Control Technologies 2500 Series User manual

2510 125VDC Power Supply
2500 Series PLC System Product Bulletin
Specifications
Field Connections:
One3-pininputterminalstrip
Input Voltage Operating Range:
90-146VDCor90-132VAC
Total Wattage Rating:
55 Watts maximum output @ 0oC to 60oC
Steady State Input Current at full load:
1.50Amps DC max
2.5 Amps AC max.
Peak Inrush Current:
50 Amps max
Fusing:
3.0Amp 250V, 3AG front panel accessible
Isolation:
2800VDC:input-to-Backplane
500VDC: Chassis-to-Backplane
1500VDC:input-to-Chassis
Module Size: Triple-wide
Operating Temperature:
0oto 60oC (32oto 140oF)
Storage Temperature:
-40oto 85oC (-40oto 185oF)
Relative Humidity:
5% to 95% (non-condensing)
Agency Approvals Pending:
UL, ULC, FM (Class 1, Div. 2), CE
Shipping Weight: 5.0 lbs (2.3 kg)
Description
TheModel 2510 is a 125 VDC Power Supply
whichprovidesup to55wattsofl powerforCTI
2500SeriesTM or SIMATIC®505 PLCs.
Systems that must operate from 125 VDC
batteriesmay usethe Model 2510to provide
power for the PLC. This is a special order
productwhichrequiresaminimum10pcorder.
The Model 2510 also accepts 110 VAC input
power.
Features
125VDC input power for utilityapplications
Also accepts 110 VAC input power
55 Watts @ +5 VDC to PLC to backplane
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5962
Phone: [phone] Fax: [phone] www.controltechnology.com

Copyright© 2006 Control Technology Inc. All Rights Reserved Siemens® is a registered trademark of Siemens AG
CTI P/N: 062-00159 02MAR09
Installing and Removing the Power Supply
Use the following steps for installing and removing the 2510 Power Supply from the system base.
1.Position the power supply so that the bezel is facing you.
2.Grasp the top and bottom of the power supply.
3.Carefully slide the power supply into the left most slot in the base until it engages into
thebackplaneconnectors.
4. Tighten top and bottom bezel screws into the base chassis.
To remove power supply, reverse procedures 1 through 4 used for installation.
Power Supply Location in Base
The Power Supply must always be installed in the left most slot of the system base.
Seefigure below.
CAUTION:
Do not attempt to operate the 2510
Power Supply out of the Input Voltage
Operating Ranges..
Damage to the Power Supply could occur
if out of range input is applied.
WARNING:
Disable all power to the base before
installing or removing the power supply.
Failure to do so could cause damage to
the equipment or injury to personnel.
