hp StorageWorks NAS b3000 v2
The HP StorageWorks NAS b3000 v2
is the answer to a network attached
storage (NAS) solution for enterprise-level
availability, scalability and performance.
The NAS b3000 scales up to 48 TB with
embedded switches or external switches,
and with external options. It provides
all components necessary for high
performance block and file serving with
the added advantage of turnkey simplicity.
The NAS b3000 is a single-managed
storage infrastructure — the solution for
businesses needing server/storage
consolidation with connectivity to an
entry-level SAN.
The NAS b3000 makes migration simple,
enabling entire RAID sets to be physically
moved and recognized. Plus, the NAS
b3000 achieves outstanding levels of
availability through Advanced Data
Guarding (ADG), fully integrated software
packages, and no-single-point-of-failure
clustered configurations. HP has combined
all these capabilities to drive down the
overall cost of storage and provide best
return on storage investment.
key features and benefits
controllable
• NAS/SAN fusion: integrates file or
block data leads to increase efficiency
of the storage network
• manageable: provides a simpler
management of file or block level
data leads, decreasing costs for
storage management
• affordable: NAS/SAN fusion provides
a more efficient storage architecture
resilient
• reliable: delivers experience critical
to a successful, affordable optimized
NAS solution
extensible
• extensive: produces enterprise and
departmental solutions that consolidate
fusion for the enterprise
• optimized: offers the right NAS
solution for each customer; there’s
no need to settle for trade-offs
what’s new
• new server platform based on
HP ProLiant DL380 G3
• snapshot technology
enabled by Columbia
Data Products Persistent
Storage Manager
• new web interface
hp StorageWorks NAS b3000 v2

warranty and support
warranty features — warranty uplifts and HP CarePaq services are offered on all HP StorageWorks NAS products
hp service and support
for more information
For more information on HP StorageWorks NAS b3000, contact any of our worldwide sales offices or visit
our web site at: http://h18006.www1.hp.com/storage/networkattached.html
Technical information in this
document is subject to change
without notice. Intel is a registered
trademark of Intel Corporation. All
product names mentioned herein
may be trademarks or registered
trademarks of their respective
companies.
© 2003 Hewlett-Packard
Development Company, L.P.
2/2003
5981-5713EN
ordering information
product number product name description
322313-001,421 NAS b3000 v2 server only NAS b3000 v2 server only component; for those customers that already
have an HP StorageWorks Modular SAN Array (msa1000) or need this
to cluster an existing NAS b3000 v2
322314-001,421 NAS b3000 v2 Server & Storage NAS b3000 v2 solution that includes both the server and the
msa1000 storage component
what’s included
• 2 x 36 GB SCSI HD; Intel®Xeon Processors; msa1000; 4 X 72 GB HD; 6 port embedded switch, HP Integrated Lights-Out Standard
Management (iLO) on system board; 1024 MB RAM; HP Advanced Memory Protection; three, full length 64-bit/100 MHz PCI-X slots,
2 hot-pluggable; Integrated Gigabit NIC, Integrated Smart Array 5i Plus Controller (Dual Channel, Ultra3); battery-backed write cache
enabler module
• HP supplied software: Windows Powered OS; HP StorageWorks NAS Data Copy; CDP Persistent Storage Manager; Rapid Launch; Web
Based Configuration Utility; Array Configuration Utility; HP Insight Manager (CIM) WBEM Win32; HP Insight Manager base console;
Smart Start 6.x software drivers; SmartStart 6.x CD (utilities only) and Management 6.x CD; Windows Powered OS drivers, including Array
Controller driver and HBA drivers; Tivoli TME, HP OpenView, IBM Netview, CA Unicenter, BMC agents installed for Enterprise (SNMP)
Management; NIC Teaming Drivers; HP UPS; APC UPS; Quick Restore CD
hp StorageWorks
NAS b3000 v2 availability
technical specifications
performance 2.125 Gb/s line speed, full duplex
protocol support CIFS, NFS, NCP, AppleTalk, HTTP, FTP
management access management GUI, HP Lights-Out board, Terminal Services, Console, Command line
dimensions (HxWxD) 3.38 x 17.50 x 25.75 in/8.59 x 44.45 x 65.41 cm
weight • maximum: 60 lb/27.22 kg
• no drives: 47.18 lb/20.41 kg
input requirements (per power supply) • range line voltage: 90 to132 VAC/180 to 265 VAC
• nominal line voltage: 100 to 120 VAC/220 to 240 VAC
• rated input current: 6A (110V) to 3A (220V)
• rated input frequency: 50 to 60 Hz
• rated input power: 600W
BTU rating 1,475 BTU/HR
SCSI connectors one external VHDCI connector
power supply output rated steady-state power: 400W
power (per power supply) maximum peak power: 400W
temperature range • operating: 50° to 95° F/10° to 35° C
• shipping: -40° to 158° F/-40° to 70° C
relative humidity (non-condensing) • operating: 10% to 90%
• non-operating: 5% to 95%
maximum wet bulb temperature 82.4° F/28° C
acoustic noise (server) idle minimum (fixed disk drives spinning)
L WAd (BELS) 7.0
L pAm (dBA) 55
operating minimum (random seeks to fixed disks)
L WAd (BELS) 7.0
L pAm (dBA) 55
acoustic noise (HP StorageWorks idle minimum (fixed disk drives spinning)
Modular SAN Array) L WAd (BELS) 7.2
L pAm (dBA) 56
operating minimum (random seeks to fixed disks)
L WAd (BELS) 7.3
L pAm (dBA) 57
