compulocks SPWSB User manual

45
2 3
1
Assembly Instructions
www.compulocks.com | [e-mail] | [phone] Sheet 1 of 3
©Compulocks Brands Inc. All Rights Reserved
SECURE DEVICE CHARGING CABLES USING CABLE BRIDGE.
USE M4 x 12mm PIN-in-TORX BUTTON HEAD SCREWS PROVIDED.
TIGHTEN USING PROVIDED TORX SCREWDRIVER
POSITION POWER STRIP CABLE THROUGH OUTLET PULL EXCESS CABLE TO SECURE POWER STRIP
CONNECT DEVICES
Secured PowerStrip SKU:SPWSB / SPWSB-EU
FOLLOW PAGE 3 FOR MOUNTING OPTIONS

9
6
Assembly Instructions
IN THE BOX
www.compulocks.com | [e-mail] | [phone] Sheet 2 of 3
©Compulocks Brands Inc. All Rights Reserved
7
8
Hardware Kit
SECURE COVER USING M4 x 12mm
PIN-in-TORX BUTTON HEAD
SCREW PROVIDED.
TIGHTEN USING PROVIDED
TORX SCREWDRIVER
OPTION TO INSTALL UP TO 2 X 10MMØ CABLES THROUGH CUT OUT INSTALL COVER,
ALIGNED WITH CABLES
SECURE COVER USING M4 x 12mm
PIN-in-TORX BUTTON HEAD
SCREW PROVIDED.
TIGHTEN USING PROVIDED
TORX SCREWDRIVER
Cable Bridge PowerStrip Cover PowerStrip Base Power strip
Secured PowerStrip SKU:SPWSB / SPWSB-EU

Assembly Instructions
www.compulocks.com | [e-mail] | [phone] Sheet 3 of 3
©Compulocks Brands Inc. All Rights Reserved
MOUNTING SCREWS
NOT PROVIDED
MOUNTING SCREWS
NOT PROVIDED
Wall Mounting
Counter Mounting
Free Standing
REGULAR MOUNTING
REGULAR MOUNTING
KEYHOLE MOUNTING
KEYHOLE MOUNTING
IDENTIFY LOCK SLOT PUSH, ROTATE 90° TO LOCK
OPTIONAL
CABLE LOCK
Secured PowerStrip SKU:SPWSB / SPWSB-EU
