Connect Tech COM Express CCG022 User manual
1
COM Express®Type 10 Mini Carrier
CCG022
Connect Tech Inc. Tel: 519-836-1291
42 Arrow Road Toll: 800-426-8979 (North America only)
Guelph, Ontario Fax: 519-836-4878
N1K 1S6 Email: sales@connecttech.com
www.connecttech.com support@connecttech.com
CTIM-00489 Revision 0.01 2019-07-04
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 2 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Table of Contents
Table of Contents...................................................................................................................................1
Preface...................................................................................................................................................4
Disclaimer .......................................................................................................................................................4
Customer Support Overview...........................................................................................................................4
Contact Information ........................................................................................................................................4
Limited Product Warranty...............................................................................................................................5
Copyright Notice.............................................................................................................................................5
Trademark Acknowledgment..........................................................................................................................5
ESD Warning ..................................................................................................................................................6
Revision History ....................................................................................................................................6
Introduction...........................................................................................................................................7
Product Features and Specifications................................................................................................................7
Part Numbers / Ordering Information .............................................................................................................8
Product Overview..................................................................................................................................9
CCG022 Block Diagram .................................................................................................................................9
Connector Summary & Locations.................................................................................................................10
CCG022 Top View.............................................................................................................................10
CCG022 Bottom View .......................................................................................................................10
Jumper Summary...........................................................................................................................................11
Detailed Feature Pinouts and Functional Descriptions .........................................................................12
COM Express Module...................................................................................................................................12
Display Outputs.............................................................................................................................................13
LVDS Video Connector .....................................................................................................................13
LVDS Backlight Power Connector ....................................................................................................14
HDMI Video Connector .....................................................................................................................15
USB...............................................................................................................................................................16
USB 2.0 Port Connectors....................................................................................................................16
USB 3.0/2.0 Port Connectors..............................................................................................................16
10/100/1000 Ethernet (GBE) Connector .......................................................................................................17
Software Support for the Intel 82574 .................................................................................................17
Serial .............................................................................................................................................................18
RS-232/485 Connector .......................................................................................................................18
RS-232/485 Jumper Configuration.....................................................................................................19
J1 –RS-232/485 Jumper Block .........................................................................................................................................19
Serial Line Modes.............................................................................................................................................................. 19
Examples ...........................................................................................................................................................................19
Audio.............................................................................................................................................................20
Software Support for the CS4207.......................................................................................................20
microSD Card Connector ..............................................................................................................................21
mini PCIe & mSATA Slots...........................................................................................................................22
Dual Function mini PCIe mSATA Slots.............................................................................................22
Half and Full Length mini PCIe / mSATA module Installation.........................................................23
Standoff and Screw Assembly Details................................................................................................23
CCG022 –External Hard Drive Installation.......................................................................................24
mini pcie / mSATA Connector Pinout................................................................................................25
System Miscellaneous...................................................................................................................................26
System Connector...............................................................................................................................26
J2 –System Jumper Block..................................................................................................................26
Input Power & Control..................................................................................................................................27
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 3 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
RTC Battery ..................................................................................................................................................27
Typical Hardware Installation Procedure ............................................................................................28
On-board Indicator LED ...............................................................................................................................28
Power Consumption and Thermals......................................................................................................29
Current Consumption....................................................................................................................................29
Thermal Properties........................................................................................................................................30
Mechanical Drawings & Models ..........................................................................................................31
Cable Kits............................................................................................................................................32
CCG022 Cable Kit - CKG044 –“Full” Cable Kit ........................................................................................32
Appendix A –COM Express Signal/Pinout Connection Details............................................................33
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 4 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Preface
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is
subject to change without notice.
Connect Tech assumes no liability for any damages incurred directly or indirectly from any technical or
typographical errors or omissions contained herein or for discrepancies between the product and the user’s
guide.
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the Connect Tech
reseller from which you purchased the product. In most cases the reseller can help you with product installation
and difficulties. In the event that the reseller is unable to resolve your problem, our highly qualified support
staff can assist you. Our support section is available 24 hours a day, 7 days a week on our website at:
http://connecttech.com/support/.See the contact information section below for more information on how to
contact us directly. Our technical support is always free.
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Email/Internet
www.connecttech.com
Note:
Please go to the Resource Center or the Support Center on the Connect Tech website for product
manuals, installation guides, device driver software and technical tips.
Submit your technical support questions to our customer support engineers via the Support Center on the
Connect Tech website.
Telephone/Facsimile
Technical Support representatives are ready to answer your call Monday through Friday, from 8:30 a.m. to
5:00 p.m. Eastern Standard Time. Our numbers for calls are:
Toll Free: 800-426-8979 (North America only)
Telephone: 519-836-1291 (Live assistance available 8:30 a.m. to 5:00 p.m. EST,
Monday to Friday)
Facsimile: 519-836-4878 (on-line 24 hours)
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 5 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Limited Product Warranty
Connect Tech Inc. provides a two-year Warranty for the COM Express®Type 10 PC Connector Carrier Board.
Should this product, in Connect Tech Inc.'s opinion, fail to be in good working order during the warranty
period, Connect Tech Inc. will, at its option, repair or replace this product at no charge, provided that the
product has not been subjected to abuse, misuse, accident, disaster or non-Connect Tech Inc. authorized
modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business
partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc. must be
pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number marked on the
outside of the package and sent prepaid, insured and packaged for safe shipment. Connect Tech Inc. will
return this product by prepaid ground shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product. This is defined
as the period during which all components are available. Should the product prove to be irreparable, Connect
Tech Inc. reserves the right to substitute an equivalent product if available or to retract the Warranty if no
replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no circumstances will
Connect Tech Inc. be liable in any way for any damages, including any lost profits, lost savings or other
incidental or consequential damages arising out of the use of, or inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech Inc. shall not
be liable for errors contained herein or for incidental consequential damages in connection with the furnishing,
performance, or use of this material. This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Connect Tech, Inc.
Copyright
©
2017 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred to in this
document as the property of their respective owners.
Not listing all possible trademarks or copyright acknowledgments does not constitute a lack of
acknowledgment to the rightful owners of the trademarks and copyrights mentioned in this document.
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 6 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any circuit
board assemblies including Connect Tech COM Express
carrier assemblies, it is recommended that ESD safety
precautions be observed. ESD safe best practices include,
but are not limited to:
•Leaving circuit boards in their antistatic packaging
until they are ready to be installed.
•Using a grounded wrist strap when handling circuit
boards, at a minimum you should touch a grounded
metal object to dissipate any static charge that may be
present on you.
•Only handling circuit boards in ESD safe areas, which
may include ESD floor and table mats, wrist strap
stations and ESD safe lab coats.
•Avoiding handling circuit boards in carpeted areas.
•Try to handle the board by the edges, avoiding contact
with components.
Revision History
Revision
Date
Changes
0.00
2017-08-01
Original Release
0.01
2019-07-04
Revised P7 Descriptions
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 7 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Introduction
Connect Tech’s COM Express® Type 10 PC Connector Carrier is an extremely small carrier board featuring a
combination of PC style connectors and locking pin header connectors. The carrier has a robust offering, with 2x
USB 3.0 Type A ports, 2x USB 2.0 Type A ports, 1x HDMI, 1x LVDS interface, and 2x GbE.
The COM Express Type 10 PC Connector Carrier Board provides support for the latest generation of low-powered
CPUs. It is ideal for space constrained applications and supports extended temperature ranges of -40°C to +85°C.
Product Features and Specifications
Specifications
Compatibility
COM Express®Type 10 Mini Modules
PICMG COM Express® COM.0 R2.1
Mini PCIe Expansion
2 x half size cards OR 1 x full length card
Both sockets have PCIe and USB signaling, one socket also can be
configured as mSATA.
Storage
1 x mSATA
USB
2 x USB 3.0 Ports (Only if supported by COM Express Module)
6 x USB 2.0 Ports (2 to USB 3.0 connector, 2 to USB 2.0 connector, 2 to
miniPCIe)
Network
2 x Gigabit Ethernet (10/10/1000) Ports:
1 from COM Express
1 from on-board Intel 82574I PHY/Controller
GPIO
8-bit GPIO
Display
1 x HDMI
1 x LVDS
Audio
HD Audio (Cirrus Logic CS4207 codec)
1 x stereo input
1 x stereo output
Serial
2 x RS-232/422/485 hardware selectable ports
Misc External Interfaces
SMBus
I2C
Battery Low Indication
System Status (S3 and Reset Outputs)
Power
Single wide input range
+8V to +14V DC (may be module dependent)
RTC Battery
No on-board RTC battery
Option to connect external RTC battery.
Connectors
USB Type A, RJ45, HDMI connectors, additional signals via shrouded
locking ruggedized 2mm pitch headers. Can be mated to CTI custom
cable set to panel mount or PC MIL type connectors
Mechanical Information
84mm x 73.415mm
CCG022: Download 3D model here
Weight
68g (carrier only, no module installed)
Operating Temperature
-40°C to +85°C
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 11 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Designator
Description
P1
GBE0/1 Connector (2x1 RJ45 Connector)
P3
microSD Card Connector
P4
Input Power Connector
P5
RTC Battery Connector
P6
USB 3.0 Connector
P7
RS-232/485 Connector
P8
COM Express Type 10 Connector
P9
LVDS Video Connector
P10
LVDS Backlight Power Connector
P11
HDMI Connector
P12
Misc/System Connector
P13
Audio Input/Output Connector
P14
USB 2.0 Port 2 & 3 Connector
P15
miniPCIe Slot-1 SIM Socket
Jumper Summary
Designator
Description
J1
RS-232/RS-485 Jumper Block
J2
System Jumper Block
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 12 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Detailed Feature Pinouts and Functional Descriptions
COM Express Module
The processor and chipset are implemented on the COM Express Type 10 CPU module, which connects to the
COM Express carrier via a Tyco fine pitch stacking connector.
Function
COM Express interface
Location
P8
Carrier
Connector PN
3-6318491-6
Manufacturer: TE
Connectivity
Mating
Connector PN
3-1827231-6
Manufacturer: TE
Connectivity
Pinout
See Appendix A
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 13 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Display Outputs
LVDS Video Connector
The COM Express carrier provides dual 18 or 24 bit LVDS display channels via P9, which are connected
directly from the COM Express module.
Function
LVDS Graphics
Location
P9
Carrier
Connector PN
DF19G-20P-1H(54) - Manufacturer: Hirose
Mating
Connector PN
DF19-20S-1C - Manufacturer: Hirose
Pinout
Pin
Signal
Description
1
+3.3 VCC_PNL
Panel Power
2
+3.3 VCC_PNL
Panel Power
3
GND
Digital ground
4
GND
Digital ground
5
LVDS_A0_N
Channel A Data
6
LVDS_A0_P
Channel A Data
7
GND
Digital ground
8
LVDS_A1_N
Channel A Data
9
LVDS_A1_P
Channel A Data
10
GND
Digital ground
11
LVDS_A2_N
Channel A Data
12
LVDS_A2_P
Channel A Data
13
GND
Digital ground
14
LVDS_CLK_N
Channel A Data
15
LVDS_CLK_P
Channel A Data
16
GND
Digital ground
17
+5 VCC_PNL [1]
Backlight Power
18
+5 VCC_PNL [1]
Backlight Power
19
GND
Digital ground
20
BKLT Control [2]
LED ADJ
[1] –+5V_VCC_PNL –This voltage can be enabled or disabled to the display via Jumper J2 position B.
[2] –BKLT Control –This signal can be connected to the COM Express backlight control pin or to GND via Jumper J2
position C and D.
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 14 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
LVDS Backlight Power Connector
The COM Express Type 10 PC Connector Carrier is equipped with a LVDS backlight inverter power supply
connector. This power supply is designed to power HDA700LPT-GHL (or similar screen type) which has 13
parallel strings of 3 series white LEDS. Each white LED has a Vf of approximately 3.3V.
Function
LVDS backlight Inverter power
Location
P10
Carrier
Connector PN
SM02B-BHSS-1-TB - Manufacturer: JST
Mating
Connector PN
BHSR-02VS-1 (N) - Manufacturer: JST
Pinout
Pin
Signal
1
VA LED
2
VK LED
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 15 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
HDMI Video Connector
The COM Express Type 10 PC Connector Carrier features a HDMI connector.
Function
HDMI Output Connector
Location
P11
Carrier
Connector PN
2007435-3 - Manufacturer: TE
Mating
Connector PN
Standard HDMI Type A Plug
Pinout
Standard HDMI Type A pinout.
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 16 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
USB
USB 2.0 Port Connectors
The COM Express Type 10 PC Connector Carrier has 2 external USB 2.0 ports. Each of these are directly
sourced from the COM Express Type 10 module and do not go through any external hubs or bridges.
Function
USB 2.0 Connector
Locations
P14
Carrier
Connector PN
067298-3091 - Manufacturer: Molex
Mating
Connector PN
Standard USB 2.0 Type A
Pinout
Standard USB 2.0 Type A
USB 3.0/2.0 Port Connectors
The maximum configuration for a Type 10 COM Express Modules allows for 2 USB 3.0 Ports with integrated
USB 2.0 Ports. However most modules currently on the market only expose a single USB 3.0 Port. The USB
3.0 signals are sourced from the COM Express Module, and run through a Pericom Semiconductor
PI3EQX7502AIZDE re-driver.
Over current protection, power supply filtering and ESD protection is also provided.
Function
USB 2.0/3.0
Location
P6
Carrier
Connector PN
1932355-1 –Manufacturer: TE
Mating
Connector PN
Standard USB 3.0 Type A
Pinout
Standard USB 3.0 Type A
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 17 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
10/100/1000 Ethernet (GBE) Connector
The COM Express Type 10 PC Connector Carrier features dual 10/100/1000 Ethernet Ports.
GBE Port 1 is coming directly from the COM Express module.
GBE Port 2 is coming from an Intel 82574 PCIe PHY Controller located on the carrier.
Function
LAN Connector
Locations
P1
Carrier
Connector PN
RJHSE-5381-02 - Manufacturer: Amphenol
Mating
Connector PN
Standard 10/100/1000 RJ45 Ethernet; refer to
IEEE 802.3
Pinout
Standard 10/100/1000 RJ45 Ethernet; refer to
IEEE 802.3
Software Support for the Intel 82574
Additional drivers will be needed to properly operate the GBE Port 2 on the COM Express carrier.
These drivers can be downloaded directly from Intel website from the below link:
http://downloadcenter.intel.com/SearchResult.aspx?lang=eng&ProductFamily=Ethernet+Components&Produc
tLine=Ethernet+Controllers&ProductProduct=Intel%C2%AE+82574+Gigabit+Ethernet+Controller
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 18 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Serial
The COM Express Type 10 PC Connector Carrier provides 2 asynchronous serial ports. Each of these ports
are derived directly from the COM Express Type 10 SER1 and SER2 connections. These ports are hardware
selectable through he means of jumpers to RS-232 or RS-422/485
RS-232/485 Connector
Function
RS-232 / RS-485
Locations
P7
Carrier
Connector
PN
98424-G52-10LF - Manufacturer: FCI
Mating
Connector
PN
10073599-010LF - Manufacturer: FCI
Pinout
Pin
Signal
Description
1
232TX0/485TX0+
RS-232 0 Transmit / RS-485 0 Transmit +
2
232RX0/485RX0+
RS-232 0 Receive / RS-485 0 Receive +
3
485TX0-
RS-485 0 Transmit -
4
485RX0-
RS-485 0 Receive -
5
232/485-GND0
Port 0 Ground
6
232/485-GND1
Port 1 Ground
7
232TX1/485TX1+
RS-232 1 Transmit / RS-485 1 Transmit +
8
232RX1/485RX+
RS-232 1 Receive / RS-485 1 Receive +
9
485TX1-
RS-485 1 Transmit -
10
485RX1-
RS-485 1 Receive -
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 19 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
RS-232/485 Jumper Configuration
Below is a listing of the 3 main configurations of jumper settings for the serial ports on the carrier board.
Positions A & B set the line mode, while positions C –F set BIAS termination for RS-485 signaling.
J1 –RS-232/485 Jumper Block
Position
Jumper Description
A
Serial Mode Bit - M0
B
Serial Mode Bit –M1
C
Port 0 RS-485 BIAS+
D
Port 0 RS-485 BIAS-
E
Port 1 RS-485 BIAS+
F
Port 1 RS-485 BIAS-
Serial Line Modes
Position A –M0
Position B –M1
Port 0 Selected Mode
Port 1 Selected Mode
OFF
OFF
RS-232
RS-232
OFF
ON
RS-422/485
RS-422/485
ON
OFF
RS-232
RS-422/485
ON
ON
Undefined
Undefined
Examples
COM Express Type 10 PC Connector Carrier Manual
Users Guide
www.connecttech.com
Document: CTIM-00489
Revision: 0.01
Page 20 of 38
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2019-07-04
Audio
The COM Express Type 10 PC Connector Carrier features HD Audio capabilities care of the Cirrus Logic
CS4207 Codec device. From the codec 1 input (microphone) and 1 output (headphone) are available.
Function
Audio Connector
Locations
P13
Carrier
Connector PN
98424-G52-10LF - Manufacturer: FCI
Mating
Connector PN
10073599-010LF - Manufacturer: FCI
Pinout
Pin
Signal
Description
1
-
No Connect
2
-
No Connect
3
MIC-R
Mic Input - Right Channel
4
MIC-L
Mic Input - Left Channel
5
GND
Mic GND / Shield
6
GND
Headphone GND / Shield
7
HPOUT-R
Headphone Right Channel
8
HPOUT-L
Headphone Left Channel
Software Support for the CS4207
The audio codec used on the carrier board is the CS4207 from Cirrus Logic.
Additional drivers will be needed to properly operate audio on the COM Express carrier. Some downloadable
ldrivers can be found below.
https://www.cirrus.com/products/cs4207/
Linux Driver: Included in kernels 2.6.30 and up.
Table of contents
