Coolon HT66 Series User manual

HT66 Luminaire with Fixed Plant Bracket
420mm 280mm
22mmØ17mm
85.5mm
136mm
34mm
34mm
45mm
20mm
MOUNTING BRACKET INSTALLATION
Mount light fitting to appropriate location.
(Tighten the M16 screws properly - not supplied)
Step 1
To adjust the mounting angle, unscrew M10 x 30 bolt
(with spring and washers) and loosen M16x40 bolt.
Adjust the angle of the fixture and once done, tighten the screws
until the fixture is fully locked in the desired position.
Step 3
Use Loctite® 243™
retaining compound
(not included)
to secure the bolt.
Page 1 / 2
[email protected] • aus. 1300 287 533 • intl. [phone] • www.coolon.com.au
Product must be installed by a suitably qualied person. All documentation is subject to change without notice. Refer to our website for the latest information.
www.coolon.com.au
Page 1 / 2 HT66 INDUSTRIAL LED LUMINAIRE MANUAL EDITION 2.0
380mm
HT66-470. Remote Power Supply *Cable glands not supplied
HT66-320. Remote Power Supply *Cable glands not supplied
269mm
324.5mm
M25x1.5
2x M25x1.5
2x M12x1.5
13mm
9.5mm
M20x1.5
2x M20x1.5
115mm
204mm
101mm
75mm 144mm
221mm
382mm
355mm
Step 2
Technical Specification
HT66-470-RPS230
HT66-470-RPS415
HT66-320-RPS
POWER
470W Max (including power supply)
470W Max (including power supply)
320W Max (including power supply)
VOLTAGE
100 – 240VAC 50/60Hz 127 – 250VDC
277 – 440VAC 50/60Hz 352 – 500VDC
200 – 440VAC 50/60Hz 254 – 550VDC
IP/IK RATING
IP66 / IK09
IP66 / IK09
IP66 / IK09
OPERATING TEMP.
-20 to +50°C
-20 to +50°C
-20 to +50°C

KIT CONFIGURATION HT66-470 (415VAC DELTA) KIT CONFIGURATION HT66-470 (230VAC)
Cable to Luminaire
HT66 - XXX - XXX - DC
PWR-CLN-600-CC2800-381AL-MP230 PWR-CLN-600-CC2800-381AL-MP415
Cable glands not included.
Size: M25 x 1.5
OUT IN
OPTIONAL
CONTROLS
FACTORY
CONNECTIONS
NOT TO BE
ALTERED
−n/c
NTC NTC
+
ACCESSORIES
Once the product has reached end of life, unit is to be disposed of in accordance to local e-waste laws or regulations. Do not dispose of these products as
unsorted municipal waste: take them for recycling. For information on your nearest recycling point, check with your local waste authority.
Distance between the power supply and luminaire can be extended up to 50 metres using a suitable extension loom.
See ACCESSORIES section for details.
If the NTC connection is not detected between the luminaire and power supply the power supply will operate in safe mode providing a 30%
power output. For optimal operation the wiring connections must be made according to the installation manual with the appropriate wire gauge.
KIT CONFIGURATION HT66-320
Luminaire
Cable = 2m
Power Supply
+
–
NTC
NTC
(Not Included)
230VAC IN
230VAC OUT
Optional
(Not Included)
Junction Box
(Not supplied)
Junction Box
(Not supplied)
Luminaire
Cable = 2m
Up to 50m
Cable Length
(Cable not supplied)
PART #
CBL-2C142C20-BKC-20
CBL-2C142C20-BKC-30
CBL-2C142C20-BKC-40
CBL-2C142C20-BKC-50
DESCRIPTION
Cable, 2C*14AWG, 2C*20AWG, Red, Black, White and Blue Conductors, Black Circular Jacket, 105°C 300V PVC/PVC, 8.5mm OD, 20 metres
Cable, 2C*14AWG, 2C*20AWG, Red, Black, White and Blue Conductors, Black Circular Jacket, 105°C 300V PVC/PVC, 8.5mm OD, 30 metres
Cable, 2C*14AWG, 2C*20AWG, Red, Black, White and Blue Conductors, Black Circular Jacket, 105°C 300V PVC/PVC, 8.5mm OD, 40 metres
Cable, 2C*14AWG, 2C*20AWG, Red, Black, White and Blue Conductors, Black Circular Jacket, 105°C 300V PVC/PVC, 8.5mm OD, 50 metres
Page 2 / 2
[email protected] • aus. 1300 287 533 • intl. [phone] • www.coolon.com.au
Product must be installed by a suitably qualied person. All documentation is subject to change without notice. Refer to our website for the latest information.
www.coolon.com.au
Page 2 / 2 HT66 INDUSTRIAL LED LUMINAIRE MANUAL EDITION 2.0
Cable to Luminaire
HT66 - XXX - XXX - DC
Cable glands not included.
Size: M25 x 1.5
OPTIONAL
CONTROLS
FACTORY
CONNECTIONS
NOT TO BE
ALTERED
−n/c
NTC NTC
+
Junction Box
(Not supplied)
Luminaire
Cable = 2m
Up to 50m
Cable Length
(Cable not supplied)
(Cable not supplied)
Up to 50m Cable Length
230VAC nominal input voltage 415VAC nominal input voltage
Use any 2 phases and connect to Aand N
**Optional loop-out terminals
are not connected on the
control board. A wiring
connection must be made
from the input wiring terminal
to the loop out terminal where
optional loop out is required.
Cable from
Luminaire
