Compur Monitox plus
The portable gas warning system for toxic gases and oxygen

Compur Monitox plus
Reliability is everything
With decades of outstanding performance, this
latest version of the Monitox is the best yet. The
Monitox plus provides unmatched performance
and value. It shows the actual gas concentration
on a recessed LCD display and responds to
hazardous concentrations within seconds giving
an audible and a visual alarm.
The electrochemical sensors manufactured by
Compur Monitors undergo strict quality control
and calibration at TLV concentration. This assures
best measurement technology and reliable alert.
Monitox plus is very small and lightweight. Its
housing is made of sturdy, galvanized ABS, with-
standing the harshest industrial environments.
The chromium plated surface protects it from
electromagnetic interference. Handling the
Compur Monitox plus is quick and easy. Sensor
replacement is a breeze since a plug-in socket
sensor allows replacement without even opening
the instrument.
A recessed button on the front side of the instru-
ment allows easy access to a menu for automa-
tic zero and calibration. Thus, even calibrations
can be done without opening the instrument.
Two alarms can easily be set to any value within
the measuring range of the instrument by push-
button.
For added safety the Monitox plus features
smart technology such as a „missing sensor-
alarm” which detects if the electrical connection
to the sensor has been damaged.
Despite all these advantages, the Monitox plus is
inexpensive to purchase and maintain.
With the optional Compur gas generator a 100%
performance test can be done within 10 sec-
onds, without a gas cylinder.
Your safety should be worth it.
www.artconcept-werbeagentur.de
Compur Monitors GmbH & Co. KG
Weißenseestraße 101
D-81539 München
Phone: ++49 89 620 38-0
Fax: ++49 89 620 38-184
E-Mail: [e-mail]
Internet: www.compur.com
AsH3
Cl2
ClO2
CO
COCl2
HCl
HCN
H2S
N2H4
NO2
O2
PH3
SO2
O2
Technical data
Monitox
Measuring range
Alarm thresholds
Measuring principle
Accuracy
Temperature of operation
Humidity
Power supply
Alarms
Display
Dimensions
Weight
Protection
Generator
Power supply
Dimensions
Weight
typ. 0 – 10 *TLV, O2: 1 – 35 %
adjustable
electrochemical
+/-10 %
-20°C to +40°C
typ. 20 – 90 % r. H.
Lithium batteries ca. 1000 h per set
audible 80 dB(A), LED
LCD four digit
115 x 62 x 24 mm
130 g
II 2 G EEx ib IIC T6
1 x 9 V Mallory for ca. 800 Tests
133 x 65 x 40 mm (H x B x T)
250 g
