Chapter 1
1 Product Introduction
1.1 Product overview
The Comset CM685V-W is an industrial grade 3G/4G/4GX LTE WiFi Modem Router based on the
latest OpenWrt platform. With download speeds of up to 150 Mbps and upload speeds of up to 50
Mbps, it is one of the few routers on the Australian market that supports band B28 (700MHz).
The Comset CM685V-W is designed to suit Australian conditions. It supports the latest LTE
Advanced Technology that performs fast and reliable data communication. It enables users to
quickly create a secure and fast wireless network. It features a built-in WiFi N150 with speeds of
up to 150 Mbps, one Ethernet WAN port for fixed internet connection and one Ethernet LAN port,
as well as a GPIO with two digital output ports. Other features include VPN IPSEC, PPTP, L2TP
and Open VPN to establish a secure connection over the 3G/4G network.
The durable and rugged design makes the CM685V-W the router of choice for remote harsh
environments. The compact design, easy integration and advanced built-in features make it
suitable for a wide range of industrial M2M applications, including industrial automation, building
automation, smart metering, security, surveillance, transportation, health, mining and
environmental monitoring.

CM685V-W User Manual
6
www.comset.com.au
1.2 Typical Application Diagram
The Comset CM685V-W 3G/4G/4GX Router is suitable for a wide range of machine-to-machine
applications (M2M). A good example is the connection of ATM machines and POS systems
back to a server over a secure 4G connection using a secure VPN IPSEC tunnel.
1.3 Features
The CM685V-W supports the following:
LTE FDD B1/B2/B3/B5/B7/B8/B20/B28 with 3G fallback to
DC-HSPA+/HSPA+/HSPA/WCDMA B1/B2/B5/B8
IEEE802.11b/g/n N150 Wi-Fi AP function, WDS bridging, WEP, WPA/WPA2
Personal/Enterprise, TKIP/AES, Authenticated encryptionmode
RS232 interface data transparent transmission and protocol conversion
On-demand dialing, including time on/off-line, voice or SMS control on/off-line, data
trigger online or link idleoffline
TCP/IP protocol stack, Telnet, HTTP, SNMP, PPP, PPPoE, network protocol
VPN IPSEC, PPTP, L2TP and Open VPN
Configuration via a user-friendly interface using a web browser

CM685V-W User Manual
7
www.comset.com.au
Chapter 2
2 Hardware Installation
1. Overall Dimensions
2. Accessories
3. Installation
2.1 Overall Dimensions

CM685V-W User Manual
8
www.comset.com.au
2.2 Ports
LAN: LAN RJ45 Ethernet port
WAN: WAN RJ45 Ethernet port
RST: sys reset button
PWR: DC power socket. DC5~40V standard, DC5~50V (optional)
VCC: DC wire positive pole
GND: DC wire ground
GND: Serial ground
RX: Serial receive
TX: Serial transmit
RST: Reset
DIO0: Digital I/O port 0
DIO1: Digital I/O port 1
NC: Not connected
WPS: WPS button

CM685V-W User Manual
9
www.comset.com.au
Antenna Connections Table
Antenna Connector
Marks
Cell
for main cell antenna
Aux
for auxiliary cell antenna
WiFi / WLAN
for WiFi antenna
GPS
for GPS antenna (optional)
2.3 Powering up the CM685V-W
Please ensure the SIM card is inserted, and the antennas are connected before powering up
the router.
2.4 SIM/UIM card
If your router has a SIM/UIM card cover, please remove it and have the SIM card properly
inserted.
2.5 Terminal block
Please refer to the following table on Pin description relating to the terminal block:
.

CM685V-W User Manual
10
www.comset.com.au
Attention:
1. If you are not using the AC adapter supplied with the router, and if you wish to power
up the unit using the terminal block, the power cable should be wired with the correct
voltage polarity. Wrong wiring will destroy the equipment. Pin 1 and Pin 2 are reserved
for power, where Pin 2 is “GND” and PIN 1 is power input “Vin”(DC5~40V).
I/O Terminal on router
Serial port (RS485 or
RS232)
Pin 3 (GND)
Pin 5
Pin 4 (RX)
Pin 2
Pin 5 (TX)
Pin 3
Note: If you do not get a serial connection, try to switch Pin 4 and Pin 5.
2.6 Grounding
To ensure a safe operation, the cabinet where the router is installed should be grounded
properly.
PIN
Signal
Description
Note
1
VCC
+5-40V DC Input,
+5~50V optional
Current: 12V/1A
2
GND
Ground
3
GND
Ground
4
RX
Receive Data
5
TX
Transmit Data
6
RST
Reset
The Reset Pin has the same
function as the reset button.
Simply short the RST pin with
the GND Pin and hold for 3 sec
and the device will restore to
factory settings. If you hold for
1 sec, the router will reboot.
7
DIO0
General Purpose
I/O
8
DIO1
General Purpose
I/O
9
NC
Not connected
10
NC
Not connected

CM685V-W User Manual
11
www.comset.com.au
2.7 Power Supply
The CM685V-W supports a wide range of DC voltage between 5 VDC and 40 VDC. The
router is supplied with a 12 VDC power adapter.
2.8 LED Description
Please refer to the following table for LED description.

CM685V-W User Manual
12
www.comset.com.au
LED
Indication Light
Description
SYS
On for 25 seconds
On for 25 seconds after power up
Blink
System set-up normally
Off or still on after 25
seconds
System set-up failure
LAN
Blink
Ethernet data transmission
Off
No Ethernet connection
On
Ethernet is connected
VPN
On
VPN tunnel set-up
Off
VPN tunnel not set-up or VPN failure
CELL
On
Cell connection is ‘UP’ and now you have access
to the Internet
WIFI
On
WiFi enabled
Off
WiFi disabled
WAN
Blink
Ethernet data transmission
Off
No Ethernet connection
On
Ethernet is connected
Signal
Off
No signal, or signal checking is not ready
Blinks once every 4s
Signal bar is 1
Blinks once every 3s
Signal bar is 2
Blinks once every 2s
Signal bar is 3
Blinks once every 1s
Signal bar is 4
Blinks twice every 1s
Signal bar is 5

CM685V-W User Manual
13
www.comset.com.au
Chapter 3
3 Software configuration
1. Overview
2. How to log into the router
3. How to configure the router
3.1 Overview
The CM685V-W router has a built-in WEB interface. Below are instructions on how to access
the web interface and configure the router.
3.2 How to log into the Router
3.2.1 Network Configuration
The router’s default parameters are:
Default IP: 192.168.1.1
Subnet mask: 255.255.255.0
There are two ways to configure the IP address of your PC.
1) Manual settings
Set the PC IP to 192.168.1.xxx (xxx = 2~254), subnet mask: 255.255.255.0, default
gateway: 192.168.1.1, primary DNS: 192.168.1.1.

CM685V-W User Manual
14
www.comset.com.au
2) DHCP settings
Choose “Obtain an IP address automatically” and “Obtain DNS server address
automatically”. Then click the ‘OK’ button.

CM685V-W User Manual
15
www.comset.com.au
3.2.2 Log into the router
Open a Web browser and type http://192.168.1.1 into the address field, then press
“Enter”.
Type in the username and password. Both User Name and Password are “admin”.
Then click on the “Login” button.
To configure the router, you can skip the following section “Router status” and go straight to
System> Setup wizard which is covered in section 3.4.1

CM685V-W User Manual
16
www.comset.com.au
3.3 Router status
3.3.1 Status overview
Click “Status” in the navigation bar, and then click “Overview”.

CM685V-W User Manual
17
www.comset.com.au
3.3.2 Network status
The Network status page consists of 3 tabs, detailing information about the cell mobile
interface, WAN and LAN.
Cell mobile interface page:

CM685V-W User Manual
18
www.comset.com.au
WAN status page:

CM685V-W User Manual
19
www.comset.com.au
LAN status page:

CM685V-W User Manual
20
www.comset.com.au
3.3.3 Firewall status
The Firewall status page shows the IPv4 and IPv6 rules and counters. Here, you can reset the
counters and restart the firewall functionality.
3.3.4 Routes
The Routes page shows rules which are currently active on the router. An ARP table is
displayed as well.
