Consort TRF25C LST User manual

46000134 Iss 04
OPERATION
Your Consort Heated Towel Rail costs less to run than a 100 Watt light bulb. It will take
a roximately 45 minutes to reach o erating tem erature and, if need be, can be left
running continuously.
CLEANING
Your heated towel rail is best wi ed down from time to time with a dam cloth. Do not
use any abrasive or corrosive cleaners. Always switch the a liance off before cleaning.
IF YOUR TOWEL RAIL DOES NOT WORK
Check that the fuse has not blown at the flex outlet, in the lug or at the distribution
board. Do NOT attem t to re air the towel rail. Should none of the above remedies
work then consult an accredited service agent. If the a liance is still under guarantee,
return it to your su lier.
GUARANTEE
This guarantee is offered to you as an extra benefit and does not affect your legal rights.
All electrical a liances roduced for the Com any are guaranteed for one year against
faulty material or workmanshi . This a lies only if the a liance has been used for
ur oses in accordance with the instructions rovided and has not been connected to an
unsuitable electricity su ly, or subject to misuse, neglect, damage or modified or
re aired by any erson not authorised by us.
CUSTOMER HELPLINE
Should you need any advice on the use of your new Consort
roduct, or should you require service or re air,
lease contact our Hel line:
O erating hours:
Monday to Thursday: 8.30am - 4.30 m
Friday: 8.30am – 3.30 m
Consort Equipm nt Products Limit d
Thornton Industrial Estate, Milford Haven
Pembrokeshire, SA73 2RT
T l: 01646 692172 Fax: [phone]
Email: t chnical@consort pl.com W b: www.consort pl.com
Installation and Op rating Instructions
Tow l Dry Tow l Rails
Mod ls: TRF25C LST, TRF30 LST, TRJ40
TRJ40C, TRJ60, TRJ60C, TRJ80
P LEASE READ THESE INSTRUCTIONS AND RETAIN FOR FUTURE REFERENCE

46000134 Iss 04
SAFETY
When using any electrical a liance, basic safety recautions should always be observed.
Please read these instructions carefully and retain for future use.
The a liance is not intended for use by ersons (including children) with reduced
hysical, sensory or mental ca abilities, or lack of ex erience and knowledge unless
they have been given su ervision or instruction concerning use of the a liance by a
erson res onsible for their safety. Young children should be su ervised to ensure
that they do not lay with the a liance.
This a liance is intended to dry towels and therefore is hot to the touch. Any rise
in ambient tem erature is directly reflected in the a liance, and as a result of this
the a liance will feel hotter to the touch during warmer eriods. Also the
insulation effect of towels will cause the o erating tem erature to increase slightly.
The avoid a hazard this heated towel rail MUST NOT be used to carry towels or any
other articles that have been in contact with oil, etroleum based roducts or dry
cleaning fluids.
Use this a liance only on the voltage s ecified on the rating label.
Do NOT use this towel rail unless it has been fitted to the wall as er these
instructions.
Do NOT immerse in any liquid.
Do NOT allow the su ly cable to come into contact with heated surfaces during
o eration.
The towel rail and flexible cable outlet must be mounted so that no art of them can
be touched by any erson using a bath or shower.
Do NOT use the a liance if damaged.
SPECIFICATIONS
DIMENSIONS
Model:
TRF30 LST TRF25C/LST/TRJ40/TRJ40C TRJ60/TRJ60C TRJ80
Width: 465mm 465mm 495mm 540mm
Height: 425mm 415mm 665mm 875mm
De th: 86mm 86mm 86mm 86mm
Weight: 1.4 kg 1.5 kg 1.9 kg 2.6 kg
ELECTRICAL
Wattage: 27-30 W 23-25 W /42-45 W 60-65 W 84-85 W
Su ly: 230-240 Volts ac 50 Hz, single hase
Ingress Protection Rating: IP34 – S lash roof – Double Insulated
This towel rail meets the requirements of EU Directive 89/336/EEC
(Amended by 92/31/EEC) for Electromagnetic Com atibility.
Please note, the TRF25C LST & TRF30 LST are Low Surfac T mp ratur models which have a
maximum surfac t mp ratur of 43
0
C wh n uncov r d to com ly with De artment of Health
guidelines. Th surfac t mp ratur of th rail b n ath a tow l can xc d this t mp ratur .
INSTALLATION
Ensure the electricity su ly is disconnected from any relevant fixed wiring before
commencing the installation.
This a liance MUST be connected in accordance with the latest IEE regulations and
fitted by a com etent electrician. The su ly circuit must be adequate for the in ut of
the a liance. The towel rail must be connected via a fused, double ole, switched
(having a contact se aration of at least 3mm in each ole), flexible cable outlet and
fitted with a 3 Am fuse or via a lug and socket.
When installed in a bathroom, the towel rail must NOT be connected via a lug and
socket. The towel rail must also be located in the a ro riate zone of the bathroom, in
accordance with section 601 of the Wiring Regulations BS 7671:1992 (Amendment 10983).
NOTE: This class II a liance does NOT require earthing.
MOUNTING PROCEDURE
Choose a suitable osition on the wall to mount
the heated towel rail. The cable entry can be
either on the left or right hand side, but it must be
horizontal and at the bottom of the frame.
WARNING: In order to avoid a hazard for young
children, the wall mounted towel rails must be
installed so that the lowest heated rail is at least
600 mm above the floor.
1. Swivel the leg brackets around so they are
angled at 90
0
to the rear of the frame.
2. Place the towel rail on a flat surface, check
that all the leg brackets are sitting arallel and
then tighten the tube clam screws sufficiently
that the tube clam sits flush into the wall
fixing bracket, but do not over-tighten.
3. Level u the to rail of the heated towel rail
and fasten to the wall with either the screws
rovided or other suitable fixings.
4. Fit the screw ca s
to cover the screw
holes in each leg
bracket.
