QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 1
Overview
What's New
• Dual optical drive support with
one fixed driveand one modular
bay drive
• Mobile Intel

Pentium

III 1.2
GHz–M, 1.13 GHz-M, or 1.06
GHz-M processor with enhanced
SpeedStep™ technology
• Digital Video Editing Port 1394
• Easy Access Internet Buttons
At A Glance
• Weighsonly7.6 lb/3.4 kg
• 1.6 in/4.1 cm thin
• 15-inch XGA TFT display
• 128 or 256-MB SDRAM (133
MHz) standard,upgradeable to
1024MB
• Integrated miniPCI 56K V.92
modem plus10/100 NIC
• Complete set of system ports
including two USB portexpansion
options, 1394 Digital Video Input
• Full-size keyboard
• Microsoft

Windows

XP Pro or
Windows 2000 Professional
preinstalled
• Protected by a One-Year,
Worldwide Limited Warranty—
certain restrictions and exclusions
apply. Consult the Compaq
Customer Support Center for
details.
What’s Special
• Modular Bay which enables
simultaneous use of up to two
optical drives,supports a second
battery, or floppy drive
• Magnesiumdisplayenclosure

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 2
Standard Features
Panel and Processor 15-inch TFT XGA display with 1024 x 768 resolution up to 16M colors
1.2 GHz-M on Mobile Intel Pentium III processor with 512-KB L2 cache, or
1.13 GHz-M on Mobile Intel Pentium III processor with 512-KB L2 cache, or
1.06 GHz-M on Mobile Intel Pentium III processor with 512-KB L2 cache
NOTE: Mobile Intel Pentium III-M processors support enhanced Intel SpeedStep technology.
Memory
Standard
Maximum 256-MB (133 MHz) SDRAM
1024-MB (133 MHz) SDRAM
NOTE:Due to the non-industry standard nature of some third-party memory modules, we strongly recommend
using only Compaq branded memory modules to ensure compatibility.
Communications Type III Mini PCI 56K (V.92) modem plus integrated 10/100 NIC
NOTE: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
NOTE:Communication availability is subject to country regulatory approval.
Keyboard Full-size desktop-compatible keyboard; special feature hotkeys for instant access to toggling between internal and
external displays, or simultaneous displays and brightness
Oversized keys and separate cursor control keys (88 keys) – 101-key compatible
Windows Key
SoftTouch Palm Rest provides a more comfortable feel.
Easy Access Internet
Buttons The Evo™ Notebook N180 comes with four Easy Access Buttons designed to increase customer productivity by providing one-touch access to helpful Compaq information, favorite Internet destinations, files, or applications.
Pointing Device TouchPad
PC Card Slots One (1) Type II PC Card Slot that supports both 32-bit CardBus (Full support in Microsoft Windows 9.x and
Windows 2000) and 16-bit PCMCIA Cards
One (1) Type I/II PC Card slot with support for 32-bit Card bus
Storage Diskette Drives 1.44-MB diskette drive (model dependant)
Fixed Optical Drives DVD-ROM drive
Modular Bay Drive 1.44-MB Floppy drive or CD-RW drive (model dependant)
Hard Drive 30 GB or 20 GB (model dependant)
Multimedia JBL Pro speakers for enhanced stereo audio
Integrated 16-bit Sound Blaster Pro-compatible stereo audio
Integrated speaker
External volume controls
Headphone-out
Microphone in
Software MPEG1 support
DVD movie playback software
DVD-ROM drive with DVD movie playback
4X AGP graphics
16 or 32-MB SDRAM (model dependant)

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 3
Standard Features
Interfaces PC Card Slot 1 Type I, II
USB 1.1 Connectors 2
Digital Video Port 1394 1
Parallel SPP/ECP standard
interface; (DB25 connector) 1
PS/2 Style Mouse or Keyboard
port 1
RJ-45 Ethernet jack 1
RJ-11 modem jack 1
A
udio ports (headphone/speaker
out, microphone-in) 2
S-Video TV-Out 1
External VGA monitor port 1
QuikDock connector 1
Graphics ATI Mobility Radeon M6 with 16 or 32-MB SDRAM (model dependant)
ATI Mobility Radeon M6 graphics processor includes hardware accelerated 3D graphics for enhanced DVD
playback and 3D performance
Display (External) Up to 32-bit per pixel color depth
Supports 1024 x 768 resolutions up to 100-Hz refresh rate, depending on monitor capability, resolution and color
depth settings
Display (Internal) 15-inch TFT XGA display with 1024 x 768 resolution up to 16.7M colors
Operating System Microsoft Windows XP Professional preinstalled, or
Microsoft Windows 2000 Professional preinstalled
Software Online Safety and Comfort Guide
Online User’s Guide
Norton Anti Virus 2001
Pinnacle Studio SW
DVD Playback SW
System Recovery Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer-installed image)
and software recovery (installs only selected standard software)

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 4
Standard Features
Security Cable lock support
Power-On Password
Supervisor Password
Power Supply External AC Adapter; 6-foot/18.2-meter power cord included
Battery The Evo Notebook N180 8-cell Lithium-Ion battery provides up to four hours of battery life; up to six hours
achieved using optional additional Modular Bay battery.
NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 4:05
(hr:min) were achieved running the eTesting Labs Inc.'s BatteryMarkTest version 4.0.1 on an N180
with an Intel Pentium III-M 1 GHz CPU, 15-inch XGA panel, 128-MB RAM, 20-GB HDD, CD, 8-cell
Lithium-Ion battery, and NIC/modem. System parameters were set according to eTesting Labs’
recommendations: panel brightness 50%, hard drive standby and video idle time three minutes, Intel
SpeedStep battery optimized mode.
NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes
no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis
Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.
Battery charge time about two hours when unit turned off.
Power Conservation Intel SpeedStep technology (allows a Battery Optimized Mode where CPU draws 50% of normal power yet
affords 70 to 80% of maximum PIII processing speed)
Hibernation
Instant-on through Standby
Pop-ups with three presets
One custom level of power conservation
ACPI compliant
Modular Bay Modular Bay devices may be swapped with the system powered on (hot) or in suspend mode (warm) under any
supported operating system.
Service and Support Compaq Services includes a One-Year Limited Warranty, whole-unit replacement through second business day,
pickup and delivery. (Eligibility depends on geographic location.) Optional services include a One-Year Warranty
Extension. Certain restrictions and exclusions apply. See the Limited Warranty Statement for details.

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 5
Standard Features
Naming Convention The Etymology of a Model name:

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 6
Standard Features
M ODELS
Display 15-inch color TFT XGA
N18P113X520VC25TOL Processor Mobile Intel Pentium III 1.13 GHz-M
Cache Memory 512-KB, L2 Cache
Memory Standard 256-MB SDRAM
Maximum 1024-MB SDRAM
Fixed Optical Drive DVD-ROM drive
Modular Bay Floppy drive
Hard Drive 20-GB
Modem Type III Mini PCI 56K (V.92) modem plus integrated 10/100 NIC
Graphics ATI Mobility Radeon M6-P graphics controller 4x AGP and 16-MB DDR SDRAM
Audio JBL Pro speakers
Operating System Microsoft Windows XP Professional
Display 15-inch color TFT XGA
N18P120X530ZC25TOL
Processor Mobile Intel Pentium III 1.2 GHz-M
Cache Memory 512-KB, L2 Cache
Memory Standard 256-MB SDRAM
Maximum 1024-MB SDRAM
Fixed Optical Drive DVD-ROM drive
Modular Bay CD-RW drive
Hard Drive 30-GB
Modem Type III Mini PCI 56K (V.92) modem plus integrated 10/100 NIC
Graphics ATI Mobility Radeon M6-P graphics controller 4x AGP and 32-MB DDR SDRAM
Audio JBL Pro speakers
Operating System Microsoft Windows XP Professional

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 7
Standard Features
M ODELS
Pentium III 1.13 GHz-M Pentium III 1.2 GHz-M
15-inch XGA 15-inch XGA
256 MB 256 MB
20-GB 30-GB
Fixed DVD-ROM drive Fixed DVD-ROM Drive
Modular Bay
Floppy Drive Modular Bay CD-RW drive
Integrated NIC Integrated NIC
Touchpad Touchpad
NORTH AMERICA
US
N180P113X520C25TOL Windows XP Professional 470030-249
N180P120X530C25TOL Windows XP Professional 470030-255
Additional Evo N180 models are available with the modules listed below through the ″Built For Your Business″, custom-configuration models at
www.directplus.compaq.com.
• Intel Pentium III-M 1.06 GHz
• Microsoft Windows 2000 Professional

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18,2002 8
Options
Memory 512-MB SDRAM (133 MHz) Memory Module 238830-B25
256-MB SDRAM (133 MHz) Memory Module 197898-B25
128-MB SDRAM (133 MHz) Memory Module 197897-B25
64-MB SDRAM (133 MHz) Memory Module 197896-B25
(Due to the non-industry standard nature of some third-party memory modules, we
strongly recommend using only Compaq branded memory modules to ensure
compatibility.)
Power Lithium-Ion (4.0AH) – Primary Battery 235883-B21
High Capacity Lithium-Ion 2
nd
Battery (Modular Bay option) 235882-B21
AC Adapter 177624-001
Auto Adapter 167895-001
Modular Bay Optical Drives 8X CD-RW 235880-B21
8X DVD-ROM 235879-B21
DVD/CD-RW combo drive 235881-B21
1.44MB Floppy Drive 274040-B21
Useful Accessories DEFCON Security Lock 201708-001
DEFCON Security System 158638-001
Carrying Cases Compaq Plus (Nylon) 242360-B25
Compaq Ultralite (Nylon) 167336-B21
Compaq Ultralite (Leather) 242359-B25
Compaq Professional (Nylon) 242361-B25
Compaq Professional (Leather) 242362-B25
NOTE: For additional Compaq Brand cases, visit http://www.compaq.com/products/notebooks/
Port Expansion Solutions QuikDock Port Replicator 235884-B21

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 9
Memory
S TANDARD M EMORY
2 slots available
Slot 1 contains 1 256MB SODIMM
Standard Slot 1 Slot 2
256 MB
256 MB
Empty
320 MB
256 MB
64 MB
384 MB
256 MB
128 MB
512 MB
256 MB
256 MB
768 MB
256 MB
512 MB
1GB
512 MB
512 MB
Following are memory options available from Compaq:
• 64-MB Memory Upgrade 197896-B25
• 128-MB Memory Upgrade 197897-B25
• 256-MB Memory Upgrade 197898-B25
• 512-MB Memory Upgrade 238830-B25

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 10
Storage
D RIVE S UPPORT
System Drive Support Quantity Supported Drive Bay Supported
Media
8x DVD-ROM 1 Modular Bay; Removable
CD-RW Drive 1 Modular Bay; Removable
DVD/CD-RW combo drive 1 Modular Bay; Removable
Secondary Battery 1 Modular Bay; Removable
1.44MB Floppy Drive 1 Modular Bay; Removable
Hard Drives
20-GB Hard Drive 1
30-GB Hard Drive 1

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 11
Technical Specifications
System Unit Dimensions (H x W x D) 1.63 x 12.91 x 10.99 in/4.14 x 32.79 x 27.91 cm
Weight 15-inch TFT with Li-Ion Battery
and weight saver 7.65 lb/3.47 kg
Nominal Operating Voltage
(8-cell Lithium-Ion) 14.8 VDC
Stand-Alone Power
Requirements
Nominal Operating Voltage
(6-cell Lithium-Ion in Modular
Bay)
11.1 VDC
Temperature Operating 50° to 95°F/10° to 35°C
Non-operating –4°to 140°F/–20°to 60°C
Operating 10% to 90% relative humidity, non-condensing
Relative Humidity
(non-condensing) Non-operating 5% to 95% relative humidity, 101.6°F/38.7°C
Maximum wet bulb temperature
Shock Operating 10 G, 11 ms, half-sine
Non-operating 60 G, 11 ms, half-sine
Vibration Operating 0.5 G zero-to-peak, 10 to 500 Hz, at 0.5
oct/min sweep rate
Non-operating 1.0 G, zero-to-peak, 10 to 500 Hz, at 0.5
oct/min sweep rate
Operating 0 to 10,000 ft/0 to 3,048 m
Maximum Altitude
(unpressurized) Non-operating 0 to 30,000 ft/0 to 9,144 m
Dimensions (H x W) 9.52 x 12.47 in/24.2 x 31.7 cm
Diagonal Size 15 in/38 cm
15-inch Color TFT XGA Display
Mounting Internal (Side Mount)
Number of Colors 256K
Contrast Ratio 150:1
Brightness 120+ nit
Pixel Resolution Pitch 0.297 x 0.297 mm
Format 1024 x 768
Configuration RGB Vertical Stripe
Backlight Cold cathode fluorescent, 1 tube
Character Display 80 x 25
Total Power Consumption 5.5W
Refresh 60 Hz

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 12
Technical Specifications
Hard Drives
Capacity 20 GB
Height 0.374 in/9.5 mm
Width 2.75 in/70 mm
Interface ATA-5
Transfer Rate Synchronous (maximum burst) 100 MB/s (Drive Capability)
20-GB
Security ATA Security
Single Track 2.5 ms
Seek Time
(typical reads, including settling) Average 12 ms
Maximum 23 ms
Rotational Speed 4200 rpm
Logical Blocks ~ 39,070,080
Operating Temperature 41° to 131°F/5° to 55°C
Capacity 30 GB
Height 0.374 in/9.5 mm
Width 2.75 in/70 mm
Interface ATA-5
Transfer Rate Synchronous (maximum burst) 100 MB/s (Drive Capability)
30-GB
Security ATA Security
Single Track 2.5 ms
Seek Time
(typical reads, including settling) Average 12 ms
Maximum 23 ms
Rotational Speed 4200 rpm
Logical Blocks ~ 58,605,120
Operating Temperature 41° to 131°F/5° to 55°C

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 13
Technical Specifications
Modular Bay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.74 lb/0.33 kg
DVD/CD-RW Drive
Center Hole Diameter 1.5 cm
Disk Diameter 12 cm/8 cm
Disk Thickness 1.2 mm
Track Pitch 0.74 µm
Random CD-ROM < 120 ms
Access Times
(typical reads, including settling) Full-Stroke CD-ROM < 175 ms
Audio Output Level Line-out 0.7 Vrms
Cache Buffer 128 KB/s (minimum)
Maximum transfer rate Read (CD-ROM): Up to 24X (3,600 KB/sec)
Read (DVD): Up to 6X (8,100 KB/sec)
Write: Up to 4X (600 KB/sec)
Re-write: Up to 4X (600 KB/sec)
Start-up Time < 7 seconds Single Session Disk
Stop Time < 4 seconds
Modular Bay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.74 lb/0.33 kg
CD-RW Drive (Modular Bay)
Center Hole Diameter 1.5 cm
Disk Diameter 12 cm/8 cm
Disk Thickness 1.2 mm
Track Pitch 0.74 µm
Random < 100 ms
Access Times
(typical reads, including settling) Full-Stroke < 200 ms
Audio Output Level Line-out 0.7 Vrms
Cache Buffer 128 KB/s (minimum)
Maximum transfer rate Read (CD-ROM): Up to 24X (3,600 KB/sec)
Write: Up to 8X (1,200 KB/sec)
Re-write: Up to 4X (600 KB/sec)
Start-up Time < 7 seconds
Stop Time < 4 seconds

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 14
Technical Specifications
Center Hole Diameter 1.5 cm
Disc Diameter 12 cm/8 cm
DVD-ROM Drive (Fixed)
Disc Thickness 1.2 mm
Track Pitch 0.74 µm
Random < 180 ms DVD Media
Access Times
(typical reads, including settling) Full-Stroke (typical) < 300 ms DVD Media
Random (typical) < 120 ms CD Media
Full-Stroke (typical) < 200 ms CD Media
Cache Buffer 512 KB/s (minimum)
Maximum transfer rate Read (CD-ROM): Up to 24X (3,600 KB/sec)
Read (DVD): Up to 8X (10,800 KB/sec)
Start-up Time < 12 seconds
Stop Time < 3 seconds
External AC Adapter Weight 0.45 lb/0.21 kg
Power Supply (Input) Operating Voltage 100 to 240 VAC RMS Nominal
Operating Current 1.5 A RMS
Operating Frequency Range 50 to 60 Hz AC Nominal
Maximum Transient 4/50 kV
Lithium-Ion Battery Pack Dimensions (H x W x D) 0.86 x 5.63 x 3.34 in/2.2 x 14.3 x 8.5 cm
Weight 0.96 lb/0.44 kg
Cells 8-cell Lithium-Ion
Energy Voltage 14.4 V
Amp-hour capacity 4.0 Ah
Watt-hour capacity 57.6Wh
Temperature Operating 50° to 104°F/10° to 40°C
Non-operating –4° to 140°F/–20° to 60°C

QuickSpecs
Compaq Evo Notebook N180
DA-10978 NorthAmerica — Version 6 — February18, 2002 15
Technical Specifications
Dimensions (H x W x D) 0.55 x 5.19 x 5.31 in/1.4 x 13.2 x 13.5 cm
Modular Bay Lithium-Ion
Battery Pack Weight 0.77 lb/0.35 kg
Cells 6-cell Lithium-Ion
Energy Voltage 10.8 V
Amp-hour capacity 3.6 Ah
Watt-hour capacity 38.9 Wh
Temperature Operating 50° to 104°F/10° to 40°C
Non-operating –4° to 140°F/–20° to 60°C
Compaq PCs use genuine Microsoft

Windows

www.microsoft.com/piracy/howtotell
Compaq, Evo, registered United States Patent and Trademark Office.
Intel, the Intel Inside Logo, and Pentium are registered trademarks of Intel Corporation.
Microsoft, MS and Windows are registered trademarks of the Microsoft Corporation in the U.S. and other countries.
Other product names mentioned herein may be trademarks and/or registered trademarks of their respective companies.
©2002 Compaq Information Technologies Group, L.P
