Contro l4 RCZ-SRC2-B User manual

System Remote Control Version 2
User Guide

ii
Disclaimer Control4®makes no representations or warranties
withrespecttoanyControl4hardware,software,or
the contents or use of this publication, and
specifically disclaims any express or implied
warranties of merchantability or fitness for any
particular purpose. Control4 reserves the right to
make changes to any and all parts of Control4
hardware, software, and this publication at any
time, without any obligation to notify any person or
entity of such changes.
Trademarks Control4 is a registered trademark of Control4
Corporation. Other product and company names
mentioned in this document may be the
trademarks or registered trademarks of their
respective owners.
Copyright Copyright © 2004-2007 Control4 Corporation. All
rights reserved. No part of this publication may be
reproduced, photocopied, stored on a retrieval
system, or transmitted without the express written
consent of the publisher.
Control4 Corporation
11734 S. Election Road, Suite 200
Salt Lake City, UT 84020 USA
http://www.control4.com
System Remote Control Version 2 User Guide
Part Number: 200-00011 Rev A
Hardware Model Number: RCZ-SRC2-B

iii
Contents
Chapter 1 Get Started....................................1
Uses and Features ........................................1
About the Modes ...........................................2
What’s New in this Model ..............................4
Install and Maintain Batteries ........................6
About System Remote Control
RCZ-SRC2-B.................................................7
Chapter 2 Use the Remote Control ............17
Use Remote with On-Screen Navigator ......17
Use LCD Navigator......................................19
Control Devices...........................................19
Chapter 3 Regulatory Info...........................21
Regulatory Compliance ...............................21

iv

CHAPTER 1Get Started
Uses and Features
Control4 System Remote Control Version 2 (model # RCZ-
SRC2-B) is intended for use in a Control4®system. It is
included with the purchase of a Media Controller or Home
Theater Controller, but may also be purchased separately.
This remote control can be used to:
•Navigate system menus and access media databases
on a television or monitor
•Navigate system menus and access media databases
in its own LCD window
•Control system devices
This remote control goes beyond a typical “universal”
remote that simply learns IR codes from TVs, VCRs, CD
players, and DVD players. Features of this device include:
•Bi-directional communication with system components
•ZigBee wireless mesh networking
•LCD with menu that provides full system access
•LCD back-lighting for ease of use in dark rooms
•Media playlists and playing options for stored media
•One-button push to control systems (such as music,
television, or videos)
•Ergonomically designed for comfort
•Standard control features for: Digital Satellite Systems
(DSS), Cable Boxes, TV Tuners, Digital Video Record-
ers (DVR), DVD Players or Changers, VCRs, TVs,
MP3 Players or CD Players or Changers
•Powered by four AAA batteries (included)

2
About the Modes
This remote control supports three different modes of
operation:
•On-Screen Navigator mode: In this mode you
access and control all system devices through a moni-
tor or TV on-screen menu (On-Screen Navigator).
Press the Control4 button to access the On-
Screen Navigator home page (or main menu) and
then press a system button (such as Radio or TV) to
display the specific submenu on the TV screen.
•LCD Navigator mode: In this mode you access all
system components through the LCD menu. Press the
LCD button to enter LCD Navigator mode and
display a menu in the LCD and press Cancel to exit.
Once you choose a media source (broadcast or
stored), the remote enters Device-Control mode and
allows you to control the device associated with the
selected media. Note: The LCD goes to sleep after 15
seconds of inactivity and it will wake up with any button press.
•Device-Control mode: In this mode you use the
System Remote Control to control the selected device.
When devices in the room are off, press RADIO,
MUSIC, TV, or VIDEOS button to enter the Device-
Control mode and begin controlling one of the associ-
ated devices. By default, it will be the most recently
used device (such as Multi Tuner) for the selected sys-
tem (such as Radio) in the current room. The remote
control will continue to control the current device until
another device is accessed.
The current mode affects the remote control behavior. The
following table shows a high-level summary of how
functionality differs from mode to mode.

3
Remote
Control
Section:
On-Screen
Navigator
mode:
LCDNavigator
mode: Device-Control mode:
LCD NA Displays LCD
menus related
to current
system.
NA
Control4 Button Press to
view On-Screen
Navigator on
your monitor/TV.
NA NA
SystemButtons If a video device
is currently on,
press one to
display system-
specific menu on
the TV.
Press one to
display system-
specific menu in
the LCD and to
choose the
device or
playback to be
controlled.
Press Radio, Music,
TV, or Videos to start
the selected system
and control play.
Press A, B, C, or D to
run room-specific or
device-specific
program.
Navigation
Buttons Use arrows to
move the
highlighter on the
TV around or
press Select to
choose the
highlighted item.
Use arrows to
move through
the LCD menu
levels or press
Selecttochoose
the highlighted
item.
Use buttons to
control sound,
change channels, or
view information
about current media
or broadcast.
Control Buttons
 
NA NA Control current
device or playback.
Numeric
Keypad
1 2 3
NA Use numbers to
select lighting
levels.
Enter specific TV
channel number or, if
device-specific
programming is
present, press
* or # to run.

4
What’s New in this Model
System Remote Control Version 2 (Model # RCZ-SRC2-B) is
the next generation of Control4 system remotes:
•We renamed, relocated, and replaced several buttons.
•We replaced black rubber with light, glow-in-the-dark
rubber.
•We added device-level programmable buttons so that
installers could program one-button shortcuts.
Table 6–1 summarizes changes from Version 1 to 2.
TABLE 6–1. CHANGES TO BUTTONS AND FUNCTIONS
Was...RCZ-SRC1-B:
Old Button Name and Function Now is...RCZ-SRC2-B: New Button Name and Function
POWER
Turned off all A/V devices in room. OFF Turns off all A/V devices in room.
DISPLAY
Provided access to Configuration
menu for the LCD.
LCD
Enters LCD Navigator mode: Displays
top menu of LCD Navigator in the LCD.
Note: The Configuration menu for the
LCD is now located under “Info” in LCD
Navigator.
RADIO, MUSIC, TV, and VIDEOS
•Short press entered LCD
Navigator mode: Displayed
chosen system menu in LCD
and chose the device to be
controlled.
•Long press when a TV was
on would display the chosen
system options on top of the
current display on the TV.
RADIO, MUSIC, TV, and VIDEOS
•Initial press provides shortcut to
the selected system—puts remote
control into Device-Control mode
and turns on the last used source
(such as a TV tuned to the last TV
broadcast). The Room name and
current device display in the LCD.
•Subsequent presses toggle
through available sources for the
selected system (such as
alternative TV sources).

5
COMFORT, LIGHTS, HOUSE,
and INFO
•Short press entered LCD
Navigator mode: Displayed
chosen system menu in LCD
and chose the device to be
controlled.
•Long press when a TV was
on would display the chosen
system options on top of the
current display on the TV.
COMFORT (A), LIGHTS (B), HOUSE
(C), and INFO (D)
•If in On-Screen Navigator mode,
these buttons provide shortcuts to
their system’s On-Screen menu
(Comfort, LIghts, House, or Info).
•If in LCD Navigator mode, these
buttons provide shortcuts to their
system’s LCD menu (Comfort,
LIghts, House, or Info).
•If in Device Control mode, these
buttons can be used as A, B, C, or
D---programmable buttons that
may have custom shortcuts for the
room or current device.
PAGE 
Page up/down for satellite & Cable
menuing.
CHANNEL + -
Arrows are changed to +/-, PAGE label
on top case is changed to "CHANNEL".
Now functions as channel up and
channel down for appropriate devices.
PIP and MENU
Picture in picture button; Menu
button for appropriate devices.
PAGE 
Up and Down arrows are printed on the
old PIP and MENU buttons
respectively. Functions as Page up/
down for satellite & cable menuing.
BACK
A Back button for menu navigation
with back arrow printed on button.
MENU
Functions as Menu button for
appropriate devices.
*Device-specific behavior *Available for custom programs
# Device-specific behavior # Available for custom programs
Was...RCZ-SRC1-B:
Old Button Name and Function Now is...RCZ-SRC2-B: New Button Name and Function

6
Install and Maintain Batteries
Install Batteries
Install the four AAA batteries (included with the
product) into the back of the device. Ensure
that you insert them into the remote control
according to the diagram provided in the
battery compartment (with the + and - terminals
aligned correctly).
Use and Care Tips
•Keep battery contacts and compartment
clean.
•Remove batteries from the remote control if
it is not expected to be in use for several
months.
•Extreme temperatures reduce battery per-
formance. Avoid putting the remote control
in very warm places.
Replacement Safety Rules
CAUTION! To prevent battery shorting, leakage or
rupture:
•Use typical AAA Alkaline batteries only in the
remote control.
•Do not mix battery types, such as Alkaline and
rechargeable NiMH batteries.
•Do not attempt to recharge a battery unless the
battery is specifically marked “rechargeable.”
•Never dispose of batteries in a fire.
+ AAA - + AAA -
+ AAA -
+ AAA -

7
About System Remote Control
RCZ-SRC2-B
System Remote Control
Model#RCZ-SRC2-Bcan be
divided into these sections:
1. LCD, LCD Button, and Off
Button
2. Control4 Button and Sys-
temButtons(alsoreferred
to as the “Circle of Power”
buttons)
3. Navigation Buttons
4. Device Control Buttons
5. Keypad
Once the system setup is
complete, the remote control
responds to each button-
press in a different way—
depending on:
•mode of remote control
•current location
•devices available in the
current location
•when the button is
pressed
•if the button has been
programmed for a
custom function
5
3
2
1
4

8
LCD, LCD Button, and Off Button
LCD (liquid crystal display)—Provides information
related to system activity. The LCD uses highlighting to
show a selected item. It includes a white backlight that
stays on for 15 seconds after a button is pressed.
LCD button—Changes the remote mode to
LCD Navigator mode and displays the menu in the LCD.
See “Use LCD Navigator” on page 19).
OFF button—Turns off all A/V devices in the current
room.

9
Control4 Button and System Buttons
Control4 button—If a TV or monitor (TV device) is
available in the current location, it puts the remote control
in On-Screen Navigator mode and displays the On-
Screen menu on the TV device. The On-Screen Navigator
display: displays the current location, provides access to
additional locations, and provides access to all systems
available at the current location.
From here you can use the remote control navigation
buttons to choose On-Screen Navigator options.
Note: For more information on using On-Screen
Navigator, refer to the Control4 System User Guide.

10
System buttons (or “Circle of Power” buttons)—
The buttons surrounding the red Control4 button (Radio,
Music, TV, Videos, Comfort [A], Lights [B], House [C], and
Info [D]) are system buttons that respond differently
depending on when they are pressed and if and how they
have been programmed, as described in the remainder of
this section:
Radio
When the remote control is in a Navigator mode (when
either On-Screen Navigator or LCD Navigator are active),
the RADIO Button acts as a shortcut into the radio
submenu in the appropriate navigator.
When devices in the room are off or the remote control is
in Device-Control mode (when no Navigator screen is
active), the RADIO button functions as a Quick Access
button: Press it to start playing the radio and to be able to
control the radio source with the device-control buttons.
Initial Press of RADIO button:
• Turns on the last used radio source, tunes to the last
used station on that source.
• The remote enters device-control mode for the current
radio source. The LCD shows current room and current
radio source.
Subsequent Presses of RADIO button prior to LCD
time-out:
• Additional presses toggle through the radio sources
listed in the LCD and turns them on. When the last radio
source is displayed, the next press loops back to the first
available source.

11
Music
When the remote control is in a Navigator mode (when
either On-Screen Navigator or LCD Navigator are active),
the MUSIC Button acts as a shortcut into the music
submenu in the appropriate navigator.
When devices in the room are off or the remote control is
in Device-Control mode (when no Navigator screen is
active), the MUSIC button functions as a Quick Access
button. Press it to start playing music and to be able to
control the music source with the device-control buttons.
Initial Press of MUSIC button
• Turns on the last used music source and begins playing
music from the last-played entry in the music queue, or
from the analog source.
• If the music queue is empty, or if there is no media in the
analog source, then the button press just turns on the
music source.
• The remote enters device control mode for the music
source. The LCD shows current room and current music
source.
Subsequent Presses of MUSIC button prior to LCD
time-out
• Additional presses toggle through the music sources
listed in the LCD and turns them on. When the last
music source is displayed, the next press loops back to
the first available source.

12
TV
When the remote control is in a Navigator mode (when
either On-Screen Navigator or LCD Navigator are
currently displayed), the TV Button acts as a shortcut into
the TV submenu in the appropriate navigator.
When devices in the room are off or the remote control is
in Device-Control mode (when no Navigator screen is
active), the MUSIC button functions as a Quick Access
button. Press it to turn on the TV and to be able to control
the TV with the device-control buttons.
Initial Press of TV button
• Turns on the TV and selects the last broadcast source
used.
• The remote enters device control mode for the TV &
broadcast source. The LCD shows current room and
current TV source.
Subsequent Presses of TV button prior to LCD time-
out
• Additional presses toggle through the TV broadcast
sources listed in the LCD and turns them on. When the
last TV broadcast source is displayed, the next press
loops back to the first available source.
Videos
When the remote control is in a Navigator mode (when
either On-Screen Navigator or LCD Navigator are
currently displayed), the VIDEOS Button acts as a shortcut
into the video submenu in the appropriate navigator.
When devices in the room are off or the remote control is
in Device-Control mode (when no Navigator screen is
active), the VIDEOS button functions as a Quick Access

13
button. Press it to begin playing a video and to be able to
control the video source with the device-control buttons.
Initial Press of VIDEO button
• Turns on the audio endpoint for the room and the last
video source used.
• The remote enters device control mode for the video
source. The LCD shows current room and current TV
source.
Subsequent Presses of VIDEO button prior to LCD
time-out
• Additional presses toggle through the video sources
listed in the LCD and turns them on. When the last video
source is displayed, the next press loops back to the first
available source.
Comfort (A), Lights (B), House (C), and Info (D)
Note: Notice that the Comfort, Lights, House, and
Info buttons have the additional labels A, B, C & D
directly on the buttons. The additional labeling is
related to custom programming that may be
provided by your installer.
When the remote control is in a Navigator mode (when
either On-Screen Navigator or LCD Navigator are
currently displayed), each of these 4 buttons acts as a
shortcut into its related submenu in the appropriate
navigator. For example, if the On-Screen Navigator Home
page is displayed on the TV and you press Comfort (A),
then a menu bar (submenu) similar to the following
displays.

14
When devices in the room are off or the remote control is
in Device-Control mode (when no Navigator screen is
active), pressing one of these buttons will run the custom
program assigned to that button for the current room or
device. Ask your installer about custom programming or
see Custom Button labels in the House menu:
Button: Custom program for Room or Device control
A: ______________________________________
B: ______________________________________
C: ______________________________________
D: ______________________________________
In the absence of custom programming, a button-press will
only wake up the LCD to display the name of the current
room and the “Options” pull-down menu option.

15
Navigation Buttons
The following buttons are for screen and menu navigation.
•PAGE 
Page Up/Down
•MUTE
Mute audio
•RECALL
Toggle to previ-
ous channel
•INFO
Current chan-
nel and pro-
gram
information
•VOLUME - +
Control
volume
•  
Menu/Option
Navigation
•SELECT
Choose the
highlighted
item
•CHANNEL + -
Channel Up/
Down
•GUIDE
Program list-
ings
•CANCEL
Clears screen
of navigation
information
•MENU
Options for cur-
rent location

16
Device Control Buttons
These familiar buttons are for device control.
•DVR (Digital Video
Recorder)
•BACK l
•NEXT l
•REW 
•PAUSE ll
•FWD 
•STOP 
•RECORD Q
•PLAY 
Keypad
The alphanumeric
keypad is for changing
TV channels, setting
lightinglevels,orentering
text.
The *and # keys are
available to the installers
for custom programming.
Ask your installer if a
custom program is
present or see Custom
Button labels in the House menu:
Button: Custom program for Room or Device control
*: ______________________________________
#: ______________________________________
