Read This First!
Before you begin using the Odyssey7Q, we strongly suggest you review
the included Quick Start Guide. We also strongly recommend the
following:
1. Always record to the internal media of the camera; this is critical for proper Timecode and
ideal for dual media / backup.
2. DO NOT REMOVE THE FOUR SCREWS FROM REAR OF CASE. This may result in damage
to the OLED panel. Such damage is not covered by warranty.
3. Power and cabling: Make sure you have PROPER POWER (6.5-34vdc), plugged in to the
proper power port (left side of recorder), and that 3G-rated SDI cables are used.
4. Power source must be able to provide up to 24 watts at all times to the Odyssey7.
5. When powering the Odyssey7 from an ARRI Alexa camera, we recommend using the
24V r/s Fischer-3 output from the Alexa using the optional Convergent Design cable.
6. Familiarize yourself with the equipment and test prior to shooting.
7. Before using the SSDs it is IMPERATIVE TO FORMAT them in the Odyssey7. Formatting
SSD media is a Destructive process; any existing data will be lost during format.
8. Ensure that the camera’s viewfinder data is not being recorded; IF YOU SEE VIEWFINDER
DATA ON THE ODYSSEY7 monitor, then it will be recorded!
9. NEVER DELETE ANY FILES OFF OF AN SSD FROM A COMPUTER, except when going
through a firmware update procedure.
10. While we recommend that you always maintain the latest firmware on your Odyssey7Q, WE
DO NOT RECOMMEND UPDATING FIRMWARE IF YOU ARE IN THE MIDDLE OF A SHOOT (unless
specifically instructed to do so by our Technical Support sta).
11. When ooading media, ALWAYS MAKE A BACKUP COPY, ideally to a RAID1 drive.
12. Be sure to allow the Odyssey7Q to finish closing a Record file before taking any further action.
13. Always safely eject SSD Media by pressing the button before removing SSD media from
the Odyssey7Q.
!

5
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Product Features
MONITORING
• Professional Monitor: 7.7” 1280x800 OLED panel featuring true blacks, and accurate color
with a full range color gamut for Rec709 or DCI-P3 viewing.
• Image analysis tools: Waveform, Vectorscope (in future update), Histogram, False color
exposure view, Zebra, three-mode Focus assist, pixel Zoom (1:1 & 2:1), LUTs, and Frame
Guides.
• Flexible I/O: One dedicated 3G-SDI input, one dedicated 3G-SDI output, one HDMI input,
one HDMI output. Active cross-conversion means that both outputs are always active no
matter which input is used.
RECORDING
• High-capacity recording. A high-speed solid state Drive (SSD), available in 256 GB or 512
GB, allows for extended recording.
• Apple ProRes 422 (HQ) up to 1080/60p, 1080/60i and 720/60p. Additional frame rates and
popular compressed codecs will be available at a later date via free firmware update.
For the latest firmware, product manuals and other information visit Convergent-Design.com
i

6
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
OTHER FEATURES
• Versatile Power. Wide voltage range (6.5-34v) and low draw (8-15w, depending on mode)
for great flexibility of battery and other power options.
• Light Weight. A magnesium case and ecient board design means only 1.25lbs for the
basic unit.
• Small size. even with a 7.7” screen, the Odyssey7 is approximately 8”x6”x1”, making it
easy to use on cameras, mounted in tight spots or held in one’s hand.
MOUNTING
The Odyssey7 features three ¼-20 threaded sockets, one on the lower rear of the case and one
each on the left and right sides of the case. Do not exceed 11mm of depth when inserting a
bolt, otherwise damage may occur to the Odyssey7. Additionally, there are four M3 threaded
socketson the rear of the case and two M4 sockets on each of the sides of the case.
Product Features (Continued)

7
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Product Specifications
Display 7.7" OLED, 1280x800, RGB 8-Bit Panel, ~ 16 million colors, wide gamut, 3400:1
Contrast, 176° Viewing, True Blacks
SDI Video I/O HD-SDI/3G Support: Single Link, 1-Input, 1-Output, Full-size BNCs, Up to 1080p60
4:2:2 10-bit
HDMI Video I/O HDMI I/O Version 1.4a support, Up to 1080p30 4:2:2 8-bit
LUT Support ARRI Log-C, Canon C-Log, Sony S-Log, S-Log2, S-Log3 LUTs (No Custom LUT
Support)
Focus Assist Video + Edges (Peaking), Edges Only, Enhanced Edges, user choice of color:
Red, Green, or Blue
Zebras Currently one programmable level, future two programmable levels
False Color False color with 5 programmable levels
Waveform Monitor Luma only, RGB Parade, Red only, Blue only, Green only
Histogram Luma only, RGB Parade, Red only, Blue only, Green only
Vectorscope (future) Color vectorscope with 2X zoom
Pixel Zoom 1:1 and 2:1 Image Magnification with frame drag
OLED Frame
Reference
Vertical Auto-Flip (defeatable), Aspect Ratio Guides
Digital Audio I/O 2-Channel Embedded Audio (48KHz, 24-bit)
Analog Audio I/O 3.5mm stereo unbalanced input up to -10dB (future), 3.5mm stereo headphone
output
Remote and
Timecode
RS-232 I/O (future), programmable GPIO (future). Timecode: LTC I/O (BNC) or
embedded SDI / HDMI (HDMI future)
User Interface Capacitive Touchscreen, Two mechanical keys
DC Power Input 6.5 to 34 VDC with built-in reverse polarity protection; lockingpower connector,
built-in power switch
Power Draw 8 Watts (monitor only), 9-12 Watts (simultaneous monitor/record mode)
Weight and Size 560 grams / 1.2 lbs., 7.9" x 6.1" x 1.0" (200 x 155 x 25 mm), -10 to +40°C
(Operating), -20 to +70°C (Storage)
Record Triggers Touchscreen, SDI record trigger (ARRI, Canon, Panasonic, Red, Sony), Optional
Remote Control Cable (future)
Recording SSD
Media
Convergent Design SSDs with power-loss protection, in 256 and 512 GB sizes,
420MB/sec write, 500MB/sec read speed, compatible with USB 3.0 and
Thunderbolt adapters. SSDs and adpaters sold separately.
Recording Formats Compressed formats: Apple ProRes 422 (HQ) up to 1080/60p, 1080/60i,
720/60p
All Specifications subject to change and update without notice.

8
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
The Odyssey7 is a single channel HD video recorder that records onto Convergent Design
Premium SSD Media from HD-SDI or HDMI inputs.
HD VIDEO The Odyssey7 records HD video as 10-bit Apple ProRes 422 (HQ)
All .DPX files are recorded 4:4:4. 4:2:2 video signals are up-converted to 4:4:4.
3G-SDI: accepted 1080p/psf frame rates: 23.98, 24, 25, 29.97, 30, 50, 59.97, 60
HDMI: accepted 1080p/psf frame rates: 23.98, 24, 25, 29.97, 30, 50i, 60i, 720p50, 60
Compressed Apple ProRes 422 (HQ) 1080p/psf 23, 24, 25, 29 50, 60; 1080i 50, 60; 720p 50, 60
Future free firmware updates will include additional compressed video codecs with expanded
frame rate.
NOTE: Convergent Design manufactures the Odyssey7Q that is designed for recording in 2K, 4K,
RAW, MultiStream and other formats. Please see our website or talk to your dealer for details.
Apple ProRes 422 (HQ)
The Odyssey7 records in Apple ProRes 422 (HQ) which is a 10-bit 4:2:2 220Mb compressed
codec. This will allow for high quality recording while avoiding high data rates of working with
uncompressed video.
RECORD TIME CAPACITIES
The Odyssey7 can record several video formats and frame rates. Record time varies based on
format and frame rate. The chart below indicates maximum record time in minutes based on the
use of one 512 GB SSD. For 256 GB, divide in half.
MAXIMUM RECORD TIME IN MINUTES TO A 512GB SSD
Recording Format 24fps 25fps 30fps 50fps 60fps
1080p Apple ProRes 422 (HQ) 330 318 264 159 132
1080i Apple ProRes 422 (HQ) - (24p using 3:2 Pulldown Removal) 330 318 204
720p Apple ProRes 422 (HQ) 158 132
Recording Capabilities

9
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Package Contents
Odyssey7 box contains one (1) Odyssey7 monitor/recorder and one (1) universal power supply.
MEDIA AND ACCESSORIES SOLD SEPARATELY!

10
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
Convergent Design SSD Media
2.5” PREMIUM SSD MEDIA
To enable recording on the Odyssey7, you must use specific SSD media: Only Convergent
Design premium SSDs will work in the Odyssey7. These SSDs, available in 256 GB and 512 GB,
must be purchased separately.
256GB SSD for Odyssey7 and 7Q CD-SSD-256GB
512GB SSD for Odyssey7 and 7Q CD-SSD-512GB
ODYSSEY UTILITY DRIVE
The Odyssey Utility Drive is designed as a lower cost alternative to the Odyssey Premium SSD
media for secondary tasks. The Odyssey Utility Drive can be used for Odyssey7 & 7Q firmware
updates, Odyssey7Q 3D-LUT files and other future functionality. The Odyssey Utility Drive
will not record video files. It is intended for Odyssey7 & 7Q owners who do not wish to tie up
an Odyssey SSD with utility features, or for Odyssey7 & 7Q owners who use their devices as
monitors and do not need to purchase the more expensive recording media.
Utility Drive for Odyssey7 and 7Q CD-SSD-UTILITY
