Continent Globe Stella User manual

Before using this product, please
read this manual carefully before
to insure user safety
OWNER’S MANUAL
Rollator
M O B I L I T Y
Continent Globe is an
Inc.
brand
OM | TMK180228-1.EN | 1000587 | Rev. 02

2
TABLE OF CONTENTS
General information............................................................................................2
Specification and intended use.............................................................................2
Warnings...........................................................................................................3
Your rollator .......................................................................................................4
Cleaning ............................................................................................................4
Maintenance ......................................................................................................4
Reuse by third parties..........................................................................................4
Using and adjusting your rollator ......................................................................5-8
Technical specs ...................................................................................................9
Limited warranty................................................................................................. 9
Our mission...................................................................................................... 10
Our values .......................................................................................................10
Contact us........................................................................................................10
GENERAL INFORMATION
These instructions for use are an integral part of the delivery of your rollator.
The user should keep them available at all times and keep them with the product
if this is passed on to a third party.
The manufacturer reserves the right to make changes relative to the information
provided in these instructions as a result of technical developments and
improvements.
This document may not be reprinted, translated and/or duplicated in any form
whatsoever, in part or in full, only subject to the manufacturer‘s prior written consent.
There is no update service for these instructions for use. Please contact the
manufacturer to keep abreast of new developments.
SPECIFICATIONS AND INTENDED USE (for indoor and outdoor use)
The STELLA rollator is intended as a walking aid for persons with reduced mobility
who weigh up to 300 lb (136 kg) for the standard model and 400 lb (180 kg) for
the heavy duty model. It also provides a limited seating function for temporary rest.
The rollator should be used only on firm, flat surfaces. It is not intended to be used
for any other purpose such as a climbing aid or to carry heavy loads. Any such use
can be dangerous!

3
- OWNER’S MANUAL
M O B I L I T Y
 WARNINGS:READCAREFULLYBEFOREUSING!
• Before sitting on the rollator, make sure the lumbar support is well positioned
horizontally to prevent falling backwards. Be sure that both knobs are fully
tightened at same height.
• Before sitting on the rollator, make sure the wheel locks are locked down.
• Before sitting on the rollator, put your hands on the hand grips and back-up
until your legs touch the seat.
• Do not lean to one side, always keep your weight balanced on the rollator.
• Do not hang bags or other items from hand grips – risk of tipping over!
• Changing direction abruptly could make the rollator tip over.
• Use this rollator on flat surfaces only.
• Do not use the rollator to go up or down escalators.
• If excess weight is put onto the hand grips, the rollator could tip backwards.
• When folding or unfolding the rollator, watch for possible pinch points.
• Do not use your walking aid to replace a wheelchair or transport chair.
When seated, the brakes should be applied.
• Test the brake handles to make sure the rollator brakes work properly.
• All the fabric exposed directly to the sun could become hot and burn
your skin, make sure before using after a long exposition in the sun.
We recommend you cover your rollator when in direct sun.
 IFYOURROLLATORBECOMESDEFECTIVE:
• Do not try to repair it yourself, contact your authorized dealer immediately.

4
YOUR ROLLATOR
1. Ergonomic handgrips
2. Brake handles
3. Back strap
height adjustment
4. Handgrip height
adjustment
5. Folding mechanism
6. Brake
CLEANING/MAINTENANCE/REUSE
Cleaning
Clean and disinfect the rollator at regular intervals. To do so, use mild soapy water
with no scouring additives. You can disinfect the rollator using commercially
available products. Never use steam degreasers. Never use scouring or harmful
cleaning agents.
Maintenance
The STELLA rollator requires low-maintenance. If the braking function weakens,
wheel movement becomes stiff or you notice any other functional impairment,
please take the rollator to your authorized dealer for servicing.
Reuse by third parties
If you pass on your rollator to a new user, please remember also to hand over all
the technical documentation needed to ensure safe operation. In accordance with
specifications, the rollator must first be inspected, cleaned and returned to pristine
condition by an authorized dealer.
5
2
3
4
6
1

5
- OWNER’S MANUAL
M O B I L I T Y
USING AND ADJUSTING YOUR ROLLATOR
1. SETTING UP/UNFOLDING YOUR ROLLATOR
Place the rollator in front of you in the
direction of travel and put the parking
brake on.
Pull the seat strap to release the
locking mechanism, press the tubes
on either side of the seat down to the
left and right until the folding locking
mechanism clicks into place.
2. BRAKE HANDLES
Pull to brake (FIG.1):
Pull up the brake handle to
slow down or stop the rollator.
Push to lock (FIG. 2):
Push down the brake handle to
lock the rollator in its position.
3. BRAKE ADJUSTMENT
The brake is set correctly if there is
no play in either the brake lever
or the cable and if the wheels turn
without rubbing.
The braking strength can be adjusted
using the gray receiver by pushing it
(FIG.1) and loosening or tightening
the cable (FIG.2).
FIG.1
FIG.2
FIG.1 FIG.2

6
using and adjusting your rollator (continued)
4. CLIMBING SMALL OBSTACLES
Pressing your foot down on the extended
frame makes it easier to lift the front
wheels to negotiate curbs.
5. HANDLE HEIGHT ADJUSTMENT
Activate the brake to immobilize the
rollator.
Press the gray adjustment button until you
obtain the required height which should
be while standing, the wrist at the height
of the handgrip. Once positioned, release
the gray button.
6. BACK STRAP ADJUSTMENT
(FIG.1):
Unscrew the gray knobs (on both sides
of the rollator) and slide the back strap
on the extruded handle until the required
height. The back strap should
be well positioned in the back in the
lumbar area.
(FIG.2):
Once positionned, tighten the gray knobs.
FIG.1
FIG.2

7
- OWNER’S MANUAL
M O B I L I T Y
using and adjusting your rollator (continued)
7. SITTING
Before sitting down, be sure that the
rollator is on a level surface and lock the
brake handles.
Before getting up, make sure the brake
handles are still in lock position and
place your hands on the handgrips
as a support.
8. FOLDING YOUR ROLLATOR
Pull the strap in the middle of the seat
and pull upwards (FIG.1) until the rollator
locks in folded position (FIG.2).
9. ATTACHING/REMOVING THE CARRY BAG
To remove the carry bag, fold the rollator
slightly (FIG.1) and slide bag out of
receptacle pulling on both ends (FIG.2).
To replace the bag, reverse above steps.
The SWL (safe working load) is
4.5 kg (10 lb)
FIG.1 FIG.2
FIG.2
FIG.1

using and adjusting your rollator (continued)
10. CUP HOLDER INSTALLATION
(FIG.1) : The installation of the cup holder
(reversible left or right) requires no
tools. Simply clip it below the handle on
the opposite side of the cane holder.
(FIG.2) : Adjust the cup holder direction
according to your preference.
The cup holder (safe working load) is
1.3 kg (3 lb)
11. CANE HOLDER INSTALLATION
No tools are necessary for the installation
of the cane holder (reversible left or right).
Simply clip both cane holder’s parts to the
same side.
(Fig.1): Clip the cane holder’s upper part
underneath the handle.
(Fig.2): Clip the cane holder’s bottom part
above the brake or above the front wheel.
(FIG.3) : For proper cane alignment once
clipped, both parts can be rotated to
desired angle.
The cane holder SWL (safe working load)
is 1.3 kg (3 lb)
FIG.2
FIG.1
FIG.3
FIG.1
FIG.2

9
- OWNER’S MANUAL
M O B I L I T Y
TECHNICAL SPECS
SPECIFICATIONS STELLA 18 STELLA 20 STELLA 23 STELLA HD
Seat height
18’’
(455 mm)
20’’
(510 mm)
23’’
(585 mm)
20’’
(510 mm)
Seat width
17.5’’
(445 mm)
17.5’’
(445 mm)
17.5’’
(445 mm)
19.5’’
(495 mm)
Overall width
24’’
(610 mm)
24’’
(610 mm)
24’’
(610 mm)
26’’
(660 mm)
Handle height
29.5’’ - 34.5’’
(750 mm - 875 mm)
30.5’’ - 35.5’’
(775 mm - 900 mm)
33.5’’ - 38.5’’
(850 mm - 980 mm)
30.5’’ - 35.5’’
(775 mm - 900 mm)
Overall length
28.5’’
(725 mm)
28.5’’
(725 mm)
28.5’’
(725 mm)
28.5’’
(725 mm)
Weight capacity
300 lb
(136 kg)
300 lb
(136 kg)
300 lb
(136 kg)
400 lb
(182 kg)
Weight
14.5 lb
(6.6 kg)
14.5 lb
(6.6 kg)
15 lb
(6.8 kg)
16 lb
(7.3 kg)
LIMITED WARRANTY
Amylior warrants this product to be free of defects in materials and workmanship.
The STELLA rollator has a lifetime warranty on the aluminum frame, 5 years on the
brake handles and a 12-month warranty on all other parts. Parts subject to wear or
misuse such as upholstery, handgrips and wheels are excluded from warranty.
If this product is found to be defective, it will be repaired or replaced according to
the manufacturer’s decision. This warranty does not cover freight or labor charges
incurred during the repair or replacement of this product.
Amylior supplies products which respect the highest standards of quality. This product
was assembled according to these standards and inspected carefully before delivery.
This limited warranty represents our confidence in our materials and workmanship.
For service, contact the dealer where you purchased this product.
If for any reason, you are not satisfied, you may contact us directly. If you need
to contact us, you must have available the product name, serial number, date of
purchase and the dealer name.
DO NOT return any products without prior authorization. This warranty does not
cover problems caused by improper or abusive use by the user.

10
OUR MISSION
Amylior’s mission is to design and distribute rehabilitation products that will help
improve the quality of life of people with a loss of autonomy.
To reach its goal, Amylior works closely with therapists, medical equipment specialists
and end-users to meet the challenges people with a loss of autonomy face every day.
OUR VALUES
Amylior strives to improve the daily life of people with reduced mobility.
That is the reason why Amylior offers affordable, high-quality products and
unparalleled service.
Our corporate values speak for themselves:
• Quality : offering superior products and impeccable service at all times,
without compromise.
• Attentiveness : meeting the real needs of people with reduced mobility.
• Compassion : understanding our customers with reduced mobility who
use our products.
CONTACT US:
[e-mail]
www.amylior.com
3190 F.-X.-Tessier
Vaudreuil-Dorion, QC
J7V 5V5, Canada
[phone]
