MISUMI MP-468E User manual

0

1
Table of Contents
1. Precautions…………………………………………. 2
2. Preparation………………………………………….. 2
Standard Accessories……………………….. 5
Parts Names………………………………….. 6
Charging the Battery Pack…..……………... 7
3. Recording Mode …………………………………… 9
Loading SD card……………………………… 9
Connect External Camera………………….. 9
Powering On/ Off……………………………. 10
Recording Video Clip………………..……… 11
4. Review Mode……………………………………….. 12
5. Delete Mode………………………………………… 13
6. Menu Mode………… ………………....................... 14
Set Date/ Time….……………………………. 14
Schedule Record……..………………………. 15
Overwrite……………………………………… 17
LCD Off.………………………………………. 17
Date Time Stamp…………………………….. 18
Format………..……………………………….. 18
7. LCD Mode………..…………………….…………… 19
8. Making Connection………………………………… 20
Connecting to PC……………….……………. 20
Download Movie..……………………………. 21
Connecting to TV for review………………… 22
Recording TV Program..…………………….. 22
9. Appendix…………………………………………….. 23
Specifications…………………………………. 23

2
Welcome
Thank you for purchasing a Mini Portable Digital Video
Recorder.
Please take a moment to read through this manual. Its
contents will send you on an educational journey into your
recorder multiple capabilities.
1. Precaution
Before using Mini Portable Digital Video Recorder, please
ensure that you read and understand the safety
precautions described below. Always ensure that the
photo viewer is operated correctly.
xNever operate Mini Portable Digital Video Recorder
inside of an aircraft or anywhere else where
operation of such devices is restricted. Improper use
creates the risk of serious accident.
xDo not try to open the case of Mini Portable Digital
Video Recorder or attempt to modify Mini Portable
Digital Video Recorder in any way. High-voltage
internal components create the risk of electric shock
when exposed. Maintenance and repairs should be
performed only by authorized service providers.
xDo not fire the flash too close to the eyes of animals
or people, especially for young children. Eye
damage may result. In particular, remain at least
one meter away from infants when using flash.
xKeep Mini Portable Digital Video Recorder away
from water and other liquids. Do not use Mini

3
Portable Digital Video Recorder with wet hands.
Never use Mini Portable Digital Video Recorder in
the rain or snow. Moisture creates the danger of fire
and electric shock.
xKeep Mini Portable Digital Video Recorder and its
accessories out of the reach of children and animals
to prevent accidents or damage to the photo viewer.
xIf you notice smoke or a strange odor coming from
Mini Portable Digital Video Recorder, turn the power
off immediately. Take Mini Portable Digital Video
Recorder to the nearest authorized service center
for repair. Never attempt to repair Mini Portable
Digital Video Recorder on your own.
xUse only the recommended power accessories. Use
of power sources not expressly recommended for
Mini Portable Digital Video Recorder may lead to
overheating, distortion of the equipment, fire,
electrical shock or other hazards.
xMini Portable Digital Video Recorder may become
slightly warm during use. This does not indicate
malfunction.
xIf the exterior of Mini Portable Digital Video
Recorder needs cleaning, wipe it with a soft, dry
cloth.

4
FCC Notice
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy. If not installed
and used in accordance with the instruction, it may cause
harmful interference to radio communication. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment on the off,
the user is encouraged to try to correct the interference by
one or more the following suggestion.
zReorient or relocate the receiving antenna.
zIncrease the distance between the equipment and
the receiver.
zConnect the equipment to a different power outlet
other than the one where the receiver is connected.
zConsult an experienced television or radio
technician for help.
CAUTION
To comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules, this device must
only be installed on computer equipment certified to
comply with the Class B limits.

5
2. Preparation
Standard Accessories
ManualExternal CameraRecorder
USB TV CABLE CD
ADAPTOR

6
Part Names
Front View

7
Charging the Battery
Long battery life is one of the key benefits of this product
compared to others. Mini Portable Digital Video Recorder
battery has already been charged prior to shipment,
however, to be safe, please charge the battery at least
4 hours when your first use. You may want to follow the
instructions below to make sure that your Mini Portable
Digital Video Recorder is fully charged. The lithium-ion
battery used in Mini Portable Digital Video Recorder
recharges automatically when Mini Portable Digital Video
Recorder is plugged into a PC via the provided USB cable.
When the battery is charging, the red LED will light up.
When charging is complete, the red LED will be off.

8
Or you could charge the battery by AC adaptor
to a power outlet. Any USB AC adapter will
function with Mini Portable Digital Video Recorder.
Battery power status
CAUTION
* It takes approximately 3 hours to fully charge a depleted battery.
* The photo viewer can be charge at ambient temperatures between 0кʳ
(32л) and +40кʳ(104л).
* The battery does not need to be fully discharge or exhausted before
being recharged.
* Lithium-ion battery loses their charge even when not used. So, be sure
to charge the battery before use.
* To ensure that your battery lasts as long as possible, switch the photo
viewer off when you are not using it.

9
3.Recording
Loading SD Card
Insert SD card into SD memory card slot and push it all
the way in.
Use finger nail to push out the SD card.
Connect External Camera
Plug the provided camera to camera port.

10
Powering ON/ OFF
Power ON
1. Press the Power Button to turn on the LCD Monitor.
2. When the LCD Monitor has been activated.
Mini Portable Digital Video Recorder is ready to
recording.
Power OFF
1. Press the Power Button again to turn off.

11
Recording Video Clip
1. Power on the camera.
2. Snap Press the OK Button to capture image.(JPG)
3. Press the OK Button 2 sec to start recording a movie.
(recording press the delete button to lock function key,
press again to unlock function key)
4. Press the OK Button again to stop recording.

12
4.REVIEWMode
Press REVIEW Button to enter movie play back mode,
Press REVIEW Button again to return Recording
status.
1. Press REVIEW Button.
2. Press OK Button for play back the current movie from
SD Card.
3. Push or to scroll the movies.
4. Press OK Button once can pause, press again to
release.

13
5.DELETEMode
Under REVIEW mode, you can press DELETE Button
to delete selected movie.
1. Under REVIEW Mode.
2. Press Delete Button once. Push to select “9” and
press OK Button to delete current movie.
2. Press Delete Button twice. Push to select “9” and
press OK Button to delete all movies.
Press Review Button to return recording status.

14
6.MENUMode
Press MENU Button and then push
ϰ
forward to
select setting modes.
Set Date/ Time
1. Under MENU mode.
2. Push ϰto select Date/ Time Mode.
3. Press OK Button.
4. Push
ϧʳ
and
ϰʳ
to adjust Year/Month/Date/
5. Hour/Minute, and then press OK button to set.

15
Schedule Record
1. Under MENU mode.
2. Push ϰto select Schedule Record Mode.
3. Press OK Button.
4. There are 3 schedules can be set for weekly
recording when power on. Maximum 180 min.
Press MENU Button again to return recording status.

16
5. Select “OFF” separately to turn off schedule record
function.

17
Overwrite
1. Under MENU mode.
2. Push
ϰ
to select Overwrite Mode.
3. Press OK Button.
4. Select Overwrite function ON or OFF and press OK
Button to set.
LCD Off
1. Under MENU Mode.
2. Push
ϰ
to select LCD Off Mode.
3. Press OK Button.
4. Push ϰto select the minutes (2 Min/ 5 Min/ 10 Min)
you want to LCD display off for power saving and
press OK Button to set.

18
Date Time Stamp
1. Under MENU Mode.
2. Push
ϰ
to select Date Time Stamp Mode.
3. Press OK Button.
4. Select Date Time Stamp function ON or OFF and
press OK Button to set.
Format
1. Under MENU Mode.
2. Push
ϰ
to select Format Mode.
3. Press OK Button.
4. Select “Start” to format SD card.

19
7.LCDOn/OffMode
You could press LCD Button to turn off LCD monitor for
power saving.
To press cable switch button to turn off camera.
