Computex PALMiCE2 Manual

Technical Information
PALMiCE2 / PALMiCE3
H8S-related Target Interface
Mar. 04, 2011
Sixth Edition
Go through the required procedures as stated under Foreign Exchange and Foreign Trade Control Law in exporting (including the case
where travellers directly carry) this product or providing this product for residents outside Japan.
 No part of this manual, whether in whole or in part, may be adapted, copied or reproduced without prior permission.
 The content of and the specifications of this product are subject to change without prior notice.
 Computex Co., Ltd. shall not be held liable for any loss or damage arising from the use of this product although all possible measures
have been taken by Computex Co., Ltd. in good faith to ensure the quality of the product.
 Contact us for any questions, feedback, comments, requests or anything of concern to you (or in the event of malfunction) regarding this
product or misprinting or missing information within this manual.
 Other names of CPUs etc. mentioned in this manual are trademarks or registered trademarks of their respective manufacturers.
 PALMiCE and COMPUTEX are registered trademarks of Computex Co., Ltd. in Japan.
Copyright (C)2008 COMPUTEX Co., Ltd.

Document change history
First Edition Feb. 18, 2008 Initial edition
Second Edition Mar. 03, 2008 Edited the note on Pin No.8 of signal table as follows:
<Before editing>
“For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C.,
however, if you connect I/O power, it will allow prevention of leak during the target system power
OFF and adaptation to power 1.8V-5V range.”
<After editing>
“For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C.,
however, if you connect I/O power, it will allow prevention of leak during the target system power
OFF and adaptation to power 1.8V-3.6V range.”
Added the following description for Pin No.8 to the note on signal table.
“However, for input, it is 5V-tolerant. If optional conversion adapter (ADP-HUDI-5V) is used, 5V is
supported for output.”
Third Edition Aug. 07, 2008 Deleted the note from the pages on H8S and H8SX family CPU listings.
Fourth Edition Aug. 08, 2008 Applied PALMiCE3 provision to this document following the release of PALMiCE3-H8S.
Added the following CPUs.
・ H8S/2166F, H8S/2167F, H8S/2168F
・ H8S/2211F, H8S/2211UF, H8S/2212UF, H8S/2218UF
・ H8S/2360F, H8S/2361F, H8S/2362F, H8S/2364F
・ H8S/2370F, H8S/2371F, H8S/2372F, H8S/2374F, H8S/2370RF, H8S/2371RF, H8S/2372RF,
H8S/2374RF, H8S/2378BF
・ H8SX/1527RF
・ H8SX/1543F, H8SX/1544F
・ H8SX/1622F
・ H8SX/1632F, H8SX/1634F, H8SX/1638F
・ H8SX/1642F, H8SX/1644F, H8SX/1648F
・ H8SX/1653RF, H8SX/1654RF, H8SX/1658RF
・ H8SX/1663RF, H8SX/1664RF, H8SX/1668RF
Fifth Edition Nov. 06, 2009 Added the supported CPUs also to this manual as they had been added in CSIDE for
PALMiCE3 H8S (Ver.5.07.00).
・ H8S/2462F
・ H8SX/1662F, H8SX/1665F
Sixth Edition Mar. 04, 2011 Added pages for description of the following:
PALMiCE3 - Supported connectors
PALMiCE3 - Target probe specifications
Deleted the specifications of the debugger described in the note on "VCC". Refer to the
Product Summary.

PALMiCE3 - Supported connector
(For detailed dimensions of the connector, refer to the documentation by manufacturer of the connector.)
14pin MIL connector
(Top view on the target board)
Recommended connector
Manufacturer: OMRON Corporation
Model : XG4C-1431
PALMiCE3 - Target probe specifications
To be used by connecting it to PALMiCE3 main unit.
H-UDI cable
Product : P3-CB-MIL14-MIL14
Probe for connecting PALMiCE3 HUDI141 main unit
to 14-pin MILconnector on the target system.
target system Target probe PALMiCE3

H8S
・ H8S/2166F, H8S/2167F, H8S/2168F
・ H8S/2215RF, H8S/2215RUF, H8S/2215TF, H8S/2215TUF
・ H8S/2211F, H8S/2211UF, H8S/2212F, H8S/2212UF, H8S/2218F, H8S/2218UF
・ H8S/2319EF
・ H8S/2329EF
・ H8S/2339EF
・ H8S/2360F, H8S/2361F, H8S/2362F, H8S/2364F, H8S/2367F, H8S/2368F
・ H8S/2370F, H8S/2371F, H8S/2372F, H8S/2374F, H8S/2377F, H8S/2378F,
H8S/2370RF, H8S/2371RF, H8S/2372RF, H8S/2374RF, H8S/2377RF,
H8S/2378RF, H8S/2378BF
・ H8S/2462F

Target interface (H8S/2166F, H8S/2167F, H8S/2168F) Mar. 04, 2011 (Second Edition)
■ H8S/2166F, H8S/2167F, H8S/2168F
Applicable product PALMiCE3-H8S
Applicable connector
(Connector for debugger) MIL connector (14-pin design)
MIL connector
Signals
CPU Pin No. CPU Pin No. Pin
No. Signal Input/ Output*1 TFP-144
Pin
No. Signal Input/ Output*1 TFP-144
1 ETCK Input 90 2 GND
3 ETRST Input 91 4 GND
5 ETDO Output 88 6 GND
7 RESIN *2 Input 8 VCC
*3 Output
9 ETMS Input 87 10 GND
11 ETDI Input 89 12 GND
13 RES Output 8 14 GND
*1: Input/output is based on the target system.
*2: RESIN is not a name of CPU pin. RESIN signal cannot be directly connected to CPU pin. For connection, consult the target connection
reference diagram.
*3: For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C., however, if you connect I/O power, it will allow
prevention of leak during the target system power OFF.
Target connection reference diagram
MIL connector specifications
Recommended connector
Manufacturer Omron Corporation
Model XG4C-1431
(Top view on the target board)
(For detailed dimensions of the connector,
refer to the documentation by manufacturer of the connector.)
*1: When debugging, bring
MD2 pin to Low state and FWE pin to High state.
Shown in the target connection reference diagram is the circuit that brings MD2 pin to Low state when you turn ON the switch.
*2: RESIN, which is connected to Pin No.7 of the connector for debugger, is the signal that the debugger outputs to CPU. Connect the signal to
CPU by using user logic reset circuit with reference to the logic shown in the target connection reference diagram.
*3: RES, which is connected to Pin No. 13 of the connector for debugger, is the signal that debugger uses for monitoring the state of RES pin of
CPU.

Target interface (H8S/2166F, H8S/2167F, H8S/2168F) Mar. 04, 2011 (Second Edition)
Document change history (H8S/2166F, H8S/2167F, H8S/2168F)
First Edition Aug. 08, 2008 Initial edition
Second Edition Mar. 04, 2011 Deleted the specifications of the debugger described in the note on "VCC". Refer to the
Product Summary.

Target interface (H8S/2215RF, H8S/2215RUF, H8S/2215TF, H8S/2215TUF) Mar. 04, 2011 (Forth Edition)
■ H8S/2215RF, H8S/2215RUF, H8S/2215TF, H8S/2215TUF
Applicable products PALMiCE3-H8S / PALMiCE2-H8S
Applicable connector
(Connector for debugger) MIL connector (14-pin design)
MIL connector
Signals
CPU Pin No. CPU Pin No.
Pin
No. Signal Input/ Output*1 TFP-120
/120V
BP-112
/112V
Pin
No. Signal Input/ Output*1 TFP-120
/120V
BP-112
/112V
1 TCK Input 107 D6 2 GND
3 TRST Input 109 B5 4 GND
5 TDO Output 106 B6 6 GND
7 RESIN *2 Input 8 VCC
*3 Output
9 TMS Input 108 A5 10 GND
11 TDI Input 110 C5 12 GND
13 RES Output 72 G11 14 GND
*1: Input/output is based on the target system.
*2: RESIN is not a name of CPU pin. RESIN signal cannot be directly connected to CPU pin. For connection, consult the target connection
reference diagram.
*3: For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C., however, if you connect I/O power, it will allow
prevention of leak during the target system power OFF.
Target connection reference diagram
MIL connector specifications
Recommended connector
Manufacturer Omron Corporation
Model XG4C-1431
(Top view on the target board)
(For detailed dimensions of the connector,
refer to the documentation by manufacturer of the connector.)
*1: When debugging, bring
EMLE pin to Low state and FWE pin to High state
Shown in the target connection reference diagram is the circuit that brings EMLE pin to Low state when you turn ON the switch.
*2: RESIN, which is connected to Pin No.7 of the connector for debugger, is the signal that the debugger outputs to CPU. Connect the signal to
CPU by using user logic reset circuit with reference to the logic shown in the target connection reference diagram.
*3: RES, which is connected to Pin No. 13 of the connector for debugger, is the signal that debugger uses for monitoring the state of RES pin of
CPU.

Target interface (H8S/2215RF, H8S/2215RUF, H8S/2215TF, H8S/2215TUF) Mar. 04, 2011 (Forth Edition)
Document change history (H8S/2215RF, H8S/2215RUF, H8S/2215TF, H8S/2215TUF)
First Edition Feb. 18, 2008 Initial edition
Second Edition Mar. 03, 2008 Edited the note on Pin No.8 of signal table as follows:
<Before editing>
“For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C.,
however, if you connect I/O power, it will allow prevention of leak during the target system power
OFF and adaptation to power 1.8V-5V range.”
<After editing>
“For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C.,
however, if you connect I/O power, it will allow prevention of leak during the target system power
OFF and adaptation to power 1.8V-3.6V range.”
Added the following description for Pin No.8 to the note on signal table.
"However, for input, it is 5V-tolerant. If optional conversion adapter (ADP-HUDI-5V) is used, 5V is
supported for output."
Third Edition Aug. 08, 2008 Added PALMiCE3-H8S to Applicable products following the release of PALMiCE3-H8S.
Forth Edition Mar. 04, 2011 Deleted the specifications of the debugger described in the note on "VCC". Refer to the
Product Summary.

Target interface H8S/2211F, H8S/2211UF, H8S/2212F, H8S/2212UF, H8S/2218F, H8S/2218UF) Mar. 04, 2011 (Forth Edition)
■ H8S/2211F, H8S/2211UF, H8S/2212F, H8S/2212UF,
H8S/2218F, H8S/2218UF
Applicable products *1 PALMiCE3-H8S / PALMiCE2-H8S
Applicable connector
(Connector for debugger) MIL connector (14-pin design)
*1: In PALMiCE2-H8S, H8S/2211F, H8S/2211UF, H8S/2212UF and H8S/2218UF are not supported.
MIL connector
Signals
CPU Pin No. CPU Pin No.
H8S/2211F,
H8S/2211UF,
H8S/2212F,
H8S/2212UF
H8S/2218F,
H8S/2218UF
H8S/2211F,
H8S/2211UF,
H8S/2212F,
H8S/2212UF
H8S/2218F,
H8S/18UF
Pin
No. Signal
Input/
Output
*1
FP-64E
/64EV
TNP-64B
/64BV
TFP-100G
/100GV
BP-112
/112V
Pin
No.
Signal
Input/
Output
*1
FP-64E
/64EV
TNP-64B
/64BV
TFP-100G
/100GV
BP-112
/112V
1 TCK Input 53 53 84 D7 2 GND
3 TRST Input 55 55 86 A7 4 GND
5 TDO Output 52 52 83 A8 6 GND
7 RESIN *2 Input 8 VCC
*3 Output
9 TMS Input 54 54 85 C7 10 GND
11 TDI Input 56 56 87 B7 12 GND
13 RES Output 36 36 58 G8 14 GND
*1: Input/output is based on the target system.
*2: RESIN is not a name of CPU pin. RESIN signal cannot be directly connected to CPU pin. For connection, consult the target connection
reference diagram.
*3: For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C., however, if you connect I/O power, it will allow
prevention of leak during the target system power OFF.
Target connection reference diagram
MIL connector specifications
Recommended connector
Manufacturer Omron Corporation
Model XG4C-1431
(Top view on the target board)
(For detailed dimensions of the connector,
refer to the documentation by manufacturer of the connector.)
*1: When debugging, bring EMLE pin to High state and FWE pin to High state
Shown in the target connection reference diagram is the circuit that brings EMLE pin to High state when you turn OFF the switch.
*2: RESIN, which is connected to Pin No.7 of the connector for debugger, is the signal that the debugger outputs to CPU. Connect the signal to
CPU by using user logic reset circuit with reference to the logic shown in the target connection reference diagram.
*3: RES, which is connected to Pin No. 13 of the connector for debugger, is the signal that debugger uses for monitoring the state of RES pin of
CPU.

Target interface H8S/2211F, H8S/2211UF, H8S/2212F, H8S/2212UF, H8S/2218F, H8S/2218UF) Mar. 04, 2011 (Forth Edition)
Document change history (H8S/2211F, H8S/2211UF, H8S/2212F, H8S/2212UF, H8S/2218F, H8S/2218UF)
First Edition Feb. 18, 2008 Initial edition
Second Edition Mar. 03, 2008 Edited the note on Pin No.8 of signal table as follows:
<Before editing>
“For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C.,
however, if you connect I/O power, it will allow prevention of leak during the target system power
OFF and adaptation to power 1.8V-5V range.”
<After editing>
“For VCC, connect I/O power of CPU. Debugging can be performed even if the signal is N.C.,
however, if you connect I/O power, it will allow prevention of leak during the target system power
OFF and adaptation to power 1.8V-3.6V range.”
Added the following description for Pin No.8 to the note on signal table.
"However, for input, it is 5V-tolerant. If optional conversion adapter (ADP-HUDI-5V) is used, 5V is
supported for output."
Third Edition Aug. 08, 2008 Added PALMiCE3-H8S to Applicable products following the release of PALMiCE3-H8S.
Added the following CPUs.
・H8S/2211F, H8S/2211UF, H8S/2212UF, H8S/2218UF
Forth Edition Mar. 04, 2011 Deleted the specifications of the debugger described in the note on "VCC". Refer to the
Product Summary.
