Introduction
Connect Tech’s GraphiteVPX/GbE Managed Ethernet Switch provides Carrier Grade Ethernet switching
capabilities in a small 3U embedded form factor. Excellent for demanding applications with rugged
environments and extreme temperatures.
The GraphiteVPX/GbE Managed Ethernet Switch is also a highly reliable way to communicate with
10/100/1000 Base-T devices in an embedded system. Powered by the latest generation Carrier Ethernet Switch
engine, the Vitesse 7429 features an embedded MIPS 32-bit CPU, 1Gb external memory and DMA-based
frame extraction and insertion support timing over packet, Ethernet OAM, and performance monitoring.
Feature
Description
Ethernet Switch Engine
Vitesse VSC7429 Carrier Grade Ethernet Switch Chipset
A powerful embedded 416 MHz RISC 32-bit CPU with DDR2
external memory and DMA-based frame extraction and insertion supports
timing over packet, Ethernet OAM, and performance monitoring.
Ethernet PHYs
8 x Cu PHY Ports from Vitesse VSC7429 Switch Engine
12 x Cu PHY Ports from Vitesse VSC8512 External PHY
Memories
1Gb DDR2 SDRAM (125MB)
128Mb Serial NOR Flash (16MB)
Ports
20 x Gigabit Ethernet (10/100/1000 Mbps )
Magnetics
On-board Gigabit Magnetics for all 20 Ports (No external Magnetics required)
Designed for Long-haul Gigabit Ethernet (10/100/1000 Mbps) applications
I/O Connectors
Standard VPX Backplane connectors
4x RJ45 front panel connectors
RJ11 connector for RS232 CLI access
Layer 2 Switching
802.1Q VLAN switch with 8K MACs and 4K VLANs
Push/pop up to two VLAN tags
IPv4/IPv6 multicast
Policing with storm control and MC/BC protection
RSTP and MSTP support
Hardware and software-based learning
Link aggregation (IEEE 802.3ad)
Independent and shared VLAN learning (IVL, SVL)
Jumbo frame support
Management Access
Web Interface
CLI via RS-232
Software API
SMNP

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 7 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Indicator LEDs
2 LEDs per port indicating connection speed
Power Good LED
Fail Status LED
Thermal Trip LED
Standalone Operation
Switch is used as a standalone unit
Input Voltage
5V (VS3) and 3.3V_AUX
Power Consumption
Idle: 1.8A, 9W Typical: 2A, 10W Max: 3A, 15W (with +5V input)
Dimensions
Standard 1” Pitch VPX
Weight
VPG201 = 380g
VPG202 = 390g
Operating Temp
-40°C to +85°C (chipset rated to +125°C TJmax)
Warranty and Support
Two Year Warranty and Free Technical Support

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 8 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Product Overview
The
Block Diagram

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 9 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Ordering Part Numbers
Part Number
Description
VPG201
Air Cooled 20 port GbE Switch, 16 backplane
channels, 4 RJ45 channels on the front panel
VPG202
Conduction Cooled 16 port GbE Switch, 16
backplane channels
RTG002
3U extended RTM, with 16 RJ45 channels

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 10 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Connector Locations (VPG201)
Note the VPG202 has P3 and P4 removed.

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 11 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Connector Summary
Designator
Connector
Description
P0
VPX P0
Standard VPX connector, has all POWER, CTRL
signals
P1
VPX P1
Is fully populated with 8 GbE BaseT channels
P2
VPX P2
Is fully populated with 8 GbE BaseT channels
P3
RJ11
RJ11 for serial communications with the Ethernet
switch, VPG201 only
P4
RJ45
4x RJ45 connectors for additional access
J1
2x5 Jumper Block
N/A

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 12 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
VPG20x - Detailed Feature Pinouts
Full pinout details are available only under an NDA (Non-Disclosure Agreement). Please contact sales at Connect
Tech Inc. for further information.
1-800-426-8979
[e-mail]
http://www.connecttech.com

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 13 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
CLI Management Interface
CLI Access via the RS232 Serial Port
To use the CLI management on the VPG you must connect to the RS-232 external management serial port (P3)
or through the backplane serial port connection. Only TX, RX and GND connections are needed for operation.
You then must open the serial port in a terminal program such as: RealTerm, Putty, HyperTerminal, minicom,
etc. The COM port must be set up to run with a baud rate of 115200, 8 data bits, 1 stop bit and no parity.
Note: the VPG external serial port is compatible with RS-232 Input/Output Levels (NOT TTL or CMOS).
RS-232 Serial Parameter
Value
Baud Rate
115200 bps
Data Bits
8
Parity
None
Stop Bit
1
Output Voltage Swing
±4.2 V
Input Voltage Range
±15 V
Input Threshold Low
0.8 V
Input Threshold High
2.4 V

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 14 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
CLI Basics
Once opening the COM port attached to the management port, after boot up your terminal output should look
like the output below. The default login is admin and password is blank(“”). So after typing admin hit
<ENTER> then hit <ENTER> again to login and “?” will display a list of the available commands.
Below is a list of common quick CLI commands. For a complete CLI reference please see the documents
described below.
Common Task
CLI Command Syntax
Help menu –from any level, add a ‘?’ to the
end of a command for a list of options at that
level.
show ? OR show ip int ?
What are the IP addresses used by my
switch?
show ip int br
What ports are linked and at what speed?
show int * status
What software version is on my switch?
show ver
How do I save my configuration?
copy running-config startup-config
How do I setup my IP address for vlan1?
conf t
int vlan 1
ip add xxx.xxx.xxx.xxx 255.255.255.0
end
Complete CLI and Protocol Configuration Reference Guide
The complete CLI and Protocol Configuration reference guide from Microsemi for the VSC7429 device can be
downloaded here.
The following documents:
- AN1104-Software_Configuration_Guide_ICLI
- AN1115Layer2ProtocolConfigurationGuide
Will have the below mentioned copyright notice.
Copyright 2002-2015 Microsemi Corporation. All Rights Reserved. Unpublished rights reserved under the
copyright laws of the United States of America, other countries and international treaties. Microsemi retains
all ownership, copyright, trade secret and proprietary rights in the documentation.

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 15 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Web Management Interface
The GraphiteVPX/GbE 16+4 - Port - Managed Carrier Ethernet Switch allows users to configure and monitor
the device from any web enabled device. Below describes how to access this management interface as well as
provides on overview on the web GUI itself.
Accessing the Web Management Interface
There are two ways to access the web interface for first time use.
Method #1 - Using the default shipping IP
This method DOES NOT require having access to the CLI interface. By default the GraphiteVPX/GbE will
have an IP address of 192.168.42.1, if you would like to connect to this address follow the steps below:
oDirectly connect any port of GraphiteVPX/GbE to your host PC using a standard Cat5e ethernet
cable
oSetup your host PC’s IP address to be on the same subnet as GraphiteVPX/GbE (192.168.42.X)
oOpen a web browser and go to the 192.168.42.1 address.
oNow you should see the login screen and from here you can setup the GraphiteVPX/GbE to an IP
address on your network.
Method #2 –Changing the GraphiteVPX/GbE IP to one on your network via the CLI
This method requires having access to the CLI interface through means of the external management serial port
or the PCIe/104 bus
oLogin to the CLI interface
oType in the following commands
oconfigure terminal
ointerface vlan 1
oip address xxx.xxx.xxx.xxx 255.255.255.0
oend
oNow connect GraphiteVPX/GbE to any place on your network.
oOnce the system is up simply go to your specified address of xxx.xxx.xxx.xxx in a web browser of
your choice and you will see the login screen for the web interface
Login Screen of Web Management Interface
To login into the web management interface, the default login is admin and the password is blank.
(See below)

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 16 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Web Management Interface Overview
Complete Web Protocol Configuration Reference Guide
As mentioned in the CLI section, the complete Protocol Configuration reference guide from Microsemi for the
VSC7429 device can be downloaded here. It will have CLI and Web configuration methods listed.
The following document:
- AN1115Layer2ProtocolConfigurationGuide
Will have the below mentioned copyright notice.
Copyright 2002-2015 Microsemi Corporation. All Rights Reserved. Unpublished rights reserved under the
copyright laws of the United States of America, other countries and international treaties. Microsemi retains
all ownership, copyright, trade secret and proprietary rights in the documentation.

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 17 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Port LED Details
The VPG uses a serialized LED stream to output the LED status for each port. This serial signal is intended to
be run through shift registers as shown below to de-serialize the stream. To accommodate the 16 ports
(VPG202 –Backplane only) requires the use of four 8-bit shift registers (or eqivilant) setup in the
configuration shown below.
An example circuit is shown below, or an example schematic can be downloaded here.

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 18 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
System Management Interface
The GraphiteVPX/GbE supports a slave I2C slave interface on the SM0 (SCL) and SM1 (SDA) signals
connected to the VPX backplane. The I2C address of this interface is determined by the Geographic Address
lines GA0#, GA1#, and GA2#. This interface operates at 100 KHz.
There are 10K OHM pull-ups to the +3.3V_AUX supply on the I2C slave interface on SM0 and SM1.
The I2C interface contains an I2C mux device (PCA9544) to allow the user access 5 temperature sensors that
monitor board edges and internal temperatures of the Ethernet Switch and Ethernet PHY.
Addressing the I2C Slave Interface (I2C Mux)
As stated above, the I2C slave interface uses GA0#, GA1#, and GA2# to determine its final I2C address. See
more details below. Refer to your backplane GA (Geographical Address) lines for the complete configuration
address.
The I2C address will be as such:
Bit7
BIT6
BIT5
BIT4
BIT3
BIT2
BIT1
BIT0
1
1
1
0
GA2#
GA1#
GA0#
R/W

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 19 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Writing to the I2C Slave Interface
Refer to the NXP PCA9544 datasheet for access details.
The I2C multiplexor is like a ‘gate’ to open an on board I2C bus to access one of three card side busses:
1) Bus 0 –is a link to one TMP422 (sensor #5) remote temperature sensor (local temp and remote
temperatures of VSC7429 and VSC8512).
2) Bus 1 –is a direct link with XMC sites I2C system interface
3) Bus 2 –is a link to 2 TMP101 temperature sensors on the top edge (Sensor 1 and 2)
4) Bus 3 –is a link to 2 TMP101 temperature sensors on the bottom edge (Sensor 3 and 4)
*Refer to the TI TMP101 datasheet for access and setup of ALERT pin interrupt to the PCA9544. A Thermal
Alert LED is accessible on the solder side of the card if a visual indicator is required.
Reading from the I2C devices
When reading from the I2C slave interface, the last value stored in the command register by a write operation
is used to determine which command to respond to. To change the command for a read operation, a new
command must be written to the command register. This is accomplished by issuing an I2C slave address byte
with the R/W# bit LOW, followed by the command byte. The master can then generate a START condition
and send the I2C slave address byte with the R/W# bit HIGH to initiate a read command. If repeated reads
from the same register are required it is not necessary to continually send the command byte. The slave I2C
interface will remember the original command value until it is changed by the next write operation.
Example XML code to open the I2C mux and access the temperature sensors using the Totalphase Aardvark™
USB to I2C controller can be provided by request.

GraphiteVPX/GbE 16+4-Port - Managed Carrier Ethernet Switch
Users Guide
www.connecttech.com
Document: CTIM-00461
Revision: 0.02
Page 20 of 26
Connect Tech Inc. 800-426-8979 | 519-836-1291
Date: 2016/10/27
Thermal Details
Thermal Parameters
Thermal Parameter
Value
Minimum Ambient Operating Temperature
-40 °C
Maximum Operating Junction Temperature
125 °C
Recommended VPG TDP
15W
SoC TDP (VSC7429)
8W
PHY TDP (VSC8512)
7W
Die junction to package case top (SoC/PHY)
3.27 °C/W
Die junction to PCB (SoC/PHY)
6.03 °C/W
Die junction to Ambient (SoC/PHY)
12.14 °C/W
Die junction to moving air @ 1 m/s (SoC/PHY)
9.42 °C/W
