CONVEY-ALL CST-1634 User manual

COMMERCIAL SEEDTENDER
Models:
CST-1634, CST-1834, CST-2034, CST-2434
OPERATOR’S MANUAL

LIMITEDWARRANTY
Convey-All warrants to the buyer that the new machinery is free from defects in material and
workmanship.
This warranty is only effective as to any new machinery which has not been altered, changed,
repaired or treated since its delivery to the buyer, other than by Convey-All or its authorized
dealers or employees, and does not apply to accessories, attachments, tools or parts, sold or
operated with new machinery, if they have not been manufactured by Convey-All.
Convey-All shall only be liable for defects in the materials or workmanship attributable to faulty
material or bad workmanship that can be proved by the buyer, and specifically excludes liability
for repairs arising as a result of normal wear and tear of the new machinery or in any other
manner whatsoever, and without limiting the generality of the foregoing, excludes application
or installation of parts not completed in accordance with Convey-All operator’s manual,
specifications, or printed instructions.
Written notice shall be given by registered mail, to Convey-All within seven (7) days after the
defect shall have become apparent or the repairs shall have become necessary, addressed
as follows: Convey-All Industries Inc, Box 2008, 130 Canada Street
Winkler Manitoba R6W 4B7
Canada
This warranty shall expire one (1) year after the date of delivery of the new machinery.
If these conditions are fulfilled, Convey-All shall at its own cost and at its own option either repair
or replace any defective parts provided that the buyer shall be responsible for all expenses
incurred as a result of repairs, labor, parts, transportation or any other work, unless Convey-All
has authorized such expenses in advance.
The warranty shall not extend to any repairs, changes, alterations, or replacements made to the
new equipment other than by Convey-All or its authorized dealers or employees.
This warranty extents only to the original owner of the new equipment.
This warranty is limited to the terms stated herein and is in lieu of any other warranties
whether expressed or implied, and without limiting the generality of the foregoing, excluded all
warranties, expressed or implied or conditions whether statutory or otherwise as to quality and
fitness for any purpose of the new equipment. Convey-All disclaims all liability for incidental or
consequential damages.
This machine is subject to design changes and Convey-All shall not be required to retrofit or
exchange items on previously sold units except at its own option.
WARRANTYVOID IF NOT REGISTERED

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
WARRANTY REGISTRATION FORM & INSPECTION REPORT
This form must be filled out by the dealer and signed by both the dealer and buyer at the time of delivery.
Buyer’s Name ______________________________ Dealer’s Name _____________________________
Address __________________________________ Address __________________________________
City ______________________________________ City ______________________________________
Province/State _____________________________ Province/State _____________________________
Postal Code/Zip Code ________________________ Postal Code/Zip Code _______________________
Country ___________________________________ Country __________________________________
Phone Number _____________________________
Unit’s Model Number ________________________ Unit’s Serial Number ________________________
Delivery Date ______________________________ General Purpose: £Private £Commercial
UNIT INSPECTION SAFETY INSPECTION
£All Fasteners Tight £All Guards, Shields Installed and Secured
£Hydraulic Hoses Free and Fittings Tight £All Safety Decals Installed and Legible
£Conveyor Belts Move Freely £Reflectors, Slow Moving Vehicle (SMV) Clean
£Conveyor Belts Aligned and Tensioned £All Lights Clean and Working
£Drive Belts Aligned and Tensioned £Reviewed Operating and Safety Instructions
£Folding conveyor Folds Freely
£Checked Engine Fluid Levels
£Lubricated Machine
Ihave thoroughly instructed the buyer on the above described equipment which review included the Operator’s
Manual content, equipment care, adjustments, safe operation and applicable warranty policy.
Date _____________________ Dealer’s Rep. Signature ___________________________________
The above equipment and Operator’s Manual have been received by me and I have been thoroughly instructed
as to care, adjustments, safe operation and applicable warranty policy.
Date _____________________ Buyer’s Signature ________________________________________
WHITE YELLOW PINK
CONVEY-ALL DEALER CUSTOMER

01.2016 i
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
TABLE OF CONTENTS
DESCRIPTION PAGE
Section 1: INTRODUCTION ............................1-1
1.1 Operator Orientation .............................1-1
1.2 Serial Number Location...........................1-1
Section 2: SAFETY...................................2-1
2.1 Safety Orientation ...............................2-2
2.2 General Safety..................................2-2
2.3 Equipment Safety Guidelines ......................2-3
2.4 Safety Training ..................................2-4
2.5 Safety Decals...................................2-4
2.5.1 How to Install Safety Signs .....................2-4
2.6 Work Preparation................................2-5
2.7 Maintenance Safety..............................2-6
2.8 Placement Safety................................2-6
2.9 Operating Safety ................................2-7
2.10 Hydraulic Safety................................2-8
2.11 Transport Safety................................2-8
2.12 Battery Safety .................................2-9
2.13 Lock-OutTag-Out Safety .........................2-9
2.14 Storage Safety.................................2-9
2.15 Safety Symbol Identification .....................2-10
Section 3: OPERATION ...............................3-1
3.1 Machine Components ............................3-2
3.2 Components and Controls.........................3-3
3.3 Machine Break-In................................3-7
3.4 Pre-Operation Checklist...........................3-7
3.5 Operating on Site................................3-8
3.5.1 Stopping Conveyor ..........................3-10
3.5.2 Emergency Stopping.........................3-10
3.5.3 Restarting after Emergency Stop ...............3-10
3.5.4 Unplugging ................................3-10
3.6 Operating Hints ................................3-11
3.7 Storage ......................................3-12
3.8 Removing from Storage..........................3-12

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
ii 01.2016
TABLE OF CONTENTS con’d
DESCRIPTION PAGE
Section 4: SERVICE AND MAINTENANCE ................4-1
4.1 Fuels, Fluids and Lubricants .......................4-1
4.1.1 Greasing ...................................4-2
4.2 Servicing Intervals...............................4-2
4.2.1 Every 10 Hours or Daily .......................4-2
4.2.2 Every 50 Hours, 50 Loads or Weekly .............4-3
4.2.3 Every 200 Hours, 200 Loads or Monthly...........4-6
4.3 Maintenance Procedures..........................4-7
4.3.1 Slave Conveyor Drive Chain ....................4-7
4.3.2 Conveyor Belt Tension.........................4-8
4.3.3 Conveyor Belt Alignment.......................4-8
4.3.4 Conveyor Belt Replacement ....................4-9
4.4 Service Record ................................4-11
Section 5:TROUBLE SHOOTING .......................5-1
Section 6: SIGN-OFF FORM ...........................6-1
Section 7: REFERENCE...............................7-1
7.1 Specifications ..................................7-1
7.2 Bolt Torque.....................................7-2

01.2016 1-1
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
Section 1: INTRODUCTION
Congratulations on your choice of a Convey-All Commercial Seed Tender to complement your seed delivery
system in your agricultural operation.This equipment has been designed and manufactured to exceed the exacting
standards for such equipment in the agricultural industry and will keep your seed delivery operation working at
optimum efficiency.
The tender is intended to be mounted onto a truck bed. The CST and truck are separate equipment.There is no
information relating to the truck in this document.
Safe, efficient and trouble free operation of your tender system requires that you and anyone else who will be
operating or maintaining the machine, read and understand the Safety, Operation, Service & Maintenance and
Trouble Shooting information contained within this Operator’s Manual.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your Convey-All
Industries Inc, dealer or distributor for assistance, information, additional/replacement copies, or a digital copy of
this manual.
1.1 OPERATOR ORIENTATION
The directions;left, right, front and rear, as mentioned
throughout this manual, are as seen from the truck
driver’s seat and facing the direction of travel.
1.2 SERIAL NUMBER LOCATION
Always give your dealer the serial number of your
bean tender when ordering parts or requesting
service or other information.
The tender’s serial number is located on the rear
hopper support leg, beside the hydraulic valves.
Write the numbers in the below for easy reference.
CST Model No: __________________________
CST Serial No: __________________________
Engine Model No. (if equipped): ________________
Engine Serial No.(if equipped): ________________
Fig 1 - Rear, Driver Side of Tender

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
1-2 01.2016
This page intentionally left blank

01.2016 2-1
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
SIGNAL WORDS:
Note the use of the signal words:
DANGER, WARNING, CAUTION and
NOTICE with their safety messages.
The appropriate signal word for each
message has been selected using the
following guide-lines.
The Safety Alert Symbol identifies
important safety messages on the
Convey-All Commercial Seed Tender
and in this manual.
When you see this symbol and/or the
signal words described below, obey
the accompanying message to avoid
possible injury or death.
Why is SAFETY important to you?
3 Big Reasons:
• Accidents Disable and Kill
• Accidents Cost
• Accidents Can Be Avoided
DANGER - Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
This signal word is to be limited to the most extreme
situations typically for machine components which,
for functional purposes, cannot be guarded.
WARNING - Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
This word identifies hazards that are exposed when
guards are removed. It may also be used to alert
against unsafe practices.
CAUTION - Indicates a potentially hazardous situation that, if not
avoided, may result in minor or moderate injury. It
may be used to alert against unsafe practices.
NOTICE - Indicates practices or situations which may result in
the malfunction of, or damage to, the equipment.
Section 2: SAFETY
This Safety Alert Symbol means:
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
2-2 01.2016
2.2 GENERAL SAFETY
• Read and understand the Operator’s
Manual and all safety signs before
operating, maintaining, adjusting or
unplugging the CST.
• Only trained competent persons shall operate
the unit. An untrained operator is not qualified to
operate the machine.
• Have a first-aid kit available for use
should the need arise and know how to
use it.
• Provide a fire extinguisher for use in
case of an accident. Store in a highly
visible place.
• Do not allow children, spectators or bystanders
within hazard area of machine.
• Wear appropriate protective gear. This list includes
but is not limited to:
- A hard hat
- Protective shoes with
slip resistant soles
- Eye protection
- Heavy gloves
- Hearing protection
- Respirator or filter
mask
• Place all controls in neutral or off, stop engine,
remove ignition key and wait for all moving parts
to stop before servicing, adjusting, repairing, or
unplugging.
• Review safety related items annually with all
personnel who will be operating or maintaining the
CST.
2.1 SAFETY ORIENTATION
YOU are responsible for the SAFE operation and
maintenance of your Convey-All Commercial Seed
Tender (CST). Be sure that you and anyone else who
will operate, maintain or work around the CST be
familiar with the safety, operating and maintenance
procedures. This manual will take you step-by-step
through your working day and alerts you to all good
safety practices that should be adhered to while
operating the CST.
Remember, YOU are the key to safety. Good safety
practices not only protect you but also the people
around you. Make these practices a working part
of your safety program. Be certain that EVERYONE
operating this equipment is familiar with, and follows
all the safety precautions. Most accidents can be
prevented. Do not risk injury or death by ignoring
good safety practices.
• CST owners must give operating instructions to
operators or employees before allowing them to
operate the machine.Procedures must be reviewed
annually thereafter per OSHA (Occupational Safety
and Health Administration) regulation 1928.57.
• The most important safety device on this equipment
is a SAFE operator.It is the operator’s responsibility
to read and understand ALL Safety and Operating
instructions in the manual and to follow them. Most
accidents can be avoided.
• A person who has not read and understood all
operating and safety instructions is not qualified
to operate the machine. An untrained operator
exposes himself and bystanders to possible serious
injury or death.
• Unauthorized modification may impair the function
and/or safety of the equipment. The change could
also affect the life of the equipment.
• Think SAFETY! Work SAFELY!

01.2016 2-3
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
• The operator should be a responsible, properly
trained and physically able person familiar with
farm machinery and trained in this equipment’s
operations.
• Under no circumstances should young children be
allowed to work with this equipment.
• If the elderly are assisting with farm work, their
physical limitations need to be recognized and
accommodated.
• Do not allow persons to operate this unit until they
havereadthismanual.They should havea thorough
understanding of the safety precautions and of how
it works.
Review the safety instructions with all users
annually.
• Never exceed the limits of a piece of machinery.
If its ability to do a job, or to do so safely, is in
question - DON’T TRY IT.
• Do not modify the equipment in any way.
Unauthorized modification result in serious injury or
death and may impair the function and life of the
equipment.
2.3 EQUIPMENT SAFETY GUIDELINES
• Safety of the operator and bystanders is one of
the main concerns in designing and developing
equipment. However, every year many accidents
occur which could have been avoided by a few
seconds of thought and a more careful approach to
handling equipment.
You, the operator, can avoid many accidents by
observing the following precautions in this section.
Toavoidpersonalinjury ordeath,studythefollowing
precautions and insist those working with you, or for
you, follow them.
• In order to provide a better view,
certain photographs or illustrations in
this manual may show an assembly
with a safety shield removed. However,
equipment should never be operated in
this condition. Keep all shields in place.
If shield removal becomes necessary
for repairs, replace the shield prior to
use.
• Replace any safety or instruction decal that is not
readable or is missing.
• Never use alcoholic beverages or drugs which can
hinder alertness or coordination while operating
this equipment.
Consult your doctor about operating this machine
while taking prescription medications.

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
2-4 01.2016
2.4 SAFETYTRAINING
• Safety is a primary concern in the design and
manufacture of our products. Unfortunately, our
efforts to provide safe equipment can be wiped out
by a single careless act of an operator or bystander.
• Hazard control and accident prevention are
dependentupon the awareness,concern,prudence
and proper training of personnel involved in the
operation, transport, maintenance and storage of
this equipment.
• Ithasbeensaid,“Thebestsafetyfeature
is an informed, careful operator.”We ask
you to be that kind of an operator. It is
the operator’s responsibility to read and
understand ALL Safety and Operating
instructions in the manual and to follow
these.Accidents can be avoided.
• Working with unfamiliar equipment can lead
to careless injuries. Read this manual before
operating, to acquaint yourself with the machine.
If this tender is used by any person other than
yourself, is loaned or rented, it is the machine
owner’s responsibility to make certain that the
current/future operators:
- Reads and understands the operator’s manuals.
- Is instructed in safe and proper use.
• Know your controls. Know how to stop the truck
engine, and tender’s conveyor quickly in an
emergency.
• Train all new personnel and review instructions
frequently with existing workers. Be certain only
a properly trained and physically able person will
operate the machinery.
Personnel who have not read this manual are not
qualified to operate the machine. An untrained
operator exposes himself and bystanders to
possible serious injury or death.
• Physical limitations of the employees need to be
recognized and accommodated.
2.5 SAFETY DECALS
• Keep signage clean and legible at all times.
• Replace safety decals that are missing or have
become illegible.
• If an original part which contained a safety decal,
has been replaced by a new part; it show also
display the decal.
• All safety decals have a part number in the lower
right hand corner. Use this part number when
ordering replacements.
• Decalsareavailablefromyourauthorizeddistributor,
dealer’s parts department or from Convey-All
Industries Inc.
2.5.1 How to Install Safety Signs:
1. Be sure that the installation area is clean and dry.
2. Ensure temperature is above 50°F (10°C).
3. Determine exact position before you remove the
backing paper.
4. Remove the smallest portion of the split backing
paper.
5. Alignthesignover thespecifiedareaand carefully
press the small portion with the exposed sticky
backing in place.
6. Slowly peel back the remaining paper and
carefully smooth the remaining portion of the sign
in place.
7. Small air pockets can be pierced with a pin and
smoothed out using the piece of sign backing
paper.

01.2016 2-5
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
• Clear working area of stones, branches or hidden
obstaclesthatmight behookedor snagged,causing
injury or damage.
• Operate only in daylight or good artificial light.
• Be sure machine is in a stable position, is adjusted
and in good operating condition.
• Ensure that all safety shielding and safety decals
are properly installed and in good condition.
• Before starting, inspect the unit for any loose bolts,
worn parts, cracks, leaks and/or frayed belts. Make
the necessary repairs.
Always follow maintenance instructions.
2.6 WORK PREPARATION
• Never operate the truck hydraulics and
CST until you have read and completely
understand this manual. Read each
of the Safety Messages found on the
safety signs on the tender.
• Personal protective equipment including;
- hard hat
- safety glasses
- safety shoes
- gloves
are recommended during operation,
adjustment, maintaining, repairing,
removal, or moving the implement.
• Do not allow long hair, loose fitting clothing or
jewelry to be around equipment.
• PROLONGED EXPOSURETO LOUD NOISE MAY
CAUSE PERMANENT HEARING LOSS!
Agricultural equipment can often be
noisy enough to cause permanent,
partial hearing loss. We recommend
that hearing protection be worn on a full-
time basis if the noise in the operator’s
position exceeds 80db.
Noise over 85db on a long-term basis can cause
severe hearing loss.
Noise over 90db adjacent to the operator over
a long-term basis may cause permanent, total
hearing loss.
Note:
Hearing loss from loud noise
(tractors, chain saws, radios, etc.)
is cumulative over a lifetime
without hope of natural recovery.

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
2-6 01.2016
2.7 MAINTENANCE SAFETY
• Review the Operator’s Manual and all
safety items before working with and
maintaining the tender.
• Place all controls in neutral or off, stop engine,
remove ignition key and wait for all moving parts
to stop before servicing, adjusting, repairing or
unplugging.
• Follow good shop practices:
- Keep service area clean and dry.
- Be sure electrical outlets and tools
are properly grounded.
- Use adequate light for the job at hand.
• Before applying pressure to a hydraulic
system, make sure all components are
tight and that hoses and couplings are
in good condition.
• Relieve pressure from hydraulic circuit before
servicing.
• Keephands,feet, hair and clothing away
from all moving and/or rotating parts.
• Make sure there is plenty of ventilation.
Never operate the engine in a closed building.
The exhaust fumes may cause asphyxiation.
• Clear the area of bystanders, especially children,
when carrying out any maintenance and repairs or
making any adjustments.
• Before resuming work, install and secure all guards
when maintenance work is completed.
• Keep safety decals clean.Replace any signage that
is damaged or not clearly visible.
2.8 PLACEMENT SAFETY
• Stay away from overhead power lines
when moving the tender. Electrocution
can occur without direct contact.
• Locate unit to provide ample space for loading or
unloading.
• Store Folding Conveyor in its folded position when
moving.Unfold only when ready to unload.
• Be familiar with the machine’s hazard zones. If
anyone enters the hazard area, shut down machine
immediately.
Clear the area before restarting.
• Operate the tender on level ground free of debris.

01.2016 2-7
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
• Be familiar with machine hazard areas. If anyone
enters these spaces, shut down machine
immediately. Clear the area before restarting.
• Keephands,feet, hair and clothing away
from all moving and/or rotating parts.
• Do not allow riders on the tender when
transporting.
• Keep working area clean and free of
debris to prevent slipping or tripping.
• Stay away from overhead obstructions
and power lines during operation and transporting.
Electrocution can occur without direct contact.
• Do not operate machine when any guards are
removed.
• Set park brake on tractor before starting.
• Be sure that conveyor is empty before raising/
lowering, swinging or folding.
2.9 OPERATING SAFETY
• Please remember it is important that you read and
heed the safety messages on the CST. Clean or
replace all decals that cannot be clearly read and
understood. They are there for your safety, as well
as the safety of others.
• Ensure that everyone operating the
CST, working on, or around it, reads
and understands all the information in
the operator’s manual.
Review the safety, operating and maintenance
instructions annually.
• Keep all bystanders, especially children, away
from the machine when loading or unloading. Only
authorized personnel should be in the area when
carrying out maintenance work.
• Do not place hands, arms or body
between tender and folding conveyor
frame to prevent pinching or crushing.
Components can move unexpectedly.
•
• Never work near the hopper gate
cylinders while they are in operation.
• Use care when climbing on frame or
ladder to prevent slipping or falling.
• Establish a lock-out, tag-out policy for the work site.
Be sure all personnel are trained in and follow all
procedures. Lock-out, tag-out all power sources
before servicing the unit or working around loading/
unloading equipment.
• Place all controls in neutral. Stop the engine.
Remove ignition key and wait for all moving parts
to stop before servicing, adjusting, repairing or
unplugging.

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
2-8 01.2016
2.10 HYDRAULIC SAFETY
• Always place all hydraulic controls in neutral before
disconnecting and working on hydraulic systems.
• Relieve pressure in hydraulic system before
maintaining or working on machine.
• Make sure that all components in the hydraulic
system are kept in good condition and are clean.
• Replace any worn, cut, abraded, flattened or
crimped hoses.
• Donotattemptanymakeshiftrepairstothehydraulic
fittings or hoses by using tape, clamps or cements.
The hydraulic system operates under extremely
high-pressure. Such repairs will fail suddenly and
create a hazardous and unsafe condition.
• Wear proper hand and eye protection
when searching for a high-pressure
hydraulic leak. Use a piece of wood
or cardboard as a backstop instead of
hands to isolate and identify a leak.
• If injured by a concentrated high-
pressure stream of hydraulic fluid, seek
medical attention immediately. Serious
infection or toxic reaction can develop
from hydraulic fluid piercing the skin
surface.
2.11 TRANSPORT SAFETY
• Close valves in hydraulic line before transporting.
• Check that all the lights, reflectors and other lighting
requirements are installed and in good working
condition.
• Always engage folding conveyor transport lock
before transporting.
• Comply with all local laws governing safety and
transporting of equipment on public roads.
• Do not exceed a safe travel speed. Slow down for
rough terrain and when cornering.
• Stay away from overhead power lines.
Electrocution can occur without direct
contact.
• Plan your route to avoid heavy traffic.
• Do not drink and drive.
• Be a safe and courteous driver. Always yield to
oncoming traffic in all situations, including narrow
bridges, intersections, etc. Watch for traffic when
operating near or crossing roadways.

01.2016 2-9
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
2.12 BATTERY SAFETY
• Keep all sparks and flames away from
batteries, as gas given off by electrolyte
is explosive.
• Avoid contact with battery electrolyte: wash off any
spilled electrolyte immediately.
• Wear safety glasses when working near
batteries.
• Do not tip batteries more than 45 degrees, to avoid
electrolyte loss.
• Toavoidinjuryfromsparkorshortcircuit,disconnect
battery ground cable before servicing any part of
electrical system.
• If equipped with optional remote control:
Boosting the engine through the battery, or
recharging the battery, will cause a short in the
remote control system, killing it.
To boost the engine:
- Remove the fuse from the remote control
receiver box
- Boost the engine
- Reinstall the fuse
To recharge the battery:
- Disconnect the battery cables
- Recharge the battery
- Reconnect the cables
WARNING
FOLLOW PROCEDURE OR
DAMAGE TO REMOTE CONTROL
WILL RESULT:
To Boost Engine;
Remove Fuse from remote control
receiver box, Boost, reinstall Fuse
To Recharge Battery;
Disconnect battery cables,
Recharge, reconnect cables 36-3000-0029
• Before using thebattery, after it hasbeeninstorage,
be sure it has the optimal charge.
2.13 LOCK-OUTTAG-OUT SAFETY
• Establish a formal Lock-Out, Tag-Out program for
your operation.
• Train all operators and service personnel before
allowing them to work around the equipment.
• Provide tags on the machine and a sign-up sheet to
record tag out details.
2.14 STORAGE SAFETY
• Store the CST on a firm, level surface.
• Store in an area away from human activity.
• If required, make sure the unit is solidly blocked up.
• Make certain all mechanical locks are safely and
positively connected before storing.
• Remove the battery. Be sure it is fully charged.
- Store it inside.
- Do not sit the battery on a cold concrete floor.
• Do not permit children to play on or around the
stored machine.
36-3000-0029

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
2-10 01.2016
2.15 SAFETY SYMBOL IDENTIFICATION
There are various types of safety messages on decals in many locations on the CST. Good safety practices include
being familiar with the signage, the type of warning, the area, and the function related to that area.
REMEMBER - If safety decals have been damaged, removed, become illegible, or parts were replaced without
signage, new decals must be applied. Decals are available from your authorized dealer.
Fig 2 - Driver Side of Tender
36-3000-0015
36-1700-0005
36-1700-0013
36-3000-0004 36-3000-0004

01.2016 3-1
Operator’s Manual:Commercial Seed Tender (CST-34 Series)
Section 3: OPERATION
It is the responsibility of the owner or operator to read this manual and to train all other operators before they start
working with the tender. Follow all safety instructions exactly. It is everyone’s business. By following recommended
procedure, a safe working environment is provided for the operator, bystanders and the area around the work site.
The design and configuration of this tender includes safety decals and equipment. Hazard controls and accident
prevention are dependent upon the personnel operating and maintaining it. Their awareness, concern, prudence
and proper training are crucial.
Many features incorporated into this machine are the result of suggestions made by customers like you. Read this
manual carefully to learn how to operate the machine safely. There are instructions on how to set it, to provide
maximum efficiency. By following the operating instructions, in conjunction with a good maintenance program, your
CST will provide many years of trouble free service.
• Read and understand the Operator’s Manual,
and all safety decals, before using. Review safety
related items annually.
• Place all controls in neutral, stop the engine,
remove ignition key. Wait for all moving parts to
stop before servicing, adjusting, repairing or
unplugging.
• Clear the area of bystanders, especially children,
before starting. If anyone enters hazard areas,
shut down machine immediately. Clear the area
before restarting.
• Install and secure all guards before starting.
Do not operate machine when any guards are
removed.
• Use care when climbing on frame or ladder to
prevent slipping or falling.
• Do not allow riders on the CST when transporting.
Operating Safety
• Stay away from overhead obstructions and power
lines during operation. Electrocution can occur
without direct contact.
• Keep hands, feet, hair and clothing away from all
moving and/or rotating parts.
• Do not place hands, arms or body between
compartment and folding conveyor frame to
prevent pinching or crushing. Components can
move unexpectedly.
• Keep hydraulic components in good condition.
• Keep working area clean and free of debris to
prevent slipping or tripping.
• Establish a lock-out, tag-out policy for the
work site. Train all personnel in, and follow all
procedures. Lock-out, tag-out all power sources
before servicing the unit or working around
loading/unloading equipment.

Operator’s Manual:Commercial Seed Tender (CST-34 Series)
3-2 01.2016
3.1 MACHINE COMPONENTS
The Commercial Seed Tender is available in three
sizes depending on the required seed capacity.
The CST is shown mounted onto a truck bed. The
owner is responsible for mounting the tender onto a
truck with sufficient load capacity.
A self-contained hydraulic power pack is an option. If
equipped, it would be mounted onto the driver side.
It would consists of an engine and battery, fuel tank,
hydraulicpump,oilreservoirandassociatedplumbing.
A remote control is also an option. The receiver
would be mounted inside the rear hopper support. All
operations on the tender could be controlled remotely.
Manual overrides are included. Each hopper can be
opened or closed individually.
The main components are shown below.
*The position of components may vary depending
on the model.
a. Hoppers (number varies by model)
b.Hopper Discharge Gate
c. Folding Conveyor
d. Slave Conveyor
e.Slave Conveyor Discharge Spout
f. Hydraulic Valves
g. Remote Control Handset (Optional)
h. Ladder
i. Catwalk with Rail
j. Canvas Tarp
k. Tarp Controls
l. Document Container
Fig 3 - Left Side of CST-1834, Remote Control Handset Above
aj
g
i
b lk b d e
fhb c
