Sunny Health & Fitness SF-T7874 User manual

1
PERFORMANCE TREADMILL WITH
AUTO INCLINE
SF-T7874
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: [email protected] or 1 - 877 - 90SUNNY (877-907-8669).

2
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this equipment
correctly. It is important to read this entire manual before assembling and using the equipment. Safe
and effective use can only be achieved if the equipment is assembled, maintained and used properly.
It is your responsibility to ensure that all users of the equipment are informed of all warnings and
precautions.
1. Before starting any exercise program, you should consult your physician to determine if you have
any medical or physical conditions that could put your health and safety at risk, or prevent you from
using the equipment properly. Your physician’s advice is essential if you are taking medication that
affects your heart rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest, irregular
heartbeat, shortness of breath, lightheadedness, dizziness or feelings of nausea. If you do
experience any of these conditions, you should consult your physician before continuing with your
exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet. To
ensure safety, the equipment should have at least 8 feet (2.4 M) of free space behind it and 2 feet
(60 CM) on each side. Do not place the treadmill on any surface that blocks air openings. To
protect the floor or carpet from damage, place a mat under the treadmill.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of the
equipment can only be maintained if it is regularly examined for damage and/or wear and tear.
6. Always use the equipment as indicated. If you find any defective components while assembling or
checking the equipment, or if you hear any unusual noises coming from the equipment during
exercise, discontinue use of the equipment immediately and do not use until the problem has been
rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may become
entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 285 pounds (130 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/or damage to the product or property, proper lifting and moving is
required.
12.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme cold,
hot or damp areas as this may lead to corrosion and other related problems.
13.This equipment is designed for indoor and home use only, it is not intended for commercial use!
IMPORTANT NOTE:
The belt must be lubricated before the first use! Please see Page 9 for instructions on how to
properly apply lubricant.

3
EXPLODED DIAGRAM

4
PARTS LIST
No.
Description
Specification
Qty.
No.
Description
Specification
Qty.
1
Main Frame
1
44
Bolt
M8*50
2
2
Left Upright Tube
1
45
Nut
M8
6
3
Right Upright Tube
1
46
Transport Wheel
2
4
Base Frame
1
47
Transport Wheel Plug
2
5
Running Belt
1
48
Flat Pad
4
6
Running Board
1
49
Screw
M6*15
4
7
Bolt
M6*30
2
50
Square Plug
2
8
Bolt
M6*25
4
51
Bolt
M10*50
4
9
Screw
ST4*16
41
52
Square Plug
6
10
Edging Washer
8
53
Incline Frame
1
11
Motor Belt
1
54
Incline Motor
1
12
Screw
M5*8
8
55
Bolt
M8*15
12
13
Screw
ST4*16
8
56L/R
Protective Cover
1 pr.
14L/R
End Cap
1 pr.
57
Foam Grip
2
15
Bolt
M6*55
2
58
Shortcut Key
2
16
Rear Roller
1
59
Safety Key Sensor
1
17
Adjusting Wheel
2
60
Console Bracket
1
18
Washer
Φ8*1.2
18
61
Safety Key Sheet
1
19
Bolt
M8*40
5
62
Safety Key
1
20
Side Rail
2
63
Hand Pulse Upper Cover
2
21
EVA Cushion
2
64
Flat Washer
D4
2
22
Nut
M6
6
65
Light Sensor
1
23
Cushion
4
66
Bolt
M8*90
1
24
Front Roller
1
67
Flat Washer
D6
4
25
Bolt
M6*45
1
68
Screw
M4*8
2
26
Control Board
1
69
Console Rear Cover
1
27
Power Cord Buckle
1
70
Console Upper Cover
1
28
Overload Protector
1
71
Console Button Board
1
29
Switch
1
72
Screw
ST3*9.5
20
30
Power Cord
1
73
Screw
ST2.9*6
2
31
Bolt
M10*40
1
74
Console Linking Wire
1
32
Washer
Φ10*1.2
6
75
Extension Wire
1
33
Nut
M10
6
76
Controller Wire
1
34
Bolt
M10*55
1
77
Bottle Holder
2
35
Bolt
M8*15
4
78L/R
Upright Tube Cover
1 pr.
36
Spring Washer
D8
6
79
Console Panel
1
37
Flat Washer
D8
6
80
Amplifier Board
1
38
Bolt
M8*30
2
81
Washer
Φ6
3
39
Bolt
M8*55
1
82
Light Sensor Bracket
1
40
Motor
1
83
Screw
M4*8
2
41
Motor Cover
1
84
Spring Washer
D4
2
42
Bolt
M8*25
1
85
Plastic Plug
2
43
Cylinder
1
86
Bolt
M4*8
2
PARTS LIST

5
HARDWARE PACKAGE
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the part(s) needed:
The model number (found on cover of manual)
The product name (found on cover of manual)
The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST” (found near the front
of the manual)
Please contact us at [email protected] or 1 - 877 - 90SUNNY (877-907-8669).
87
Bolt
M5*16
4
92
MP3 Connecting Wire
1
88
Plastic Pad
2
93
Loudspeaker
2
89
Filter
1
94
Loudspeaker Platen
2
90
Allen Wrench
S=5
1
95
Audio Jack
1
91
Pulse Bottom Cover
2
96
Spanner
S=13,14,15
1
螺栓包
#18 Φ8*1.2 12PCS
# 96 S=13,14,15 1PC
# 55 M8*15 12PCS
# 90 S=5 1PC
# 9ST4*16 2PCS

6
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 1:
We recommend having two people to do
the assembly.
Open the carton and remove contents.
Place the Main Frame (No. 1) on level
ground, and ensure that you have a work
area that is clean and has adequate
space. Do not cut the Packing Belt (No.
B) until the assembly is complete!
STEP 2:
Lift up the Left Upright Tube (No. 2) and
hold the tube by hand to prevent it from
falling down.
Fix the Left Upright Tube (No. 2) to the
Base Frame (No. 4) with 3 Bolts (No. 55)
and 3 Washers (No. 18) using Allen
Wrench (No. 90). Do not fully tighten the
bolts at this time.
Repeat to assemble the Right Upright
Tube (No. 3). Do not fully tighten the bolts
at this time.
Note: Make sure you do not cut or pinch
the wire inside the Right Upright Tube
(No. 3).

7
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 3:
Insert the 2 Screws (No. 9) marked in
circles to the Console Bracket (No. 60)
and tighten with Spanner (No. 96). See
Fig. A.
Thread the Extension Wire (No. 75)
through Right Upright Tube Cover (No.
78R). Put the Upright Tube Covers (No.
78L/R) on the Left & Right Upright
Tubes (No. 2 & 3). Connect the Console
Linking Wire (No. 74) and the Extension
Wire (No. 75).
Attach the Console Bracket (No. 60) to
the Left & Right Upright Tubes (No. 2 &
3) with 6 Bolts (No. 55) and 6 Washers
(No. 18) using Allen Wrench (No. 90).
Then tighten all Bolts (No. 55) and
Washers (No. 18) of Left & Right
Upright Tubes (No. 2 & 3) tightly. Make
sure to tighten the 6 Bolts (No. 55) and 6
Washers (No. 18) at the bottom of the
Left & Right Upright Tubes (No. 2 & 3)
that were assembled in Step 2.
Note: Make sure you do not cut or pinch
the wire inside the Right Upright Tube
(No. 3).
Remove 4 Screws (No. 9) from Console
Bracket (No. 60). Fix the Upright Tube
Covers (No. 78L/R) to the Console
Bracket (No. 60) with 4 Screws (No. 9)
that were removed. Tighten and secure
with Spanner (No. 96).
Remove 2 Screws (No. 9) from Left &
Right Upright Tubes (No. 2 & 3) and 4
Screws (No. 9) from Base Frame (No.
4).Cover the Protective Covers (No.
56L/R) to the Base Frame (No. 4) and
Left & Right Upright Tubes (No. 2 & 3)
with 6 Screws (No. 9) that were removed.
Tighten and secure with Spanner (No.
96).
Now you can cut the Packing Belt (No.
B).
Fig. A

8
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 4:
Put the Safety Key (No. 62) on the E slot
of Console Button Board (No. 71).
The assembly is complete!
IMPORTANT NOTE!
You will need to lubricate
your treadmill before the first
use. See Page 9.

9
MAINTENANCE & CARE
General cleaning will help prolong the life and performance of your treadmill. Keep the unit clean and
maintained by dusting the components on a regular basis. Clean both sides of the Running Belt (No.
5) to prevent dust from accumulating underneath the Running Belt (No. 5). Keep your running shoes
clean so that dirt from your shoes does not wear out the Running Board (No. 6) and Running Belt
(No. 5). Clean the surface of the Running Belt (No. 5) with a clean damp cloth.
To better maintain the treadmill and prolong its life it is suggested that the machine be powered off for
10 minutes every 2 hours and fully powered off whenever not in use.
A loose Running Belt (No. 5) will result in the runner sliding off when running, while too tight of a
Running Belt (No. 5) will negatively affect the motor’s performance and also create more friction
between the roller and Running Belt (No. 5). The most suitable tightness for the Running Belt (No. 5)
is pulled out 50-75mm from the Running Board (No. 6).
CENTERING THE RUNNING BELT:
Place the treadmill on level ground and set it at 3-5mph to check if the Running Belt (No. 5) drifts.
1. If the Running Belt (No. 5) moves
to the right, turn the adjusting bolt on
the right side ¼turn clockwise, then
turn the left adjustment bolt ¼ turn
counter-clockwise. If the Running
Belt (No. 5) does not move, keep
adjusting ¼ turn at a time until it
centers. Refer to Fig. A.
2. If the Running Belt (No. 5) moves
to the left, turn the adjusting bolts on
the left side ¼of a turn clockwise,
then turn the right adjustment bolt ¼
turn counter-clockwise. If the
Running Belt (No. 5) does not move,
keep adjusting ¼ turn at a time until it
centers. Refer to Fig. B.
3. Over time the Running Belt (No. 5)
will loosen. To tighten the Running
Belt (No. 5) turn the Left & Right side
adjustment bolts one full turn
clockwise, check the tension of the
Running Belt (No. 5). Continue this
process until Running Belt (No. 5) is
at the correct tension. Make sure to
adjust both sides equally to ensure
correct Running Belt (No. 5)
alignment. Refer to Fig. C.
Fig. A
Fig. B
Fig. C

10
LUBRICATING THE TREADMILL
*IMPORTANT NOTE:
You will need to lubricate your treadmill before the first use.
Lubricating the Running Board (No. 6) and Running Belt (No. 5) is essential as the friction between
the two affects the life span and function of the treadmill. Inspect the Running Board (No. 6) and
Running Belt (No. 5) regularly. Should you find any wear on the Running Board (No. 6), please
contact us at: [email protected].
WARNING: Always unplug the treadmill from the electrical outlet before cleaning, lubricating or
repairing the unit.
HOW TO LUBRICATE:
1. Raise the Running Belt (No. 5) up on one side and apply lubricant to the Running Board (No. 6).
Use a rag to thoroughly wipe the lubricant over the Running Board (No. 6). Repeat this process for the
other side.
2. The moving parts should turn freely and quietly. Abnormality of moving parts will affect the safety of
the equipment. Inspect and tighten bolts regularly.
3. To better maintain the treadmill and prolong its lifespan, it is suggested that maintenance be done on
a regular basis.
4. A loose Running Belt (No. 5) will result in the runner sliding off during use, while too tight of a
Running Belt (No. 5) will negatively affect the motor’s performance and also create more friction
between the roller and Running Belt (No. 5). The most suitable tightness for the Running Belt (No. 5)
is pulled out 50-75mm from the Running Board (No. 6).
The following time table is recommended:
Light user (less than 3 hours/ week) every five months
Medium user (4-7 hours/ week) every two months
Heavy user (more than 7 hours/ week) every one months
