CONOPU OZC19S01 User manual
UK
Dehumidifier
User Manual
Thank you for choosing CONOPU!
Model: OZC19S01
Please read and save these important safety instructions.
Product Description
Structure
Specification
Instructions
Maintenance
Cautions
Warranty
0
1
1
1-2
3
4
5
Contents
Product Description
This sleek dehumidifier is designed for compact and portable use. Apart
from having the advantage of energy-saving and environment-friendly, this
product is equipped with 7-colors LED lights,most of all, also performs well
on dehumidification.
By quickly inhaling the moist air through the fan, the machine removes the
water vapor from the air and discharges the dry and fresh air out of the
machine that aims to get rid of the mold from the humid environments,
which greatly creates a comfortable and healthy living conditions for you.
Ideal for home, oce and any small space.
Structure
ON/OFF Button
1
Air Outlet
2
Front cover
3
LED Lights
4
Handle
5
Air Inlet
6
DC port
7
8Adaptor
9Cable
Floater
10
Tank Cover
11
Water Tank
12
Specification
Name:Dehumidifier Model:OZC19S01
Rated voltage:12V Rated power: 40W
Instructions
please ensure all the parts are completed and undamaged prior to use.
1. When the dehumidifier is plugged in, a long “beep” can be heard .
It’s in the standby standards. （see Pic.1）
Press “ ”on the top with 1 short “beep”, and light up , the
machine starts working; Press again to stop. (see Pic.2)
1
4
1
3
5
7
6
28
10
9
12
11
（Pic.1） （Pic.2） （ Pic.3）
（Pic.4） （ Pic.5） （ Pic.6）
2. When it’s working, the 7-colors LED lights will turn on automatically. Press “ ”
to lock your desired color; 2nd Press to turn o the light , button lights o too;
3rd Press to turn on again. (see Pic.3)
3. When the water tank is 700-800ml full, the red warning light at the bottom
will flicker with 3 “beeps” , the machine stops working automatically.
(see Pic.4)
★Stopping-at-almost-full is a protection to prevent water overflow when moving the tank.
5. Press “ ” to restart, after fitting the water tank back.
4. How to empty the water tank
When the machine is powered o, take the tank by holding the sides of the
tank and pressing the front cover with your fingers( see Pic.5). Take o the
cover and pour out the water.(see Pic.6)
2
Maintenance
SAFETY INSTRUCTIONS
Please make sure the product is powered o before maintenance.
WHY IS IT UNDERPERFORMING? (less water in the tank)
1.Wipe the machine body with neutral detergent and wash the tank directly
with water to ensure the service life of the machine.
2.When the machine has been cleaned, wipe to dry with a soft and dry cloth.
3.After being cleaned and wiped, put it back to the box for storage.
• ls the door or window open ? (Please close the doors and windows.)
• ls there any obstacle blocking the air inlet/outlet ?
• ls there any other equipment releasing steam indoors ?
• Is the indoor temperature too low ?
(the dehumidification capacity will be aected in a low temperature and
low humidity environment. If the indoor temperature is lower than 8℃/46.4℉,
the eect of dehumidification is not obvious).
This dehumidifier was made with safe and environmental protection
materials, it has been certified and complied with the requirement of sale
region’s related regulations or laws.
Important: Please read the Cautions Notice before using the device. Basic
precautions should always be followed to reduce the risk of fire, electrical
shock, and injury to persons or damage to the product.
3
Cautions
1. Before use, please check the applied voltage matches with the adapter
label.
2. DO NOT turn on the machine when the wire is damaged, ask customer
service for help.
3. Keep it away from the obstacles to avoid any block-up of the air inlet or
outlet.
4. DO NOT use in inflammable and explosive environment or which is above
40℃/104℉. Ideal operation environment: Temp: 8℃-40℃(46.4℉-104℉).
5. Please switch o and plug out the machine if you’re not using it.
6. DO NOT twist or pull the wire.
7. DO NOT use the dehumidifier in a lean place of angle more than 10
degrees.
8. DO NOT cover the machine to avoid overheating.
9. DO NOT use the dehumidifier in condition of low temperature, dusty or
volatile place of acid, alkali and oil.
10. DO NOT touch the plug with a wet hand in case of electric shock.
11. DO NOT put any object into the dehumidifier while it’s working.
12.This appliance can be used by children aged from 8 years old and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
13.Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
14. Machine surface can be cleaned by soft cloth neutral detergent
instead of petroleum, alcohol and other organic agents.
15. DO NOT use unmatched adaptor.
16. DO NOT disassemble the product or component by yourself.
17. It is normal that the adapter will get hot (no more than 80 °C or 176°F)
during running. 4
Warranty
5
We appreciate your feedback and will do our best guarantee your satisfac-
tion.
Within 1 year after your purchase,shall the product has defects, we will
provide a refund or resend you a new one. Please email us with your
concern and order number. Your inquiries will be taken care of as soon as
possible.
This warranty only cover orders from authorized brand online stores and
our ocial website. We are not responsible for any purchases from other
distribution channels.
