Conti Grinder 200 User manual

- Edition 11/2016
SACOME, Document CONFIDENTIEL,Ne peut être reproduit ni communiqué sans notre accord préalable.
SACOME, CONFIDENTIAL Document,it is forbidden to duplicate or communicate this document without previous authorization.
CG-200 OD
사용자 매뉴얼

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,Ne peut être reproduit ni communiqué sans notre accord préalable.
- 1 -
1. PREFACE________________________________________________________________ 14
2. TECHNICAL SPECIFICATIONS ______________________________________________ 14
3. GENERAL DESCRIPTION ___________________________________________________ 14
4. UNPACKING AND INSTALLATION: ___________________________________________ 15
5. OPERATION______________________________________________________________ 16
6. ACCESSORIES ___________________________________________________________ 17
7. SAFETY DEVICES _________________________________________________________ 19
8. MAINTENANCE AND SERVICE ______________________________________________ 20
9. CLEANING _______________________________________________________________ 20

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,Ne peut être reproduit ni communiqué sans notre accord préalable.
- 12 -

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,Ne peut être reproduit ni communiqué sans notre accord préalable.
- 13 -
WARNINGS
1 This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
2 Children should be supervised to ensure that they do not play with the appliance.
3 Care is needed when handling cutting blades during cleaning.
4 If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a hazard.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
WARRANTY INFORMATION
The manufacturer provides warranty in accordance with the legislation of the customer's own country of
residence, starting from the date on which the appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service centre. When making a
claim under the warranty, the original bill of purchase (with purchase date) must be submitted.
The warranty will not apply in cases of:
Normal wear and tear Incorrect use, e.g. overloading of the appliance, use of non approved
accessories, use of force, damage caused by external influences, damage caused by
nonobservance of the user manual, e.g. connection to a none suitable mains supply or none
compliance with the installation instructions Partially or completely dismantled appliances.

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 14 -
1. PREFACE
Congratulations for purchasing the CG200 OD grinder with dispenser.
The CG200 OD is a commercial applianceto be used in coffee shops, espresso bars, hotels,
restaurants, etc.
CG200 OD will grind whole been coffee into variable, user selectable (from super fine to course)
coffee powder and will dose It to your espresso machine filter holder.
Read this manual from cover to cover before using the appliance as it contains important
instructions for the safety, operation, and maintenance of the appliance.
Keep the manual in a safe place for future use and reference. The manufacturer reserves the right to
modify the appliance and the manual accordingly.
2. TECHNICAL SPECIFICATIONS
•Dimensions [mm]: Height: 560mm
Width: 350mm
Length: 250mm
•Weight: 11,5Kg
•Burrs diameter: 64mm (flat type)
•Hopper capacity: 1,2Kg
•Electrical Specifications: Europe: 230V/50Hz
110V/60z or 220V/60Hz (on request)
•Power: 350W
•RPM: 1400 – 50Hz ; 1600 – 60Hz
•Grinding capacities: 7Kg/hour
3. GENERAL DESCRIPTION

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 15 -
4. UNPACKING AND INSTALLATION:
Warning: All appliances’ technical handling operations such as installation, maintenance, or service should
be performed by certified personnel or by your local dealer.
• After opening the box, make sure that the appliance is intact and that there is no visible
damage. If there is any doubt, DO NOT use the appliance and call your local dealer for further
assistance.
• Unpack the carton box carefully. For your convenience we suggest storing all packaging
materials where they can be used in the future, whenever the appliance’s transportation is
necessary.
• Place the grinder on a stable flat counter in a dry area away from water or watersplashes.
• Position the coffee residue tray underneath the body in front of the appliance.
• Install the beans hopper firmly on top of the body inside the top blade holder.
• Fasten the hopper to the appliance body by means of the supplied screw. (fig.4.1) Make sure that
the screw is inserted completely through both holes in the hopper and in the top blade holder.
Fig.4.1
• NEVER OPERATE THE GRINDER IF THE BEAN HOPPER IS NOT FULLY SECURED IN ITS
POSITION.
• Before plugging in the electrical cord, makesure:
o The appliance voltage and frequency rating (according to the back side label) is the
same as the supply mains.
o The wall socket is fitted with an efficient ground contact. DO NOT plug the appliance into
the supply mains if the ground system was not positively checked to be in compliance with
current safety rules. IT IS COMPULSORY TO GROUND THE APPLIANCE. The
manufacturer cannot be held responsible in the event that this regulation is not complied
with.
o The power consumption of the appliance (according to the backside label) is
consistent with the relevant wall socket capacity.
o The wall socket is protected against short outs and powersurges.
o Do not use extension cables, plug adapters for multiple sockets, or make shift connections.
• Plug in the appliance.
• Upon first time operation, and before placing beans in to the hopper, VISUALLY check that the
blade rotation direction is clockwise by switching the appliance ON for a fewseconds.
• Should the rotation direction be wrong, do not use the appliance and contact your local dealer
for further instructions.

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 16 -
5. OPERATION
Grinding coffee with CG200 OD:
Fig.5.1
A. Modes of operation:
The CG200 OD can be operated in 3 different modes (Fig.5.1)
Activating (or deactivating) each one of the modes, is achieved by single pressing on the relative mode
selector button. Once activated, a green LED will turn to ON state on each one of the selectors.
• Continuous mode, while in continues mode pressing longer than 3 sec on continuous-mode
button will start the grinder (the relative LED will blink as long as the grinder is running) stopping
the grinder by another short press on continuous-mode button.
• Single cup mode, while in single cup mode any press on the demand switch (fig.5.2) will
activate the grinder to grind a precisely timed dose (time can be programmed by user) into the
filter handle.
• Double cup mode, while in double cup mode any press on the demand switch (fig.5.2) will
activate the grinder to grind a precisely timed dose (time can be programmed by user) into the
filter handle.
Remark: Stopping an undesired grinding operation (before reaching complete dose) by pressing
continuous mode button.
Fig.5.2
Continues mode selector
Counter selector button
Programming dial

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 17 -
B. Dose counting LCD:
• The CG200 OD model is equipped with 3 independent dosingcounters.
• In order to view each one of the counters a single press on the counter selector will flip
the LCD to the next counter and the relative counter’s LED will turnon.
• 2 of the counters are resettable (middle and left most LED); in order to reset each of
these 2 counters a 5 sec continues press on the counter selector will zero the
relative counter.
• On single cup mode each coffee demand will increase the counting on all the 3 counters in 1.
• On double cup mode each coffee demand will increase the counting on all 3 counters in 2.
• On continuous mode the counters are notcounting.
C. Programming grinding time for single and double cup modes:
The CG200 OD is factory set with time values for single and double dose grinding periods. These
pre set values are obviously estimated and user should find his own times according the coffee
grinding request. In general as the coarseness of grind is coarser the time required to grind
same weight of coffee is shorter. Additionally different type of coffee blends and coffee shops
are requiring different dose size for their single and double cups:
→6.5gr to 9.5gr per single cup
→11gr to 18gr for double cup
D. Grinding time setting:
The CG200 OD is supporting the need of the user to change grinding time setting frequently. In order to
change time setting of single cup or double cup mode please follow these steps:
1. Press the desired mode selector button continuously for longer than 3 sec.
When in programming mode the mode selector’s LED is blinking.
2. Watch the LCD display is now showing your current set up time (in seconds and tents of
seconds).
3. In order to increase or decrease set up time simply rotate the peripheral scale of the knob
and watch the time set up on the LCD is changing up or down according direction of
rotation.
4. When reaching the desired time value press shortly the mode selector button to return to
normal working mode (watch the display is returning to counter mode).
E. Adjusting coffee grind :
The grinding blades’ distance was factory pre adjusted to satisfy different common coffee grinds (from
super fine to coarse) corresponding gap distance from 0.05mm to 0.5mm.
→Turning the grinding dial incrementally counterclockwise will make the grind finer
→Turning it clockwise will make the grind coarser.
Grind a small amount of coffee and test its coarseness with your espresso machine.
As coffee beans’ qualities and characteristics are changing from time to time, it is recommended
repeating this adjustment once in a while.

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 18 -
6. ACCESSORIES
•Filter holder support
Fig.6.1 Fig.6.2
Fig.6.3 Fig.6.4
•Notice the two holes under the filter fork support (fig.6-1)
•Unpack the accessory (fig.6.2), which is packed separately within the grinder packaging.
•Insert the accessory into the 2 holes (fig.6.3)
•Place your filter supported by the fingers and the back accessory. (fig.6.4)

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 19 -
7. SAFETY DEVICES
A. Thermal overload protection
In order to eliminate the risk of fire the motor is equipped with an overheat protection device which will
cut off the motor’s power supply should it reach a high temperature.
• In the event that the thermal protection is tripped as a result of malfunction (e.g.: jammed blades,
worn out bearings, foreign object in grinding chamber, etc.) the appliance main switch should be
turned off immediately and the main power plug must be disconnected. For further handling of the
device contact your local service provider, and allow the appliance to cool down before any further
maintenance.
• In the event that the thermal protection is tripped as a result of a long continuous operation (read
section 5, for operating intervals) allow the appliance to cool down and reset the thermal cutoff
protection by unplugging the main cable from the socket. On the first operation after resetting a
tripped overheat protection device observe the grinding quality and noise level, and if there are any
irregularities shut down the appliance and call a certified technician for a complete analysis of the
appliance.
B. Grinding chamber safety screws
The grinding chamber can be a hazardous area if the proper precautions aren’t observed. The hopper
safety screw (fig.4.1) and the grinding dial safety screw (fig6.1) should never be removed during normal
operation of the appliance unless the appliance is disconnected from the power source.
Fig.6.3
C. SAFETY INSTRUCTIONS
• NEVER OPERATE THE GRINDER IF THE BEAN HOPPER IS NOT FULLY SECURED TO
THE TOP BLADE HOLDER. BEFORE REMOVING THE HOPPER FOR ANY REASON MAKE
SURE TO DISCONNECT THE POWER SUPPLY.
• AVOID CLEARING FOREIGN OBJECTS FROM THEGRINDING CHAMBER OR HOPPER
WHEN THE APPLIANCE IS PLUGGED INTO A POWER SOCKET.
• Never attempt to insert your fingers or any foreign objects into the grinding chamber or blades.
• Be aware that grinding blades continue rotating for a short while after the grinding operation has
ended.
• BEFORE ANY MAINTENANCE, EVEN FOR CLEANING, ALWAYS DISCONNECT THE POWER
SUPPLY.
• In the event that the appliance has a malfunction or the blades need to be replaced, do not
attempt to service the appliance, unless you got the specific training by a certified trainer to do
so.
• Do not change or tamper with the appliance.
• Do not use the appliance barefoot or if your hands or feet are damp.
• Do not use the cable wire to pull and disconnect the power plug.
• Always keep the appliance dry (internally and externally).
• Never re grinds grinded coffee.
• Never attempt grinding anything else other than coffee beans.

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 20 -
8. MAINTENANCE AND SERVICE
Warning: All appliances’ technical handling operations, such as installation, maintenance or service
should be performed by certified personnel or by your local dealer.
Good condition blades will result in a high quality grind and prevent the appliances overheating. Replace
grinding blades every 400KG of grinded coffee (using only original replacement parts)
Be aware of the appliance’s noise level. In case the noise level is higher than normal or irregular noises
are coming from within the appliance, get certified personnel to perform an overall check of the
appliance.
9. CLEANING
BEFORE ANY CLEANING ROUTINE DISCONNECT THE APPLIANCE POWER SUPPLY. NEVER USE
RUNNING WATER TO CLEAN THE MAIN BODY AND DOSER. USE ONLY PERFECTLY CLEAN
CLOTHS OR BRUSHES TO CLEAN THE APPLIANCE. DO NOT USE ABRASIVE CLEANING
PRODUCTS AS THEY MAY WEAR OUT THE APPLIANCE COATING.
A. Cleaning the bean hopper
Take off the bean hopper (by releasing Bean Hopper safetyscrew) and rinse it thoroughlywith water and
soap. As the bean hopper is made of clear polymer, use only liquid detergent (free of abrasive
components) and soft sponge. Before reinstalling the beans hopper back to its position, make sure it is
dried thoroughly. To ensure great coffee taste, clean the bean hopper periodically.
B. Cleaning the Outlet powder chute
The Grinder is provided with detachable powder outlet.
In order to clean the outlet chute follow the next steps:
• Disconnect the grinder from the power source to avoid undesired operation
• Pull the outlet chute out and use wet sponge and soap to clean the coffee oils and
the powder’s residue. (Fig.9.1)+ (Fig9.2)
• Brush -empty the grinding tunnel from powder (using the provided brush) (Fig.9.3)
Remark: Outlet Chute internal surface its Teflon coated, use only soft sponge and liquid soap
to clean it, avoid scratching it.
Fig.9.1 Fig.9.2 Fig.9.3

Edition 11/2016 - CG200 OD
SACOME, Document CONFIDENTIEL,
Ne peut être reproduit ni communiqué sans notre accord préalable.
- 21 -
C. Cleaning the grinding chamber grinding parts and powder outlet housing
•Follow the instruction below for grinding chamber and grinding parts cleaning:
Step 1 Step 2 Step 3 Step 4
By using a screw driver
take out the dial’s safety
screw. Rotate the
grinding dial clock wise
to take it off.
Pull out the upper
blade holder; make
sure not to lose the
upper blade three
supporting springs.
Use a brush, a dry cloth,
and a vacuum cleaner to
clean the grinding chamber
thoroughly
Use a brush, a dry
cloth, and a vacuum
cleaner to clean the
upper and lower blade
thoroughly.
• Do not use sharp objects to scrape coffee residue off of the blades or the internal Teflon coating
of the outlet port.
• Examine both of the blades’ condition and replace them if necessary.
• The replacement and assembly of a new set of blades is a delicate task.
Only skilled technical personnel should be allowed to perform blade removal.
• If a more thorough clean is required, then the operation must be performed by skilled technician.
After all cleaning and replacing tasks are through make sure to assemble all of the parts and safety
screws the same way as they were disconnected. If anything does not fit back together or there are
some leftover parts, do not attempt to operate the appliance, call for the assistance of your engineer.
To ensure long lasting grinder and great fresh taste of coffee, the cleaning procedure,
as described above, should be repeated periodically and at least once per month or as necessary
according the grinder’s usage and quality of beans.

La Ruche - 1, Avenue Albert II - B.P.119 - MC 98007 MONACO Cedex
Tél.: [phone] Fax : [phone]
http ://www.conti-espresso.com http ://www.conti-spareparts.com
E-mail:[e-mail]
