Confidence RO 300 User manual

822 90 16-XX
822 90 16-33

TACK för att vi fick förtroendet att leverera Din nya vattenrenare, som vi hoppas ska ge Dig många års
bekymmersfri användning. För att undvika problem är det viktigt att Du läser igenom bruksanvis-ningen och noga
följer «Säkerhetsinformationen» och anvisningarna om «Installation». Alla som använder vattenrenaren ska vara väl
förtrogna med användningssättet och säkerhetsdetaljerna.
Spara manualen och låt den följa med vattenrenaren vid flytt eller ägarbyte, så att alla som använder
produkten kan läsa om de olika funktionerna och säkerhetsinstruktionerna.
Bruksanvisningens svenska handledning börjar på sida 93.
THANK YOU for entrusting us to supply your new water purifier. We are confident it will provide you with many years
of trouble-free use.
To avoid problems, it is important for you to read the user instructions. Read the «Safety information»and the
«Installation»instructions especially carefully. Everybody using the water purifier should be familiar with how to operate
it and its safety features
The manual should be kept and stay with the water purifier. If it is ever moved or changes owners, the user
of the appliance should be able to read about the various functions and safety instructions.
The user manual's English instructions begin on page 3.
- 2 -
Your new water purifier
Vielen Dank, daßSie unseren Wasseraufbereiter gewählt haben. Wir hoffen, daßSie viele Jahre Freude an dem
Gerät haben werden. Um Probleme zu vermeiden, ist es wichtig, daßSie dieses Benutzer-Handbuch lesen und die
Hinweise und Anweisungen der «Sicherheits-informationen»und der «Installationsanleitung»genau befolgen. Jeder,
der diesen Wasseraufbereiter benutzt, sollte wissen wie er funktioniert und was in einem Störungsfall zu tun ist.
Dieses Handbuch ist immer bei dem Wasseraufbereiter aufzubewahren. Geben Sie diese Unterlagen auch im
Falle eines Verkaufes an den neuen Besitzer weiter.
Die Deutche Bedienungsanweisungen dieses Handbuchs beginnen auf Seite 21.
NOUS VOUS REMERCIONS d’avoir choisi le purificateur d’eau RO 300, qui remplira son office sans faillir pendant de
nombreuses années. Pour obtenir les performances optimum de votre purificateur d’eau, il est recommandéde lire
attentivement le présent document et de le conserver en lieu sûr àdes fins de consultation ultérieure.
Afin d’éviter tout problème, on ne manquera pas de lire la section intitulée«Sécurité», ni de se conformer
scrupuleusement aux instructions d’«installation». Quiconque utilise le purificateur devra en connaître le
maniement et les dispositifs de sécurité.
Conserver avec soin le présent manuel d’instructions et veiller àce qu’il accompagne le purificateur en cas
de déplacement ou de vente de ce dernier, de façon àce que tout utilisateur puisse àtout moment consulter
le manuel d’instructions complet et les instructions de sécurité.
Le instructions en français du manuel d'utilisation commencent page 39.
GRACIAS por confiar en nosotros como proveedores de su purificador de agua, el cual esperamos utilice durante
muchos años sin problemas.
Es importante para usted la lectura de este manual, con el fin de evitar problemas, y que siga cuidadosamente los
consejos de la «Información sobre Seguridad»asícomo las instrucciones de «Instalación». Todo usuario del
purificador de agua debe familiarizarse con su modo de funcionar y con los consejos sobre seguridad
correspondientes.
Este manual debe ser guardado y acompañar al purificador. Así, incluso en el caso de que cambiara de
propietario, cualquiera que lo utilice, pueda tener acceso a las diferentes funciones del purificador y a las
instrucciones de seguridad.
El manual de instrucciones en Espanol comienza en la pagina 57.
EN
DE
FR
ES
IT
SE
GRAZIE per la fiducia che ci avete accordato acquistando questo nuovo apparecchio per il trattamento delle
acque potabili. Siamo certi che potrete contare sul suo perfetto funzionamento per molti anni.
Per evitare problemi, èimportante che l'utente legga attentamente le seguenti istruzioni, prestando particolare
attenzione ai capitoli "Informazioni sulla sicurezza" e "Installazione". Chiunque utilizza un elettrodomestico
dovrebbe conoscere le modalitàdi funzionamento e le caratteristiche di sicurezza di tale apparecchio.
Conservare il presente manuale assieme al dispositivo. Se l'apparecchio viene spostato o ceduto a un altro
proprietario, l'utente deve sempre avere la possibilitàdi consultare la documentazione relativa alle varie
funzioni e alle istruzioni di sicurezza.
Le istruzioni in italiano del manuale inizano a pagina 75.

Contents
- 3 -
For the user
Safety information 4-5
- Installation 4
- Child safety 4
- Use 4
- Waste management 5
Information 5
- Consumables 5
- Extra accessories 5
- Facts about reverse osmosis 5
Product description 6
Using the water purifier 7
- Production of pure water 7
Maintenance 8-12
- Replacing the filter 8
- Descaling 9
- Disinfection 10
- Storage 11
- Cleaning the grid 12
Regular care of the water purifier 12
If the water purifier is not working 13
- Trouble-shooting table 13
Service 14
- Service and spare parts 14
For the installer
Technical facts 15
Installation 16-19
- Unpacking 16
- Positioning the water purifier 16
- Installing the pure water faucet 16
- Water connection 17
- Electrical connection 17
- Connecting the water purifier 18
- Flushing 19
- Moving the water purifier 19
Guide to use the manual
The following symbols will be found in the text to guide you throughout
the instructions:
Safety information
Environment information
Step by step instructions
Hints and information

Safety information
Installation
●Check that the water you want to purify meets the
requirements specified in «Technical facts».
●The water purifier must be connected to an earthed
electrical supply. As some operations require the
power supply to be temporarily interrupted, it is best
to connect using a plug that is also easily accessible
after installation. Permanent wiring to the electrical
supply may only be carried out by a qualified electrician
and the installation should be performed with a
safety switch. Incorrect installation can result in
personal injury and/or damage to property which
are not covered by any warranty.
●Plumbing work should be performed by a qualified
plumber. If you do the installation yourself, be sure
to follow applicable local plumbing and sanitary codes.
●It is important for the water purifier to be installed
upright on a horizontal surface and that hoses and
cables do not get stretched or jammed when moving
the purifier, e.g. during installation and cleaning.
●If the feed water is classed as unfit, have the purified
water checked after installation. After this, test the
purified water once a year or if there is any change
in the taste or odour, to check that the water purifier
is working well. Do not drink the water if the results
are unsatisfactory. Contact your dealer.
●When the water purifier is new, the purified water
may not be drunk until the flushing procedure has
been completed.
Child safety
●Do not let children play with the water purifier.
●Never leave packaging material lying around so that
children can play with it.
Use
●The water purifier is intended to produce the quantity
of water that is normally required for cooking and
drinking in a household. The purifier may only provide
one water supply point with water. It must not be
connected to existing pipes, tanks, dishwashers or
similar. There is a risk of corrosion in water pipes
and water-heaters. For the same reason, no other
faucet for pure water may be used than the one
included or recommended by your dealer.
●Purified water may only be drunk if the light on the
faucet glows green when the water is produced.
It can take up to 120 seconds before the water
purifier indicates good water quality.
●The water purifier must be connected to water and
electricity in order for the automatic flushing system
to work. It flushes automatically after water has been
purified and when the plug is connected. If purified
water is produced for more than 2 hours, the water
purifier will automatically stop and flush and then
switch to standby mode.
●The top of the water purifier may not be used to
place items on.
●Do not use the purified water in aluminium vessels.
There is a risk of corrosion of the vessel and a higher
concentration of aluminium in the purified water.
●Do not change or modify the water purifier in any
way. This can result in personal injury and/or damage
to property which is not covered by any warranty.
●If the water purifier is to be disconnected from water
and electricity for an extended period (1 week), it
should be stored as described in «Storage». This also
provides protection against freezing down to -30 °C.
●The water purifier may not be used without a filter
(except during cleaning and storage). It could be
seriously damaged.
●If the water purifier contains preserving agents or
detergents, it must be flushed in accordance with
«Flushing»before the purified water may be used.
●Once a month, check that the connections are
watertight. Leaks outside the appliance cannot be
detected by the internal safety system. If leakage
occurs, immediately switch off the water supply and
break the current to the appliance by pulling the plug
out of the wall socket or unscrewing the fuse in the
electrical distribution board.
●If the mains plug has been damaged in some way,
it must be replaced by a qualified person to avoid
damage or injury.
- 4 -
Carefully read the user instructions, which contain directions, advice and warnings, before installing and starting to
use the water purifier. It will then work in a correct manner and provide the greatest benefit. Everybody using the
water purifier should be familiar with how to operate it and its safety features.
The user manual should be kept and stay with the water purifier if it is ever moved or changes owners, the user of
the appliance should be able to read about the various functions and safety instructions.

Water
«Pure water»is pleasant tasting, good water without
harmful, unhealthy or undesirable quantities of organic
and inorganic substances. Water purification means
the separation of these particles and substances.
Traditional purification is characterised by certain
substances being separated from the water. Reverse
osmosis is a superior filtration whereby extremely
small molecules and particles can also be separated.
The technique involves the unpurified water being
separated into two streams, the pure water and a
concentrate containing all the substances separated
from the water.
Osmosis - Reverse osmosis
In nature, for example in our bodies, water is
transported by means of osmosis. The cell walls are
a natural osmotic membrane which separates
impurities from pure water. With the reverse osmosis
water purification technique, water is forced under
high pressure through a semi-permeable, synthetic
membrane. The result is pure water, the osmosis
water. The membrane is only permeable to water.
Other substances with molecules just a little larger
than the water molecule cannot pass through the
membrane, but are separated. One major advantage
of reverse osmosis is that no chemicals are used
during treatment.
Safety information
Information
- 5 -
Waste management
Packaging
80% of the components used in the appliance
and its packaging are identified with symbols to
assist the process of recycling and disposal.
This labelling is in accordance with international standards.
The packaging parts are made from recyclable corrugated
board and can be deposited at collection points for
recycling.
Old apparatus
At the end of the water purifier’s life, disconnect the plug
from the electrical supply and cut the cable at the point
where it enters the appliance. Make sure that children do
not play with the left cable.
Contact your local authority for information about where
the water purifier can be left, or contact your dealer.
●Break the current to a damaged water purifier by
pulling out the plug. Otherwise remove the water
purifier’s fuse from the electrical distribution board.
Consumables
Filter Part no. 919 24 00-84
Descaling agent Part no. 150 72 07-01
Preserving agent Part no. 150 72 06-02
Extra accessories
Sound absorbing carpet Part no. 919 24 09-03
Consumables and extra accessories can be ordered
through your dealer.
(Specify the part number as listed above.)
Basic facts about reverse osmosis

- 6 -
1 Bracket for reject water hose
2 Reject water hose
3 Feed water hose
4 Hose clip
5 Angle bracket for pure water hose
6 Pure water hose
7 Connection to the indicator light on the faucet
8 Pure water faucet
9 Indicator light
10 Button
11 Adapter for feed water hose
12 Filter spanner
Product description
ON
FILTER
SERVICE
6
5
3
7
2
CONTROL PANEL
6
4
1
8
10
3
2
7
9
12
11

- 7 -
Using the water purifier
When the water purifier has been installed and flushed according to the instructions, it is ready to be used.
The water purifier has an electronic control system which makes it easy to use.
Remember the following:
●Change the filter when filter replacement is indicated on the control panel (2 - 3 times/year).
●Clean the purifier when the flow has reduced by 50%.
Production of pure water
To start pure water production:
●Press the button on the faucet once. The water purifier
produces pure water until the button is pressed again.
See fig. A.
●Hold the button pressed. The water purifier produces
pure water until the button is released. See fig. A.
Indication
The indicator lights on the control panel and the faucet
indicate status and water quality.
The lights on the control panel indicate the following, see fig. B:
The indicator light on the faucet indicates the following, see fig. A:
Green light Good water quality.
Yellow light Unsatisfactory water quality.
Flashing yellow light Control panel attracting your
attention.
It can take up to 120 seconds before good water quality
is indicated on the pure water faucet.
The water purifier is most efficient when producing
pure water for longer periods, e.g. filling a whole jug
rather than a drinking glass.
Automatic flushing
●When the combined drawing time has been longer than
60 seconds, an automatic flush is performed.
●If pure water production has lasted for more than 2
hours, the water purifier automatically stops, flushes and
goes into standby mode. The flushing procedure takes
5 minutes and cannot be interrupted.
●When the water purifier is connected to water and electricity,
flushing is automatically performed 6 hours after the most
recent flush.
ON (green) The purifier is connected.
FILTER (flashing yellow) Replace filter.
FILTER (yellow) Emergency stop because
filter replacement has not
been carried out.
SERVICE (flashing yellow) Warning of deterioration in
water quality.
SERVICE (yellow) Emergency stop due to
deterioration in water quality.
A
ON
SERVICE
FILTER
B

- 8 -
123
78910
Replacing the filter
It is important to pay attention to filter replacement, as
the filter’s primary job is to protect the membrane. Check
that the container is not leaking after filter replacement,
and perform follow-up checks.
Replace the filter when:
●the filter light flashes or lights
●the water purifier emits a noise
●when the flow is reduced by half.
1. Check that the water purifier is in standby mode.
Press and hold in the service button, using a
pen, until the service light comes on (approx.
6 seconds). Release the button. The lights on
the faucet now flashes rapidly for 15 seconds.
This procedure will prevent flushing from
taking place during filter replacement.
2. Open the front cover using the grip, as
illustrated.
3. Lift the lock plate on the filter cover and
unscrew the container. Use the supplied
filter spanner if necessary. Remember that
the container is full of water and that it can
overflow!
4. Remove the old filter.
5. Wipe up any spillage on the base plate.
6. Clean the filter container with a brush and
water.
7. Insert the new filter with the pin pointing up.
Fill up the container with water to the lowest
thread.
8. Screw back the filter container. Tighten the
filter container until the locking plate clicks
into the groove. Do not tighten any more.
9. Close the front cover.
10. Reset the filter indicator by pressing in the
filter button and keeping it pressed until the
filter light goes out (approx. 3 seconds).
Use a pen.
The filter replacement is now complete and the water
purifier is ready to be used.
Filter replacement before indication:
If the filter is replaced before the light indicates that repla-
cement is necessary, reset in accordance with point 10.
The only difference is that the filter light first comes on
and then go out.
6
5
Maintenance
4

Descaling
When the flow is reduced, the water purifier should be
descaled to extend its lifetime. When the flow cannot be
restored despite descaling and filter replacement, contact
your dealer. During the descaling procedure, which takes
around 10 hours, the water purifier cannot be used.
The descaling product can be ordered from your dealer,
see «Consumables».
The descaling product must be kept out
of the reach of children! Wash your hands
after using it.
1. Check that the water purifier is in standby
mode.
2. Press the service button, using a pen, until
the service light comes on. Release the button.
The light on the faucet now flashes rapidly for
15 seconds. This will prevent flushing from
taking place during descaling.
3. Unscrew the filter container in accordance
with «Replacing the filter», points 2 - 5.
Remove the filter and put it a side.
4. Mix 50 g (approx. 1/4 of the bag) of the desca-
ling product with 7 dl of lukewarm water.
Stir until the powder has dissolved, see fig. A.
5. Screw the filled container in place.
6. Start the water purifier and produce pure
water for 30 seconds.
7. While production is still in progress, pull
out the plug, see fig. B.
8. Allow the water purifier to stand for approx.
10 hours (e.g. overnight).
9. Undo the container and empty the water.
Replace the filter in accordance with
«Replacing the filter», points 7 - 8, except
that the previously used filter is used here.
10. Close the front cover and connect the plug.
11. Flush the water purifier in accordance with
«Flushing».
Do not use the purified water until
flushing is complete.
The descaling process is now finished. The water
purifier is ready to be used.
- 9 -
Maintenance
A
B

Disinfection
If the feed water has a high content of micro-organisms,
the water might develop an odour if the water purifier is
not used for an extended period of time (1 week). It is
then necessary to disinfect it. After the disinfection the
filter has to be changed.
The disinfectant, sodium hypochlorite (concentration
approx. 3.5%, odourless), can be purchased from
supermarkets or chemists.
The disinfectant must be kept out of reach
of children! Wash your hands after using it.
1. Check that the water purifier is in standby
mode.
2. Press the service button, using a pen, until
the service light comes on. Release the button.
The light on the faucet now flashes rapidly
for 15 seconds. This prevents flushing from
taking place during disinfection.
3. Disconnect the filter container in accordance
with «Replacing the filter», points 2 - 5.
Remove the filter and discard it (should not
be saved).
4. Fill the container with 7 dl of lukewarm water
and pour in 1/4 dl of disinfectant. See fig. C.
5. Screw the filled container in place.
6. Start the water purifier and produce pure
water for 30 seconds.
7. While production is in progress, pull out
the plug as shown in fig. D. Allow the water
purifier to stand for around 30 minutes.
8. Disconnect the container and insert a new
filter into it, in accordance with «Replacing
the filter», points 7 - 8.
9. Connect the plug.
10. Close the front cover.
11. Flush the water purifier in accordance with
«Flushing».
Do not use the purified water until flushing
is complete.
The disinfection process is now finished. The water
purifier is ready to be used.
- 10 -
C
D
Maintenance

- 11 -
Storage
The water purifier should be put into storage if:
●it is going to be disconnected from water and
electricity for an extended period (1 week or more).
●it is not going to be used to produce purified water
for a period of 4 months or longer.
Preserving agents can be ordered from your dealer,
see «Consumables».
The preserving agent must be kept out of
reach of children! Wash your hands after
using it.
1. Check that the water purifier is in standby
mode.
2. Close the shut-off valve on the feed water
connection.
3. Disconnect the feed water hose from the
shut-off valve.
4. Unscrew the filter container in accordance
with «Replacing the filter», points 2 - 5.
Remove the filter and discard it (should not
be saved).
5. Put the filter container back in accordance
with «Replacing the filter», points 8 - 9.
6. Mix 2 litres of preserving agent and 2 litres
of water in a bucket.
7. Insert the feed water hose in the mixture,
making sure that the mouth of the hose is
constantly below the surface level of the
liquid, see fig. E.
8. Start producing pure water. The water
purifier now draws the mixture into it. Stop
the production of pure water once all the
liquid has been fed into the water purifier.
Note! The noise produced by the water
purifier changes during the first few
seconds.
9. Disconnect the feed water and pure water
hose from the water purifier.
10. Pull out the plug.
The water purifier is put into storage and can be kept
in this way without the risk of freezing.
On reinstallation, the water purifier should:
●stand somewhere where the temperature is above
+5°C for at least 48 hours.
●be supplied with a new filter, see «Replacing the
filter».
●be flushed in order to wash out the preserving agent,
in accordance with «Flushing».
Don’t forget to insert a new filter in the
water purifier.
Maintenance
E

Cleaning the grid
The grid blocks larger particles and is situated in the
feed water connection. If the flow is reduced or the
purifier makes a noise, the grid may be blocked.
1. Check that the water purifier is in standby
mode.
2. Close the shut-off valve at the feed water
connection.
3. Unscrew the feed water hose from the water
purifier.
4. Using pliers or similar, grip and pull out the
grid in accordance with fig. G. Remember
which way the grid is installed.
5. Clean and rinse the grid. Reinsert the grid
in the feed water connection using the
pliers.
6. Screw back the feed water hose.
7. Open the shut-off valve at the feed water
and check that there is no leakage.
The grid is now clean and the water purifier is ready
to be used.
- 12 -
G
Maintenance
Regular care of the water purifier
Listed below are things you need to remember in the regular care of your water purifier. The points are listed
according to how often they need to be performed:
●Every day, check that the indicator lights are not
indicating that something has to be attended.
●Keep the appliance clean. Externally, the appliance
may only be cleaned with a damp cloth. Do not use
a wet cloth and do not pour water over the
appliance. Do not use detergents.
●Once a month, check that all the connections are in
place and watertight. Wipe off any condensation
that has collected on the base plate.
●Make sure that you always replace filter in time.
The lifetime of filter depends e.g. on the feed water.
●After replacing a filter, stand the filter so that most of
the water runs out over a few minutes. The filter can
be discarded with normal household rubbish, as it
does not contain any environmentally hazardous
substances.
●Depending primarily on the hardness of the feed
water and its content of micro-organisms, the water
purifier should be descaled when the flow is reduced
and disinfected if the water smells or tastes bad.
●When the capacity of the purifier is reduced even
after filter replacement and descaling, contact your
dealer for membrane replacement.
●If the feed water has been classed as unfit, the water
produced by the water purifier should be tested
once a year by an approved lab.
●If the water purifier is not going to be used in the
next 4 months or is going to be disconnected from
water and electricity, the water purifier should be put
into storage.

- 13 -
ON light not lit.
Yellow light on the faucet flashing
and filter light flashing.
Yellow light on the faucet flashing
and filter light lit.
Yellow light on the faucet flashing
and service light flashing.
Yellow light on the faucet flashing
and service light lit.
Yellow and Green light on the
faucet lit and service light lit.
Noise from the water purifier.
Motor not starting.
Yellow or green light on the faucet lit.
Motor not starting.
Low flow from the faucet.
No flow from the faucet.
Dripping from the faucet during
flushing.
Unpleasant smell.
If the water purifier is not working
Trouble-shooting table
To protect the user and the water purifier from incorrect
use, there are built-in alarms which cause the purifier to
give an indication and stop. The table below gives probable
causes of warnings given by the water purifier.
● The water purifier is not receiving power.
- Is the plug connected?
●Indicates that it is time for filter replacement.
- Change filter in accordance with «Replacing the filter».
●Emergency stop due to filter not having been replaced.
- Change filter in accordance with «Replacing the filter».
●Indication of deterioration in water quality.
- Contact your dealer for membrane replacement.
●Emergency stop due to air in the system caused by filter replacement.
- Pull out the plug and connect it again. Let the purifier go throug the
flush before starting production of pure water.
●Emergency stop due to deterioration in water quality.
- Contact your dealer for membrane replacement.
●The water quality measurement is not working.
- Contact your dealer for replacement.
●The water purifier is not receiving sufficient water.
- Is the inlet pressure lower than 1.5 bar during operation?
- Is the grid blocked? - Clean the grid.
- Is the filter blocked? - Change filter.
●The overflow protection has been triggered.
- Pull out the plug and wipe clean the base plate.
- If it is triggered again, call your dealer.
●The water purifier is flushing.
- Wait for 5 minutes.
- Is the faucet cord connected?
- Is the membrane blocked?
- Descale the water purifier in accordance with «Descaling».
- Make sure the pure water hose is not jammed.
- Is the shut-off valve for the feed water open?
●The hight distance between the faucet and the water purifier is less
than 500 mm.
- See «Installation».
●Odour problems can be caused by micro-organisms in the water because the
water purifier has not been used for an extended period (1 week or longer).
- Clean the water purifier in accordance with «Disinfection».
CHECK/REMEDIAL ACTIONSYMPTOM
If you are still having problems with your water purifier after having read through and tried the procedures described
in the trouble-shooting table, contact your dealer.
extinguished flashing lit

Service and spare parts
Before calling service, use the trouble shooting table
«If the water purifier is not working»to try to attend to the
fault yourself. If service is called in to solve a problem that
is in this list, there is a risk that you will be responsible for
the cost. This is also true if you have used the appliance
for a purpose other than it is intended for.
Note that electrical faults should always be rectified by a
certified electrician.
Give the appliance’s model designation, product and
serial numbers according to the data plate (see fig. A).
The plate is located behind the filter. (Remove the cover
to see the data plate.)
You can record these details here:
TYPE ............................................................
MOD ............................................................
PROD.NO ............................................................
SER.NO ............................................................
Purchase date............................................................
- 14 -
Service
A

- 15 -
Technical facts
Dimensions:
-height 462 mm
-depth 365 mm
-depth with hoses 390 mm
-width 150 mm
-weight (on delivery) 15 kg
-weight (filled with water) 18 kg
capacity
(water temp. 15 °C) 2.5 (±0.4) l/min
electrical connection 230 V, 50 Hz,
10 A, earthed supply
total output 350 W
operating cycle 2 hours
noise level when installing
in undersink cupboard <60 dB(A)
Water efficiency
- during operation approx. 65 %
- including flushing approx. 50%
Operating range
air temperature 2 - 43 °C
relative humidity (RH) 25 - 95 %
Variant -05 -06
water flow >6 l/minute >6 l/minute
water pipe pressure 150 - 1000 kPa 150 - 1000 kPa
(dynamic) (1.5 - 10 bar) (1.5 - 10 bar)
water temperature 2 - 40°C 2 - 40°C
Chemical
conductivity <200 mS/m <120 mS/m
/salt <1500 mg/l <750 mg/l
/chloride Cl-<900 mg/l <400 mg/l
cloudiness slight / distinct* slight / distinct*
turbidity <0.5 FNU* <0.5 FNU*
pH value 6 - 9 6 - 9
calcium: Ca2+
magnesium: Mg2+ <140 mg/l <140 mg/l
/hardness <20 °d <20 °d
iron: Fe2+ <0.5 mg/l* <0.5 mg/l*
iron: Fe3+ <0.3 mg/l* <0.3 mg/l*
manganese: Mn <0.3 mg/l* <0.3 mg/l*
COD Mn: O2<5 mg/l <5 mg/l
* in the event of higher values, extra filter required
Microbiological
heterotrophic bacteria
48 hours 1,000/1 ml 1,000/1 ml
coliform bacteria 1,000/100 ml 1,000/100 ml
e.coli 100/100 ml 100/100 ml
INORGANIC SUBSTANCES %
-turbidity (cloudiness) >99
-colour rating >99
Cations/Metals
-sodium >96
-potassium >97
-calcium (hardness) >99
-aluminium >99
-iron >99
-manganese >99
Cations/Heavy metals
-copper >99
-lead >99
-zinc >99
-mercury >99
-cadmium >99
-chrome >98
-nickel >99
Anions
-fluoride >99
-chloride >98
-nitrate >97
-sulphate >97
ORGANIC SUBSTANCES %
Hydrocarbons
-heptane, octane, decane, etc. >98
-benzene, toluene, xylene,
ethyl benzene, etc. >99
-diesel oil >99
Polyaromatic hydrocarbons
-PAH >99
Chlorinated hydrocarbons
-compounds which can form
when water is chlorinated >99
Trihalomethanes (THM)
-trichloromethane >60
-bromodichloromethane,
dibromochloromethane,
tribromomethane >99
Pesticides
-PCB >99
MICRO-ORGANISMS
-heterotrophic bacteria >99
-coliform bacteria/e.coli >99
Examples of rejection for substances which may be present in water
}
Requirements on feed water to water purifier:

Unpacking
●If the appliance has been damaged during
transportation, you should immediately notify
the company responsible for delivering it.
●Carefully lift out the water purifier by taking
hold of the plastic bag and the rear handgrip.
The appliance can be damaged if it is lifted
in any other way.
●Check the purifier for any signs of damage
and check that no accessories are missing.
Any damage, faults or missing parts should
be notified to the supplier.
●Do not leave the packaging material lying
around so that children can play with it.
Positioning the water purifier
The water purifier must be installed under the sink unit
and the following points should be observed:
●The purifier is installed upright, without support,
on a horizontal surface that can take the load.
●The installation space should be close to
cold water supply, drainage and an earthed
electrical supply.
●It should be easy to inspect the control panel.
●It should be possible to open the front cover
so that the filter container can be accessed.
●The water purifier should be installed with a
2 cm gap to any adjacent fittings or walls to
ensure good ventilation around the appliance.
●Connections can be routed in any direction
from the connection point; make sure no
connections are crushed or damaged.
The dimensions of the area required for the
water purifier are specified in fig. A.
Installing the pure water faucet
The pure water faucet is supplied complete with a pure
water hose. The faucet can be raised and lowered and
can be turned in either direction.
If the hose has to be cut, use a sharp knife e.g. a carpet
knife, so that a flat, smooth and circular cut surface is
achieved, see fig. B. This is essential in order for the
connection to be watertight.
If the distance between the faucet's highest
point and the water purifier's highest point is
less than 500 mm, water can drip from the
faucet during flushing. See fig. A.
1. Mark out the position on the sink unit where
the pure water faucet is to sit. Make sure
there is room on the underside for the hose
and the faucet fittings.
2. Drill a hole with a diameter Ø20 mm.
3. Install the pure water faucet on the sink unit
as shown in fig. C1. Maximum unit thickness
is 40 mm. Adjust the height of the faucet to
the desired position and secure it with the
black nut. Make sure that the cable to the
faucet does not get jammed during
installation. See fig. C2.
- 16 -
A
C1
B
C2
Installation

Installation
- 17 -
Water connection
Feed connection: The water purifier is connected to
cold water (2 - 40 °C) via the feed water hose. The
connection should be supplied with an easily accessible
shut-off valve, see fig. D.
If the connection is with new pipes or pipes that have not
been in use for an extended period, the water should be
allowed to run for a while before the hose is connected in
order to flush out sand and rust.
1. Check that the black washer is in position
in the connection on the feed water hose's
straight end.
2. Screw the feed water hose’s straight end
onto the shut-off valve as shown in fig. D.
If the 3/4”hose connection does not fit, it
can be changed to a 1/2”connection using
the adapter supplied. Put the black washer
in the adapter and screw the adapter onto
the shut-off valve for feedwater. Screw the
feed water hose onto the adapter.
Reject water outlet connection: The flushing water
passes via the reject water hose to the reject water
outlet. The hose may be extended up to 4 m, and the
minimum internal diameter is 13 mm.
The connection is made to the water trap via
the dishwasher drain or simular connections.
If the reject water outlet spigot is already
connected, the intermediate section should
be changed to one with two spigots. The
reject water outlet spigot is placed before
the water trap. Affix the hose as shown in
fig. E securely with the aid of the hose clip
and bracket for the reject water hose.
The reject water hose should be placed
at least 50 mm above the water purifier’s
upper section and existing water trap
using the enclosed bracket.
.
Electrical connection
The water purifier should be connected to an earthed
electrical supply (230 V, 50 Hz and 10 A). We recommend
connection using a plug, as some operations require the
power supply to be temporarily interrupted. The plug
should also be easily accessible after installation.
E
D

Connecting the water purifier
Before the water purifier is placed in its intended position,
remove the plug at the end of the reject water hose and
the two plugs in the connections on the purifier, see fig. F.
Connect the two hoses and the faucet cord to the appliance
as shown in fig. G.
Feed water
1. Screw the bent end of the feed water hose
onto the water purifier. Check that the seal is
in place in the connection. See fig. G no. 1.
2. Open the shut-off valve on the feed water
and check that there is no leakage at the
feed water hose.
Pure water
The pure water is routed via the pure water hose to the
faucet installed on the sink unit.
1. Connect the pure water hose from the pure
water faucet to the water purifier. Push the
hose into the bottom position, up to the mark
(approx. 19 mm). See fig. Gno. 2.
Reject water
The reject water hose has already been connected to
the water purifier on delivery. The other end of the hose
is connected to the waste water pipe.
Indicator light
1. Connect the cable from the faucet indicator
light, as shown in fig. Gno. 3, and place the
water purifier in the intended position.
Electrical connection
1. Connect the plug to the earthed wall socket
as shown in fig. H.
The water purifier starts and flushes for 90 seconds.
Flushing is performed every time the plug is connected.
Do not drink the water until the flushing
procedure under «Flushing»has been
completed.
Installation
- 18 -
H
F
G
1
2
3

- 19 -
Installation
Flushing
Flushing should take place when the water purifier:
●is new and has never been used before
●is reinstalled after having been stored/protected
against freezing
●has been cleaned, in order to rinse out the
detergent
●has been fitted with a new membrane.
Do not use the pure water until flushing
is complete.
First check that:
●the shut-off valve on the feed water is open
●the connection for the feed water is watertight
●the reject water outlet and pure water connections
are watertight
●the filter container is properly tightened.
Check that there is no leakage from the connections
during flushing. In the event of leakage, pull out the plug
and fix the leak. Connect the plug and perform flushing
again as described below.
1. Check that the water purifier is in standby
mode.
2. Press the service button, using a pen, until
both the service and filter lights come on
(approx. 15 seconds). The lights on the
faucet now flashes rapidly.
3. Release the button. The flushing procedure
is now performed and takes 25 minutes.
Water will be purified at the end of the
procedure.
This water must not be used.
When the flushing procedure is complete,
the lights on the faucet goes out.
The water purifier is now ready to be used.
Moving the water purifier
If you move the purifier from one place to another, you
should remember the following points:
●Close the shut-off valve for the feed water before
removing the feed water hose.
●Pull out the plug.
●Always transport the appliance upright.
●Install in accordance with the installation instructions.
If the water purifier will not be used for four months or
more, or if it is to be disconnected from the water and
electricity for several days, it should be put into storage.
See «Storage».

03-11
