Comprehensive CP-HDA100 User manual

CP-HDA100
3D Mini HDMI Analyzer
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Comprehensive Cable assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Comprehensive Cable assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Comprehensive Cable reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Comprehensive Cable.
© Copyright 2011 by Comprehensive Cable.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
•
electrical shock and injury to persons.
•
moisture or install this product near water.
•Never spill liquid of any kind on or into this product.
•Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
•Do not attach the power supply cabling to building surfaces.
•Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
•Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
•To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VS1 09/02/12 First Release

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Top Panel ..........................................5
7 OSD Menu ............................................... 7
7.1 System Info........................................8
7.2 Sink Edid ............................................9
7.3 Source Infoframe .............................9
7.4 CEC Command ...............................9
7.5 Audio Return.....................................9
7.6 Deep Color Set...............................10
7.7 Exit....................................................10
8. OLED Display ........................................ 11
9. Timing Table (Pattern Mode) .............. 12
10. Support Pattern Table........................ 13
11. Connection Diagram ........................ 15
.................................... 16
13. Acronyms ........................................... 17

1
1. INTRODUCTION
The 3D Mini-HDMI Analyzer is a tool for checking both source (Blu-
ray or DVD players) and display devices (TV or monitors). With touch
button controls and built-in OLED (Organic Light Emitting Diode)
display it can show the status and information of both the input and
output devices connected to it by HDMI.
The analyzer can be used to analyze the input source device info-
frame and output sink device EDID. It also has a built-in pattern
generator that can be used to test the capabilities of the output
device including 3D and resolution/timing support.
2. APPLICATIONS
•Apparatus testing
•Equipment checking
•EDID checking
•
•Production testing
•R&D design and debug
3. PACKAGE CONTENTS
•3D Mini-HDMI Analyzer
•Operation Manual
•5 V Power Adaptor
4. SYSTEM REQUIREMENTS
HDMI input port connected to the source/HDMI system with HDMI
cable and HDMI output connected to the display/HDMI system with

2
5. FEATURES
•SupportsTiming include SD, HD upto 1080p, PC upto WUXGA and 3D
•Provides 25 timings, 6 patterns and 1 pattern for 3D timing
•'Deep color' video support (up to 12-bit, 1080p@60 Hz)
•Supports input signal bypass, digital video formats in 'Deep Color'
Mode up to 36-bit (12-bit/color) and new lossless compressed
digital audio (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master
Audio)
•Supports internal pattern audio LPCM 2CH 48/96/192 kHz, LPCM
5.1CH 48/96 kHz, LPCM 7.1CH 48/96kHz
•Analyze the input source info-frame and output sink EDID
information
•Touch button control function
•OLED display shows Input/Output timing information
•Supports ARC (Audio Return Channel) following HDMI v1.4
•Supports 'Deep Color' (8/10/12-bit) output
•Supports HDCP repeater function and complaint with HDCP
•Supports CEC bypass

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
DC 5V
HDMI IN
2
1
1HDMI IN
Connect the HDMI input port to the HDMI output port of the source
device for testing and displaying the EDID information.
2DC 5V
Plug the DC 5 V power supply into the Mini-HDMI Analyzer and
connect the adaptor to an AC wall outlet.

4
6.2 Rear Panel
ARC OPTICAL OUT
SERVICE HDMI OUT
2 3
1
1SERVICE
Use a DB9 (RS-232) to 3.5 mm (phone jack) cable to do the
software upgrade.
NOTE: This feature is not available to the enduser. The DB9 to 3.5mm
phone jack is not included in the package.
2ARC OPTICAL OUT
Optical digital out for testing the ARC function of a TV connected
to the HDMI. Connect to the opticl digital input of an audio system
(such as an AV receiver) to monitor the audio output of the
attached sink device.
3HDMI OUT
Connects the Analyzer to a display or to devices connected to the
display when testing the capabilities of the system.

5
6.3 Top Panel
M/
INT/EXT AUDIO PATTERN TIMING
PC/HD/3D
821 3 4 5 6 7
Note:
before using the touch key function.
1
POWER
Press this button to turn on the device, the LED will turn blue. Press
again to switch the unit to standby mode, the LED will turn red.
2
INT/EXT
Press this button to toggle between the built-in internal pattern
generator or the external source device. The LED will illuminate in
blue when the external input is selected. To retrieve the external
EDID information, an external source device must be connected
otherwise the device will only generate the test patterns to display
on the TV/monitor.

6
3PC/HD/3D
Press this button to cycle through the test patterns (PC/HD or 3D
timings). The OLED display will show the timing currently selected.
4AUDIO
Press this button to select the audio sample rate from LPCM 2CH,
LPCM 5.1CH and LPCM 7.1CH 48 kHz or LPCM 2CH, LPCM 5.1CH
and LPCM 7.1CH 96 kHz or LPCM 2CH and LPCM 5.1CH 192kHz.
Note: Press and hold for 3 seconds to select Audio mute function.
5M/
selection.
6PATTERN (▲/▼)
Press these keys to select the patterns or when in OSD manual
press these keys to select for option.
7TIMING (▲/▼)
Press these keys to select the required timings.
8OLED Display
Displays the relevant Information about attached devices. See
Section 8 for details.

7
7 OSD MENU
Press the M/button from the device to bring up the OSD on the
display.
•Press pattern’s [▲/▼]to highlight on option
•Press [M/]

8
7.1 System Info
Press this button to show the EDID information for any connected
device. When an output display is connected, press this button
repeatedly to bring up the patterns for display (Refer to Section 10 for
pattern details).
Press [M/] to check the input/output device information and
software version.

9
7.2 Sink Edid
OPTION DESCRIPTION
Block Data To check the sink Block0 and Block1's EDID table
Description To check the sink description of EDID
7.3 Source Infoframe
OPTION DESCRIPTION
AVI (AVI infoframe data) To check the source video infoFrame Packet
AUD (Audio infoframe data) To check the source audio infoFrame Packet
7.4 CEC Command
OPTION DESCRIPTION
Stand By To set the source to standby mode
Active Source To turn on the source
Monitor (Read) To detect the command data on the CEC
Bus
Note: Source equipment must support CEC function in order to
activate this function.
7.5 Audio Return
OPTION DESCRIPTION
Audio Return On/Off

10
7.6 Deep Color Set
OPTION DESCRIPTION
8-bit On/Off
10-bit On/Off
12-bit On/Off
Note: The device will auto-detect the sink device's 'Deep Color' setting
and if any of the settings are not supported, the option in the Deep
Color set will not be selectable.
7.7 Exit
Select to Exit the main menu

11
8. OLED DISPLAY
6
4
3
1
5
2
1080P@60
H:1920 3DTB
48K 2CH ARC
1Sampling Rate
The Analyzer supports audio sampling rates of 48/96/192 kHz,
display will show the signals current sample rate. If external audio is
selected the OLED will display 'BYPASS'.
2Audio Channels
The device supports audio channels from LPCM 2, 5.1 and 7.1CH. If
external audio is selected the OLED will display 'BYPASS'.
Note: When the audio button is held down for 3 seconds, both 1
& 2will show AUDIO MUTE.
3ARC
Audio Return Channel, when this function is selected the OLED
display will show 'ARC' if an ARC signal is present.
4V Timing
Please refer to the Timing Table in Section 9 for details of the
supported timing and V sync.
5H Timing
Please refer to the Timing Table in Section 9 for details of the
supported H Sync.
63D Format
Only when the 3D pattern is selected, the OLED display will show
the pattern details.
Note: When in EXT Mode, the OLED display will show the input H/V
Sync with the timing frequency and 3D pattern if any.

12
9. TIMING TABLE (PATTERN MODE)
No. Resolution V Hz
T01
T02
T03
T04
T05
T06
T07
T08
T09
T10
T11
T12
T13
T14
T15
T16
T17
T18
T19
T20
T21
T22
T23
T24
T25
480p
480i
720P
1080i
1080p
576i
576p
720p
1080i
1080p
1080p
640×480
800×600
1024×768
1280×1024
1920×1200
720p (3D Frame Packing)
720p (3D Side-by-Side)
720p (3D Top-to-Bottom)
720p (3D Frame Packing)
720p (3D Side-by-Side)
720p (3D Top-to-Bottom)
1080p (3D Frame Packing)
1080p (3D Side-by-Side)
1080p (3D Top-to-Bottom)
60
60
60
60
60
50
50
50
50
50
24
60
60
60
60
60
60
60
60
50
50
50
24
24
24

13
10. SUPPORT PATTERN TABLE
GROUP NO. PATTERN Description
Standard Type
1
Primary colors:
Red, Green,
Blue
P1: Red
P2: Green
P3: Blue
2
3
4
P4: Horizontal
RGB Bar
5
P5: H Grey
Scale
6
P6: HDCP
handshaking
and link-
integrity test

14
3D Type
*7
(FP)
P7(FP): Frame
Packing
Non-3D Display
P7(FP): Frame
Packing
3D Display
*7
(SH)
P7(SH): Side-by-
Side (Half)
Non-3D Display
P7(SH): Side-by-
Side (Half)
3D Display
*7
(TB)
P7 (TB): Top-
and-Bottom
Non-3D Display
P7 (TB): Top-
and-Bottom
3D Display

15
11. CONNECTION DIAGRAM
For checking both the source and display device's information, press
M/ to display the System Information.
1080P@60
H:1920
48K 2CH
1080P@60
H:1920
48K 2CH
DVD or Blu-ray
Player
Monitor or
HDMI 3D TV
For checking only the display device's supported timings, connect the
HDMI output only to the display device and press the PATTERN and
TIMING buttons.
1080P@60
H:1920
48K 2CH
1080P@60
H:1920
48K 2CH
Monitor or
HDMI 3D TV

16
12. SPECIFICATIONS
TMDS Clock Frequency 225 MHz
Input Port 1× HDMI (Female type)
Output port 1× HDMI (Female type)
EXT Mode (HDMI input)
HDMI Resolution 480i/p, 576i/p, 720p~1080p
PC Resolution VGA~WUXGA
INT Mode (internal pattern)
HDMI Resolution 480i/p, 576i/p, 720p~1080p
PC Resolution VGA~SXGA, WUXGA
3D Resolution Frame Packing (1080p@24,720p@50/60 )
Side-by-Side (Half) (1080p@24, 720p@50/60)
Top-and-Bottom (1080p@24/, 720p@50/60)
Audio Format 480i/p, 576i/p or VGA~SVGA supports LPCM 2CH
48/96/192 kHz, LPCM 5.1CH 48 kHz, LPCM 7.1CH 48 kHz,
720p~1080p or XGA~WUXGA
support LPCM 2CH, 48/96/192 kHz,
LPCM 5.1CH 48/96 kHz, LPCM 7.1CH, 48/96 kHz
HDMI Cable In 1080p/8-bit 15 m, 1080p/12-bit 10 m
HDMI Cable Out 1080p/8-bit 15 m, 1080p/12-bit 10 m
ESD Protection Human Body model: ±8 kV (air-gap discharge)
±4 kV (contact discharge)
Power Supply 5 V/1
Dimensions 119.5 mm (W) x 70 mm (D) x 25 mm (H)
Weight 128 g
Chassis Material Plastic
Silkscreen Color Black
Operating Temperature 0 ˚C~40 ˚C/32 ˚F~104 ˚F
Storage temperature −20 ˚C~60 ˚C/−4˚ F~140 ˚F
Relative Humidity 20~90 % RH (no condensation)
Power Consumption 4 W (Max)
Note A: This system was tested with 24AWG cables if using cables of another type, the performance of
this system may be different.
Note B: Cable distance tested with a PS3 and 40″ Samsung UA40B700 12-bit LED TV.
Note C:
