Vermeiren Gemini 2 User manual

VERMEIREN
Gemini 2
U S E R M A N U A L
M A N U E L D ' U T I L I S A T I O N
G E B R U I K S A A N W I J Z I N G
G E B R A U C H S A N W E I S U N G
M A N U A L E D I I S T R U Z I O N I
M A N U A L D E I N S T R U C C I O N E S
I N S T R U K C J A O B S Ł U G I
N Á V O D K O B S L U Z E

Instrukcje dla wyspecjalizowanego
All rights reserved, including translation.
Tous droits réservés, y compris la traduction.
Alle rechten, inclusief vertaling, voorbehouden.
Alle Rechte, auch an der Übersetzung, vorbehalten.
Tutti i diritti riservati (anche sulla traduzione).
Todos los derechos reservados, incluidos los de la
traducción.
Wszelkie prawa zastrzeżone, łącznie z tłumaczeniem.
Všechna práva vyhrazena, včetně překladu.
EN
Instructions for specialist dealer
This instruction manual is part and parcel of the
product and must accompany every product
sold.
Version: D, 2021-06
FR
Instructions pour les distributeurs
Ce manuel d'instructions fait partie du produit et
doit accompagner chaque produit vendu.
Version : D, 2021-06
NL
Instructies voor de vakhandelaar
Deze handleiding is deel van het product en
dient bij iedere product te worden geleverd.
Versie: D, 2021-06
DE
Hinweise für den Fachhändler
Diese Gebrauchsanweisung ist Bestand-teil des
Produkts und ist bei jeder Produkts
auszuhändigen.
Version: D, 2021-06
IT
Istruzioni per il rivenditore
Il presente Manuale di istruzioni è parte
integrante del prodotto e deve essere fornito
assieme alla prodotto.
Versione: D, 2021-06
ES
Instrucciones destinadas a los distribuidores
especializados
El presente manual de instrucciones es parte
integrante del producto yse debe adjuntar a
todas las producto que se vendan.
Versión: D, 2021-06
PL
sprzedawcy
Niniejsza instrukcja obsługi jest nieodłączną
częścią produktu i musi być dołączona do
każdego sprzedawanego produktu.
Wersja: D, 2021-06
CS
Pokyny pro specializovaného prodejce
Tento návod k obsluze je součástí dodávky a
musí být součástí každého prodaného
produktu.
Verze: A, 2021-06
Basic UDI: 5415174 122103Gemini 2 9D
Multi version: A, 2021-06

Gemini 2
2021-06
Contents
1
EN
NL
Contents
Contents ..................................................................................................................... 1
Preface........................................................................................................................ 2
1 Your product .................................................................................................. 3
1.1 Accessories ................................................................................................... 3
2 Before use ..................................................................................................... 4
2.1 Intended use ................................................................................................. 4
2.2 Explanation of symbols ................................................................................. 4
2.3 General safety instructions ............................................................................ 4
2.4 Transport ....................................................................................................... 5
2.5 Assembling / Disassembling the wheelchair ................................................. 5
2.6 Storage ......................................................................................................... 6
3 Using your wheelchair .................................................................................. 7
3.1 Operating the brakes ..................................................................................... 7
3.2 Comfort adjustments ..................................................................................... 7
3.3 Transfer in and out of the wheelchair .......................................................... 11
3.4 Riding the wheelchair .................................................................................. 12
4 Maintenance ................................................................................................ 13
4.1 Points of maintenance ................................................................................. 13
4.2 Maintenance instructions ............................................................................ 13
4.3 Troubleshooting .......................................................................................... 14
4.4 Expected lifespan ........................................................................................ 14
4.5 Reuse .......................................................................................................... 14
4.6 End of use ................................................................................................... 14
4.7 Warranty ...................................................................................................... 14
5 Technical specifications ............................................................................. 15

Gemini 2
2021-06
Preface
2
EN
NL
Preface
Congratulations! You are now owner of a Vermeiren wheelchair!
This wheelchair is made by qualified and committed personnel. It is designed and produced
according to high quality standards, guarded by Vermeiren.
Please read this manual carefully; it will help you to get familiar with the operation, capabilities
and limitations of your wheelchair. If you still have questions after reading this manual, do not
hesitate to contact your specialist dealer. He/she will be glad to help you.
Important note
To ensure your safety, and to prolong the lifetime of your product, please take good care of it and
have it checked and serviced on a regular basis.
This manual reflects the latest product developments. Vermeiren has the right to implement
changes to this type of product without any obligation to adapt or replace similar products
previously delivered.
Pictures are used to clarify the instructions in this manual. Details of the depicted product may
deviate from your product.
Information available
On our website http://www.vermeiren.com/ you will always find the most recent version of the
information in this manual. Please consult this website regularly for possible updates.
Visually impaired people can download the electronic version of this manual and have it read out
by means of a text-to-speech software application.
User manual For user and specialist dealer
Installation instructions For specialist dealer
Service manual for wheelchairs For specialist dealer
EC declaration of conformity

Gemini 2
2021-06
Your product
3
EN
NL
1 Your product
1.1 Accessories
The following accessories are available for the Gemini 2:
 Rain cover
 Canopy
 Leg cover
 Foot fixation strips
 Side cushions
 Stabilisation and support pieces
Contact your specialist dealer about other accessories. He will gladly advise you.
1
2
3
4
5
6
7
8
9
10
11
1. Push bar
2. Backrests
3. Safety belt
4. Seat
5. Footrest
6. Footplate
7. Steering wheels (front
wheels)
8. Driving wheels (rear wheels)
9. Brake
10. Frame
11. Location identification plate

Gemini 2
2021-06
Before use
4
EN
NL
2 Before use
2.1 Intended use
In this paragraph a brief description of the intended use of your wheelchair is given. Additionally,
relevant warnings are added to the instructions in the other paragraphs. In this way we would like
to make you aware of the possible misuse that may appear.
 Indications and contraindications: The wheelchair can be pushed by an attendant or parent.
The wheelchair is intended for children with a disability or movement dysfunction because of
brain damage. The modular construction allows you to choose the optimal design for your
child’s specific needs.
 The wheelchair is suited for indoor and outdoor use.
 The wheelchair is designed to transport one (1) child with a maximum weight as specified in
§5. It is not designed for transportation of goods or objects, nor for any use other than
previously described.
 Only use accessories and spare parts approved by Vermeiren.
 Please read all technical details and limits of your wheelchair in chapter 5.
 The warranty of this product is based on normal use and maintenance as described in this
manual. Damage to your product caused by improper use or lack of maintenance will cause
the warranty to lapse.
2.2 Explanation of symbols
Maximum weight of the user in kg
Indoor/outdoor use
Maximum safe slope in ° (degrees).
Type designation
2.3 General safety instructions
 As an attendant, do not use the wheelchair if you are under the influence of alcohol, medicines
or other substances that may influence your riding abilities.
 Be aware that some parts of your wheelchair may get very hot or cold due to ambient
temperature, solar radiation or heating devices. Be careful when touching. Wear protective
clothing if the weather is cold. When going outdoors, riding gloves can be used to improve the
grip on the hand rims.
 Do not modify your wheelchair in any way.
 To prevent injury and/or damage to your wheelchair, make sure that no objects and/or body
parts are caught in the spokes of the driving wheels.
Be aware that your wheelchair may interfere with some types of anti-theft systems, depending on
the settings used. This may cause the shop's alarm to go off.

Gemini 2
2021-06
Before use
5
EN
NL
2.4 Transport
2.4.1 Moving out of the way
The best way to move the wheelchair is to make use of the wheels and roll the wheelchair.
If this is not possible (e.g. when the rear wheels are taken off for transportation in a car), firmly
grasp the frame on the front and rear. Do not use the footrests or the wheels to grasp the
wheelchair.
2.4.2 Transport by vehicle, as luggage
Risk of injuries
Do NOT use your wheelchair as seat in a vehicle, see the symbol.
Never use the same safety belt for passenger and wheelchair.
1. Fold the wheelchair to its most compact size according to the instructions in § 2.5.
2. Store the wheelchair and its wheels in the luggage compartment or behind the passenger seat.
If luggage and passenger compartments are NOT separated or enclosed, fasten the
wheelchair frame securely to the vehicle.
2.5 Assembling / Disassembling the wheelchair
Risk of injuries
Keep fingers away from moving parts of the wheelchair.
To fold the wheelchair:
1. Use the central brake to stop the wheelchair from moving,
see §3.1.
2. Pull the red lever under the front of the seat (1). The lever
can be reached through the opening in the leg rest
upholstery, or by folding up the leg rest upholstery.
3. Lift the front of the seat up and pull the seat as a whole
forward. You can now remove the seat from the frame.
4. Pull parts (2) upwards on both sides until the upper frame
is unlocked.
5. Push the push bar (3) to the front to fold the frame.
6. Let the frame rest on the rear wheels and frame tube. Now the
frame can be folded completely.
7. Turn the push bar downwards, see §3.2.9.
8. If necessary, take off accessories from the seat and fold the
backrest down (4).
WARNING
CAUTION
1
2
3
4

Gemini 2
2021-06
Before use
6
EN
NL
To unfold the wheelchair:
1. Grasp the push bar (3) and move it upwards to unfold the frame.
2. Turn the frame so the front and rear wheels can rest on the ground.
3. Move the push bar backwards to unfold the frame completely.
4. Check that parts (2) click over the lower frame tube and the frame is firmly secured.
5. Turn the push bar in the desired position, see §3.2.9.
6. Take the seat and unfold the backrest if necessary.
7. Install the rear of the seat first*: the two metal hooks must be placed over the lower frame
rod that is furthest away from the front of the seat.
8. When the rear of the seat has been placed correctly, the front can be easily locked by
pushing down. A click will be heard.
9. Make sure that the seat has been attached properly to the lower frame.
10. Adjust the seat for the comfort of your child and install any accessories that had been
removed for transport (see §3.2).
*The seat of Gemini 2 can be installed with your child facing forwards or facing towards you as
you push. The same instructions apply for both options.
It is also possible not to remove the seat and fold the Gemini 2. Be aware that you should first
remove all the accessories and supports before completely folding the backrest to the front.
2.6 Storage
Make sure that your wheelchair is stored in a dry environment to prevent mould from
growing and the upholstery from being damaged, see also chapter 5.

Gemini 2
2021-06
Using your wheelchair
7
EN
NL
3 Using your wheelchair
Risk of injuries and/or damage

First read previous chapters and inform yourself about the intended use. Do NOT use your
wheelchair unless you have read and fully understood all instructions.
 In case of doubts or questions, do not hesitate to contact your local specialist dealer,
your care
provider or technical adviser to help you with this.

Make sure that your hands, clothes, belts, buckles or jewellery don’t get caught by wheels or
other moving parts, during use or adjustment.
3.1 Operating the brakes
Risk of injury
 The brakes are not used to slow down the wheelchair during movements. Use the brake only
to prevent the wheelchair from unintended movements.
 Good operation of the brakes is influenced by wear and contamination of the tires (water, oil,
mud, …). Check the condition of the tires before each use.
 The brakes are adjustable and can wear. Check the operation of the brakes before each use.
 Make sure the wheelchair is on a flat horizontal surface before releasing the brakes. Never
release both brakes simultaneously.
Gemini 2 brakes are operated by one central brake lever:
 Push the central brake in direction (1) to activate the
brake.
 By pushing the central brake in direction (2), the brake
will be released.
3.2 Comfort adjustments
Risk of injury and/or damage
Make sure that all adjustments are firmly secured before using the wheelchair.
3.2.1 Seat inclination
1. Press the lever (3) on the side of the push bar.
2. Press down on/lift the front of the seat until the desired
inclination.
3. Release the lever.
CAUTION
WARNING
WARNING
1
2
3

Gemini 2
2021-06
Using your wheelchair
8
EN
NL
3.2.2 Backrest inclination
Seat width 32:
1. Loosen the lever (4) on the rear side of the
backrest.
2. Push or pull the backrest tubes in the desired
position (from folded position for easy transport, to
lying down position: 0° - 45°). The backrest
automatically stops when it reaches the maximum
inclination.
3. Retighten the lever (4).
4. Check that the backrest is well fixated.
Seat width 40:
1. Pull the pin (5).
2. Pull or push the backrest until the desired angle (6 different positions
in steps of 8°). The backrest automatically stops when it reaches the
maximum inclination.
3. Release the pin (5).
4. Check that the backrest is well fixated.
There is an extra hole that prevents that the backrest will be lift back in the
vertical position when the backrest is folded to the seat (for transportation
purposes).
3.2.3 Backrest height
Remove the upholstery to alter the backrest
height.
1. Loosen the two wing nuts (6) on the back of
the backrest.
2. Move the upper part (headrest) (7) of the
backrest upwards or downwards until the
desired backrest height.
3. Retighten the two screws and wing nuts (6)
firmly by hand.
4
5
6
7

Gemini 2
2021-06
Using your wheelchair
9
EN
NL
3.2.4 Footrest inclination
1. Loosen the levers (8) on both sides.
2. Adjust the footrest to the desired position
(stepless; range 83° for seat width 32, range
85° for seat width 40).
3. Retighten both levers (8).
4. Make sure that the footrest is firmly fixated.
3.2.5 Footrest length (only for seat width 32)
The footrest can be set into 4 different lengths (steps
of 30 mm):
1. Retract both blocking pins (9).
2. Slide the footplate up/down to the desired
position.
3. Block the undercarriage again with the blocking
pins (9).
4. Make sure the footplate is firmly fixated.
3.2.6 Foot supports (optional)
The angle of the foot supports (10) can be adjusted in several positions (Seat width 32: 5 positions,
10° steps – Seat width 40: 4 positions, 8,5° steps)
1. Loosen the wing nuts (11) on het bottom of the footplate.
2. Turn the foot supports (10) in the desired position.
3. Retighten the wing nuts (11).
4. Make sure that the foot supports are firmly fixated.
8
9
11
10
10
11
32
40

Gemini 2
2021-06
Using your wheelchair
10
EN
NL
3.2.7 Side supports (optional)
Head pelots
Adjusting width:
1. Loosen the two knurled knobs (12) on the rear
side of the backrest.
2. Move the head pelot (13) inwards or outwards
until the desired position (stepless, range 25
mm each side).
3. Retighten the two knurled knobs (12).
4. Check that the pelot (13) is well fixated.
5. Repeat these instructions for the other pelot
(13).
Adjusting height:
1. Loosen the two knurled knobs (12) on the rear
side of the backrest.
2. Move the head pelot (13) up or down until the
desired height (stepless, range 30 mm).
3. Retighten the two knurled knobs (12).
4. Check that the pelot (13) is well fixated.
5. Repeat these instructions for the other pelot
(13).
Adjusting height:
1. Loosen the two knurled knobs (14) on the side
of the pelot.
2. Move the head pelot (15) up or down until the
desired height (stepless, range 25 mm).
3. Retighten the knurled knobs (14).
4. Check that the pelot (15) is well fixated.
5. Repeat these instructions for the other pelot.
Adjusting depth:
1. Loosen the two knurled knobs (14) on the side
of the pelot.
2. Move the head pelot (15) to the front or back
until the desired depth (stepless, range 22,5
mm).
3. Retighten the two knurled knobs (14).
4. Check that the pelot (15) is well fixated.
5. Repeat these instructions for the other pelot.
12
13
14
15

Gemini 2
2021-06
Using your wheelchair
11
EN
NL
Backrest pelots height
The backrest pelots (16) can be placed in 2 positions
(40 mm distance). Slightly lift the pelot upwards to
detach it from the backrest. Place it in the desired
position by placing the screws (17) through the holes in
the backrest. Repeat for the other pelot.
3.2.8 Abduction Wedge (optional)
The abduction wedge (18) is mounted with two
wing nuts (19). It can easily be removed by
loosening/tightening the wing nuts (19).
The abduction wedge can be moved
forward/backward over a distance of 115 mm.
3.2.9 Push bar position
Simultaneously push both buttons (20) at the clamp
of the pushbar and move to the desired position.
Releasing the buttons (20) on the clamp will
automatically lock the pushbar in the desired
position.
3.3 Transfer in and out of the wheelchair
Risk of injury and/or damage
 Do not stand on the footplates.
1. Position the wheelchair as close as possible to the chair, couch or bed to/from which you
wish to transfer.
2. Check that the central brake is activated.
3. Transfer the child to/from the wheelchair.
4. Secure the safety belt.
WARNING
20
16
16
17
17
18
19

Gemini 2
2021-06
Using your wheelchair
12
EN
NL
3.3.1 Correct position in the wheelchair
Some recommendations for a comfortable use of the wheelchair:
 Position your backside as close as possible to the backrest.
 Make sure your upper legs are horizontal. If needed, adjust the length of the footrests.
3.4 Riding the wheelchair
Risk of injuries and damage
 Before every usage, make sure that:
o parking brakes are working properly.
o tires are in good condition, see §4.
 Prevent your fingers from being caught by the wheel spokes.
 Do NOT drive on slopes, obstacles, steps or kerbs larger than specified in §5.
 When you stop on a (small) slope, use your brakes.
 Make sure all four wheels touch the ground while riding up or down a slope.
 Pay attention if the road has holes or gaps that may cause entrapment of the wheels.
 Avoid stones and other objects that may block the wheels.
 Make sure that the footplates do not touch ground while taking an obstacle.
 Use the safety belt.
 Always keep the swing range of the footplate in mind to prevent
bystanders from being injured
or objects from being damaged.

Stairs should always be negotiated with the help of two attendants.
3.4.1 Riding your wheelchair
The wheelchair can only be operated by an attendant:
1. Take hold of the push bar.
2. Release the brakes.
3. Push the wheelchair.
CAUTION

Gemini 2
2021-06
Maintenance
13
EN
NL
4 Maintenance
4.1 Points of maintenance
Risk of injuries and damage
Repairs and replacements may only be undertaken by trained
persons and only genuine
replacement parts of Vermeiren should be used.
The service frequency depends on the frequency and intensity of use. Contact your dealer
to agree to a common timetable for inspection/maintenance/repair.
For the maintenance manual, refer to our website: www.vermeiren.com .
Before each use
Inspect the following points:
 All parts: Present and undamaged or unworn.
 All parts: Clean, see § 4.2.2.
 Wheels, backrest, seat, calf rests, arm rests, footplate: Well secured.
 Condition of wheels/tyres, see § 4.2.1;
 Condition of frame parts: No deformation, instability, weakness or loose connections
 Seat, backrest, arm pads, calf pads and head rest (if applied): No excessive wear (like
dented spots, damage or tears).
 Brakes: Undamaged and functioning
Contact your specialist dealer for possible repairs or part replacements.
Yearly or more often
Have your wheelchair inspected and serviced by your specialist dealer, at least once a year, or
more often. The minimum maintenance frequency depends on use and should therefore be
commonly agreed on with your specialist dealer.
4.2 Maintenance instructions
4.2.1 Wheels and tyres
Proper working of the brakes depends on the state of the tyres, and can change due to
wear and contamination (water, oil, mud, …).
Keep your wheels free of wires, hair, sand and fibres.
Check the profile of the tyres. If the tread depth is less than 1 mm, the tyres need to be replaced.
Contact your specialist dealer for this matter.
Inflate each pneumatic tyre to the correct pressure (see pressure indication on the tyres).
4.2.2 Cleaning
Risk of damage by moisture

Never use a hose or high
-
pressure cleaner to clean the wheelchair.
Wipe all rigid parts of the wheelchair with a damp cloth (not drenched).
If necessary, use a mild soap, suitable for varnishes and synthetics.
The upholstery can be cleaned with lukewarm water and a mild soap. Do not use abrasive
cleaning agents to clean.
CAUTION
CAUTION

Gemini 2
2021-06
Maintenance
14
EN
NL
4.2.3 Disinfection
Risk of damage

Disinfections may only be
undertaken by trained persons. Consult your specialist dealer.
4.3 Troubleshooting
Even if you use your wheelchair properly, a technical problem may occur. If this is the case,
contact your local specialist dealer.
Risk of injuries and damage to the wheelchair

NEVER attempt to repair the wheelchair yourself.
The following symptoms may indicate a serious problem. Therefore always contact your specialist
dealer if you spot any of the following deviations:
 Strange sound;
 Uneven tread wear on one of the tyres;
 Jerky movements;
 Wheelchair deflects to one side;
 Damaged or broken wheel assemblies.
4.4 Expected lifespan
The average lifespan of your wheelchair is 5 years. Depending on the frequency of use, driving
circumstances and maintenance, the lifespan of your wheelchair will increase of decrease.
4.5 Reuse
Before each reuse, have the wheelchair disinfected, inspected and serviced according to the
instructions in §4.1 and §4.2.
4.6 End of use
At end of life, you need to dispose your wheelchair according to the local environmental
legislation. The best way to do so, is to disassemble the wheelchair to facilitate the transport of
recyclable parts.
4.7 Warranty
The warranty on this product is subject to the general terms and conditions of each country, as
you can consult on our company website.
CAUTION
WARNING

Gemini 2
2021-06
Technical specifications
15
EN
NL
5 Technical specifications
The technical details below are only valid for this wheelchair, at standard settings and optimal
ambient conditions. Take these details into account during use.
The values are no longer applicable if your wheelchair has been modified, damaged or suffers
from severe wear.
Table 1: Technical specifications
Make
Vermeiren
Type
Manual wheelchair
Model
Gemini 2
Description
Seat width 32
Seat width 40
Maximum occupant mass 35 kg 50 kg
Overall length with footrest 950 mm 1060 mm
Effective seat width 320 mm 400 mm
Overall width 620 mm 690 mm
Overall height 1200 mm 1275 mm
Folded length 820 mm 930 mm
Folded width 620 mm 690 mm
Folded height 460 mm 560 mm
Total mass 18 kg 27 kg
Mass of heaviest part Seat: 7,2 kg Seat: 13,55 kg
Effective seat depth 300 - 360 mm 380 - 430 mm
Seat surface height at front edge 510 mm 510 mm
Seat angle -25° - +30° -25° - +30°
Backrest height 520 - 640 mm 650 - 780 mm
Backrest angle 0° - 45° 0° - 40°
Distance between footrest and seat 250 - 340 mm 315 - 400 mm
Angle between seat and footrest 2,5° - 85,5° 3° - 88°
Distance between armrest and seat 200 mm 200 mm
Front location of armrest structure 235 mm 310 mm
Horizontal location of axle (deflection) 230 mm 150 mm
Minimum turning diameter Footplate folded up: 1200 mm
Footplate folded down: 1480 mm
Footplate folded up: 1620 mm
Footplate folded down: 1850 mm
Diameter Rear wheels 295 x 50 mm
Tyre pressure, rear (driving) wheels Max. 2.5 bar
Diameter Steering wheels 200 x 40 mm
Tyre pressure, front (steering) wheels Max. 2.5 bar
Storage and use temperature + 5 °C - + 41 °C
Storage and use humidity 30% - 70%
We reserve the right to introduce technical changes. Measurement tolerance ± 15 mm / 1,5 kg / 1,5°

Gemini 2
2021-06
Table des matières
1
EN
FR
NL
Table des matières
Table des matières..................................................................................................... 1
Préface........................................................................................................................ 2
1 Votre produit .................................................................................................. 3
1.1 Accessoires ................................................................................................... 3
2 Avant l’utilisation .......................................................................................... 4
2.1 Utilisation prévue........................................................................................... 4
2.2 Explication des symboles .............................................................................. 4
2.3 Instructions générales de sécurité................................................................. 4
2.4 Transport ....................................................................................................... 5
2.5 Montage / démontage du fauteuil roulant ...................................................... 5
2.6 Entreposage .................................................................................................. 7
3 Utilisation ...................................................................................................... 8
3.1 Utilisation des freins ...................................................................................... 8
3.2 Réglages de confort ...................................................................................... 8
3.3 Transfert dans et hors du fauteuil roulant .................................................... 13
3.4 Déplacements avec le fauteuil roulant ........................................................ 13
4 Entretien ...................................................................................................... 14
4.1 Points d’entretien ........................................................................................ 14
4.2 Instructions d’entretien ................................................................................ 14
4.3 Résolution des problèmes ........................................................................... 15
4.4 Durée de vie attendue ................................................................................. 15
4.5 Réutilisation ................................................................................................ 15
4.6 Mise au rebut .............................................................................................. 15
4.7 Garantie ...................................................................................................... 15
5 Spécifications techniques .......................................................................... 16

Gemini 2
2021-06
Préface
2
EN
FR
NL
Préface
Félicitations ! Vous êtes à présent l’heureux propriétaire d'un fauteuil roulant Vermeiren !
Ce fauteuil roulant a été fabriqué par un personnel qualifié et responsable. Il est conçu et produit
conformément aux normes de qualité élevées, appliquées par Vermeiren.
Veuillez lire attentivement ce manuel. Vous pourrez ainsi vous familiariser avec le
fonctionnement, les capacités et les limites de votre fauteuil roulant. Si vous avez encore des
questions après la lecture de ce manuel, n’hésitez pas à prendre contact avec votre commerçant
spécialisé. Il vous aidera volontiers.
Remarque importante
Pour assurer votre sécurité et prolonger la durée de vie de votre produit, prenez-en grand soin et
faites-le contrôler ou entretenir régulièrement.
Ce manuel est le reflet des derniers développements du produit. Vermeiren a le droit d’apporter
des modifications à ce type de produit sans être tenu d'adapter ou de remplacer des produits
similaires fournis précédemment.
Les images sont fournies afin de clarifier les instructions de ce manuel. Les détails du produit
illustré peuvent diverger de votre produit.
Informations disponibles
Sur notre site Internet http://www.vermeiren.com/, vous trouverez toujours la dernière version
des informations décrites dans le présent manuel. Veuillez consulter régulièrement ce site
Internet pour connaître les éventuelles mises à jour.
Les personnes malvoyantes peuvent télécharger la version électronique de ce manuel et la lire
au moyen d'une application de texte-parole.
Manuel d'utilisation
Pour l'utilisateur et le revendeur spécialisé
Instructions d'installation
Pour le revendeur spécialisé
Manuel d'entretien des fauteuils roulants
Pour le revendeur spécialisé
Déclaration de conformité CE
