CONWIN Precision Air V5 User manual

Precision Air V5 Inflator
Instruction Sheet
Setting the Precision Air Inflator Size Setting Chart
1 Precision Air Inflator
1 Power Cord
1 Foot Pedal
1 Carrying Case
2 Latex Outlets
2 Extension Tips
Precision Air Inflator Includes:
READ PRIOR TO USE:
1. To prevent the risk of electrical shock, do not use the Precision Air Inflator outdoors when weather
conditions are wet. Never operate unit on a wet floor or work area.
2. Prior to plugging the Precision Air Inflator into an electrical outlet, verify that the electrical rating
(listed on the label on the back of the Precision Air Inflator) is suitable for the outlet. The Precision
Air is not recommended for use in countries where electrical current is not consistently regulated.
3. Allow the unit to fully exhaust the air through the vent located on the bottom of the Precision Air
before tapping the foot pedal to begin the next cycle.
4. Operate the Precision Air in a temperature controlled environment. When working outdoors,
keep the unit out of direct sunlight. Avoid operating unit outdoors in extremely hot weather. If the
unit reaches temperatures that exceed normal working conditions, the thermal shut-off control will
automatically shut the system down.
5. If the Precision Air Inflator malfunctions or is damaged in any way discontinue use and unplug unit
from electrical outlet. Contact an authorized Conwin Service Center for details on how to receive service.
Never attempt to repair the Precision Air Inflator yourself. Opening the Precision Air Inflator case will
automatically void manufacturer warranty. Contact an authorized Conwin Service Center for all repairs.
Extension Tip
Foot Pedal
Digital Settings
Latex Outlet
To attach the outlets, firmly press on to each
filling port.
Plug the foot pedal into the side of the unit.Plug the power cord into the side of the unit and into an electrical
outlet. (A power strip with a surge protector is recommended.)
The digital display will appear when unit has power.
Reference the Size Setting Chart (Fig 1.0) to set
the Precision Air for the proper balloon size. Set
the appropriate number of Seconds by pressing
the arrow buttons on the left side of the control
panel digital display window.
Set the appropriate number of Tenths of a Second
by pressing the arrow buttons on the right side of
the control panel digital display window.
The following settings should be used as guidelines
for the Precision Air. Please note that size settings
will vary based on user preference, balloon color,
manufacturer and from unit to unit. To adjust the
size of balloon to your individual preference it is
necessary to inflate test balloons.
BALLOON SIZE APPROX. TIME SETTING
5"BALLOON 0.8 SECONDS
9"BALLOON 1.5 SECONDS
11"BALLOON 2.5 SECONDS
16"BALLOON 8 SECONDS
1
1
2
2
3

Service & Warranty
For assistance with service & repair issues or for warranty information,
please visit ConwinOnline.com, or call (818)-246-9233
CONWIN
4510 Sperry Street • Los Angeles, CA 90039
Phone [phone] FAX [phone]
0615 © Conwin Inc.
Using and Resetting the Counter
• Every time the foot pedal is pressed the cycle count will be displayed on the digital
display windows.
• The time setting for the ination cycle will disappear once the foot pedal has been
pressed. To verify or change the time setting for the inflation cycle, press any of the arrow
buttons on the control panel once.
• The balloon time setting will be displayed on the digital window. Press the Reset button
in the center of the control panel to set the counter back to zero.
If you detect balloons are not being identically sized from both outlets, follow the instructions below to recalibrate your inflator.
NOTE: Always use 11"balloons when comparing sizes. Once the desired size is
reached, all balloon sizes should consistently inflate to the same size when the digital
settings are changed. For time settings, refer to the Size Setting Chart on the front of
this instruction sheet.
To increase
balloon size
To decrease
balloon size
Determine which outlet is not
inflating to the correct size and
remove the detachable friction
fit outlet from the filling port
by pulling upward and gently
twisting as needed.
To increase the size of the balloon,
turn the tool counter clockwise in
quarter turn increments. To
decrease the size of the balloon,
turn the tool clockwise in quarter
turn increments. IMPORTANT:
Be careful not to over tighten
the setting. STOP turning the tool
clockwise if you feel resistance on
the tool.
Remove the allen wrench and
press the detachable friction
fit outlet back onto the filling
port by pushing downward and
gently twisting as needed. Inflate
two balloons to compare sizes.
Repeat steps 1 through 3 until
both balloons are identically
sized.
Insert the allen wrench into the filling outlet. Gently
apply downward pressure and slowly rotate the
tool until you hear a “click” sound and feel the tool
become fully engaged in the outlet.
Calibration Instructions
Inflating Balloons with the Precision Air Inflator
Place the Extension Tip over the Latex Outlet when
inflating 5"balloons. Slide the neck of the balloon all
the way down on the Extension Tip until the neck is
touching the base. To achieve consistent results, do
not cover the opening of the Extension Tips with
your fingers.
For 9" balloons and larger, remove the Extension
Tip and roll the neck of the balloon over the Latex
Outlet. To achieve consistent results, do not cover
the opening of the outlet with your fingers.
Tap the foot pedal to begin the inflation
cycle. When the system automatically
shuts-off, remove the balloons from the
outlets without allowing any of the air to
escape, and tie. Wait 3 seconds for the
auto exhaust vent to shut off before the
next cycle.
1
1
2
2
3
3 4
A 3/8 (9mm) allen wrench is required for calibrating the Precision Air.
