Control Techniques USB User manual

User Guide:
Communications module
For use with D1/D2 soft starters
USB

Product Compatibility
This communications module is suitable for use with Digistart D1 and D2 soft starters.
For the latest manuals and software, please visit our website.

USB Module Disclaimer
Contents
1Disclaimer .......................................................................................................................... 1
2Important User Information .............................................................................................. 1
3Introduction ....................................................................................................................... 2
4Installation ......................................................................................................................... 2
5Connection ........................................................................................................................ 3
6Configuration..................................................................................................................... 3
7Specifications .................................................................................................................... 4
1 Disclaimer
The examples and diagrams in this manual are included solely for illustrative purposes.
The information contained in this manual is subject to change at any time and without prior
notice. In no event will responsibility or liability be accepted for direct, indirect or
consequential damages resulting from the use or application of this equipment.
2 Important User Information
Observe all necessary safety precautions when controlling the soft starter remotely. Alert
personnel that machinery may start without warning.
It is the installer's responsibility to follow all instructions in this manual and to follow correct
electrical practice.
User Manual 1/5

Introduction USB Module
3 Introduction
The USB Module lets the soft starter connect to a PC, allowing the starter to be configured
via dedicated management software.
These instructions detail the installation, set-up and configuration of the USB Module. For
details on using the management software, refer to the software help file.
4 Installation
CAUTION
Remove mains and control voltage from the soft starter before attaching or
removing accessories. Failure to do so may damage the equipment.
4.1 Installation Procedure
1. Remove control power and mains supply from the soft starter.
2. Fully pull out the top and bottom retaining clips on the module. [A]
3. Line up the module with the comms port slot. [B]
4. Push in the top and bottom retaining clips to secure the module to the starter. [C]
5. Apply control power to the soft starter.
ABC
10178.C
Remove the module using the following procedure:
1. Remove control power and mains supply from the soft
starter.
2. Take the module off-line.
3. Disconnect all external wiring from the module.
4. Fully pull out the top and bottom retaining clips on the
module. [A]
5. Pull the module away from the soft starter.
03550.C
A
2/5 User Manual

USB Module Connection
5 Connection
For successful operation, links must be fitted across terminals A1, 02 on the soft starter.
08585.B
1
2
3
12
4 3
1
Soft starter (Remote mode)
A1, 02: Stop input
2
USB Module
3
USB port
6 Configuration
The USB Module requires a driver to operate correctly. Contact your local supplier for the
latest version of the driver.
To bring the USB Module on-line:
1. Remove control power and mains supply from the soft starter.
2. Attach the module to the soft starter.
3. Connect the module to the PC via a USB cable. The PC should detect the module and
the Hardware Update Wizard will open.
4. Install the USB driver to operate the module as follows.
08588.A
Welcome to the Found New
Hardware Wizard
Windows will search for current and updated software by
looking on your computer, on the hardware installation CD, or on
the Windows Update Web site (with your permission).
Read our privacy policy
Can Windows connect to Windows Update to search for
software?
Yes, this time only
Yes, now and every time I connect a device
No, not this time
Click Next to continue.
This wizard helps you install software for:
FT232R USB UART
If your hardware came with an installation CD
or floppy disk, insert it now.
What do you want the wizard to do?
Install thesoftware automatically (Recommended)
Install from a list or specific location (Advanced)
Click Next to continue.
08589.A
Select the folder that contains drivers for your hardware.
To view any subfolders, click a plus sign above.
My Documents
My Computer
My Network Places
USB Comms Drivers
Win98_ME
WinXP_Vista
amd64
i386
Please choose your search and installation options.
Search for the best driver in these locations.
Use the check boxes below to limit or expand the default search, which includes local
paths and removable media. The best driver found will be installed.
Search removable media (floppy, CD-ROM...)
Include this location in the search
C:\Documents and Settings\user\Desktop\USB Comm
Don’t search. I will choose the driver to install.
Choose this option to select the device driver from a list. Windows does not guarantee that
the driver you choose will be the best match for your hardware.
Browse
Next >< Back Cancel
OK Cancel
User Manual 3/5

Specifications USB Module
Click on Ok, then Next. The software will install. If you see a prompt, click Continue
Anyway. Once installation is complete, click Finish.
5. The PC will prompt you to install serial port driver software. Repeat the procedure in
Step 4. You may need to restart your PC once the driver software is installed.
6. Identify the USB Serial Port assignment by checking Control panel > System >
Hardware > Device Manager > Ports (COM & LPT).
08590.A
Computer
Disk drives
Display adapters
DVD/CD-ROM drives
Floppy disk controllers
Floppy disk drives
Human Interface Devices
IDE ATA/ATAPI controllers
IEEE 1394 Bus host controllers
Keyboards
Mice and other pointing devices
Monitors
Network adapters
Ports (COM & LPT)
Communications Port (COM1)
ECP Printer Port (LPT1)
Intel(R) Active Management Technology - SOL (CO
USB Serial Port (COM5)
Processors
NOTE
If the USB port is not shown, disconnect then reconnect the cable. If the
problem persists, restart your PC.
7. Open WinMaster and change the settings as follows:
Protocol: AP ASCII or AP Binary
Baud rate: 9600
Address: 20
Port: Use the serial port number identified above
8. Apply control voltage to the soft starter and bring the Master on-line.
NOTE
The starter may trip on Starter Comms while the Master is off-line. Reset the
soft starter and place the Master on-line.
NOTE
The drivers will configure the USB port that the module is connected to. You must
use the same physical USB port every time you connect the module to the PC.
7 Specifications
•Enclosure
Dimensions ..................................................... 40 mm (W) x 166 mm (H) x 90 mm (D)
Weight ................................................................................................................. 250 g
Protection .............................................................................................................. IP20
•Mounting
Spring-action plastic mounting clips (x 2)
•Connections
Soft starter .................................................................................... 6-way pin assembly
Network .............................................................................................................. USB-B
Maximum cable length ............................................................. 3 metres (not supplied)
4/5 User Manual

USB Module Specifications
•Settings
Protocol ................................................................................... AP Binary or AP ASCII
Address .................................................................................................................... 20
Data rate (bps) ..................................................................................................... 9600
User Manual 5/5
