Condair RO-U Installation and operating instructions

IMPORTANT! Read and save these instructions. This manual to be left with the equipment.
2594385_A_EN_1811_RO_IOM
INSTALLATION, OPERATION,
AND MAINTENANCE MANUAL
Reverse Osmosis System
RO-U
Humidification and Evaporative Cooling

Thank you for choosing Condair
Installation date (DD/ MM / YYYY):
Commissioning date (DD / MM / YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Ltd. Neither this
document, nor the information contained herein shall be reproduced, used, or disclosed to others
without the written authorization of Condair Ltd., except to the extent required for installation, operation
or maintenance of the customer's equipment.
Liability Notice
Condair Ltd. does not accept any liability due to incorrect installation, maintenance or operation of the
equipment, or due to the use of parts/components/equipment that are not authorized by Condair Ltd..
Copyright Notice
Copyright 2018, Condair Ltd., All rights reserved.
Technical modification rights reserved.

RO-U 2594385_A_EN_1811_RO_IOM Contents |3
CONTENTS
1 Introduction 5
1.1 Before You Start 5
1.2 General 5
1.2.1 Limitations of the Manual 5
1.2.2 Symbols Used in This Manual 5
1.2.3 Storage of Manual 5
1.2.4 Available Manuals and Languages 6
1.3 Receiving and Storage 6
1.3.1 Inspection 6
1.3.2 Storage, Packaging, and Transportation 6
1.4 Safety Precautions 6
1.5 Compliance 7
2 For Your Safety 8
3 Hygiene 11
3.1 Important Notes on Hygiene 11
3.2 Hygiene Risk Management 11
3.2.1 Guidelines to Keep a Clean System and Prevent Micro-organism Growth 11
3.3 Risk Monitoring and Assessment 12
4 Product Description 13
4.1 General Description 13
4.1.1 Buffer tank, Fitting, and Wall Bracket 14
4.2 Model Designation 15
4.3 Functional Description 15
4.4 Options 17
4.5 Accessories 18
5 Product Specifications 19
5.1 Technical Data 19
5.1.1 Capacity 19
5.1.2 Weights 19
5.1.3 Dimensions 19
5.2 Operating Data 19
5.2.1 Water Quality 19
5.2.2 Temperature 19
5.2.3 Power 20
6 Installation and Planning 21
6.1 General 21
6.1.1 Installation Overview 22
6.2 Location Requirements 23
6.3 Clearance Requirements 23
6.4 Site Requirements 24
6.4.1 Water Supply Requirements 24
6.4.2 Drainage Requirements 27
6.4.3 Power Supply Requirements 27
6.5 Installation 28

6.5.1 Safety 28
6.5.2 Mounting the Reverse Osmosis System 28
6.5.3 Connecting the Water Supply 28
6.5.3.1 (Optional) DI System 29
6.5.4 Connecting the Drain Line 31
6.5.5 Installing the Electrical Connections 31
7 Operation 32
7.1 General 32
7.2 Starting Up 33
7.2.1 Start Up Procedure 33
7.3 Shutting Down the Unit 34
8 Maintenance 35
8.1 General 35
8.2 Cleaning and Disinfecting 35
8.3 Maintenance List 36
8.4 Maintenance Procedures 37
8.4.1 Adjusting the Buffer Tank Pressure 37
8.4.2 Replacing the RO-U Filter 37
8.4.3 Testing the Permeate 38
8.4.4 Cleaning-RO-Membrane 38
9 Troubleshooting 39
9.1 General 39
9.2 General Troubleshooting 39
10 Spare Parts List: Reverse Osmosis System 42
11 Commissioning 44
11.1 General 44
11.2 First-time Commissioning 44
12 Decommissioning 45
12.1 General 45
12.2 Removing Unit from Service 45
12.3 Disposing or Recycling the Unit 45
A Appendix: Installation Checklist 47
Contents |42594385_A_EN_1811_RO_IOM RO-U

1 Introduction
RO-U 2594385_A_EN_1811_RO_IOM Introduction |5
1.1 Before You Start
Thank you for purchasing the Reverse Osmosis System.
The Reverse Osmosis System incorporates the latest technical advances and meets recognized safety
standards. Improper use of the Reverse Osmosis System may result in danger to the user or third
parties, and/or damage to property.
To ensure safe, proper, and efficient operation of the Reverse Osmosis System, please observe and
comply with all information and safety instructions contained in this manual, as well as all relevant doc-
umentation of components of the installed humidification system.
If you have additional questions, please contact your Condair representative. They will be glad to assist
you.
1.2 General
1.2.1 Limitations of the Manual
The subject of this manual is the Reverse Osmosis System. It is intended as a supplement to the install-
ation, operation and maintenance manuals.
This manual is restricted to the installation, operation, and maintenance of the Reverse Osmosis Sys-
tem. This manual is intended for well trained personnel who are suitably qualified for their respective
tasks.
1.2.2 Symbols Used in This Manual
CAUTION!
The catchword "CAUTION" in conjunction with the general caution symbol is used to provide safety
instructions that, if neglected, may cause damage and/or malfunction of the unit or damage to prop-
erty.
WARNING!
The catchword "WARNING" in conjunction with the general warning symbol is used to provide safety
instructions that, if neglected, may cause injury to personnel. Other specific warning symbols may also
be used in place of the general symbol.
Danger!
The catchword "DANGER" in conjunction with the general danger symbol is used to provide safety
instructions that, if neglected, may cause severe injury to personnel or even death. Other specific
danger symbols may also be used in place of the general symbol.
1.2.3 Storage of Manual
Keep this manual in a place where it is safe and readily accessible. If the equipment is moved to
another location, please ensure that it remains with the equipment.
If the manual is lost or misplaced, please contact your Condair representative for a replacement.

6|Introduction 2594385_A_EN_1811_RO_IOM RO-U
1.2.4 Available Manuals and Languages
Installation
Manual
Operation and
Maintenance
Manual
Installation,
Operation, and
Maintenance
Manual
Spare Parts
List
Engineering
Manual
Ultrasonic Humid-
ifier US
2588786_A_EN_
1811_US_IM
2588787_A_EN_
1811_US_OM
—2588788_A_EN_
1811_US_SPL
—
Reverse
Osmosis System
RO-U
— — 2594385_A_EN_
1811_RO_IOM
— —
Table 1: Document (Part) Numbers and Languages of Available Manuals
1.3 Receiving and Storage
1.3.1 Inspection
After receiving the shipment, inspect the goods as follows:
lInspect the shipping boxes for damage. Report any shipping box damages to the shipping com-
pany without delay.
lCheck the goods against the packing slip to ensure that all items have been delivered. Report
any shortages to your Condair representative within 48 hours of receipt of the goods. Condair
does not assume responsibilities for any shortages beyond this period.
lUnpack the parts/components and check for any damage. If parts/components are damaged,
notify the shipping company immediately.
lVerify the model type on the specification label to ensure that it is suitable for your installation.
Refer to "Model Designation" on page15.
1.3.2 Storage, Packaging, and Transportation
Storage
Store the Resistive Steam Humidifier in its original packaging inside a protected area that meets the fol-
lowing requirements until it is installed, or if it needs to be stored for an extended period of time:
lRoom temperature: 5 to 40 °C (41 to 104 °F)
lRoom humidity: 10 to 95% RH (non-condensing)
Transportation
For optimum protection always transport the unit and components in their original packaging, and use
appropriate lifting/transporting devices.
Packaging
Keep the original packaging of the unit/components for later use.
If the packaging needs to be disposed, observe local regulations on waste disposal. Please recycle
packaging where possible.
1.4 Safety Precautions
Regard all safety precautions described in this manual.

For more information, refer to "For Your Safety" on page8.
1.5 Compliance
Follow all local guidelines and regulations regarding the installation and operation of the unit; this
includes (and not limited to) mounting, plumbing, water, gas, ventilation, and electrical connections.
Please consult your local Condair representative to learn more.
RO-U 2594385_A_EN_1811_RO_IOM Introduction |7

2 For Your Safety
For Your Safety |82594385_A_EN_1811_RO_IOM RO-U
General
Every person who is tasked with the installation, operation and/or maintenance of the Reverse Osmosis
System must read and understand this manual, as well as any respective installation, operation and/or
maintenance manuals before performing any work. Knowing and understanding the contents of these
manuals is a basic requirement for protecting personnel against any kind of danger, preventing faulty
operation, and operating the unit safely and correctly.
All labels, signs and markings applied to the Reverse Osmosis System must be observed and kept in a
readable state.
Personnel Qualifications
All procedures described in this document must only be performed by personnel who are adequately
qualified, familiar with the unit, well trained, and are authorized by the customer.
For safety and warranty reasons, any activity beyond the scope of this manual must only be performed
by qualified personnel authorized by Condair.
All personnel working with the Reverse Osmosis System unit must be familiar with, and comply with the
appropriate regulations on workplace safety and prevention of accidents.
Intended Use
The is intended exclusively for air humidification using a Condair-approved within specified operating
conditions. Refer to "Technical Data" on page19 for details. Any other type of application, without the
express written consent of Condair, is considered to be NOT conforming to its intended purpose, and
may lead to dangerous operation and will void the warranty.
In order to operate the equipment in the intended manner all information contained in this manual, in
particular the safety instructions, must be observed closely.
Safety Precautions that Must be Observed
DANGER!
Risk of electric shock!
The Reverse Osmosis System is 24 VAC powered. Live parts may be exposed when the access
panels or doors are removed. Touching live parts may cause severe injury or even death.
Prevention: The Reverse Osmosis System must be connected to the humidifier only after all mounting
and installation work has been completed and checked for correct workmanship, and the access pan-
els/doors to the humidifier are closed and fastened securely.
Only qualified personnel should perform maintenance or repairs on the unit.
Follow any lockout procedures when servicing the unit.
DANGER!
Poorly maintained RO-U systems may be hazardous.
Poor maintenance of the Reverse Osmosis System poses a health risk to spaces humidified by
the Ultrasonic Humidifier. When adequately operated or poorly maintained, micro-organisms that
cause disease, such as Legionnaire's, may grow in the water system and in the humidifier which
dispel the micro-organisms into the air.
Prevention: Read, understand, and follow maintenance guidelines to ensure the humidification sys-
tem remains safe. Ensure that the unit is cleaned and disinfected, as directed in this manual, and
avoid shutting off the unit (max. 48 hours). If the unit has been off for 48 hours or more, disinfect and
flush the system thoroughly before humidifying the space with the Ultrasonic Humidifier.

WARNING!
Do NOT leave the unit without power. Risk of contamination.
Do NOT leave the unit unpowered for more than 48 hours, or else a total system disinfect will be
required. Without power, the system will not flush properly, resulting in standing water and con-
ditions that may promote the growth of micro-organisms.
Prevention: Leave your unit powered on. If you do not need humidification during the 48 hours, set
the humidifier to standby or set the demand to 0.
WARNING!
Risk of contamination.
Do NOT use oil, grease, glue, Teflon, silicon, O-ring lubrication, etc. when assembling pipes or
hose connections. All of the above products can act as food for bacteria, posing health risks.
Prevention: For lubricant, use dish soap. Wash hands and wear clean gloves while assembling parts
in direct contact with water. Keep dust covers on pipes and hoses until assembly.
WARNING!
Water from RO-U systems may cause metals to corrode quickly.
Water produced from a Reverse Osmosis System is aggressive and can cause some metals to
quickly corrode. The RO-U system should always be connected to piping and equipment that is
suitable to handle RO water.
Prevention: Read, understand, and follow maintenance guidelines to ensure the humidification sys-
tem remains safe.
CAUTION!
The RO-U System contains pressurized water.
Hoses in the RO-U System contain pressurized water that may spray if the hose connections are
loose or there is a leak.
Prevention: Do not re-tighten or unscrew hoses while the system is pressurized. Test for leaks and
replace broken hoses.
CAUTION!
Do NOT fasten the RO-U System, including the tank, hoses, and pipes to vibrating surfaces.
Preventing Unsafe Operation
All personnel working with the must immediately report to the customer any alterations or changes to
the unit that may affect safety, and secure the unit against accidental power-up.
If it is suspected that the unit cannot be operated safely for any of the reasons listed below, shut it down
immediately.
Alterations and changes that may affect safe operation include:
ldamage to the unit
lloose or damaged electrical connections
limproper operation
lleaks in the distribution system
RO-U 2594385_A_EN_1811_RO_IOM For Your Safety |9

10 |For Your Safety 2594385_A_EN_1811_RO_IOM RO-U
Modifications to the Unit Prohibited
Modifications are NOT permitted on the Reverse Osmosis System without the express written consent
of Condair.
