Configure FS700 RAW Recording (Continued)
MENU » CAMERA SET » SLOW AND QUICK » RAW 2K SUPER SLOW » EXECUTE
4Setup FS700 High Frame Rate
Select your desired frame rate*:
TIME SAVER TIP: A quicker way of doing this is once the S&Q is set to RAW
HIGH SPEED, you can press and hold the S&Q button, then once the RAW Super
Slow frame is highlighted, you can now switch from 120 to 240. (or 100 to 200 in
record.)
TO ACCESS HIGH FRAME RATES:
» Press the S&Q button » Select 120fps or 240fps
The Odyssey7Q also has the ability of recording the buered 4K 100/120 p from
the FS700. If you wish to record this set the camera to 4K Raw, and enable S&Q.
Then the Odyssey7Q will record 4K100/120, for up to a 4 second burst.
RAW 4K SUPER SLOW 120FPS AND 100 FPS 7-8 SECOND BURST
Start Trigger - > 440 Frames
End Trigger -> 440 Frames
End Half Trigger -> 220 Frames
Start Trigger Processes 440 frames from when RECord button is pressed.
End Trigger Sends a buer of the 440 frames prior to hitting the REC button.
End Half Trigger sends a buer of the 220 frames prior to hitting the REC button.
120fps is 3.7 seconds record time - (440 frames) - 60fps playback
100fps is 4 seconds - (440 frames) - 50fps playback
NTSC 120
240
PAL 100
200
