Compass CSWEU2LED User manual

Outdoor Wet Location LED Emergency Light
CSWEU2LED
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed including the following.
READ AND FOLLOW
ALL SAFETY INSTRUCTIONS
1. Rated for temperature range of 10°C-40°C (50°F-104°F) and suitable for use in an application that is designated
as a wet location area as defined by NEC Article 100, Location, wet.
2. Used indoors or outdoors.
3. Equipment should be mounted in locations and at heights (Max: 9ft) where it will not be subject to tampering by
unauthorized personnel.
4. Do not mount near gas or electric heaters.
5. The use of accessory equipment is not recommended by the manufacturer and may cause an unsafe condition.
6. Do not use this equipment for anything other than its intended use.
7. Servicing of this equipment should be performed by qualified personnel.
8. Disconnect AC power before servicing.
INSTALLER:
•SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
•SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
J-Box Mounting
1. Open the Base plate and lead out a wire after getting through the hole on the Base plate. Fix the Base
plate on J-Box with screws.
2. Then connect to AC power (Fig.4).
3. Connect to the battery with connectors (Fig.5/ Fig.6).
4. Install the housing to Base plate, turn on the AC power and press the “TEST” button check light (Fig.8).
Conduit
1. Use tool such as at head screw driver to open the housing. (Fig.1)
2. Hold the unit by one hand and use tool to pry the 2 lock buttons at the base plate (Fig.2), separate the unit
from the base plate (Fig.3).
3. Secure Base Plate to wall surface. Route wires through hole in conduit ange and make conduit
connection. Use exible conduit only.
4. Connect battery before continuous AC power is being supplied to the unit (Fig. 5/ Fig. 6).
5. Press the unit back onto the base plate, make sure it be hold by the lock buttons. (Fig. 7)
6. Align snaps and push housing directly onto the Base Plate (Fig. 8). Apply continuous AC power and press
“TEST” button to check light.
INSTALLATION
Fig. 1 Fig. 2 Fig. 3

RECYCLING INFORMATION
All steel, aluminum and thermoplastic parts are recyclable.
NOTICE: Emergency units contain rechargeable batteries which
must be recycled or disposed of properly.
Fig. 4 Fig. 5 Fig. 6
Fig. 7 Fig. 8
1. During an electrical power failure, the lamps on the unit will automatically come ON for a minimum of 90 minutes.
2. 2. To test this unit, let it charge correctly with AC power supply for a minimum of 24 hours after its rst installation
and then depress the “TEST” switch, the emergency lamps will illuminate. When the switch is released, the lamps
will turn OFF.
Operation
Wiring Diagrams
Warning: Unused wires must be capped using enclosed wire nuts
LED Wiring Diagram MR16 Wiring Diagram
604052
currentlighting.com/compass
