Conlin GT6 User manual

GT6
Commercial Motorized Treadmill

- 1 -
Thank you very much to choose our products. Before installation and usage, please read the
instructions carefully.
Contents
I. Warning, main technical parameters and features ………………………………………………………1
II. Product introduction…………………………………………………………………………………………3
III. Product explosion diagram ………………………………………………………………………………4
IV. Particular sheet of explosion diagram……………………………………………………………………5
V. Assembly step ………………………………………………………………………………………………6
VI. Display and function operation of electronic meter ……………………………………………………7
VII. Use method and safety protection for treadmill ………………………………………………………14
VIII. Precautions ………………………………………………………………………………………………15
IX. Daily servicing and maintenance of electric treadmill ………………………………………………16
X. Elimination methods for common faults ………………………………………………………………19
XI. Precautions for exercise …………………………………………………………………………………20
I. Warning, main technical parameters and features
Warning !
1. When you are using the treadmill, please prevent your kids from approaching the treadmill.
Juveniles should not use the treadmill without the adult’s accompany to prevent any accident.
2. Before using the treadmill, please clip the safety switch on the clothes of users. Please take down the
safety switch when you do not use the safety switch.
3. The power supply for treadmill should be well grounded. The tread
mill may be damaged by using outlet without good grounding and the Manufacturer may not provide
warranty for this! After the practice, stop the treadmill and shut off the power supply.
4. Laymen must not open the front cover of treadmill and adjust the electronic control without approval,
to avoid unnecessary troubles.
5. In order to lengthen the service life of treadmill and ensure your safety, it is forbidden for
overweighed (beyond the weight limit) persons to use the treadmill and for two or more persons to
use one treadmill simultaneously.
6. Please do not walk up or down the treadmill from the rear part to avoid getting hurt by the machine.
7. When the treadmill is operating, do not contact the running belt with hands or run on the treadmill
with bare feet.
8. The heart rate monitoring is only for reference and cannot act as medical data; hypertensives and
cardiopaths should not use the treadmill alone to prevent accident.
9. When you are using the treadmill, if you feel chest tightness and dizziness, stop your motion
immediately for excessive motion may cause serious harm or accident.
10. Emergency jump-off method: if emergency happens during the movement process and the
treadmill belt does not stop, hold the handrail with your hands to support your body and separate
your feet from the treadmill belt surface, step on the stepping platform at two sides as well as get
away from the treadmill from one side.
11. A 2000mm×1000mm safety area shall be reserved behind the treadmill to prevent accident during
treadmill operation.
For the health and safety of your family, please read following operating instructions and
precautions before your start practicing on it so that you can get more fun from the
practice. (It is forbidden for unauthorized after-sales service personnel to adjust the
treadmill.)
The weight limit is exposed on this product. If your body weight is over 150Kg (330Ib), the service life of
the treadmill may be affected.
Special
Note

- 2 -
Main technical parameters
Input power voltage: AC220V-240V(50Hz-60Hz)
Rated voltage: 11A
Operating ambient temperature: 0~40℃
Motor power: 3375W
Scope of operating speed: 1~20 (km/h)
Gradient regulating range: 0~18%
Time display range: 0 : 0 0 ~ 1 8 0 ( M : S )
Distance display range: 0.00~99.9 0 ( k m )
Scope of heart rate: 50~200 (b/pm)
Scope of calorie display: 0~999.0(calories)
Floor area: 2 0 0 ×8 6 ×1 5 0 c m
Effective usable floor area: 146×55cm
Features
3375W AC variable frequency motor.
Dual safety protection mode with emergency stop.
Ergonomic PU armrests, comfortable, safe and environmentally friendly.
6.8 inches Multi-window LED display
24 built-in exercise programs with warm up, half marathon and relaxation program, 3 customized
programs.
Body index measurement function, convenient for users to exercis and assess body index.
Acrylic display panel and high sensitivity touch buttons.
Energy-saving function, automatic shutdown after 5 minutes of no-load operation, safe,
energy-saving and environmentally friendly.
High-sensitivity heart rate sensor, real-time monitoring of the heartbeat status during exercise.
High-fidelity surround dual speakers, support Bluetooth music input.
Equipped with fans to enhance air circulation in the running area, increase oxygen supply.
Simple operation interface, convenient control, user-friendly system setting management.
New structure design, hidden mobile equipment support frame.
New non-bearing absorber system.
Smart sports App, supports multi-platform (IOS system and Android system.)
The intelligent IoT treadmill, makes the running process full of fun. Sharing running data,
interacting with the community, participating in online running competitions in real time.

- 3 -
II. Product introduction

- 4 -
III. Product explosion diagram

- 5 -
IV. Particular sheet of explosion diagram
S/N
Part name
Qty.
S/N
Part name
Qty.
1
Lower Console
1
34
Welding part of left upright pole
1
2
M6X25 hexagon socket head cap bolt
4
35
M10 small flat gasket
25
3
M6 flat shim
4
36
Bulkhead of upright pole
6
4
Screen
1
37
M10X30 round head hexagon socket screw
4
5
Safety switch
1
38
M8X20 hexagon socket pan head screw
6
6
Front roller
1
39
Decorative element at lower left of the meter
1
7
M8X45 hexagon socket head cap bolt
1
40
M4X10 round head tail-cut tapping screw
4
8
Motor cover
1
41
M4X8 flat head screw
18
9
Upper edge strip
2
42
Decorative element at lower right of the meter
1
10
Running belt (tire tread)
1
43
AC motor
1
11
Rear roller
1
44
M10X60 hexagon screw
1
12
M8X75 hexagon socket head cap bolt
2
45
M10X30 hexagon screw
1
13
φ8×1.6 flat washer
9
46
M10X40 hexagon socket head cap screw
4
14
High-density running plate
1
47
M10X45hexagon socket pan head screw
1
15
Edge strip at right side
1
48
Lifting motor
1
16
Right regulating box
1
49
M10X95 hexagon socket pan head screw
1
17
Left regulating box
1
50
Plastic shim
2
18
Universal foot pad
2
51
Spring shim
4
19
Edge strip at left side
1
52
Left side strip trim
1
20
M10X70 hexagon socket pan head
screw
2
53
Decorative element of right upright pole
1
21
M10 self-locking nut
6
54
Rubber belt of motor
1
22
Welding part of erector
1
55
M8X45 crossed countersunk head screw
2
23
Castor
2
56
Support column of running plate
1
24
M10X60 hexagon socket pan head
2
57
Shock pad
6
25
Cover plate
1
58
M8X25 crossed countersunk head screw
6
26
Motor’s bottom cover
1
59
Edge strip positioning buckle
6
27
Decorative element of left upright pole
1
60
Motor shock absorption pad
4
28
Frequency converter
1
61
M4X12 flat head screw
4
29
Adapter
1
62
Welding part of running plate
1
30
Front protective cover
1
63
Tabletting of edge strip
4
31
One-piece switch
1
64
Right side strip trim
1
32
Welding part of right upright pole
1
89
Step on the anti-skid strip with your left foot
1
33
M10X20 round head hexagon socket
screw
4
90
Step on the anti slip strip with your right foot
1

- 6 -
V. Assembly step
All parts of electric treadmill have been strictly assembled and debugged before the ex works. An
electric treadmill can be easily assembled into if the installation is carried out by observing following
steps.
Step I: Install upright pole: Open the packing box
(box B) and then bring out the treadmill. Firstly,
lock the left upright pole on the treadmill frame in
2 M10X20 and 2 M10X30 round head hexagon
socket screw (containing shim); secondly,
connect the right upright pole (control line is
provided in the upright pole) with the control line
reserved on the control line; then, insert the
connector of the control line into the wire-through
hole of the right upright pole; finally, lock the right
upright pole on the treadmill frame in 2 M10X20
and 2 M10X30 round head hexagon socket screw
(containing shim), as shown in the figure below:
Step II: Install meter head: Open the packing box
(box A) and then bring out the meter head. Firstly,
connect the control line in the right upright pole
with that at the lower right of the meter head;
secondly, insert the meter head into the left and
right upright poles; finally, lock the meter head on
the left and right upright poles in 6 M8X20
hexagon socket pan head screw (containing
shim), as shown in the figure below:
Step III: Install screen: Open the packing box and
then take out the screen. Firstly, connect the wire
of the screen with that of the meter head in
one-to-one way; secondly, insert the screen into
the meter head; finally, lock the screen on the
meter head in 4 M6X25 hexagon socket head cap
bolts (containing shim), as shown in the figure
below:
Step IV: Install the decorative elements of upright
pole and lower meter: Firstly, fix the decorative
elements of left and right upright poles at the
treadmill in 6 M8X8 large crossed flat head
screw; secondly, fix the decorative elements at
lower left and right of the meter on the left and
right upright poles below the meter head in 2
M4X8 large crossed flat head screw and 4
M4X10 round head tail-cut tapping screw, as
shown in the figure below:
M4X10 round
head tail-cut
tapping screw
M4X8 flat
head screw

- 7 -
Step V: Install bulkhead and power line: Firstly, plug the installing holes below the left and right upright
poles and the meter head with 6 bulkhead; finally, connect the power line with one-piece power switch
of the treadmill (note: guarantee the power line is off before connecting the power line, so as to avoid
personal injury), as shown in the figure below:
Step VI: Carefully check if each part of the treadmill is tightened. Run the treadmill at the slow speed
and check if the each part of the running belt is flexibly rotated and whether the tightness of the running
belt is proper. As for the running belt, no offset and sliding will prevail (see“Daily maintenance of
powered treadmill”). Move the treadmill to the proper position and then use it after the check is
completed.
VI. Display and function operation of electronic meter
1. Introduction on operating interface of electronic meter

- 8 -
2. Display functions:
2.1 “Incline”window:Display the current slope value.
2.2 “Speed”window: Display the current speed.
2.3 “Calorie”window: Display Calories (Count up and count down)
2.4 “Time”window: Display time (Count up and count down), display “FAT”during
the program selection.
2.5 “Distance”window：Display distance (Count up and count down)
2.6 “Pulse”window: Display the heart rate, display the program number during the
program selection.
When the user holds the heart rate sensor with both hands, the system can automatically detect
the user’s heart rate and display the reading in this window. The heart rate reading range :50 - 200
beats/min. (The data is for reference only and cannot be regarded as medical data.)
During the program selection, “P01 - P24. U01-U24”are displayed
2.7 The large dot matrix window displays the runway diagram, program diagram, countdown start
information prompt etc.
3. Key Functions:
3.1 START/PAUSE button：When the power is turned on and the safety lock is in reset position, press
this button to start the treadmill. During the running, press this button to pause the exercise.
3.2 STOP button：During the exercise, this button can be used to stop the running of the treadmill
and reset to zero. Press this key during the setting of the treadmill to exit the setting.
3.3 PROGRAM button：In the standby state, press this key to select the built-in programs.
3.4 MODE button：In the standby state, press this key to select different modes. “30:00”for the
time countdown mode, “1.00”for the distance countdown mode, and “50.0”for the Calorie
countdown mode. When selecting the modes, user can use the speed and slope adjusting
buttons to set the relevant countdown value. After the setting is completed, press the “Start”
button to start the treadmill.
3.5 Speed+ & Speed- buttons ：In the standby state, it is used to adjust the set value. During the

- 9 -
running, it is used to adjust the speed, the adjusting interval is 0.1 for each press. It will continue
to increase or decrease if the user press and hold the button for more than 0.5 seconds.
3.6 Incline︽& Incline︾buttons：In the standby state, it is used to adjust the set value. During the
running, it is used to adjust the slope of the running deck. The adjusting interval is 1 for each
press. It will continue to increase or decrease if the user press and hold the button more than 0.5
seconds.
3.7 Speed：6、9、12、15：Speed shortcut buttons, can quickly set the speed.
3.8 Incline：6%、9%、12%、15%：Incline shortcut buttons, can quickly set the slope.
3.9 Custom button：In the standby state, press this key to selecgt through the custom programs
U01 - U03.
3.10 Warm up button: In the standby mode, press this button to start a 3 minute warm-up
exercise(the time window flashes), the treadmill runs at a speed of 1.0 km/h, counts down for 3
minutes, then gradually accelerates to 6 km/h, and then stop. If the user adjust the speed during
the warm up program, the treadmill will run at the speed set by the user until the end of the 3
minutes countdown.
3.11 Lose weight button：In the standby state, press this button to start the body shaping program.
3.12 Burn fat button：In the standby state, press this button to directly select the fat burning program.
3.13 Mountain button：In the standby state, press this button to directly select the mountain run
program.
3.14 Half marathon button：In the standby state, press this button to start the half marathon, the
distance is 21.1 km.
3.15 Relax button: Press this button during the running, if the current speed is ≥8km/h, the
treadmill will automatically decelerate to 8km, and then slow down from 8km to a stop in 3
minute; if the current speed is <8 km/h and ≥2.5 km/h, , the treadmill will slowly decelerated to
stop in 2 minutes; if the current speed is less than 2.5 km/h, the treadmill will slowly
decelerated to stop in 18 seconds. In the state of relaxation program, the time window flashes
and it can only be decelerated but not accelerated. In this state, pause button is invalid.
3.16 Fan button：When the fan is off, press this button to turn on the fan, press it again to turn
off the fan.
3.17 In the standby state, press and hold both "speed+" and "speed-" buttons for 3 seconds to view
the total milage of the treadmill, the unit is KM. Press “stop” button to exit.
4. Main functions:
4.1 Quick start (manual mode):
4.1.1 Turn on the power switch and correctly attach the safety lock to the safety lock position of the
treadmill.
4.1.2 Press the "start/pause" key, the system will enter a 3-second countdown, and the buzzer will
sound a warning tone. at the same time, the speed window will show that the treadmill will start
running at a speed of 1km/h after the countdown of 3, 2, 1, and 3 seconds is completed.
4.1.3 After starting, the speed of the treadmill can be adjusted according to needs by using the
"speed+""speed-"; Use the "Slope" and "Slope" keys to adjust the slope of the treadmill.
4.2 Operation during exercise:
4.2.1 Press “Speed –” key to reduce operating speed of the treadmill.
4.2.2 Press “Speed +” key to increase operating speed of the treadmill.
4.2.3 Press “Incline ︾” key to reduce incline of the treadmill.

- 10 -
4.2.4 Press “Incline︽” key to increase incline of the treadmill.
4.2.5 Press “Stop” key so that the treadmill will slow down and stop operation.
4.2.6 Heartbeat data will be displayed for about 3 seconds (heartbeat data is only used for
general reference of exercise, and cannot be used as medical data) when the sporter holds
the heartbeat handle with both hands.
4.3 Manual mode:
4.3.1 Press the "Start" key directly in the standby state, and the treadmill will start running at a
speed of 1.0km/h and a slope of 0. Other windows count forward from 0, and press the
"Slope︽," "Slope ︾" or "Speed+""Speed-"keys to change the slope and speed.
4.3.2 Press “Target setting” to enter into time count-down mode in standby state, “Time” window
display “30:00” and flashes. Press “Incline︽” key, “Incline︾” key, “Speed +” key, “Speed –”
key to set exercise time, setting range is:5:00—180:00.
4.3.3 In time count-down mode, press “Target setting” to enter into distance count-down mode,
“Distance/Calorie” window displays “1.00” and flashes. Press “Incline︽” key, “Incline︾” key,
“Speed +” key, “Speed –” key to set exercise distance, and setting range of the distance is:
0.50–180:00。
4.3.4 In distance count-down mode, press “Target setting” to enter into calorie count-down mode,
“Distance/Calorie” window displays “50.0” and flashes. Press “Incline︽” key, “Incline︾” key,
“Speed +” key, “Speed –” key to set calorie, and setting range of the calorie is: 10.0–999.0.
4.3.5 Select one of the three reverse counting modes and press the start button after the setting is
completed. The treadmill will start running after reverse counting for 3 seconds. Press the
"Slope ︽," "Slope ︾" or "Speed+""Speed-"keys to adjust the speed and slope; Press the
stop key to stop the treadmill.
4.4 Built-in Program:
Press the “Program” button to select the built-in programs among P01- P24
The “ Pulse” window displays: P01---P24；
The dot matrix display displays the program diagram corresponding to P01 - P24
“ Time” window displays the default exercise time and flashes. The exercise time can be
adjusted by press the Incline︽& Incline︾buttons, or the speed+ and speed- buttons. (The built-in
program is divided into 16 sections, and the running time of each section is the set time divided by 16.)
Press the "Start" key, the system will start running according to the speed and slope value of the
first segment of the built-in program after entering the countdown of "3, 2 and 1". After the last segment
is finished, the next segment will automatically run. The slope and speed will be automatically adjusted
to the value of this segment at the same time. During the running process, the slope can be adjusted
by pressing the "Slope ︾" "Slope ﹀" key, and the speed can be adjusted by pressing the
"Speed+""Speed-"key. However, it will automatically adjust to the program default value when entering
the next paragraph. After all segments are completed, the program ends, and the treadmill slowly
slows down to a stop. The user can press the "stop" key or disconnect the "safety switch" at any time to
stop the running of the treadmill during exercise.
Date sheet of built-in program
Time section
Program
Operating time of each section = setting time/16

- 11 -
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P01
Lose weight
SPEED
3
6
7
8
9
10
9
8
8
9
10
9
8
7
6
3
INCLINE
0
2
2
4
4
4
2
2
2
3
3
4
4
3
2
1
P02
Burn fat
SPEED
5
7
9
9
11
8
8
10
10
8
10
8
6
5
4
3
INCLINE
3
5
4
4
3
5
5
3
3
5
3
5
5
3
3
3
P03
Mountain
SPEED
3
4
6
5
3
5
6
4
5
6
7
6
8
6
5
3
INCLINE
6
8
10
12
14
12
10
14
12
10
8
10
6
4
3
2
P04
Road
SPEED
3
6
7
7
8
9
9
10
10
10
9
9
8
6
4
3
INCLINE
1
1
2
2
3
3
3
2
2
2
3
3
2
2
1
1
P05
Race
SPEED
3
5
6
8
12
8
6
5
6
8
12
8
6
8
6
3
INCLINE
3
6
5
3
1
3
5
6
5
3
1
3
5
3
5
2
P06
Slow walk
SPEED
3
4
5
5
6
5
5
4
5
5
6
5
5
4
5
3
INCLINE
2
2
3
2
3
2
3
2
3
3
2
2
3
3
2
2
P07
Quick walk
SPEED
3
5
6
7
7
6
6
7
7
6
6
7
7
6
5
3
INCLINE
3
4
5
5
4
4
3
3
4
4
5
5
4
4
2
2
P08
Random
SPEED
5
10
6
11
7
11
8
11
9
6
10
7
11
9
6
3
INCLINE
3
4
5
6
5
4
5
6
5
4
5
6
5
4
3
2
P09
Jog
SPEED
5
7
8
9
9
9
8
8
9
9
9
8
9
8
6
5
INCLINE
2
2
3
3
4
4
3
3
4
4
3
3
4
4
3
2
P10
Sprint
SPEED
2
6
7
8
9
10
10
11
11
11
10
9
8
6
4
2
INCLINE
4
5
6
7
8
9
10
10
10
10
10
9
5
7
5
2
P11
Gradual
SPEED
3
4
5
6
7
7
5
6
7
7
5
7
6
5
4
3
INCLINE
2
2
3
2
3
2
3
2
3
3
2
3
2
3
2
2
P12
Learner
SPEED
3
5
6
5
5
6
5
5
6
5
5
5
5
4
3
3
INCLINE
2
3
2
3
3
2
3
4
3
3
3
3
3
2
2
1
P13
Basic
SPEED
6
6
6
5
5
5
5
4
4
3
3
3
2
4
4
4
INCLINE
1
2
3
4
5
6
7
8
9
10
11
12
4
2
2
0
P14
Strides
SPEED
2
2
8
2
2
8
8
10
4
4
12
4
4
12
4
2
INCLINE
0
2
2
2
6
6
2
2
4
4
2
2
4
2
2
0
P15
Park
SPEED
2
4
4
4
4
4
6
6
6
6
6
4
4
4
4
2
INCLINE
0
2
2
2
2
2
2
2
2
2
2
2
2
2
2
0
P16
Accelerate
SPEED
4
6
6
6
12
12
12
12
6
6
4
4
4
6
6
2
INCLINE
0
2
2
4
4
6
8
8
6
6
6
4
4
2
2
0
P17
Endurance
SPEED
2
4
6
12
12
12
4
4
4
4
12
12
12
6
4
2
INCLINE
0
2
4
6
6
6
6
6
6
4
4
2
2
2
4
0
P18
Recovery
SPEED
4
4
6
6
6
6
8
8
6
6
8
8
6
8
6
4

- 12 -
INCLINE
0
2
4
4
4
4
4
2
2
2
2
2
2
2
2
0
P19
Repeat
SPEED
2
2
2
3
3
3
4
4
4
3
3
3
2
2
2
2
INCLINE
0
1
1
1
1
2
2
2
2
1
1
1
1
1
1
0
P20
Interval
SPEED
2
2
6
6
6
8
8
10
10
12
8
6
6
6
4
4
INCLINE
0
2
2
4
2
2
2
4
2
2
2
4
2
2
2
0
P21
Mixed
SPEED
2
4
8
10
2
4
8
10
2
4
10
2
4
10
4
2
INCLINE
0
2
2
4
4
6
6
8
8
10
8
6
4
2
2
0
P22
Cardio
SPEED
4
6
6
8
8
8
6
8
6
8
6
10
6
10
8
4
INCLINE
0
2
2
2
4
4
4
4
4
4
6
6
6
4
4
0
P23
Long
Distance
SPEED
6
7
7
10
9
9
12
12
10
10
12
12
8
10
8
6
INCLINE
2
2
3
3
4
4
6
6
8
8
10
10
6
5
5
0
P24
Tempo
SPEED
4
6
8
10
8
6
4
6
8
12
8
6
8
12
12
6
INCLINE
0
2
2
4
4
6
6
8
8
6
6
4
4
2
2
0
4.5 User defined program:
Except 12 system built-in programs, treadmill is equipped another three user defined programs
that allows self to set according to personnel situation: U01, U02 and U03.
4.5.1 Custom program settings：
In the standby state, press the “Program” button until the Pulse window displays
“U01～U03”，Time window displays the default exercise time and flashes. Press Incline
︽& Incline︾buttons, or the speed+ and speed- buttons to adjust the exercise time.，then
press the “Mode” buttons to confirm the time，Time window displays “S～01…S～
16” ，speed、incline windows displays the relevant data of the corresponding segment，then the
user can set each time period (a total of 16 time periods). When setting, use the "speed+" and
"speed-" buttons to set the speed, use the "slope︾" and "slope︽" buttons to set the slope, and
press the "Mode" "Button to complete the setting of this time period and enter the next time
period, after all 16 time periods is completed, the setting process is finished; The data will be
stored permanently until you reset it next time, this data will not be erased even the power is cut
off.
4.5.2 Start of user defined program:
Press the "Custom Program" key in standby state until the user-defined program (U01-U03)
you want to run is reached, and press the start key after the running time is set.
Pressing the start button can also start immediately after the user-defined program and
runtime settings are completed.
4.5.3 Setting description of user defined program:
Each program divides operating time into 16 time section. During setting, complete settings
of speed, lifting time and operating time of 16 time sections so that start key can be pressed to
start the treadmill.
4.6 Body fat measurement:
Press the "program switching" key continuously to enter the body mass index (FAT)
detection function in the standby state , and press the "target setting" key to enter the F-1, F-2,

- 13 -
F-3, F-4, F-5 interfaces (f-1-gender, f-2-age, f-3-height, f-4-weight, F-5- body mass detection),
Press the "Slope ︽" , "Slope ︾" , "Speed+," Speed-"keys to set the parameters of 01-04 (the
parameters are shown in the following table). After setting, press the" Target Setting "key to
enter the F-5 physical examination interface. At this time, your body mass index will be displayed
after holding the heart rate handle in both hands for 5-6 seconds to see if your weight and height
are commensurate. Body mass index (FAT) is a measure of the relationship between a person's
height and weight, not the proportion of the body. FAT is suitable for any male or female and
provides the basis for people to adjust their weight together with other health indicators. The
ideal FAT should be between 20 and 24. If it is lower than 19, it means too thin. If it is between 25
and 29, it is overweight. If it is over 30, it is considered obese. (This data is for reference only
and cannot be used as medical data.)
F-1
Gender
01Male
02Female
F-2
Age
10------99
F-3
Body height
100----200
F-4
Body weight
20-----150
F-5
Body fat index
≤19
Too thin
Body fat index
=(20---24)
Ideal
Body fat index
=(25---29)
Overweight
Body fat index
≥30
Fat
4.7 Display range of each value:
Setting parameter
Initial
Setting initial value
Setting range
Display range
Time (m:s)
0:00
30:00:00
5:00-180
0:00－180
Slope (section)
0
0
0-18
0-18
Speed (km/h)
1.0
1.0
1.0-20
1.0-20.0KMH
Distance (km)
0.00
1.00
0.50-99.90
0.00－99.90
Heart rate (time/m)
P
N/A
N/A
50-200
Calorie (kcl)
0.0
50.0
10.0-999.0
0.0－999.0
5.Safety lock function：
Pulling off the safety lock can stop the running of the treadmill in any state . The treadmill is
stopped in an emergency. The window displays "- - -",and the buzzer gives an alarm of "BB" 3 times.
At this time, the treadmill cannot perform any other operation except shutdown. After the safety lock
is correctly installed again, the treadmill enters the standby state again, waiting for the input
command.
6. Interconnection function：
The treadmill provides a connection function with the "Fitshow" App, which can control the
treadmill wirelessly. At the same time, the "Fitshow" App records and stores the user’s exercise data,
which is convenient for the exercisers to check and share.
Instructions:
6.1 For smart phones, you can directly search for "Fitshow" in the App store to
download and install, or scan the QR code on the machine to download
and install. Fitshow installation requirements: iPhone require 4S or higher,
and Android smart phones require 5.0 or higher.

- 14 -
Note: For anything in the “Fitshow” that involves becoming a member, the need to pay and other
commercial activities have nothing to do with the treadmill manufacturer.
6.2 Open the "Sports" page in the “Fitshow” App, click "Quick start, objectives, procedures", the "Nearby
Devices" dialog box pops up, click "renovate" to find the Bluetooth (Bluetooth: FS-XXXXXX) of the
treadmill, and click "Select" to pair , After the pairing is successful, click "Start" and the treadmill will
start slowly after 3...2...1... countdown.
If the Fitshow APP is connected to the Bluetooth, and the Bluetooth is automatically disconnected
during the operation, please restart the phone (or turn off and on the phone) once, and then run the
APP.
7.Bluetooth audio：
The treadmill can be connected to mobile phones, tablets or other devices to play music.
How to use: Turn on the Bluetooth switch of the external device, search and pair the Bluetooth of the
treadmill (Bluetooth name of the treadmill: Conlin), after the pairing is successful, the treadmill will emit
a beep. When playing audio from an external device, the volume of the audio is controlled by the
external device.
Note: After user 1 is successfully connected and paired, user 2 cannot connect to paired Bluetooth
when user 1 does not disconnect.
When the external device is far away from the treadmill, it will automatically disconnect, and when the
external device returns to the range of the treadmill, the treadmill will automatically connect.
8.Energy saving function
No-load shutdown：The treadmill system will detect the user at all times. When the user leaves the
running belt for more than 5 minutes, the system recognizes that there is no user exercise state, the
system will stop the treadmill and enters the standby state to ensure the safety of the user. (This
feature is off by default)
Turn on and off of no-load shutdown function: press the emergency button (interface prompt: safety
lock disconnected)，press“ Speed- ”、“ Slope︾”at the same time for 3 seconds，The treadmill emits
2 short beep to turn on, and 1 long beep to turn off.
Dormant：In the standby state, when there is no operation for more than 10 minutes, the system
closes all windows and enters the dormant state. Press any key to wake up to the standby interface.
9. Shut down
At any time, you can turn off the treadmill by turning off the power switch, it will not damage the
treadmill.
10. Precautions:
10.1 Check whether the power supply is loaded before the movement; Check whether the safety
lock is valid.
10.2 Whether there are abnormal conditions or not during sporting; the treadmill may quickly slow
down until to stop by pulling off the safety lock; put the safety lock in the place again and reset the
equipment waiting for entering order.
10.3 If you have any questions about the treadmill, please contact the distributor. It is not allowed
for laymen to disassemble or maintain the treadmill for fear of damaging the treadmill.
VII. Use method and safety protection for treadmill

- 15 -
1. Debugging of treadmill
1.1 After the installation is completed, position the safety lock to the corresponding position of
electronic meter.
1.2 Before the powering, inspect whether the power ground wire is well grounded and pull the
running belt with hands to check whether it can run flexibly without any abnormal sound.
1.3 Plug in the power supply and open the power supply lock. Then, all windows on the
electronic meter show the initial values and the running belt is still.
1.4 Press the “Start” Key and the treadmill starts operating at a low speed (the operating speed
is 1km/h). Observe whether the treadmill and electronic meter can operate normally.
1.5 Press the “Speed-up” Key and “Speed-down” Key to observe whether the regulation is
normal.
1.6 Press the “Stop” Key or pull in the safety lock, and the treadmill may stop operating. Turn off
the power switch and unplug the power supply.
2. Operating instructions
After being debugged, the electric treadmill can be put into use
2.1 Plug the power supply in the household 220V outlet. The outlet must be provided with
appropriate grounding wire.
2.2 Emplace the safety lock and press “Start” Key, and then the running belt may operate slowly
(the speed is about 1km/h). The speed per hour is displayed on the meter.
2.3 If the treadmill needs to be accelerated, press the “Speed-up” Key and the buzzer’s “tick”
indicates one level up. The maximum speed per hour is 18km/h.
2.4 If you cannot wait for the deceleration while running on the treadmill at a high speed, you can
pull out the safety lock and the treadmill may immediately stop.
2.5 Press “STOP” after running and the treadmill slows down until it stops.
3. Safety protection for treadmill
3.1. In any emergency, as long as the exerciser takes off the safety lock, the treadmill may be
power off. Therefore, when you are exercising, please be sure to clip the safety lock on the
appropriate position the on your clothes to ensure the safety.
3.2. When the treadmill belt skids or the running belt is stuck, the motor may stop in about 3s.
VIII. Precautions
1. Circuit
1.1 Avoid using other electric appliances in the same power supply circuit. The power supply
circuit must be able to supply over 11A electricity current.
1.2 It is required that the service voltage should be in the range of 220V±10%. The voltage
beyond this range may lead to the abnormal operation.
1.3 Check whether the power is on or not before sporting; check whether the safety lock is
efficient or not.
1.4 Whether there are abnormal conditions or not during sporting; the treadmill may quickly slow
down until to stop by pulling off the safety lock; put the safety lock in the place again and reset
the equipment waiting for entering order.
1.5 After being used, the treadmill should be immediately unplugged.
1.6 In Winter, certain humidity should be kept indoors to avoid strong static electricity.
1.7 If the power wire is damaged after use, please go to specified products distributor for
replacement or purchase.

- 16 -
1.8 If you have any questions about the treadmill, please contact the distributor. It is not allowed
for laymen to disassemble or maintain the treadmill for fear of damaging the treadmill.
2. Placing environment
2.1 It is only proper for the treadmill to be placed indoors for protection against humidity. It is
forbidden to splash water on the treadmill. It is forbidden to place any foreign materials on or
inserted them in the treadmill.
2.2 During the operation of the treadmill, the motor may generate a small number of sparks, so
the treadmill should be placed at a drafty place and kept away from explosives.
2.3 When the treadmill is used, ensure its fore and rear feet reliably contact the ground. If the
ground surface is uneven, it should be stably padded with carpet or rubber plate.
2.4 Pay attention to the interior hygiene usually to reduce indoor dust because its sensibility may
be influenced by the dust adhered on the electronic components.
3. Precautions before or during exercise
3.1 For your safety, wear sports clothes and select suitable sports shoes when using the
treadmill. It is strictly forbidden to exercise on the treadmill with bare feet.
3.2 It is not allowed for two or more persons to do exercises on the treadmill at the same time.
3.3 Prepare a towel before running to prevent sweat from dropping on the running belt and being
thrown into the enclosure to damage the electric appliance.
3.4 The beginner can get on the treadmill only after he stands on the edge to test several times
with one foot and feels capable of keeping up with the speed of the running belt.
3.5 The treadmill has enough motor power. In principle, the zero start can be realized, but to
extend the service life of the treadmill, it is suggested that you should stand on both edges of the
treadmill and get on it for exercise after the normal start.
3.6 It is strictly forbidden to get on and off from the rear end as it is very easy for people to
tumble in such way.
3.7 The strength should be equal when the hands are on the armrests and run on it straightly to
avoid belt deflection.
3.8 When people run in a normal state, the two hands should be moved from the armrests. The
arms can be swung boldly so that the exercise result may be better.
3.9 You should press the “Stop” button and leave the treadmill until it stops completely.
3.10 Keep the child away from the running treadmill for fear that the hand or the clothes may
clamped by the running belt to cause serious injury.
3.11 It is strictly forbidden to touch the working running belt by hands.
4. Additional precautions
4.1 The cardiac should not use the electric treadmill alone.
4.2 Determine the running speed according to your physical conditions; and the sick should not
use the treadmill or use it under the instruction of a doctor.
4.3 The heart rate sensor is not a medical facility and the detection results are for reference only.
IX. Daily servicing and maintenance of electric treadmill
During the daily use of the treadmill, the following should be noted for the maintenance.
1. Keep the treadmill clean
1.1 The service life of the treadmill can be significantly extended by keeping clean. Often wipe
the running board and footboard exposed on the two sides of the running belt. Reduce long-term

- 17 -
accumulation of the dust and dirt under the running belt.
1.2 The running belt can be wiped with soft cloth dipped with soapsuds. Don’t let the water flow
to the bottom of the running belt and into the shield.
1.3 Regularly check each bolt and nut. Please tighten and fix them immediately with tools if they
are loose.
1.4 Regularly check whether the groove of the motor belt is clean. If there are residual, they
must be cleaned off to avoid unnecessary vibration when it is used.
1.5 Regularly clean the electric control system and the dust surrounding the motor to ensure
normal operation of the treadmill.
2. Lubrication
2.1 A bottle of special lubricating oil for running board is attached. Running board surface should
be evenly lubricated with special lubrication regularly to avoid the damage of running belt and
running board caused by the temperature rise due to the friction between them, and to reduce
the load of the motor. (Note: the child should not play with it in fear of eating by mistake)
2.2 After the treadmill has been used for accumulatively 50km, the running belt and running
board should be lubricated with the special lubricant. The lubrication should not be excessive. It
is recommended that a 30ml bottle of special lubricating oil for the treadmill should be used for
ten times.
2.3 Lubricating method: Loosen the right and left adjustment bolts at the rear end of the treadmill
with special tools, lift the running belt about 10-15cm, pour a good amount of special lubricating
oil on the top surface of the running board, and smear it evenly and tighten the running belt. (For
adjustment method, see the “Adjusting method for the tightness of running belt”) The over
lubrication should be avoided. As for the lubrication, it is by no means “the more the better”.
Please remember: reasonable lubrication is an important factor to extend the service life of the
treadmill!
3. Judgment for friction:
The frictional force of the running board and running belt can be increased by uncleanness
or reduction of lubricant, which may damage the motor and control panel. The excessive
frictional force is characterized with followings:
3.1 Under the power off condition, it is arduous to drive the belt by feet, or even the belt cannot
be driven;
3.2 The treadmill runs at an intermediate speed. The running belt completely stops as soon as
the safety switch is turned off;
3.3 The increment of frictional force may cause the damage of motor or control panel, short
circuit, tripping, fuse burn-out, etc.
4. Adjustment for the tightness of running belt:
4.1 Although all treadmills have been adjusted at exworks, the running belt may become loose
after the treadmill is used for some time. The maintenance is mainly carried out by the user. If
the running belt is too loose, the skidding phenomenon of running belt and drum may occur
when you step on the running belt. But excessive tightness is not good either because it may
damage motor, running belt and drum, increase the running noise of the treadmill, etc. In general
condition, it is better to lift the two sides of running belt 5-6cm away from the running board.
4.2 Judgment method for tightness of running belt
Adjust the treadmill speed to 1.5 km/h, grasp the armrest forcefully with both hands and prevent

- 18 -
the operating of running belt with feet. At this time, if the running belt stops running, the front
drum continues running, but the running belt continues running after being released, indicating
that the running belt is excessively loose. Meanwhile, the user may feel the halt at sometimes,
and the long-term use under the loose state may shorten the service life of running belt.
Therefore, adjustment should be done timely.
4.3 Adjusting method for the tightness of running belt: After the treadmill is used for some time,
the halt may be felt while you are running on it, which is caused by the excessive loose running
belt. The tightening adjustable bolt of the right and left rear regulating box is used to adjust the
tightness and deflection. It is the core component of the adjustment of the complete treadmill.
Adjusting method: (note: the clockwise means tightening and the anticlockwise means loosening.
All the tightening and loosening as shown below stand for clockwise and anticlockwise
respectively.) After the treadmill is used for some time, the running belt may get extended slightly.
If you feel the skidding running bet, it shows the running belt is too loose. Thus, tighten the
adjustable bolts of rear cover at both sides at the same time by 1/4 circle until no skidding or halt
is felt while you are running on the treadmill.
Special attention: As for the running belt, it is not the tighter the better. The tightness should be
adjusted as required. The service life of the running belt may be shortened if it is too tight.
5. Adjustment for deflection of running belt:
As for all treadmills, although the running belt has been adjusted at exworks, the running belt
may suffer the deflection after the treadmill is used for some time. This is attributed to following
reasons:
5.1 The treadmill body is placed unevenly.
5.2 While exercising on the treadmill, the user fails to run on the central position of the running
belt.
5.3 The strength of user’s feet is uneven.
5.4 Adjustment for deflection: It only takes a few minutes to recover artificial deflection by
no-load operation. As for the non-recoverable deflection, the running belt adjusting bolts should
be adjusted with the auxiliary special tools by half a circle. For example, if the deflection is
leftward, clockwise adjust the left adjusting bolts or anticlockwise adjust the right adjusting bolts,
and if the deflection is rightward, clockwise adjust the right adjusting bolts or anticlockwise adjust
the left adjusting bolts. The deflections of running belt are mainly maintained and repaired by the
user. As the deflection may seriously damage the running belt, the deflection should be timely
corrected if any.
6. Adjustment for motor belt:
6.1 As for all treadmills, although the motor belt has been adjusted at exworks, the running belt
may suffer the halt after the treadmill is used for some time, because the motor belt gets loose.
6.2 Judgment method for tightness of running belt: adjust the treadmill speed to 1.5 km/h, grasp
the armrest forcefully with both hands and prevent the operating of running belt with feet. If the
running belt stops running, the front drum continues running, but the running belt continues
running after being released, indicating that the running belt is excessively loose. Meanwhile, the
user may feel the halt at sometimes, and the long-term use under the loose state may shorten
the service life of running belt. Therefore, adjustment should be done timely.
6.3 Solution: Use special tools to clockwise adjust the motor belt adjusting bolts for several
circles until the user cannot feel the halt. This adjustment is mainly carried out by the user.

- 19 -
Adjusting method for motor belt: Clockwise adjust the motor belt adjusting bolts by half a circle
with auxiliary tools.
X. Elimination methods for common faults
Fault or phenomenon
Possible reasons
Handling method
No display on the treadmill
A. Power supply isn’t connected or
there is no power supply
Plug power line into AC line or check AC
socket
B. Power switch isn’t on
Place power switch in ON position
C. Mainboard has no power supply
or is damaged
Check whether power line of electronic
meter is connected or replace mainboard
D. Signal line of electronic meter is
disconnected
Replace or reconnect signal line
E. Electronic meter is damaged
Replace electronic meter
The treadmill display is
incomplete and some strokes
of letters are missing.
A.display faulty welding or
continuous welding of the driving IC.
It needs to be repaired. Check the welding
spot and reweld it in place.
B.display poor driving of IC.
It needs to be repaired and weld a new
display driving IC.
Treadmill exercise is not
smooth, weak or jittered
A. Driving position has resistance
Adjust the driving position or add lubricating
oil
B. Driving belt is too tight or too
loose
Adjust tightness of driving belt
C. Torque of actuator is too small
or too large
Adjust the torque potentiometer to the
appropriate position
Display of the Electronic meter
Safe lock falls off
A. Safe lock falls off
Place safe lock on the panel to attract or
plug-in card position
B. Magnetron isn't attracted
Assemble magnetron to right position
E01- communication
failure (no frequency
converter signal
received)
E08- frequency
converter fails to
receive signal of display
board
A. Signal line of electronic meter
isn’t connected well or is in poor
connection
Reconnect plug wire
B. Signal line of electronic meter is
damaged with short-circuit or open
circuit condition
Replace signal line
C. Signal Line fault of electronic
meter
Replace electronic meter
