaps, and bright key legends for improved visibility in low light conditions.
One-Touch Productivity
Buttons
Provide one-touch access to the following features: Wireless On/Off, Volume down, Volume up, and
Volume Mute.
Pointing Device Touchpad with scroll zone and two soft-touch buttons
Expansion Card Slots
One Type I/II PC Card
slot
Supports 32-bit CardBus and 16-bit PC Cards
Internal Storage Primary Storage 1 GB Flash Module
Optional Fixed Optical
Drive
DVD-ROM
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 4

Interfaces PC Card Slot One – Type I/II
External Monitor One – VGA
External Microphone One
Headphone/Line out One
Power Connector One
RJ-11 (Modem) One
RJ-45 (NIC) One
USB 2.0 Three
Docking Connector One
Accessory Battery
Connector
One
LED Status Indicators Nine
Audio ADI1981HD High Definition CODEC
Integrated 16-bit Sound Blaster Pro compatible audio
24-bit DAC
Integrated stereo speakers
External volume up, volume down, and mute buttons
Stereo headphone/line out
Stereo microphone in
Software Preinstalled Software Enhanced Write Filter
Altiris Deployment Client
HP ThinState Tools
HP Session Allocation Manager
Microsoft RDP
Citrix ICA
HP Quick Launch Buttons
TeemNT Terminal Emulation
PDF Complete
Intervideo WinDVD
Additional software
available from the Web
HP RGS Graphics Compression Client
HP OpenView Client Configuration Manager
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 5

Security Standard Features Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
Kensington Lock Slot
Power Supply External 65-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter).
HP Fast Charge Technology*
*Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does
not apply to 12-cell Ultra-Capacity batteries.
Battery Primary Battery 6-cell (47Wh) high capacity Lithium-Ion
Optional 8-Cell Extended
Life Battery
8-cell (52Wh) high capacity Lithium-Ion
Optional HP 12-Cell Ultra-
Capacity Battery
12-cell (95Wh) high capacity Lithium-Ion
Battery Life Primary Battery Up to 5 hours
Primary Battery and
optional HP 8-Cell
Extended Life Battery
Up to 10 hours and 45 minutes
Primary Battery and
optional HP 12-Cell Ultra-
Capacity Battery
Up to 14 hours and 30 minutes
NOTE: The listed battery life measurements were taken on models running Microsoft Windows XP
Professional. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time Up to 1 week
Power Conservation Standby
ACPI compliance
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 6

Docking HP Docking Station
HP's shared docking solution provides simple and convenient port replication and cable management.
Supported features include 10/100 Ethernet NIC pass through, modem pass through, legacy parallel
and serial ports, USB 2.0 ports, and integrated security mechanism.* This docking solution is compatible
across multiple Business Notebook platforms enabling a lower total cost of ownership.
*HP/Kensington Cable Lock required (purchased separately)
Service and Support HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x
24 hardware technical phone support (depending on model). On-site service and warranty upgrades are
also available.
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
Select Model(s)
6720t
KL145AA#ABA (English)
KL145AA#ABC (Fr CAN)
Regional
Processor Intel Celeron M Processor 423 (1.06 GHz)
Operating System Genuine Windows XP Embedded
System Memory 1024MB 667MHz DDR2 SDRAM (1 DIMM)
Internal Storage 1 GB Flash Module
Display 15.4-inch diagonal WXGA anti-glare
Graphics Intel GMA 950, up to 224MB shared system memory
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Integrated Wireless Broadcom 4311AG 802.11a/b/g
Pointing Device Touchpad with scroll zone
Optical Drive none
Battery 6-cell (43 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
* Intel's numbering system is not a measurement of higher performance.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 7

6720t
KL145AT#ABA (English)
KL145AT#ABC (Fr CAN)
Smart Buy
Processor Intel Celeron M Processor 423 (1.06 GHz)
Operating System Genuine Windows XP Embedded
System Memory 1024MB 667MHz DDR2 SDRAM (1 DIMM)
Internal Storage 1 GB Flash Module
Display 15.4-inch diagonal WXGA anti-glare
Graphics Intel GMA 950, up to 224MB shared system memory
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Integrated Wireless Broadcom 4311AG 802.11a/b/g
Pointing Device Touchpad with scroll zone
Optical Drive none
Battery 6-cell (43 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
* Intel's numbering system is not a measurement of higher performance.
6720t
KL147AA#ABA (English)
KL147AA#ABC (Fr CAN)
Regional
Processor Intel Celeron M Processor 423 (1.06 GHz)
Operating System Genuine Windows XP Embedded
System Memory 1024MB 667MHz DDR2 SDRAM (1 DIMM)
Internal Storage 1 GB Flash Module
Display 15.4-inch diagonal WXGA anti-glare
Graphics Intel GMA 950, up to 224MB shared system memory
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Integrated Wireless Broadcom 4311AG 802.11a/b/g
Pointing Device Touchpad with scroll zone
Optical Drive 8x DVD
Battery 6-cell (43 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
* Intel's numbering system is not a measurement of higher performance.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 8

6720t
KL147AT#ABA (English)
KL147AT#ABC (Fr CAN)
Smart Buy
Processor Intel Celeron M Processor 423 (1.06 GHz)
Operating System Genuine Windows XP Embedded
System Memory 1024MB 667MHz DDR2 SDRAM (1 DIMM)
Internal Storage 1 GB Flash Module
Display 15.4-inch diagonal WXGA anti-glare
Graphics Intel GMA 950, up to 224MB shared system memory
Audio ADI High Definition CODEC
Stereo headphone/line out and microphone in
Integrated microphone
Communications Integrated Broadcom 10/100 Ethernet Controller
56K V.92 modem
Integrated Wireless Broadcom 4311AG 802.11a/b/g
Pointing Device Touchpad with scroll zone
Optical Drive 8x DVD
Battery 6-cell (43 WHr) Lithium-Ion
Power External 65W adapter
Warranty 1/1/0
* Intel's numbering system is not a measurement of higher performance.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Standard Features
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 9

Memory 1-GB 667-MHz DDR2 SDRAM EM994AA
2-GB 667-MHz DDR2 SDRAM EM995AA
Other Storage HP USB Diskette Drive DC361B
Expansion Solutions HP Docking Station EN488AA#ABA
HP Monitor Stand PA507A
HP Adjustable Notebook Stand PA508A
Power HP 1-bay Battery Charging Station RW635AA#ABA
HP 5-bay Battery Charging Station RW636AA#ABA
Battery Adapter Kit RW637AA
65W Smart AC Adapter ED494AA#ABA
90W Smart AC Adapter ED495AA#ABA
90W Smart Auto Adapter ED493AA
65W Air/Auto/AC Smart Combo Adapter ED993AA#ABA
6-cell 47Whr Li Ion Battery TBD
HP 8-cell Extended Life Battery PB993A
HP 12-cell Ultra-Capacity Battery EJ092AA
Carrying Cases HP Basic Carrying Case AJ078AA
HP Value Nylon Case RR314AA
HP Universal Nylon Case RR315AA
HP Executive Leather Case RR316AA
HP Deluxe Nylon Backpack RR317AA
HP Deluxe Roller Case GD405AA
Security HP/Kensington MicroSaver Security Lock PC766A
Input/Output Devices USB/PS2 Optical Mouse DC369A
HP USB Optical Travel Mouse RH304AA
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Options
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 10

Supports up to 2048 MB* of 667-MHz DDR2 SDRAM
One DIMM slots
DIMM sizes supported: 1024 MB and 2048 MB
Standard Memory 1024 MB (1024 MB x 1)
Optional Memory Upgrades Support for up to 2048 MB* of memory is available (with the installation of optional DDR2 SDRAM
memory kit). Memory slot is user accessible. Please refer to the Hardware and Software Guide for
installation procedures.
Up to Slot 1
2048 MB 2048 MB
NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded
memory modules to ensure compatibility.
Memory Upgrades 2-GB 667-MHz DDR2 SDRAM EM995AA
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Memory
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 11

Removable Media Drive Support
Quantity Supported Drive Bay
DVD-ROM Drive One Fixed optical drive bay
Internal Storage Support
Quantity Supported Drive Bay
Primary Hard Drives
1 GB Flash Module One Flash Drive Bay
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Storage
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 12

System Unit Dimensions (HxWxD) 1.2 in (at front) x 14.1 in x 10.2 in
30 mm (at front) x 357 mm x 260 mm
Weight 5.4 lb (2.45 kg)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight
includes 6-cell battery, 1 GB memory, 1 GB flash module, 802.11 wireless communications module.
Weight varies by configuration and components.
Stand-Alone Power
Requirements
Normal Operating Voltage 19 V
Average Operating Power 25 W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating -50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating -50 to 40,000 ft (-15.24 to 12,192 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ICES Yes
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
MIC Yes
BSMI Yes
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 13

HP 65W Smart AC
Adapter
Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class
B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at
25°C ambient condition.
Option Kit Contents 65W AC Adapter, power cable, warranty booklet
47Wh Primary 6-Cell
Battery
Dimensions (H x W x L) 0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)
Weight 0.74 lb (0.336 kg)
Cells/Type 6-cell Lithium-Ion
Energy Watt-hour Capacity 47Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 1.5 hours
when system is OFF
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 14

Optional HP 8-Cell
Extended Life Battery
Dimensions (H x W x L) 1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
Weight 1.00 lb (0.455 kg)
Cells/Type 8-cell Lithium-Ion
Energy Watt-hour Capacity 52Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
3 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
Optional HP 12-Cell Ultra-
Capacity Battery
Dimensions (H x W x L) 1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight 1.77 lb (0.803 kg)
Cells/Type 12-cell Lithium-Ion
Energy Watt-hour Capacity 95Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
3 to 4 hours
System ON 4 to 5 hours (depending on system power
consumption)
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 15

15.4-inch Color TFT
WXGA Display
Active Area (W x H) 13.0 x 8.1 in (33.1 x 20.7 cm)
Diagonal Size 15.4 in (39.1 cm)
Surface Treatment Anti-glare
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 170 nit (typical)
Pixel Resolution Pitch 0.259 mm
Format 1280 x 800
Configuration RGB stripe
Backlight CCFL
PPI 98
Viewing Angle ±45° Horizontal, ±25° Vertical (typical)
Internal Storage
1 GB Flash Module Drive
(PATA)
Interface Standard ATA / IDE
Connector 40-pin (2.54mm pitch) / 44-pin (2.00mm pitch)
Capacities 64MB~8GB
Transfer mode PIO Mode-4; MWDMA Mode-2
Sustained Read/Write
Performance
11 / 7 (MB/sec)
ECC Support 3 random 12 bit symbol ECC per 512 bytes (RS)
Low Power Consumption
(3.3V/5.0V)
Active mode: 35mA/55mA
Sleep mode: 100µA/150µA
Security function Write protection jumper (Optional)
Factory-programmed, up to 20-byte unique ID (Software Protect mechanism)
Protection Zone (Optional)
Product types Standard, Low-profile, Housing, Through Pin, Dual Through Pin
Orientation 90D, 180D, 270D
Removable Storage Drives – Fixed Bay
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 16

DVD-ROM Drive Access Times Random <116 ms CD
<125 ms DVD
Max Data Transfer Rate 24X CD-ROM 3,600 KB/s
8X-DVD 10,800 KB/s
Transfer Mode Multiword DMA Mode 2
Interface EIDE
Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-
CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW
Supported Media (write) None
Max Media Capacity
(read)
4.7 GB
Transport Tray Loading
PremierSound Audio
Hardware Implementation ADI1981HD High Definition CODEC
Volume Controls Up, down, and mute buttons
Full Duplex Yes
Sound Blaster Pro
compatible
Yes
Microphone Jack Stereo or mono
Headphone/Line Out Jack Stereo
Audio Output Quality Frequency Response 20 Hz – 20 kHz
Signal to Noise Ratio >85 dB
Total Harmonic Distortion 0.01%
Noise Floor -110 dB
Play/Record Sampling
Rate (s)
8 kHZ – 48kHz
DAC 16, 20 or 24-bit
ADC 16 or 20-bit
Internal Speakers Power Rating 2 Watts
Impedance 4 Ohms
Communications
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 17

Integrated Broadcom
10/100 Ethernet PCI
Controller (BCM4401)
Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Manageability Wake-on-LAN from standby (configurable; Magic Packet and Microsoft)
Wake-Up Frame)PXE 2.1 Remote Boot
Statistics Gathering (RMON, Ethernet-like MIB, Ethernet MIB (802.3x, clause
30)
Comprehensive diagnostic and configuration software suite
Interface 32-bit PCI, 33-MHz
NIC Device Driver Name Broadcom 440X 10/100 Integrated Controller
V.92 56K Data/Fax
Modem
Form Factor MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part
15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE
Mark, Other Countries
Data Mode Capabilities V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 18

Fax Mode Capabilities TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
Command Set V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
Broadcom 4311AG
802.11a/b/g WiFi
Adapter
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at: www.hp.com/go/notebooks/WLAN )
Frequency Band 2.4 GHz and 5 GHz
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4).
Sub-channels Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power (for CKK)
2
17.5 dBm
Output Power (for OFDM;
power varies by data
rate)
2
15 dBm
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 19

Power Consumption Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range 802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor PCI-Express MiniCard
Weight 0.026 lb (12 g)
Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
LED Activity LED Off – Radio OFF; Solid LED On – Radio ON
1
Check latest software/driver release for updates on supported security features.
2
Maximum output power may vary by country according to local regulations.
3
In Power Save Polling mode.
4
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
5
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be
compatible with certain third-party software supplicants.
QuickSpecs
HP Compaq 6720t Mobile Thin Client
Technical Specifications
DA - 12906 Canada English QuickSpecs — Version 4 — 2/20/2008 Page 20
