CoolSpace BLIZZARD50 User manual

Operation and Maintenance Manual
BLIZZARD
50
CS6-50-VD
120V/60HZ


CS6-50-VD
Operation & Maintenance Manual
Table of Contents:
1.0 Introduction
1
2.0 Unpacking your COOL- SPACE®
1
3.0 Set-up of COOL-SPACE®unit
1
3.1 Connecting the water supply
1
3.2 Connecting the electrical supply
2
4.0 Operating procedures
3
4.1 Filling the unit with water
3
4.2 Starting the fan
4
4.3 Starting the pump and adjusting the water flow
4
5.0 Maintenance and storage
4
5.1 Removing the cooling media & accessing the inside of the unit
4
5.2 Daily maintenance
5
5.3 Periodic maintenance
5
5.4 Storage
5
6.0 Troubleshooting/Repair
6
6.1 Troubleshooting
6
6.2 Repair procedures
9
6.3 Technical support
9
7.0 Warranty
10
7.1 Warranty form
10
7.2 Warranty parts
10
7.3 Optional accessories and replacement parts
10
Due to continuous product innovations, we reserve the right to change product
specification without due notice.

1
Signal Word Definitions
DANGER indicates an imminently hazardous situation which,
if not avoided, WILL result in death or serious injury.
WARNING indicates a potentially hazardous situation which,
if not avoided, COULD result in death or serious injury.
CAUTION indicates a potentially hazardous situation which,
if not avoided, MAY result in minor or moderate injury.
IMPORTANT indicates a potentially hazardous situation
which, if not avoided, MAY result in property damage.
1.0 Introduction
COOL-SPACE®is a patented and registered Trademark of Hale Industries, Inc. and
manufactured in Indiana.
The COOL-SPACE®unit is a compact, self-contained, high-efficiency portable evaporative
cooler.
2.0 Unpacking your COOL-SPACE®unit
Carefully examine the carton for damage before opening. If the carton is damaged notify the
shipping company immediately.
3.0 Set-up of the COOL-SPACE®unit
The COOL-SPACE®unit is factory tested and ready to use. The unit should be placed on a
level surface, and the casters locked to prevent inadvertent movement. Follow instructions
below to connect water and electrical supply.
3.1 Connecting the water supply
Do not connect the COOL-SPACE®unit to any water source where water pressure exceeds 120
psi. This will cause permanent damage to the unit.
The COOL-SPACE®unit comes equipped with a female garden hose water source connection.
Attach the unit to a standard garden hose outlet for a water source. It is not recommended that
the unit be attached to any water source with operating pressures above 120 psi. If you have
purchased the optional portable water tank, use a standard garden hose (not provided) to
connect the tank to the cooler.

2
3.2 Connecting the electrical supply
The COOL-SPACE®unit should be plugged into a fused or circuit breaker protected 20 amp, 120
volt, and 60 Hz circuit.
All models utilize standard 120-volt power supply. The unit should be plugged into a fused or
circuit breaker protected 20 amp, 120 volt, 60 Hz circuit.
Table 1 shows the amperage requirements for the specific models. If an extension cord is
required, refer to Table 2 for the proper 3-conductor heavy-duty cord required.
Do not exceed the amperage ratings of the extension cord. Undersized extension cords result in
excessive drops in voltage, which cause the electric motors to generate excessive heat. This
condition results in inefficient motor operation and premature motor failure, WHICH WILL VOID
THE WARRANTY.
Table 1. Electrical Requirements
CS Model Number
Volts ± 10%
Frequency (Hz)
Running Amps
CS6-50-VD
120
60
8.2
Table 2. Cord size requirement based on length and max amp draw
Length In
Feet
Cord Size
16 Ga
14 Ga
12 Ga
10 Ga
0-50
13 A
18 A
25 A
30 A
50-100
10 A
13 A
18 A
25 A
A: Amps at 120 volt (de-rate for lower voltage)

3
4.0 Operating procedures
There are 3 factors to consider when determining where to place the COOL-SPACE®unit.
1. Fresh air supply: The inlet side of the unit (pad side) requires a constant,
uninterrupted supply of fresh air for maximum performance. A distance of 3 feet
clear space to any obstructions at the rear or inlet side of the unit is
recommended.
2. Discharge air flow: The cool air discharged from the unit should be free of
obstruction to allow the air to circulate in order to maximize the cooling zone.
3. Ventilation: In order to operate at maximum effectiveness, it is helpful to have
provisions to remove the air discharged from the COOL-SPACE®unit from the
cooling area. This ensures that the COOL-SPACE®unit does not recirculate air that
has already been through the evaporative cooling process.
The COOL-SPACE®unit must be placed on a level surface to operate correctly. Units create
an oval shaped air pattern. Obstacles such as racks and workbenches may interfere with the
air flow. An attempt should be made to locate the unit in such a manner that interruption of the
air pattern is held to a minimum. Multiple units may be required to cover larger areas.
4.1 Filling the unit with water
Once the COOL-SPACE®unit has been connected to a water source as described in 3.1, open
the water supply valve and the unit will fill with water. The float valve will shut off the water flow
when the sump is full.
4.2 Starting the fan
Set the fan switch to the “ON” position and adjust speed to your comfort level.

4
4.3 Starting the pump and adjusting the water flow
DO NOT flood the pads with water, keep them moist. New pads will take a few days before they
become completely saturated. It is normal to have several dry streaks on the face of the pads
about 1 to 2 inches wide. If the streaks are larger adjust the flow control knob to allow more water
to flow onto the pads. NOTE: New pads may also emanate an odor under initial operating
conditions from the resin used to construct the media. Flush the pads by running the pump
without the fan running for at least 12 hours; overnight is best. Empty the sump and refill. Repeat
if odor still exists.
NOTE: Run fan while adjusting the water flow.
Once the sump is full, the pump switch may be turned to the ‘ON’ position. The flow control
knob will need to be adjusted on initial start-up. It is located at the side of the unit; it controls
the volume of water that is delivered to the top of the cooling pads.
Prolonged use of hard water without proper water treatment will create mineral deposit
build up causing the pump to fail which is NOT COVERED BY WARRANTY
Pump is equipped with a LOW WATER CUT OFF which may take up to 5 minutes to reset each
time.
5.0 Maintenance and storage
ELECTRICAL SHOCK HAZARD
Disconnect the power supply before performing any service or maintenance on the unit. Failure
to do so may result in serious injury or death.
5.1 Removing the cooling media to access the inside of the unit
In order to perform any maintenance on internal components, the cooling pads must be
removed to access the inside of the unit.
1. Remove the (4) bolts connecting the pad retainer bar (pad-side) from the housing.
2. Starting with one of the center pads, tilt pads from the top; lift out of the unit.
Note: Reinstall pads correctly according to the markings on the pads.
An instructional video for removing the cooling media can be found at www.cool-space.com

5
5.2 Daily maintenance
When shutting down the COOL-SPACE®unit at the end of each workday, the pump should be
turned off approximately 15 minutes before the fan is turned off. This will allow the pads to drain
and dry out. This simple guideline will ensure long and efficient pad life as well as help to
control mildew and bacteria growth.
5.3 Periodic maintenance
ELECTRICAL SHOCK HAZARD
Disconnect the power supply before performing any service or maintenance on the unit. Failure
to do so may result in serious injury or death.
Depending on how often the COOL-SPACE®unit operates, this procedure should be
performed anywhere from every week for heavy use to monthly for light use. Shut down the
unit and drain the water sump. The cooling pads act as a filtering agent and remove dust and
other particles from the incoming air stream. These particles will flow into the sump and collect
there. Also, impurities in the water will collect in the sump. Maintenance tablets available at
www.cool-space.com.
Draining the Water Sump
1. Close the water flow valve and open the drain valve.
2. Run pump until it shuts off automatically. The sump will not be completely empty.
3. Turn unit off and disconnect the power supply.
4. Remove cooling pads, refer to section 5.1.
5. Clean out reservoir with either a towel or wet/dry vacuum.
6. Remove the water spray bar and its plug. Insure holes are free of debris.
7. Reinstall pads and pad retainer.
To keep the COOL-SPACE®unit operating at peak efficiency, ensure that the cooling pads are
kept clean and dust-free. Dust and other particles have an adverse effect on the media’s ability
to introduce water into the air stream. If the pad surface becomes dirty or dusty, clean with a
soft brush and water.
5.4 Storage
1. Remove the pads, as described in section 5.1
2. Clean with a soft brush and water to remove dust and debris. Never use bleach based
products as it will cause the pads to deteriorate.
3. Drain sump using procedure described in section 5.3 and wipe dry
4. Store the COOL-SPACE® unit in a dry area and cover if possible to prevent dust build-
up. Covers for your unit can be found online at www.cool-space.com

6
6.0 Troubleshooting/Repair
6.1 Troubleshooting
ELECTRICAL SHOCK HAZARD
Disconnect the power supply before performing any service or maintenance on the unit.
Failure to do so may result in serious injury or death.
The COOL-SPACE®unit consists of three systems: the fan, water distribution and pump. It is
important to determine which system of the COOL-SPACE®unit the problem is associated with.
This may not always be obvious, in that certain problems may be associated with more than one
system.
When determining which system has a problem, you must define the associated problem, (e.g.
the pump is not running). Although this might seem a bit simplified, several things may cause
this particular problem. So while defining the problem, a careful check of all systems should be
made to fully understand the extent of the problem.
If you have a complete understanding of all of the systems of the COOL-SPACE®unit and how
they depend on each other, it will be simple to define and solve any problem.
Necessary Tools:
Although the COOL-SPACE®unit is designed to be simple to maintain, it will be necessary to
have some basic hand tools (screwdrivers, pliers, adjustable wrenches, etc.) as well as a
volt/ohm meter when troubleshooting the electrical system.

7
6.1 Troubleshooting (continued)
Please use caution when troubleshooting or repairing all electrical components. Be certain that
all power is disconnected from the COOL-SPACE®unit before the cooling pads are removed to
gain access to the fan.
Water System
The water distribution system consists of two (2) assemblies:
oThe Water Inlet Assembly
Brass bulkhead fitting
Float valve assembly
oThe Hose and Valve Assembly
Spray Bar Assembly
Valve Assembly
Connection Hose
Problem
Check
Solution
Floor at side of COOL-SPACE®
unit is wet
Water inlet hose is loose at
supply hose or inlet hose is
loose at bulkhead fitting.
Tighten connections and/or
replace hose washers.
COOL-SPACE®unit overflows
from reservoir
Float valve is loose at bulkhead
fitting.
Water pressure is too high to
allow float valve to shutoff
(120psi max).
Tighten connections and/or
replace hose washers. Reduce
water pressure by adding an
inline reducer.
Water spitting from the unit or
dripping from pads.
Flow of water too strong
Cracked Hose & Valve
Assembly.
Hose connection loose
Drip retainer on spray bar
Ensure pads were installed
correctly
Reduce flow
Replace Hose & Valve
Assembly.
Tighten hose
Adjust
Reinstall correctly
Water leaking from drain valve. For worn washer, worn stem.
Make sure drain valve is closed
Replace washer.
Replace drain valve.
Water leaking from water flow
control valve.
Washer worn. Stem worn.
Jam nut or lock nut loose.
Replace water flow control
valve. Tighten Jam nut.
Too many dry streaks in the
pads.
Holes in spray bar blocked.
Adjust water flow.
Remove spray bar. Remove
plug and clean tube and holes.
Open water flow control valve.

8
6.1 Troubleshooting (continued)
Pump
Problem
Check
Solution
Pump motor will not run when
switch is turned on.
Turn fan on to check for power.
Is water level high enough to
make the low- water cut-off
circuit?
If fan doesn’t start; check
breaker and cord plug-in. If fan
does start; check for power to
and through pump switch (when
turned on). Fill water reservoir.
Pump motor hums when switch
is turned on, but does not pump
water.
Obstruction in impellor.
Pump motor failure.
Remove object(s).
Replace pump.
Pump makes loud noise while
running.
Object(s) in impellor, impellor
loose. Pump bearings bad.
Remove object(s).
Replace pump.
Breaker trips or fuse blows when
switch is turned on.
Check power cord length and
breaker rating.
Check for locked-up pump.
Refer to page 2 for unit
amperage draw and to
determine required cord gauge.
Replace pump.
Pump won’t run and power is
available. Pump is functional.
Make certain switch is working.
Is water level high enough to
make the low- water cut-off
circuit?
Replace switch if not completing
circuit. Fill water reservoir
enough to activate Low Water
Shut-off switch.
Pump runs but does not pump
water.
Air lock in outlet side of pump.
Make certain the impellor is
turning in pump.
Turn off and on to bleed.
If not, replace pump.

9
6.2 Repair procedures
Repairs should be performed by a qualified technician!
ELECTRICAL SHOCK HAZARD
Disconnect the power supply before performing any service or maintenance on the unit. Failure
to do so may result in serious injury or death.
BLIZZARD (CS6-50-VD) Fan Motor Replacement
1. Remove cap from bottom of motor. Disconnect wires. Clip wire ties.
2. Remove (4) fan mounting bolts from the front. (Support fan to ensure it doesn’t fall.)
3. Pull the fan out of the unit.
4. Remove blade mounting nut and blade.
5. Remove mounting arms by loosening (8) bolts holding the arms to the motor. (Make
note of arms positions for reinstallation.)
6. Install arms and blade on new motor.
7. Install fan in opening and secure with mounting bolts.
8. Reconnect wires and tie cord to motor arm to keep them out of fan.
Pump Replacement
1. Disconnect hose from pump.
2. Unplug the cord from the top of the pump by removing (2) screws
3. Remove pump from water sump and install new pump.
4. Reverse the above procedures to reconnect the wiring, lift pump bracket and reconnect
the hose. Secure wires to fan frame with wire ties to clear the fan blades. Be sure to
position the plug correctly.
5. Reinstall cooling pads and guards, reconnect power and test pump.
6.3 Technical support
Technical support and service are available directly from your distributor or
COOL-SPACE®Technical Support Line at 1-800-557-5716
Visit: www.cool-space.com
Email: sales@cool-space.com

10
7.0 Warranty
Under normal use, the warranty covers the unit and its components for sixty (60) months from
date of invoice. Refer to the manufacturer’s Warranty Policy for details. (Applies to units
purchased after January 1, 2017)
7.1 Warranty Form
You must register your COOL-SPACE®Portable Evaporative Cooler within fifteen (15) days of
initial purchase to validate your cooler’s warranty. You may fill out the warranty form supplied with
your unit and fax it to 1-317-485-0118 or register online at www.cool-space.com.
7.2 Warranty parts
Warranty replacement parts are available through your local distributor or supplier where you
purchased your COOL-SPACE®unit. If you have any questions or concerns, please contact us
direct at 1-800-557-5716 or at sales@cool-space.com. Please have your model number and
serial number ready.
DO NOT DISCARD FAULTY PARTS Check with the Manufacturer as they may need to be
returned for warranty credit.
7.3 Optional Accessories and Replacement Parts
Accessories and replacement parts are available from your local distributor or supplier or they
can be found online at www.cool-space.com.
Common BLIZZARD Replacement Parts
Fan Motor
CS-M50-VD-60HZ
Variable Speed
BLIZZARD-50 Variable Speed Direct Drive Motor
CS-E163-2
Pump w/ Low Water Shut Off
8” Pads
CS-H48-140
BLIZZARD-50 Cooling Media (Pad) w/ Edge Coat (6 required)
Float
CS-P143
½'' Compact Water Control Valve - Vertical
For exploded view drawings and wiring diagrams please go to
www.cool-space.com


CS-MAN-50V60H 02162018al
315 N Madison Street
Fortville, IN 46040
317-577-0417 · 800-557-5716
suppor[email protected]
www.COOL-SPACE.com

Switches machine between auto and manual
mode
In Auto Mode
• Indicator light will be on
• Machine will run when motion is detected
• When no motion detected, machine will run
for 10 minutes and then shut down
Puts machine into shutdown mode
• When pressed the pump shuts o and the fan
will continue to run for 15 minutes and then
shut down
• Works in auto and manual mode
Fan Pump Auto/Manual
Mode
15 Min.
Countdown
Timer
Remote
Sensor
Power Indicator
Red Light - Power Connected
Green Light - Power On Low Water Indicator
Power
On/O
Fan
REM
This manual suits for next models
1
Table of contents
Other CoolSpace Freezer manuals
