Continuum Maestro Opus User manual

Maestro Opus Pedicure Chair
INSTALLATION MANUAL
1-400-0089 • Rev A • 2/5/20
© Continuum 2020, All Rights Reserved
*shown with oponal accessories and/or nishes

READ AND SAVE THESE INSTRUCTIONS
1
IMPORTANT SAFETY INSTRUCTIONS - FOR COMMERCIAL USE ONLY
Read all instructions before using this product.
Safety Symbols
Familiarize yourself with the following
Safety & Warning symbols. They are
designed to prevent damage and
injury to you, your clients, and your new
Continuum product.
IMPORTANT: The important safety
instructions and warnings in this manual
cannot cover all possible problems and
conditions that can occur. Use common
sense and caution when installing,
operating, or maintaining this appliance.
Indicates an imminently hazardous
situation which could result in serious
or fatal injury.
Indicates a potentially hazardous
situation which could result in serious
injury.
Indicates a potentially hazardous
situation which could result in
equipment damage and/or injury.
SECTION 1: SAFETY INFORMATION
1. RISK OF ELECTRIC SHOCK. Connect only to a circuit protected by a ground-fault
circuit-interrupter (GFCI).
2. Grounding is required. The unit must be installed by a licensed electrician and
grounded.
This product must be grounded. If it should malfunction or break down, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This product is equipped with
a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into
an appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
Improper connection of the equipment-grounding connector can result in a risk of electric shock. Check
with a qualied electrician or serviceman if you are in doubt as to whether the product is properly grounded.
Do not modify the plug provided with the product - if it will not t the outlet, have a proper outlet installed by
a qualied electrician.
INSTALLATION INSTRUCTIONS / GROUNDING INSTRUCTIONS
Reset
Button
GFCI Outlet
Grounding Pin
Test
Button
See User Manual for all safety information and warnings pertaining to use of this product.

Length 61.25” (156 cm)
Width 36” (92 cm)
44.75” (113 cm), with side trays
Overall Height 52” (132 cm)
Seat Height 23.5” (60 cm)
Net Weight 310 lbs (141 kg)
Weight Capacity 300 lbs (136 kg)
Basin Capacity 5.7 gallons (22.3 liters)
Construcon
Welded steel frame with veneered wood panels or For-
mica® laminate; completely sealed to prevent delamina-
Basin Glass, pre-plumbed
Jet system One (1) standard NoPipe™ jet; removable screen and impel-
Massage Relaxor heat & massage
Chair Controls
Armchair
unlocks chair to allow swivel
2
SECTION 2: PRODUCT OVERVIEW
Product Specications

SECTION 3: INSTALLATION
3
• All pedicure chairs MUST be installed by a licensed electrician and a licensed plumber in
accordance with all naonal, state, and local codes/regulaons.
• Failure to comply with these codes and/or regulaons will result in the limited warranty
being null and void.
• Your chair will not operate properly unless it has sucient water pressure and
temperature, proper drainage and adequate electrical power.
• ANY INSPECTIONS OR APPROVALS ARE THE SOLE RESPONSIBILITY OF THE PURCHASER.
PRIOR TO INSTALLATION, ONE SHOULD CONTACT THEIR LOCAL BUILDING INSPECTOR TO
MAKE SURE ALL LOCAL CODES ARE COMPLIED WITH.
• IMPORTANT: Client’s venlaon intake needs to pull a minimum 80 CFM at the chair’s
connecon point to achieve 50 CFM from open vent.
Install to Permit Access for Servicing
EXTREMELY IMPORTANT:
Your warranty is null
and void if pedicure chair is not properly secured to nished oor.
• Locaon & Support:
• DEPENDING ON THE USE OF MANICURE TRAYS AND/OR CARTS, THE EXACT DISTANCE
BETWEEN PEDICURE CHAIRS WILL VARY GREATLY. THIS MUST BE DISCUSSED PRIOR
TO ORDERING PEDICURE CHAIRS. THIS WILL ENSURE PROPER INSTALLATION AND
ADEQUATE WORKING SPACE.
•
be noted chair does recline. To ensure chair does not touch back wall, please review
Step 1:
steel guard and not the wood or Formica®.
Step 2:
Installation Instructions
Important Installation Notes

4
SECTION 3: INSTALLATION
•
pedicure chair. Failure to do so renders the Limited Warranty null and void.
• I
Failure to do so renders the Limited Warranty null and void.
• Note: IF INSTALLED IN CANADA THIS UNIT MUST BE IN ACCORDANCE WITH THE
CANADIAN ELECTRICAL CODE, PART 1.
Electrical Requirements
•
•
• Maximum water temperature must not exceed 105F (41
•
•
provided.
•
Incoming:
Sprayer/Filler:
Discharge:
Size of supplied plumbing ngs:
•
•
Plumbing Requirements

SECTION 3: INSTALLATION
Top View
Minimum distance
from wall
5

SECTION 3: INSTALLATION
Bottom View - Shrouds Removed
6

Contact Us
Continuum
990 Joshua Way
Vista, CA. 92081
(877) 255-3030
(760) 597-5707 Int’l
Hours of operation:
Monday - Friday
8:00 a.m. to 5 p.m. PST
Saturday - Sunday
Closed
Visit us online at: mycontinuumpedicure.com
