Graco 204-352 User manual

306–568
Rev. B
Supersedes 4/75
First choice when
quality counts. 

INSTRUCTIONS–PARTS LIST
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
120 to 400 lb. SIZE, EXPOSED DRUM
Elevator
200 psi (1.4 MPa, 14 bar) Maximum Working Pressure
Model 204–352
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1996, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001

 
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Drawing, Elevator Assembly 5. . . . . . . . . . . . . . . .
Parts Drawing, Support & Mounting Brackets 6. . . . . .
Parts List 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting Hole Layout 8. . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Warranty 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Number 12. . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
DThis equipment is for professional use only.
DRead all instruction manuals, tags, and labels before operating the equipment.
DUse the equipment only for its intended purpose. If you are not sure, call your Graco distributor.
DDo not alter or modify this equipment.
D Check equipment daily . Repair or replace worn or damaged parts immediately.
D Handle hoses carefully . Do not pull on hoses to move equipment.
DRoute hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 66_ C (150 _F) or below –40_ C (–40 _F).
DComply with all applicable local, state, and national fire, electrical, and safety regulations.
DUse only hand-powered pumps to fill the booster gun with lubricant.


Installation
1. Place the unit in the desired location, making sure
to have adequate clearance for plumbing while the
unit is being raised or lowered. Overall height of
the unit when raised is 94” (2930 mm) See
Dimensions on page 8.
2. Level the base, using metal shims if necessary,
and bolt the unit to the floor using the mounting
holes provided in the elevator base.
3. If desired, the elevator base can be repositioned to
permit raising the pump from one drum, pivoting
180, and lowering it into another drum. See
Fig. 1. The support bracket swivels 360on the
elevator riser tube.
4. Loosen the elevator clamps and slide the support
bracket down over the elevator riser tube. See
Fig. 1. Temporarily position the bracket high
enough to permit mounting the pump, and loosely
clamp the bracket to the elevator riser tube.
5. Place the pump in the pump mounting bracket,
and secure it with the provided screws.
6. Loosen the elevator clamps, and slide the bracket
and pump down until the pump intake valve rests
on the floor.
7. Mount the elevator control valves on the wall, and
connect them to the elevator and air supply as
shown in the Parts Drawing on page 6. Connect
the fluid lines and air lines to the pump.
06571
Fig. 1
elevator clamps
elevator riser tube
pump mounting
bracket
elevator base

4 306-568
Operation
See Fig. 2. To raise the elevator, pull out on the knob
of the push-pull valve. The speed at which the elevator
raises can be adjusted at the restrictor valve: Loosen
the locknut, and turn the restrictor valve screw clock-
wise to decrease the speed, and counterclockwise to
increase the speed. Tighten the locknut when adjust-
ment is complete.
Position an opened drum of material against the eleva-
tor base. Loosen the setscrews holding the pump
mounting plates to support the bracket and position the
pump to line up with the drum opening. Tighten the
setscrews.
Push in on the knob of the push-pull valve, and guide
the pump into the drum.
Lubrication
Every two to six weeks, lubricate the elevator as
follows: Disconnect the air supply, and relieve the air
pressure; remove the elevator cap (19), and lubricate
the inner surface of the elevator riser tube (14) and
leather cup (10) with a few drops of lightweight,
high-grade motor oil. See Fig. 3.
06532
Fig. 2 06570
Fig. 3
19
14
10
push–pull
valve
restrictor
valve
Service
Elevator Service
To disassemble the elevator for service, unscrew and
remove the elevator riser tube (14), unscrew the piston
cap screw (20) from the piston body (11), and unscrew
the guide tube (13) from the piston body . Clean and
inspect all parts for wear or damage and reassemble,
using new parts as needed.
When reassembling, use plastic thread sealer on all
threads, and coat the inner surface of the riser tube
(14) with no. 2 lithium-base grease.
Push-Pull V alve Service
Worn washers, gaskets, or seals may cause valve
failure. Shut off the air supply and remove the valve
from the mounting bracket. Place the valve body in a
vise and disassemble. Replace any worn parts and
reassemble using the parts drawing on page 6 as a
guide.


Parts Drawing,
Elevator Assembly
06524
3
7
19
18
9
20
10
5
4
8
15
14
17
16
13
11
12
22
21

 
Parts Drawing,
Support & Mounting Brackets
06566
06527
06567
41
40
*48
52
49
*44
47*
51
46
*45
43
50
42
56
55
57
54
Detail A, Push–Pull Valve Detail B, Restrictor Valve
29
30
26
37
58
34
28
24
28 39
push-pull valve
(see Detail A)
27
36
24
27
to air supply
53
restrictor valve
(see Detail B)
59

7306-568
Parts List
Ref.
No. Part No. Description Qty.
1 204–385 ELEVAT OR ASSY . (Series C)
Includes items 2–22 1
2 100–055 . SCREW , type “u” drive;
no. 6 x 0.25” (not shown) 2
3 100–139 . PLUG, pipe; 1/8 npt 1
4 100–422 . LOCKWASHER, int shkprf; 0.75” 1
5 150–230 . W ASHER, spreader 1
6 150–707 . PLA TE, serial (not shown) 1
7 155–899 . GASKET 1
8 156–306
. W ASHER 1
9 157–633 . SPRING, compression 1
10* 158–260 . LEA THER, cup 1
11 158–261 . BODY , elevator piston 1
12 158–262 . BEARING, elevator piston 1
13 158–263 . TUBE, elevator guide 1
14 158–264
. TUBE, elevator riser 1
15 158–265 . W ASHER 1
16 158–267 . TUBE, elevator stop 1
17 158–270 . BASE, elevator 1
18 158–429 . GASKET , copper 1
19 161–320 . CAP , elevator riser tube 1
20 162–408
. SCREW , elevator piston cap 1
21 167–871 . HOUSING, bearing 1
22 167–872 . BEARING, tape; T eflon1
23 204–510 SUPPOR T & MOUNTING BRACKETS
(Series C) Includes items 24–59 1
24 057–024 . TUBING, copper; .25” (6.4 mm)
OD; 5 ft (1524 mm) 1
25 100–055 . SCREW , type “u” drive;
no. 6 x 0.25” (not shown) 2
26 100–057 . SCREW , hex hd cap; .31”–18 x .75” 7
27 100–112 . FITTING, male elbow compression
0.25” (6.4 mm) tube x 1/8 npt 2
28 100–113
. FITTING, straight compression;
0.25” tube x 1/8 npt 2
Ref.
No. Part No. Description Qty.
29 100–181 . NUT , square; .31”–18 4
30 100–214 . LOCKW ASHER, spring; .31” 4
31 100–333 . SCREW , hex hd cap; .25”–20 x .50” 4
33 100–469
. SCREW , hex hd cap; .38”–16 x .75” 4
34 100–640 . SCREW , slotted hdless; .19–18 x .5” 4
35 150–707 . PLA TE, serial (not shown) 1
36 154–634 . BRACKET , valve 1
37 158–271 . CLAMP , elevator rise tube 2
38 161–327 . PLA TE, pump mounting 2
39 202–295
. PUSH-PULL V ALVE
Includes items 40–52 1
40 100–282 .. LOCKW ASHER, int shkprf; no. 6 1
41 100–757 .. SCREW , oval hd; no, 6–32 x .38” 1
42 154–519 .. KNOB 1
43 154–526 .. W ASHER 1
44* 154–570
.. W ASHER 1
45* 154–594 .. O-RING, nitrile rubber 1
46 155–500 .. O-RING, nitrile rubber 1
47* 155–811 .. SEAL, valve 1
48* 155–921 .. SEAL, valve 1
49 157–160 .. BODY , valve 1
50 157–161
.. GUIDE, valve 1
51 161–129 .. STEM, valve; large 1
52 161–132 .. STEM, valve; small 1
53 203–743 .. RESTRICT OR V ALVE
Includes items 54–57 1
54 101–448 .. NUT , ham; .38”–24 1
55 157–628
.. O-RING, nitrile rubber 1
56 160–162 .. BODY , valve 1
57 160–163 .. NEEDLE, restrictor valve 1
58 205–610 .. BRACKET , support, upper 1
59 205–611 .. BRACKET , support, lower 1
* Recommended tool box spare parts. Keep these spare
parts on hand to reduce down time.

 
Mounting Hole Layout
06533
5.50” (140 mm)
8.875”
(219 mm)
0.562”
(14.27 mm) holes
Dimensions
06565
Raised
94” (2390 mm)
Lowered
55” (1400 mm)
23” (585 mm)
13”
(330 mm)

9306-568
