Compaq nc2400 - Notebook PC User manual

Pointing Devices and Keyboard
User Guide

© Copyright 2007 Hewlett-Packard
Development Company, L.P.
Windows is a U.S. registered trademark of
Microsoft Corporation.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: January 2007
Document Part Number: 419708-001

Table of contents
1 Pointing devices
Using the pointing stick ........................................................................................................................ 2
Using an external mouse ...................................................................................................................... 2
Setting pointing device preferences ..................................................................................................... 2
2 Keyboard
Hotkeys ................................................................................................................................................ 3
Hotkey quick reference ........................................................................................................ 4
Hotkey procedures ............................................................................................................... 4
Display and clear system information (fn+esc) ................................................... 4
Initiating Sleep (fn+f3) ......................................................................................... 5
Switch the screen image (fn+f4) .......................................................................... 6
Viewing battery pack charge information (fn+f8) ................................................. 6
Decrease screen brightness (fn+f9) .................................................................... 6
Increase screen brightness (fn+f10) .................................................................... 6
HP Quick Launch buttons (select models only) .................................................................................... 7
Presentation button .............................................................................................................. 8
Info Center button ................................................................................................................ 9
HP Quick Launch Buttons control panel ............................................................................ 10
Opening the Quick Launch Buttons control panel ............................................. 10
Setting button preferences ................................................................................ 11
Displaying the Q Menu ...................................................................................... 11
Setting Q Menu preferences ............................................................................. 11
Removing a Q Menu item ................................................................. 12
Adding a listed item to the Q Menu .................................................. 12
Adding a user-defined item to the Q Menu ....................................... 12
Changing a user-defined item .......................................................... 12
Repositioning a Q Menu item ........................................................... 13
Removing an item from the Items to display on Q Menu list ............ 13
Setting tiling preferences ................................................................................... 13
Setting other preferences .................................................................................. 13
3 Keypads
Using the embedded numeric keypad ................................................................................................ 16
Enabling and disabling the embedded numeric keypad .................................................... 16
Switching key functions on the embedded numeric keypad .............................................. 16
Using an external numeric keypad ..................................................................................................... 16
Enabling or disabling num lock mode as you work ............................................................ 16
ENWW iii

Index ................................................................................................................................................................... 17
iv ENWW

1 Pointing devices
The following illustration and table describe the computer pointing devices.
Component Description
(1) Pointing stick Moves the pointer and selects or activates items on the screen.
(2) Left pointing stick button Functions like the left button on an external mouse.
(3) Right pointing stick button Functions like the right button on an external mouse.
*This table describes default settings. To view and change pointing device preferences, select Start > Control Panel >
Hardware and Sound > Mouse.
ENWW 1

Using the pointing stick
Press the pointing stick in the direction you want to move the pointer on the screen.
Use the left and right pointing stick buttons as you would the left and right buttons on an external mouse.
Using an external mouse
An external USB mouse can be connected to the computer using one of the USB ports on the computer.
A USB mouse can also be connected to the system using the ports on an optional docking device.
Setting pointing device preferences
Use Mouse Properties in Windows® to customize settings for pointing devices such as mouse speed
preferences.
To access Mouse Properties, select Start > Control Panel > Hardware and Sound > Mouse.
2 Chapter 1 Pointing devices ENWW

2 Keyboard
The following sections provide information on the keyboard features of the computer.
Hotkeys
Hotkeys are preset combinations of the fn key (1) and either the esc key (2) or one of the function
keys (3).
The icons on the f3, f4, and f8 through f10 keys represent the hotkey functions. Hotkey functions and
procedures are discussed in the following sections.
ENWW Hotkeys 3

Hotkey quick reference
To perform this function Press
Display system information. fn+esc
Clear system information fn+esc or click OK
Initiate Sleep. fn+f3
Resume from Sleep. Power button
Alternate between computer display and external display fn+f4
Display battery information. fn+f8
Clear battery information fn+f8
Decrease screen brightness. fn+f9
Increase screen brightness. fn+f10
Hotkey procedures
To use a hotkey command on the computer keyboard, either
●Briefly press the fn key, and then briefly press the second key of the hotkey command.
– or –
●Press and hold down the fn key, briefly press the second key of the hotkey command, and then
release both keys at the same time.
Display and clear system information (fn+esc)
Press fn+esc to display information about system hardware components and the system BIOS version
number. Press fn+esc a second time to remove the system information from the screen.
In the Windows fn+esc display, the version of the system BIOS (basic input-output system) is displayed
as the BIOS date. On some computer models, the BIOS date is displayed in decimal format. The BIOS
date is sometimes called the system ROM version number.
4 Chapter 2 Keyboard ENWW

Initiating Sleep (fn+f3)
Press fn+f3 to initiate Sleep.
When Sleep is initiated, your information is stored in random access memory (RAM), the screen is
cleared, and power is conserved. While the computer is in the Sleep state, the power light blinks.
CAUTION To reduce the risk of information loss, save your work before initiating Sleep.
The computer must be on before you initiate Sleep.
NOTE If a critical battery level occurs while the computer is in the Sleep state, the computer
initiates Hibernation and the information stored in RAM is saved to the hard drive. The factory
setting for critical battery action is Hibernate, but this setting can be changed in advanced power
settings.
To exit Sleep, briefly press the power button.
The function of the fn+f3 hotkey can be changed. For example, you can set the fn+f3 hotkey to initiate
Hibernation instead of Sleep.
NOTE In all Windows operating system windows, references to the sleep button apply to the
fn+f3 hotkey.
ENWW Hotkeys 5

Switch the screen image (fn+f4)
Press fn+f4 to switch the screen image among display devices connected to the system. For example,
if a monitor is connected to the computer, each time you press fn+f4 the image switches among the
computer display, the monitor display, and a simultaneous display on both the computer and the
monitor.
Most external monitors receive video information from the computer using the external VGA video
standard. The fn+f4 hotkey can also alternate images among other devices receiving video information
from the computer.
The following video transmission types, with examples of devices that use them, are supported by
the fn+f4 hotkey:
●LCD (computer display)
●External VGA (most external monitors)
●S-Video (televisions, camcorders, VCRs, and video capture cards with S-Video-in jacks, on select
models)
●Composite video (televisions, camcorders, VCRs, and video capture cards with composite-video-
in jacks)
NOTE S-Video and composite video devices can be connected to the system only by using
an optional docking device.
Viewing battery pack charge information (fn+f8)
Press fn+f8 to display charge information for all installed battery packs. The display indicates which
battery packs are charging and reports the amount of charge remaining in each battery pack.
Decrease screen brightness (fn+f9)
Press fn+f9 to decrease screen brightness. Hold down the hotkey to decrease the brightness level
incrementally.
Increase screen brightness (fn+f10)
Press fn+f10 to increase screen brightness. Hold down the hotkey to increase the brightness level
incrementally.
6 Chapter 2 Keyboard ENWW

HP Quick Launch buttons (select models only)
Use the HP Quick Launch buttons to open frequently used programs, sometimes called applications in
the HP Quick Launch Buttons control panel.
Component Description
(1) Info Center button Launches Info Center, which enables you to open various software
solutions. You can also reprogram this button to perform one of the
following actions:
●Open Presentation mode or the Q Menu.
●Open an e-mail editor.
●Open a search box that allows you to search for a Web site.
For more information, refer to “Setting button preferences” or “Info
Center button.”
(2) Presentation button Starts the presentation feature. This feature opens a program,
folder, file, or Web site, and simultaneously displays it on both the
computer screen and on an external device. Refer to “Presentation
button” for more information.
The presentation button can be reprogrammed to perform one of
the following actions:
●Open the Q Menu or Info Center.
●Open an e-mail editor.
●Open a search box that allows you to search for a Web site.
For information about reprogramming the presentation button,
refer to “Setting button preferences.”
ENWW HP Quick Launch buttons (select models only) 7

Presentation button
When you press the presentation button the first time, the Presentation Settings dialog box opens. In
this dialog box, you can set the button to perform one of the following actions:
●Open a program, folder, file, or Web site that you specify.
●Choose a display setting.
The image simultaneously displays on the computer screen and on an external device connected to
one of the following:
●The external monitor port
●Ports and jacks on an optional docking device
If you choose not to use the presentation button default settings, you can reprogram the button to perform
one of the following actions:
●Open the Q Menu or the Info Center.
●Open an e-mail editor.
●Open a search box that allows you to search for a Web site.
8 Chapter 2 Keyboard ENWW

Info Center button
When you press the Info Center button the first time, the Info Center opens, enabling you to open preset
software solutions. If you choose not to use this default setting for the Info Center button, you can
reprogram the button to perform one of the following actions:
●Open the Q Menu or start the presentation feature.
●Open an e-mail editor.
●Open a search box that allows you to search for a Web site.
ENWW HP Quick Launch buttons (select models only) 9

HP Quick Launch Buttons control panel
NOTE Some of the preferences listed in the HP Quick Launch Buttons control panel may not
be supported by your computer.
You can use the HP Quick Launch Buttons control panel to
●Program the presentation button and the Info Center button, and change the settings for each
button.
●Add, modify, and remove items on the Q Menu.
●Set preferences for tiling windows on the Windows desktop.
●Specify other preferences, including the following
●Preferences for the display of the HP Quick Launch Buttons icon.
●Display of HP Quick Launch Buttons desktop notifications.
●Enabling or disabling automatic mode change.
●Enabling or disabling quick switch.
●Enabling or disabling the display resolution change detection feature.
The following sections provide instructions for setting preferences within the control panel. For additional
on-screen information about any item on the control panel, click the help button in the upper-right corner
of the window.
Opening the Quick Launch Buttons control panel
You can open the HP Quick Launch Buttons control panel in any of the following ways:
●Select Start > Control Panel > Hardware and Sound > Quick Launch Buttons.
●Double-click the HP Quick Launch Buttons icon in the notification area, at the far right of the
taskbar.
●Right-click the HP Quick Launch Buttons icon in the notification area, and select Adjust HP
Quick Launch Buttons Properties.
10 Chapter 2 Keyboard ENWW

Setting button preferences
You can program a button to open the Q Menu, open Info Center, open an e-mail editor, search for a
Web site, or open a program, folder, file, or Web site when the button is pressed.
To open the Q Menu or to open the Info Center when the button is pressed
1. In the HP Quick Launch Buttons control panel, click the Programmable Buttons tab.
2. Click the down arrow next to the button you want to set, and click Q Menu or HP Info Center.
3. To save your preferences and close the control panel, click Apply, and then click OK.
To open an e-mail editor or to search for a Web site when the button is pressed:
1. In the HP Quick Launch Buttons control panel, click the Programmable Buttons tab.
2. Click the down arrow next to the button you want to set, and click Launch eMail or Search URL.
3. To save your preferences and close the control panel, click Apply, and then click OK.
To open a program, folder, file, or Web site when the button is pressed:
1. In the HP Quick Launch Buttons control panel, click the Programmable Buttons tab.
2. Click the down arrow next to the button you want to set, and click Presentation.
3. Click the Configure button.
4. In the box under Program to Start, type the name of the program, folder, or file, or the URL of the
Web site.
– or –
Click Browse to search for available programs, folders, files, or Web sites, and then click to select
one.
5. To save your preferences and close the control panel, click Apply, and then click OK.
Displaying the Q Menu
The Q Menu provides quick access to many of the system tasks accessed with the buttons, keys, or
hotkeys found on most computers.
To display the Q Menu on the desktop:
▲Right-click the HP Quick Launch Buttons icon and select Launch Q Menu.
Setting Q Menu preferences
The Q Menu can display up to 40 items. Several system-defined items are set at the factory. You can
choose to display these items or choose not to display them. Only user-defined items can be added. All
items, including the default items, can be removed.
The items on the Q Menu are managed from the Items to display on Q Menu list.
ENWW HP Quick Launch buttons (select models only) 11

Removing a Q Menu item
To remove an item from the Q Menu:
1. In the HP Quick Launch Buttons control panel, click the Q Menu tab.
2. On the Items to display on Q Menu list, clear the check box for each item you want to remove.
3. To save your preferences and close the control panel, click Apply, and then click OK.
Adding a listed item to the Q Menu
To add an item from the Items to display on Q Menu list to the Q Menu:
1. In the HP Quick Launch Buttons control panel, click the Q Menu tab.
2. Select the check box for the item you want to add.
3. To save your preferences and close the control panel, click Apply, and then click OK.
Adding a user-defined item to the Q Menu
To add an item to both the Items to display on Q Menu list and to the Q Menu when it is not on the
Items to display on Q Menu—for example, an item on a drive, network, or the Internet:
1. In the HP Quick Launch Buttons control panel, click the Q Menu tab.
2. Click Add.
3. In the Add New Menu Entry dialog box, you can add the item by typing or by browsing:
●To add the item using the keyboard, type a name for the item in the Display Name box and
type the path to the item in the File Name box. If you prefer to type the Display Name, but
browse for the File Name, leave the File Name box blank.
●To add an item by browsing, click the Browse button.
In the window, select the item. (The full name of the item is displayed in the File Name box
and, if you did not type a name earlier in the Display Name box, a Display Name is generated
from the item name and displayed in the Display Name box.)
4. To save your preferences and close the control panel, click Apply, and then click OK.
Changing a user-defined item
User-defined items can be changed, but system-defined items cannot be changed. If you select a
system-defined item on the Items to display on Q Menu list, the Modify button is unavailable.
To change the display name and/or file name of a user-defined item:
1. In the HP Quick Launch Buttons control panel, click the Q Menu tab.
2. Click the item on the Items to display on Q Menu list.
12 Chapter 2 Keyboard ENWW

3. Click Modify.
●To change the Display Name or File Name of the item using the keyboard, type the new name
for the item in the Display Name box or type the new path to the item in the File Name box.
If you prefer to type the Display Name, but browse for the File Name, leave the File Name
box blank.
●To change the Display Name or File Name by browsing, click the Browse button.
In the window, select the item. (The full name of the item is displayed in the File Name box
and, if you did not type a name earlier in the Display Name box, a Display Name is generated
from the item name and displayed in the Display Name box.)
4. To save your preferences and close the control panel, click Apply, and then click OK.
Repositioning a Q Menu item
To change the location of an item on the Q Menu:
1. In the HP Quick Launch Buttons control panel, click the Q Menu tab.
2. Select the item on the Items to display on Q Menu list. Then
●To move the item up in the list, click the Move Up button.
●To move the item down in the list, click the Move Down button.
3. To save your preferences and close the control panel, click Apply, and then click OK.
Removing an item from the Items to display on Q Menu list
System-defined items cannot be removed from the Items to display on Q Menu list.
To remove a user-defined item:
1. In the HP Quick Launch Buttons control panel, click the Q Menu tab.
2. Click the item you want to remove.
3. Click Remove.
4. To save your preferences and close the control panel, click Apply, and then click OK.
Setting tiling preferences
To set tiling preferences on the Windows desktop:
1. In the HP Quick Launch Buttons control panel, click the Quick Tile tab.
2. Click Vertical Tile or Horizontal Tile, and then click the programs you want to be tiled in the
Applications currently running box.
3. To save your preferences and close the control panel, click Apply, and then click OK.
Setting other preferences
You can set other preferences in the Quick Launch Button control panel.
ENWW HP Quick Launch buttons (select models only) 13

NOTE Some of the preferences listed on the Preferences tab may not be supported by your
computer.
To set a preference:
1. In the HP Quick Launch Buttons control panel, click the Preferences tab.
2. To display or enable a preference, select the check box next to the item.
– or –
To clear or disable a preference, clear the check box next to the item.
NOTE For on-screen information about any item on the Preferences tab, click the Help button
in the upper-right corner of the window, and then click the item.
14 Chapter 2 Keyboard ENWW

3 Keypads
The computer has an embedded numeric keypad and also supports an optional external numeric keypad
or an optional external keyboard that includes a numeric keypad.
Component
(1) Embedded numeric keypad
(2) fn key
(3) num lock light
(4) num lk key
ENWW 15

Using the embedded numeric keypad
The 15 keys of the embedded numeric keypad can be used like the keys on an external keypad. When
the embedded numeric keypad is turned on, each key on the keypad performs the function indicated by
the icon in the upper-right corner of the key.
Enabling and disabling the embedded numeric keypad
Press fn+num lk to enable the embedded numeric keypad. The num lock light is turned on. Press fn
+num lk again to return the keys to their standard keyboard functions.
NOTE The embedded numeric keypad will not function while an external keyboard or numeric
keypad is connected to the computer or to an optional docking device.
Switching key functions on the embedded numeric keypad
You can temporarily alternate the functions of keys on the embedded numeric keypad between their
standard keyboard functions and their keypad functions by using the fn key or the fn+shift key
combination.
●To change the function of a keypad key to keypad functions while the keypad is off, press and hold
the fn key while pressing the keypad key.
●To use the keypad keys temporarily as standard keys while the keypad is on:
●Press and hold the fn key to type in lowercase.
●Press and hold fn+shift to type in uppercase.
Using an external numeric keypad
Most keys on most external numeric keypads function differently according to whether num lock mode
is on or off. (By default num lock mode is off.) For example:
●When num lock is on, most keypad keys type numbers.
●When num lock is off, most keypad keys function like the arrow, page up, or page down keys.
When num lock on an external keypad is turned on, the num lock light on the computer is turned on.
When num lock on an external keypad is turned off, the num lock light on the computer is turned off.
If an external keypad is connected, the embedded numeric keypad cannot be turned on.
Enabling or disabling num lock mode as you work
To turn num lock on or off on an external keypad as you work:
▲Press the num lk key on the external keypad, not on the computer.
16 Chapter 3 Keypads ENWW
