Component Solution Services Verity SM05J User manual

A division of
Component Solution Services, LLC.
56600 Twin Branch Dr.,
Mishawaka, IN 46545
www.verityrvs.com
Please read this manual completely before operating the SYSTEM
© Verity Rear Vision Systems
All rights reserved 2019
Just View It!®
5 INCH DIGITAL
MONITOR SYSTEM
Part # SM05J

2
www.VerityRVS.com
Verity Rear Vision Systems
Just View It!®
Now includes our
ADD25F Heavy Duty Mount
allowing for more
mounting options

3
4. About Us
5. Think Safety Frist
6. Continued
7. System Features
8. System Components
9. Connections
10. Continued
11. Camera Mounting
12. Continued
13. Monitor Mounting
14. Continued
15. Monitor / remote operations
16. Menu operations
17. Continued
18. Continued
19. Warranty
20. Support and contact information
TABLE OF CONTENTS

4
Component Solution Services LLC., offers the Verity
Rear Vision Systems® to meet any requirements
and price point within the trucking, specialty vehicles,
and RV industry. Our standard cabled systems offer
unparalleled features into the trucking and RV
industries. Designed for professional drivers, Verity
Rear Vision Systems develops and markets products
and applications to transmit video, audio, and data
either individually or in any and all combinations. The
company has also developed, manufactured, and
marketed different kinds of personal and vehicle video
cameras, DVRs, and accessories for the commercial
transportation, fire/rescue, and marine OEM markets.

5
Most likely, your system came preinstalled so the installation
section would be for reference.
Thank you for your purchase of our Verity Rear Vision
System®. When installed and used properly, your SM05J is
designed to deliver you years of trouble-free operation. This
manual contains important information required to properly
install and operate the unit. Verity Rear Vision Systems are
designed for quick installation by trained professionals in
proper installation environments. Our designs are based on
decades of working with vehicle manufacturers.
Verity Rear Vision Systems’products are intended to be
installed as a supplement and our observation systems
and/or products are not intended for use as substitutes for
rear-view mirror devices, or for any other standard motor
vehicle equipment which may be required to be installed on
vehicles by law. Verity Rear Vision Systems' products
promote improving the vehicle operator’s field of view. Our
products are no substitute for proper defensive driving
techniques, observance of traffic laws and motor vehicle
safety regulations.
Installation Location
It is unlawful in most locals for any person to drive a motor
vehicle equipped with a television viewer/screen located at
any point forward of the back of the driver’s seat (or in any
location that is visible, directly or indirectly), to the driver
while operating the vehicle. Our systems are designed to be
used primarily as a rear observation device.
DO NOT OPEN ANY COMPONENT. There are no
serviceable parts inside any of the components of the Verity
Rear Vision products. Opening the product will break the
tamper indicators and void the warranty.
Think Safety First
Read our manual before operating or installing.

6
WARNING
Do not place heavy objects on cables or cover
them with carpet or mats.
Do not place cables where they can be
crushed in any manner.
Our systems are designed as a driving aid.
Watching videos, broadcasts, DVDs and/or any
images other than intended driving assistance
cameras is prohibited.
CAUTION
To avoid damage to the electronic circuit, stop
using this product while doing welding work to
the vehicle and/or trailers.
Never immerse any component in water, and
do not employ spray cleaners. When cleaning,
use a damp lint-free cloth only.
Connect this unit only to other compatible
devices.
Although our products have built-in surge and
cross polarity protection, make sure all cables
are connected properly; improper cable
connections may damage the camera and the
monitor.
Cables should not be allowed to touch hot or
rotating parts, such as the engine, ventilator,
etc.
Do not locate the monitor near heat generating
vents or devices.
Turn off power to the monitor when connecting
the camera.
Monitors are not designed to be waterproof. (Our
SM07F waterproof monitor is the exception.)
Exposure to water, such as rain, may damage the
unit.

7
3 ¼”
2 7/8”
1 3/4”
1”
2”
MONITOR SPECIFICATIONS
Screen size: 5-inch digital screen (16:9)
Long Life High Resolution: 640 x 480 Pixel (RGB)
System: PAL/NTSC selectable
Contrast: 400:1 Brightness: 450cd/m2
Power supply: DC 12V~24V with reverse polarity protection
Operation temperatures: -30~70C Storage temperature: -40~80C
3 AV color coded inputs with color coded trigger wires, auto blue screen if no
signal on activated channel
Features: HD sunshade, auto light sensor dimming for buttons and LCD
screen, LED blue light buttons, high quality processor, in-line waterproof fuse
Easy to use OSD menu function via buttons & remote: reversing image delay
time 0~15s, (for side cameras) Mirror/Normal image, plus horizontal flip per
signal channel, multi-language, NEW! Adjustable guidelines.
1 / 3” COLOR CCD SENSOR SPECIFICATIONS
With Audio and IR
TV System: NTSC
Aluminum shelled waterproof camera with hex bolts for insured positioning
Image Type: 1/3 Inch Color CCD Sharp® or equivalent (no cheap off brands)
Horizontal Resolution: 700 TV Lines
Effective pixel: NTSC: 510 (H) × 492(V)
Illumination: 0 Lux (built-in 20 high output IR LED's for night vision)
Viewing angle: 120°
Aluminum housing.
Waterproof: IP69K Shockproof: 10G
Operating temperature: -40°C to +70°C
Power supply: 12V DC (powered by monitor)
SYSTEM FEATURES

8
I/F Remote
Night-vision
Weatherproof Camera
65 foot
Camera Cable
Heavy Duty Mount
13-pin to Monitor Cable
5-Inch HD Digital
Panel
Manual
VERITY
SYSTEM COMPONENTS

9
It is recommended to determine all wire connections before
making any permanent installation of components.
Connect the wires on the monitor cable to the proper
connections using Verity Rear Vision Systems Wire
Connection Key (Fig. 1) and the connection diagrams
located under connection operations (Fig. 2).
A larger wire diagram can be located on our website at
www.verityrvs.com/sm05j or by using the bar code provided
Figure 1.
Verity Rear Vision Systems Wire Connection Key
4-pin camera connectors & trigger wires
Brown -Camera 1 rear (Brown 4-pin)
Blue -Camera 2 optional (Blue 4-pin)
Red wire to key-on hot (+) 10-32v. DC (fused)
Black wire to GND. (-)
Brown wire to positive Back-up light
Blue wire to positive power Left turn signal
Brown wire to positive power Right turn signal
USE ARROWS TO ALIGN 13-PIN CONNECTION!
If force is applied to this connection when not aligned, it
may damage plug pins and void the warranty.
CONNECTIONS

10
Figure 2.
Thru-wall Gasket to Seal
Thru-Vehicle Exterior
Secondary Waterproof Sleeve
Slides Over Aviation Connection
Waterproof Aviation
Connectors
13-Pin female
Female on Both
Ends
CAM 1
CAM 2
13-Pin male
3-amp fuse

11
Verity C001JCamera bracket hole pattern and grommet size:
When mounting the camera be careful to check the area
where you will be setting the screws. Be sure you will not drill
into items such as other cables, roll up door mechanics,
marker lights, etc. and the surface will support the item being
attached. Make sure there is room for a proper drip loop.
Install A proper “Drip-Loop”
This provides a way for water to drip away from the truck and not into the truck.
DO NOT RUN CAMERA CABLE THROUGH
THE CENTER OF THE BRACKET
49.2
mm
1
.94
”
3
9.
6
mm
1
.
60
”
16.48 mm
0.65”
.
44.52 mm
1.75”
0.810"
CAMERA MOUNTING

12
A video about drip loops can be viewed using our FAQs on
our website www.verityrvs.com/faqs. Or use the following bar
code to view.
Suggested Camera placements
Above Shows
Camera Washer
On RVs, it is suggested
you just keep the camera
on the center line
Top Mid-truck
best location.
Low Mid-truck
secondary
location.

13
This monitor can be mounted on the dash and can be mounted on
both horizontal and vertical surfaces. Make sure the view is
suitable to the driver to observe the images. Take care not to block
any necessary viewing area when mounting. Before mounting the
system, permanently hook up all connections to ensure proper
operation.
Mounting the Monitor
1. After determining the monitor location, position the monitor
support bracket, mark the bolt hole location, and then drill the
holes. Be careful not to drill into any other surface that may be
hidden.
2. Attach monitor bracket. Mount the monitor to the support
bracket with supplied hardware. When mounting the monitor
bracket be careful to check the area where you will be setting the
screws. Be sure you will not drill into items such as other cables,
dash air bags, etc. and the surface will support the item being
attached.
There are guidelines on what part of the windshield can be blocked.
Department of Transportation Federal Motor Carrier Safety
Administration 4910-EX-P. Indicates the following information.
More information can be found at our website FAQs.
MONITOR MOUNTING GUILDLINE

14
Suggested Monitor Locations

15
VOLUME
DECREASE
DIM Auto Dimming Photo Cell
CAM
Switches between cameras
M/N
Mirrored / Normal View
D/N
Day / Night screen brightness (Works only when not in
auto dim mode)
POWER Power on/off button RED power off / BLUE powered
MENU
Activates operational menu
Down
Volume DOWN / switches down when in menu
UP Volume UP / switches up when in menu
IR Remote sensor
VOLUME
INCREASE
MENU
POWER
SWITCH
CAMERA
VERITY
MONITOR / REMOTE OPERATION

16
Press Menu:
The red highlighted text shows the current selection. Press the
MENU button to advance through the available options and use the
DOWN/UP arrow buttons to adjust the selection.
1 time: BRIGHTNESS
Use the DOWN / UP arrows to turn the brightness
2 times: CONTRAST
Use the DOWN / UP arrows to adjust contrast
3 times: COLOR
Use the DOWN / UP arrows to adjust color
4 times: VOLUME
Use the DOWN / UP arrows to adjust volume
5 times: LANGUAGE
Use the DOWN / UP arrows to adjust between 10 languages
6 times: DIMMER
Use the DOWN / UP arrows to turn the auto dim on/off
BRIGHT DIMMER AUTO
CONTRAST PARK OFF
COLOR CAM1 TIME 0 S
VOLUME CAM1 NORMAL
ENGLISH CAM SCAN OFF
llllllllllllllllllll------------- 50
MENU OPERATIONS

17
7 times: PARKING LINES
Use the DOWN / UP arrows to turn on park lines
If parking lines on:
Use the DOWN / UP arrows to adjust parking lines vertically
Use the DOWN / UP arrows to adjust parking lines width
Movement
Movement
in & out
w
MENU OPERATIOIN CONTINUED

18
8 times: CAMERA TIMER
Use the DOWN / UP arrows to select CAM 1 or CAM 2,
then use the MENU button to move right. Use the DOWN /
UP arrows to adjust the camera time from: 0S, 3S, 5S, 7S,
and 10S
9 times: CAMERA VIEW
Use the DOWN / UP arrows to select CAM 1 or CAM 2,
then use the MENU button to move right. Use the DOWN /
UP arrows to adjust either CAM 1 or CAM 2 to a mirrored or
normal view.
10 times: CAMERA SCAN
Use the DOWN / UP arrows to adjust camera scan
MENU OPERATIOIN CONTINUED

19
Verity Rear Vision Systems
A division of
COMPONENT SOLUTION SERVICES (CSS)
LIMITED ONE (1) YEAR WARRANTY
1. CSS products’ warranties are not transferable. The warranties apply to the
retail consumer for one (1) year and covers against defects in material and
workmanship.
2. Defective components will be replaced or repaired, based on a CSS
evaluation of the component. In-bound shipping charges, based on the CSS rate
allocated in the RMA (returned merchandise agreement), will be covered once
the component has been deemed defective at the CSS warranty facility. The
pre-assigned in-bound freight will be supplied upon return of product. All
repaired/replaced warranty parts shall be for the remaining duration of the
original warranty time period.
3. CSS takes pride in our products and will aid in the processing of your
components:
a) All warranty claimants must have consulted our technical support department
for trouble shooting and the acquiring of an RMA. Contact can be made via
email at [e-mail] or call 574-807-6002.
b) When the warranty claim is made, the consumer must establish the warranty
start dates by presenting documentation regarding the date of retail purchase
(e.g., bill of sale). c) Service performed by non-authorized service personnel
may void all warranty claims.
d) CSS will make no payments for system removal / system re-installing, mileage
allowance, or transportation expenses.
The limited warranty does not cover damage resulting from misuse, accident,
modification or alteration to hardware or software, tampering, unsuitable physical
or operating environment beyond product specifications, improper maintenance,
or failure caused by a product for which CSS is not responsible. There is no
warranty for any product with removed or altered identification labels. CSS
DOES NOT PROVIDE ANY OTHER WARRANTIES OF ANY KIND,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. SOME JURISDICTIONS DO NOT ALLOW THE LIMITATION OF
IMPLIED WARRANTIES, SO THIS LIMITATION MAY NOT APPLY TO YOU.
4. This warranty gives you specific legal rights, and you may also have other
rights that vary from state to state.

20
Technical Support
A service ticket can be filled out online to supply the quickest
service. The service ticket can be easly found on our web site
www.verityrvs.com or use the code to the right. Please have the
serial number of the system which is found on the back of the
monitor when contacting the service department. We take great
pride in delivering the most dependable product in the industry.
Each item was 100% QC tested and then we randomly recheck
another up to 10% before it leaves our hands to you. We have a
.034% issue rate with this product.
Email Tech Support: [email protected]
Phone Tech Support: 574-807-6002
Note: if you are a fire/rescue customer in need of
tech support after hours or on weekends, leave a
message and a technician will return your call as
soon as one becomes available.
a division of
Component Solution Services
56600 Twin Branch Drive
Mishawaka, IN 46545
574-807-6002
Toll Free 844-875-4799
We at Verity Rear Vision Systems would like to
personally thank you for purchasing our
product. Our company strives to supply the
best products at a fair price. We care that you
enjoy a safe driving experience.
2019 Verity Rear Vision Systems
All content is copy right protected
Revision 6 HR
