Control Technologies 2500 Series User manual

2500C-PS-120V-35 120VAC 35 Watt Power Supply
DESCRIPTION
The 2500C-PS-120V-35 is a triple wide module that
provides power for the CPU and all IO modules
plugged in the Compact Chassis.
FEATURES
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5914
Phone: [phone] Fax: [phone]
www.controltechnology.com
Input Specifications◊
Field Wiring Connector 3 Pin Removable Connector
Input Voltage Operating
Range
80-264 VAC, 47-63Hz, single phase
Total Wattage Rating 35 watts maximum output
@ 0 to 60ºC
Steady State Input Current
at full Load
0.78 Amps max @ 90VAC
0.63 Amps max @ 120VAC
0.36 Amps max @ 240VAC
Peak Inrush Current 5.1 Amps max @ 120VAC
9.1 Amps max @ 220VAC
Fusing 1.0 Amp 240VAC,
3 x 20mm front panel accessible
Hold Up Time 86 mSec @ 35 Watt Full Load
Module Size Triple wide module
Isolation 110/220 VAC to
Backplane 1500VAC
Isolation 110/220 VAC to
Chassis 1500VAC
Operating Temp Range 0ºC to 60ºC (32ºF to 140ºF)
Storage Temperature -40ºC to 85ºC (-40ºF to 185ºF)
Relative Humidity 5% to 95% (non-condensing)
Shipping Weight 2.0 lb. (0.91 Kg)
Agency Approvals Pending UL, ULC, FM(Class 1, Div 2), CE
◊ Note: All measurements are made from a power supply at
25ºC .
2500 Series™ Compact System
 Triple wide module
 110/220 VAC 50/60Hz
 Maximum 35 watts backplane power
 86mSec holdup time
Copyright© 2015 Control Technology Inc All Rights Reserved 21 January 2015

2500 Series™ Compact System
Control Technology Inc.
5734 Middlebrook Pike, Knoxville, TN 37921-5914
Phone: [phone] Fax: [phone]
www.controltechnology.com
2500C-PS-120V-35 120VAC 35 Watt Power Supply
Warning:
Disable all power to the base be-
fore installing or removing the
power supply. Failure to do so
could cause damage to the
equipment or injury to personnel.
2500C Compact Power Supplies
are always located in the left
most slot
Caution:
Do not attempt to operate the
2500C-PS-120V-35 out of the Volt-
age Operating Ranges specified.
Damage to the Power Supply could
occur if out of range power input is
applied.
Installing Power Wiring
Use the following steps for installing and removing the 2500C-PS-120V-35 Power Supply from the 2500C Chassis.
1. Position the power supply so that the bezel is facing you.
2. Grasp the top and bottom of the power supply
3. Carefully slide the power supply into the left most slot in the base until it engages into the backplane connector.
4. Strip power wiring back, insert the wire into the wiring connector as shown above, then tighten screws
5. Check to make sure the power input wires are securely inserted and the fastened in the wiring connector.
6. Insert and tighten down the 3 pin removable wiring connector.
7. Be sure to tighten the top and bottom bezel screws completely.
8. Once all the chassis modules including controllers and IO are inserted then you may apply power to the power supply
inputs.
To remove the power supply, remove power from the power input by removing the power wiring connector or turning off the
power source, loosen the bezel screws, and pull the power supply forward out of the chassis until it clears the chassis.
