ControlByWeb X-417 User manual

See users manual for setup instructions:
www.ControlByWeb.com/support/
| Quick-Start Guide
X-417
Rev 1.0
1. Power the module and connect to network.
2. Set IP address on computer to be on the same network as
the module. (Example: Set computer to 192.168.1.50)
3. To configure the module, open a web browser and enter:
http://192.168.1.2/setup.html
4. Assign permanent IP address to module, then restart module.
5. Restore computer’s IP address, if necessary, and access the
module at its new IP address to finish setup.
Basic Setup Steps
IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Control Page Web Address: http://192.168.1.2
Control Password: (no password set)
Setup Page Web Address: http://192.168.1.2/setup.html
Setup Username: admin
Setup Password: webrelay (all lower case)
Factory Default Settings

1681 West 2960 South, Nibley, UT 84321, USA
| Pinout Diagram
X-417
Vin-
Vin+
Com
Out4
Com
Out3
Com
Out2
Com
Out1
Com
Out5
Logic
Power
Supply Digital To
Analog
DC/DC
Converter
+
-
Digital To
Analog
Digital To
Analog
Digital To
Analog
Digital To
Analog
Power
Analog Outputs
Vin+ : Power Supply Input (9-28VDC)
Vin- : Power Supply Input (Ground)
Com 1-5 : Analog Common (Isolated from Vin-)
Out 1-5 : 0-5V, ± 5V, 0-10V, ± 10V, 4-20mA Output
