Decorative High-Bay
Luminaire

1
AVID Series
INNOVATION IN AN AESTHETICALLY DESIGNED SERIES
- Airports
- Automobile Dealerships
- Office
- Warehouse Retail
- Corridors
- Restaurants
LUMARK AVID
By combining an architectural form with superior lighting performance, the AVID series offers a scalable, aesthetically pleasing
series of luminaires that satisfies the needs of lighting designers, architects, and building owners. The series is designed with
four scaled sizes, enabling one consistent look throughout an application from the general lighting of large open spaces to
decorative accents over counters and retail displays. The AVID series offers a variety of optical choices including borosilicate
glass lens, prismatic acrylic lens, high performance aluminum reflector and an optional shroud. With a large range of lamping
options that include 20-400 watt metal halide, single and multi-lamp compact fluorescent, quartz halogen, and incandescent,
the series offers a high performance solution for a wide array of applications.

2
- Complete optical offering delivers high efficiencies up to 96%
- Multiple mounting configurations and decorative lens options create many different looks
- Cast aluminum construction makes the AVID series durable
- Available in four sizes, the AVID series is ideal for many different applications
SIZE APPLICATIONS
Mini Restaurant accent lighting
Small Office interiors and point of sales areas
Medium Retail spaces
Large Automotive dealerships
INDEX
Applications . . . . . . . . . . . . . . . . .pgs. 3 – 4
Mini and Small . . . . . . . . . . . . . .pgs. 5 – 8
Medium and Large . . . . . . . . . .pgs. 9 – 12
Product Matrix . . . . . . . . . . .pgs. 13 – 14

AVID Series
3
AVID SMALL

The AVID series provides superior performance in a wide range of
applications. The AVID Small is ideal for office interiors providing
general lighting for corridors and in conference rooms. The AVID
Mini is an attractive accent fixture that is perfect in a restaurant
setting. Open ceiling applications, such as automotive showrooms,
need superior foot candle levels on the floor space. The AVID
Medium and Large deliver the proper light levels at higher mounting
heights while maintaining the aesthetics of the space. The series
of products allows lighting designers the flexibility to use one size
or a combination of all four sizes to maintain a consistent look.
The AVID series delivers the required performance in a sleek
contemporary design.
4
AVID MINI
AVID MEDIUM

5
MOUNTING
Cast aluminum top can be specified for pendant or suspension mounting.
Pendant mounting comes with 3/8" pipe for the Mini and 1/2" pipe for the
Small with internal locking screw assuring security. Suspension mounting has
two stainless steel suspension cables with quick adjustment enabling the
luminaire to be quickly leveled.
FINISH
Housing components are finished in a five-stage cleaning and corrosion pretreatment system and coated and baked
with a premium TGIC polyester powder providing superior protection against fading and pealing. Standard colors
include white, grey, bronze, black, graphite metallic, and dark platinum. RAL or custom color matches available.
INTEGRAL BALLAST HOUSING
Integral ballast housing consists of heat dissipating aluminum finned
construction allowing thermal transfer from the electrical compartment to
the exterior surfaces through convection heat transfer assuring a lasting
reliable electrical gear.
MIDSECTION
Cast aluminum midsection is designed to dissipate the heat energy
away from the lamp compartment separating the optical cavity
from the integral ballast housing assuring a cool operation.
OPTICAL SYSTEM
Optical construction is designed to remain flexible providing
multiple distributions and optical types. The extensive
refractive and reflective optical systems with internal
distribution adjustments allow for a wide range of
application needs.
LAMP AND BALLAST SYSTEM
With a vast array of lamps available, the luminaire can be specified with the latest cost
effective lighting systems for the application needs.
Beautiful form in a compact package, the AVID Mini is a perfect fixture over tables in a restaurant or display counters.
Available with a wide array of optical choices and mounting options, the AVID Small is ideal for point of sale areas.
AVID Series
MINI AND SMALL

Product
Family
AIS=AVID
Series
Small
Finish
BK=Black
AP=Grey
BZ=Bronze
WH=White
DP=Dark Platinum
GM=Graphite Metallic
Options
F1=Single Fuse
F2=Double Fuse
LL=Lamp Included
FGS=Frosted Glass
Lens
CGL=Clear Glass Lens
DFR=Decorative
Frosted Ring
OR=Open Rated Socket
Lamp Wattage
HID
39=39W T6 G12
50=50W Medium Base
70=70W Medium Base
100=100W Medium Base
Compact Fluorescent
X=Number of Lamps
X26=(1 or 2) 26W
X32=(1 or 2) 32W
X42=(1 or 2) 42W
Quartz 1
250=250W
Incandescent 1
200=200W
Lamp Type
MH=Metal Halide
CF=Compact Fluorescent
IN=Incandescent
QZ=Quartz Halogen
Voltage
120=120V
208=208V
240=240V
277=277V
UNV=120-277V
MT=(standard
120/208/240/277)
Optical System
Borocilicate Glass
G12=12" Glass Refractor
SG12=12" Shroud with Glass Refractor
Aluminum
A12=12" Performance Reflector 2
Acrylic
AC12=12" Clear Acrylic
SAC12=12" Shroud with Clear Acrylic
Mounting Options
Pendant4
P36=36" Pendant Kit
P60=60" Pendant Kit
P120=120" Pendant Kit
Cable
SC=Cable Mount
with Straight
Power Cord3
(Standard Length 120")
CC=Cable Mount with
Coiled Power Cord3
(Standard Length 4'-10')
Ballast Housing
I=Integral
Distribution
N=Narrow
M=Medium
W=Wide
NOTES: 1 Cannot be used with AC12 Optic. 2Shroud comes standard with Performance Reflector. 3Specify W for white cord, example: SCW. 4Pendant dimension refers to the distance from the mounting plane
to the bottom of the fixture. 5Specifications and dimensions subject to change without notice.
6
AVID SMALL ORDERING LOGIC
Refer to Cooper Lighting’s website for the latest information on the AVID series.
SAMPLE NUMBER: AIS-100-MH-120-A12-M-I-SC-GM
AVID MINI ORDERING LOGIC
Refer to Cooper Lighting’s website for the latest information on the AVID series.
SAMPLE NUMBER: AII-39-MH-120-G7-N-I-SC-GM
Product
Family
AII=AVID
Series
Mini1
Finish
BK=Black
AP=Grey
BZ=Bronze
WH=White
DP=Dark Platinum
GM=Graphite Metallic
Options
F1=Single Fuse
LL=Lamp Included
FGS=Frosted Glass
Lens
CGL=Clear Glass Lens
DFR=Decorative
Frosted Ring
Lamp Wattage
HID5
20=20W T4.5 G8.5
39=39W T4.5 G8.5
Compact Fluorescent
7=7W
13=13W
Incandescent
25=25W
Lamp Type
MH=Metal Halide
CF=Compact Fluorescent
IN=Incandescent
Voltage
120=120V
X=Incandescent
Optical System
Borocilicate Glass
G7=7" Glass Refractor
SG7=7" Shroud with
Glass Refractor
Aluminum
A7=7" Performance Reflector3
S7=7" Shroud
Mounting Options
Pendant6
P36=36" Pendant Kit
P60=60" Pendant Kit
P120=120" Pendant Kit
Cable
SC=Cable Mount
with Straight
Power Cord 4
(Standard Length 120")
CC=Cable Mount with
Coiled Power Cord 4
(Standard Length 4'-10')
Ballast Housing
I=Integral
Distribution2
N=Narrow
W=Wide
NOTES: 1 Avid Series Mini “AII” is 120V only. 2Mini available only in Narrow and Wide distributions. 3Shroud comes standard with Performance Reflector. 4Specify W for white cord, example: SCW.
5Must specify FGS or CGL. 6Pendant dimensions refer to the distance from the mounting plane to the bottom of the fixture. 7Specifications and dimensions subject to change without notice.

7
170
510
340
90°
60°
30°
CP/1000
AII-20-MH-G7-W-CGL
20-Watt Clear Ceramic Metal Halide 7" Glass
Refractor with Clear Glass Lens Wide Distribution,
1,600-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
178 75 71 68 75 71 69 66 66 63 61 60 59 57 56 54 53 50
272 66 61 57 69 64 59 56 59 55 52 54 51 49 50 48 46 44
366 59 54 49 63 57 52 48 53 49 45 49 46 43 45 43 40 38
461 53 48 43 59 52 46 42 48 44 40 45 41 38 42 39 36 34
557 49 42 38 55 47 41 37 44 39 36 41 37 34 38 35 32 31
653 44 38 34 51 43 37 33 40 35 32 38 34 31 35 32 29 28
750 41 35 31 48 39 34 30 37 32 29 35 31 28 33 29 27 25
846 37 32 28 45 36 31 27 34 30 26 32 28 25 30 27 24 23
944 35 29 25 42 34 28 25 32 27 24 30 26 23 28 25 22 21
10 41 32 27 23 39 31 26 23 30 25 22 28 24 21 26 23 21 19
Candlepower
Degree CP
0 387
5 412
15 470
25 480
35 327
45 151
55 127
65 49
75 54
85 55
90 62
95 66
105 53
115 41
125 18
135 18
145 19
155 21
Spacing Criterion 1.2
Zone %Lamp Zone %Lamp
0-30 25.0 0-90 60.7
0-40 37.4 90-180 14.2
0-60 50.2 Total 74.9
AII-39-MH-G7-W-CGL
39-Watt Clear Ceramic Metal Halide 7" Glass
Refractor with Clear Glass Lens Wide Distribution,
3,400-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
180 76 73 70 76 73 70 68 67 65 63 62 60 58 57 56 54 52
273 68 63 59 70 65 61 57 60 57 54 56 53 50 51 49 47 45
368 61 55 51 65 58 53 49 54 50 47 50 47 44 47 44 42 40
463 55 49 44 60 53 48 43 49 45 41 46 42 39 43 40 37 35
559 50 44 39 56 48 43 38 45 40 37 42 38 35 40 36 34 32
655 46 40 35 52 44 39 34 41 37 33 39 35 32 37 33 30 29
751 42 36 32 49 41 35 31 38 33 30 36 32 29 34 30 28 26
848 39 33 29 46 38 32 28 35 31 27 33 29 26 32 28 25 24
945 36 30 26 43 35 30 26 33 28 25 31 27 24 30 26 23 22
10 42 33 28 24 41 32 27 24 31 26 23 29 25 22 28 24 22 20
Candlepower
Degree CP
0 1023
5 1054
15 1114
25 1063
35 671
45 318
55 238
65 106
75 118
85 123
90 137
95 138
105 116
115 74
125 37
135 39
145 41
155 46
Spacing Criterion 1.1
Zone %Lamp Zone %Lamp
0-30 26.8 0-90 62.4
0-40 38.9 90-180 14.0
0-60 51.5 Total 76.4
400
1200
800
90°
60°
30°
CP/1000
PHOTOMETRICS – MINI
AII-39-MH-SG7-W-CGL
39-Watt Clear Ceramic Metal Halide 7" Glass
Refractor with Shroud and Clear Glass Lens,
Wide Distribution, 3,400-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
175 73 71 69 73 72 70 68 69 67 66 66 65 64 64 63 62 61
271 67 64 61 69 66 63 61 64 61 59 62 60 58 60 58 57 56
366 62 58 55 65 61 57 54 59 56 53 57 55 53 56 54 52 51
463 57 53 49 61 56 52 49 54 51 48 53 50 48 52 49 47 46
559 52 48 45 58 52 48 45 51 47 44 49 46 44 48 46 43 42
655 49 44 41 54 48 44 41 47 43 40 46 43 40 45 42 40 39
752 45 41 38 51 45 41 38 44 40 37 43 40 37 42 39 37 36
849 42 38 35 49 42 38 35 41 37 35 40 37 34 40 37 34 33
947 40 35 32 46 39 35 32 39 35 32 38 34 32 37 34 32 31
10 44 37 33 30 44 37 33 30 36 33 30 36 32 30 35 32 30 29
Candlepower
Degree CP
0 2377
5 2077
15 1857
25 1311
35 725
45 376
55 149
65 33
75 13
85 3
90 0
Spacing Criterion 0.8
Zone %Lamp Zone %Lamp
0-30 38.3 0-90 66.7
0-40 51.8 90-180 0
0-60 65.2 Total 66.7
800
2400
1600
90°
60°
30°
CP/1000
AVID Series
MINI AND SMALL

8
450
1350
900
90°
60°
30°
CP/1000
AIS-70-MH-G12-W
70-Watt Coated Ceramic Metal Halide 12" Glass
Refractor, Wide Distribution, 6,000-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
188 83 79 75 84 79 76 72 73 70 67 66 64 62 61 59 57 54
279 72 66 61 76 69 63 59 63 59 55 58 54 51 53 50 47 45
372 63 56 50 69 60 54 48 55 50 45 51 46 42 46 43 40 37
466 55 48 42 63 53 46 41 49 43 38 45 40 36 41 37 34 31
560 49 41 35 57 47 40 35 43 37 33 40 35 31 37 32 29 27
655 44 36 30 53 42 35 30 39 33 28 36 31 27 33 28 25 23
751 39 32 26 48 38 31 26 35 29 24 32 27 23 30 25 22 20
847 36 28 23 45 34 27 23 32 26 21 29 24 20 27 23 19 17
944 32 25 20 42 31 24 20 29 23 19 27 22 18 25 20 17 15
10 41 30 23 18 39 28 22 18 26 21 17 25 20 16 23 18 15 14
Candlepower
Degree CP
0 954
5 951
15 881
25 943
35 1150
45 1307
55 727
65 336
75 291
85 287
90 274
95 267
105 255
115 222
125 156
135 66
145 27
155 26
Spacing Criterion 1.8
Zone %Lamp Zone %Lamp
0-30 13.0 0-90 68.6
0-40 25.1 90-180 16.9
0-60 52.6 Total 85.5
AIS-142-CF-G12-M
42-Watt CF42DT/E/841, 12" Glass Refractor,
Medium Distribution, 3,200-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
187 82 77 73 82 78 74 70 70 67 64 63 60 58 56 54 52 49
278 70 63 57 74 66 60 55 59 54 50 53 49 46 48 44 42 38
370 60 52 46 66 57 50 44 51 45 40 46 41 37 41 37 34 31
464 52 44 37 60 50 42 36 45 38 33 40 35 30 36 31 28 25
558 46 37 31 54 44 36 30 39 33 28 35 30 25 31 27 23 21
653 41 32 26 50 39 31 25 35 28 23 31 26 22 28 23 20 17
749 36 28 23 46 34 27 22 31 25 20 28 23 18 25 20 17 15
845 33 25 20 42 31 24 19 28 22 17 25 20 16 23 18 15 13
942 30 22 17 39 28 21 16 26 19 15 23 18 14 21 16 13 11
10 39 27 20 15 37 26 19 14 23 17 13 21 16 12 19 15 11 10
Candlepower
Degree CP
0 158
5 176
15 275
25 350
35 450
45 481
55 397
65 304
75 201
85 185
90 181
95 169
105 153
115 129
125 96
135 55
145 29
155 21
Spacing Criterion 2.8
Zone %Lamp Zone %Lamp
0-30 8.9 0-90 65.4
0-40 18.2 90-180 21.7
0-60 42.3 Total 87.1
170
510
340
90°
60°
30°
CP/1000
PHOTOMETRICS – SMALL
AIS-242-CF-AC12-M
42-Watt CF42TTT/E/841, 12" Clear Acrylic Refractor,
Medium Distribution, 3,200-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
185 80 75 70 80 75 70 66 66 62 59 57 55 52 50 48 46 42
276 67 60 54 71 63 57 51 55 50 46 48 44 40 41 38 35 32
368 58 50 43 63 54 47 41 47 41 36 41 36 32 35 31 28 25
462 50 42 35 57 47 39 33 41 35 30 36 30 26 30 26 23 20
556 44 35 29 52 41 33 28 36 30 25 31 26 22 27 22 19 16
651 39 31 25 48 36 29 23 32 26 21 28 22 18 24 19 16 14
747 35 27 21 44 33 25 20 29 22 18 25 20 16 21 17 14 11
844 31 23 18 41 29 22 17 26 20 15 22 17 14 19 15 12 10
940 28 21 16 38 27 20 15 23 18 13 20 15 12 18 13 10 8
10 38 26 19 14 35 24 18 13 21 16 12 19 14 10 16 12 9 7
Candlepower
Degree CP
0 385
5 388
15 409
25 521
35 783
45 915
55 904
65 782
75 611
85 416
90 402
95 365
105 327
115 308
125 289
135 262
145 234
155 178
Spacing Criterion 2.4
Zone %Lamp Zone %Lamp
0-30 6.4 0-90 58.7
0-40 13.5 90-180 28.7
0-60 33.7 Total 87.4
800
400
90°
60°
30°
CP/1000

9
The AVID Medium bridges the gap between the higher and lower mounting heights allowing for a consistent look throughout an
entire space. With its combination of lamps and high performance optics the AVID large is perfect for open ceiling applications.
AVID Series
MEDIUM AND LARGE
MOUNTING
Cast aluminum top can be specified for pendant mounting. Pendant
mounting comes with a 3/4" or 1/2" pipe with internal locking
screw assuring security.
FINISH
Housing components are finished in a five-stage cleaning and corrosion pretreatment system and coated and baked
with a premium TGIC polyester powder providing superior protection against fading and pealing. Standard colors
include white, grey, black, bronze, graphite metallic, and dark platinum. RAL or custom color matches available.
INTEGRAL BALLAST HOUSING
Integral ballast housing consists of heat dissipating aluminum
finned construction allowing thermal transfer from the electrical
compartment to the exterior surfaces through convection heat
transfer assuring a lasting reliable electrical gear.
MIDSECTION
Cast aluminum midsection is designed to dissipate the heat
energy away from the lamp compartment separating the
optical cavity from the integral ballast housing assuring a
cool operation.
OPTICAL SYSTEM
Optics are designed to deliver high fixture efficiencies
and the maximum foot candle levels to the floor at
mounting heights above 20'. The field adjustable
socket bracket has three settings concentrated,
medium, and wide which allows the distribution
to be optimized for the application.
LAMP AND BALLAST SYSTEM
Lamps available in a range from
150-400 watts in both standard and
pulse start metal halide. High power
factor ballast with class H insulation
minimum starting temperature
is -30°C (-20°F) for MH, and MP.

10
Product
Family
AIM=AVID
Series
Medium
Finish
BK=Black
AP=Grey
BZ=Bronze
WH=White
DP=Dark
Platinum
GM=Graphite
Metallic
Options
Q=Quartz Restrike (Hot Strike Only)
EM=Quartz Restrike with “Delay Relay”
(Quartz lamp strikes at both hot
and cold starts)
EM/SC=Emergency Separate Circuit
F1=Single Fuse
F2=Double Fuse
LL=Lamp Included
OR=Open Rated Socket
FGS=Frosted Glass Lens
CGL=Clear Glass Lens
DFR=Decorative Frosted Ring
Lamp Wattage
HID
150=150W
Medium
Base
175=175W
Mogul
Base
250=250W
Mogul
Base
Lamp Type
MH=Metal Halide
MP=Pulse Start
Metal Halide
Voltage
120=120V
208=208V
240=240V
277=277V
347=347V
480=480V
MT=(standard
120/208/240/277)
TT=(standard
120/277/347)
5T=(standard
120/208/240/277/480)
Optical System
Borocilicate Glass
G16=16" Glass Refractor
SG16=16" Shroud with Glass Refractor
Aluminum
A16=16" Performance Reflector1
Acrylic
AC16=16" Clear Acrylic 2
Mounting Options
Pendant3
P36=36" Pendant Kit
P60=60" Pendant Kit
P120=120" Pendant Kit
Ballast Housing
I=Integral
Distribution
N=Narrow
M=Medium
W=Wide
AVID MEDIUM ORDERING LOGIC
Refer to Cooper Lighting’s website for the latest information on the AVID series.
SAMPLE NUMBER: AIM-175-MH-MT-AC16-M-I-P36-GM
Product
Family
AIL=AVID
Series
Large
Finish
BK=Black
AP=Grey
BZ=Bronze
WH=White
DP=Dark Platinum
GM=Graphite Metallic
Options
Q=Quartz Restrike (Hot Strike Only)
EM=Quartz Restrike with “Delay
Relay” (Quartz lamp strikes at
both hot and cold starts)
EM/SC=Emergency Separate
Circuit
F1=Single Fuse
F2=Double Fuse
LL=Lamp Included
OR=Open Rated
Socket
FGS=Frosted Glass Lens
CGL=Clear Glass Lens
DFR=Decorative Frosted Ring
Lamp Wattage
HID
250=250W
Mogul
Base
320=320W
Mogul
Base
350=350W
Mogul
Base
400=400W
Mogul
Base
Lamp Type
MH=Metal Halide
MP=Pulse Start
Metal Halide
Voltage
120=120V
208=208V
240=240V
277=277V
347=347V
480=480V
MT=(standard
120/208/240/277)
TT=(standard
120/277/347)
5T=(standard
120/208/240/277/480)
Optical System
Borocilicate Glass
G19=19" Glass Refractor
SG19=19" Shroud with Glass Refractor
Aluminum
A19=19" Performance Reflector1
Mounting Options
Pendant2
P36=36" Pendant Kit
P60=60" Pendant Kit
P120=120" Pendant Kit
Ballast Housing
I=Integral
Distribution
N=Narrow
M=Medium
W=Wide
NOTES: 1 Shroud comes standard with Performance Reflector. 2Pendant dimension refers to the distance from the mounting plane to the bottom of the fixture.
3Specifications and dimensions subject to change without notice.
AVID LARGE ORDERING LOGIC
Refer to Cooper Lighting’s website for the latest information on the AVID series.
SAMPLE NUMBER: AIL-400-MH-MT-G19-M I-P36-GM
NOTES: 1 Shroud comes standard with Performance Reflector. 2Rated for 25˚C ambient environments. 3Pendant dimension refers to the distance from the mounting plane to the bottom of the fixture.
4Specifications and dimensions subject to change without notice.

11
2500
1250
90°
60°
30°
CP/1000
AIM-250-MH-A16-W
250-Watt Coated Metal Halide 16" Performance
Reflector, Wide Distribution,19,800-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
183 79 74 70 78 74 70 67 66 63 60 58 56 54 51 49 48 44
275 67 61 56 70 64 58 53 56 52 48 50 46 43 44 41 38 35
368 58 51 45 63 55 49 43 49 44 39 43 39 35 38 35 32 29
462 51 43 38 58 48 41 36 43 37 33 38 33 30 33 29 26 24
556 45 37 32 53 43 35 30 38 32 28 33 29 25 29 25 22 20
651 40 32 27 48 38 31 26 34 28 23 30 25 21 26 22 19 17
747 36 28 23 44 34 27 22 30 24 20 27 22 18 24 20 16 14
844 32 25 20 41 31 24 19 27 22 18 24 19 16 21 17 14 12
941 29 22 17 38 28 21 17 25 19 15 22 17 14 19 15 13 11
10 38 27 20 15 35 25 19 15 23 17 14 20 16 12 18 14 11 9
Candlepower
Degree CP
0 1422
5 1454
15 1711
25 2125
35 3104
45 3233
55 2228
65 1251
75 972
85 1041
90 1058
95 1090
105 1112
115 1070
125 967
135 633
145 286
155 181
Spacing Criterion 2.1
Zone %Lamp Zone %Lamp
0-30 8.3 0-90 58.0
0-40 18.1 90-180 25.8
0-60 40.6 Total 83.8
AIM-250-MH-G16-W
250-Watt Clear Metal Halide 16" Glass Refractor,
Wide Distribution, 20,500-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
189 86 84 81 87 85 82 80 81 79 77 78 76 75 75 74 73 71
282 77 72 68 80 75 71 67 72 69 66 70 67 64 68 65 63 61
376 68 62 58 74 67 61 57 65 60 56 62 58 55 60 57 54 53
469 61 54 49 68 60 53 49 58 52 48 56 51 48 54 50 47 45
564 54 47 42 62 53 47 42 51 46 42 50 45 41 48 44 41 39
659 48 42 37 57 48 41 36 46 40 36 45 40 36 44 39 36 34
754 44 37 32 53 43 36 32 42 36 32 41 35 31 40 35 31 30
850 39 33 28 49 39 33 28 38 32 28 37 32 28 36 31 28 26
947 36 29 25 45 35 29 25 35 29 25 34 28 25 33 28 25 23
10 43 33 27 22 42 32 26 22 32 26 22 31 26 22 30 25 22 21
Candlepower
Degree CP
0 4889
5 4782
15 4754
25 4992
35 6016
45 6228
55 3570
65 477
75 116
85 28
90 0
Spacing Criterion 1.8
Zone %Lamp Zone %Lamp
0-30 20.2 0-90 80.6
0-40 38.6 90-180 0.0
0-60 77.3 Total 80.6
90°
60°
30°
2050
4100
6150
CP/1000
PHOTOMETRICS – MEDIUM
AIM-250-MH-SG16-M
250-Watt Coated Metal Halide 16" Glass Refractor with
Shroud, Medium Distribution,19,800-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
166 64 62 60 65 63 61 59 60 59 57 58 57 56 56 55 54 53
261 57 54 51 60 56 53 50 54 51 49 52 50 48 50 49 47 46
356 51 47 43 55 50 46 43 48 45 42 47 44 42 45 43 41 40
452 46 41 37 51 45 40 37 43 40 37 42 39 36 41 38 36 34
548 41 36 32 47 40 36 32 39 35 32 38 34 32 37 34 31 30
644 37 32 28 43 36 32 28 35 31 28 34 31 28 33 30 28 26
741 33 28 25 40 33 28 25 32 28 25 31 27 25 30 27 24 23
838 30 26 22 37 30 25 22 29 25 22 28 25 22 28 24 22 21
935 28 23 20 35 27 23 20 27 23 20 26 22 20 25 22 19 18
10 33 25 21 18 32 25 21 18 25 21 18 24 20 18 23 20 18 17
Candlepower
Degree CP
0 3009
5 3105
15 3661
25 4470
35 5189
45 3767
55 1730
65 541
75 135
85 40
90 0
Spacing Criterion 1.7
Zone %Lamp Zone %Lamp
0-30 17.4 0-90 59.8
0-40 33.5 90-180 0.0
0-60 56.0 Total 59.8
1450
4350
2900
90°
60°
30°
CP/1000
AVID Series
MEDIUM AND LARGE

12
90°
60°
30°
1480
2960
4440
5920
CP/1000
AIL-400-MH-G19-W
400-Watt Metal Halide 19" Glass Refractor,
Wide Distribution, 35,000-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
197 92 87 83 92 87 83 79 79 76 73 72 69 66 64 62 61 57
288 80 73 67 83 76 70 65 69 64 60 62 58 55 56 53 50 47
380 70 62 55 76 67 59 53 60 54 50 55 50 46 49 46 42 39
473 62 53 47 69 59 51 45 54 47 42 49 43 39 44 40 36 33
567 55 46 40 63 52 44 38 48 41 36 43 38 33 39 35 31 28
661 48 40 33 58 46 38 32 42 35 30 38 33 28 35 30 26 24
756 42 34 28 53 41 33 27 37 30 25 34 28 24 31 26 22 20
851 38 29 24 48 36 28 23 33 26 21 30 24 20 27 22 19 16
947 34 26 20 44 32 25 19 29 23 18 27 21 17 24 19 16 14
10 43 30 22 17 41 29 21 16 26 20 15 24 18 14 22 17 13 11
Candlepower
Degree CP
0 3782
5 3875
15 4588
25 5586
35 7025
45 8277
55 4959
65 2289
75 2192
85 2306
90 2302
95 2290
105 2112
115 1799
125 1331
135 653
145 181
155 102
Spacing Criterion 2.4
Zone %Lamp Zone %Lamp
0-30 11.9 0-90 72.9
0-40 24.0 90-180 22.9
0-60 53.0 Total 95.8
AIL-400-MH-SG19-W
400-Watt Metal Halide 19" Glass Refractor with
Shroud, Wide Distribution, 35,000-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
179 76 73 71 77 74 72 70 71 70 68 69 67 66 66 65 64 63
273 68 64 61 71 67 63 60 65 62 59 62 60 58 60 58 56 55
367 61 56 52 66 60 55 52 58 54 51 56 53 50 54 51 49 48
462 55 49 45 61 54 49 45 52 48 44 50 47 44 49 46 43 42
557 49 43 39 56 48 43 39 47 42 38 45 41 38 44 40 37 36
652 43 37 33 51 43 37 33 41 36 33 40 36 32 39 35 32 31
747 38 32 28 46 37 32 28 36 31 27 35 31 27 34 30 27 26
843 34 28 24 42 33 28 24 32 27 23 31 27 23 31 26 23 22
940 30 24 20 39 29 24 20 29 24 20 28 23 20 27 23 20 18
10 36 27 21 17 35 26 21 17 25 20 17 25 20 17 24 20 17 15
Candlepower
Degree CP
0 5376
5 5523
15 6552
25 7566
35 8748
45 9390
55 5157
65 1333
75 412
85 68
90 0
95 0
105 0
115 0
125 2
135 5
145 5
155 8
Spacing Criterion 2.2
Zone %Lamp Zone %Lamp
0-30 16.8 0-90 70.7
0-40 32.3 90-180 0.0
0-60 65.3 Total 70.7
90°
60°
30°
1700
3400
5100
6800
CP/1000
PHOTOMETRICS – LARGE
AIL-400-MH-G19-N
400-Watt Metal Halide 19" Glass Refractor,
Narrow Distribution, 35,000-Lumen Lamps
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
181 77 74 70 77 74 71 68 68 65 63 62 61 59 57 56 55 52
274 68 63 59 71 66 61 57 61 57 54 56 53 51 52 49 47 45
369 61 56 51 66 59 54 50 55 50 47 51 47 44 47 44 42 40
464 56 50 45 61 54 48 44 50 45 42 47 43 40 43 40 38 36
559 50 44 40 57 49 43 39 46 41 37 43 39 35 40 36 34 32
655 46 40 35 53 44 39 35 42 37 33 39 35 32 37 33 30 29
751 42 36 31 49 40 35 31 38 33 30 36 32 28 34 30 27 26
848 38 32 28 46 37 31 28 35 30 27 33 29 26 31 27 25 23
944 35 29 25 43 34 28 25 32 27 24 30 26 23 28 25 22 21
10 41 32 26 22 40 31 26 22 29 25 21 28 23 21 26 22 20 18
Candlepower
Degree CP
0 9728
5 9807
15 9454
25 8419
35 7345
45 5115
55 1798
65 1520
75 1628
85 1664
90 1621
95 1584
105 1445
115 1188
125 739
135 263
145 122
155 108
Spacing Criterion 1.2
Zone %Lamp Zone %Lamp
0-30 21.2 0-90 63.0
0-40 33.9 90-180 14.5
0-60 49.4 Total 77.5
90°
60°
30°
2080
4160
6240
8320
CP/1000

PERFORMANCE REFLECTOR
Mini, Small, Medium and Large
LENSES
OPTICS
Product Matrix
AVID Series
- Optics
- Lenses
- Mounting Options
- Dimensions
BOROSILICATE GLASS
Mini, Small, Medium and Large
13
DIMENSIONS
MINI SMALL
3-3/4"
[95mm]
6-7/8"
[176mm]
11 "
[279mm]
8-1/16"
[205mm]
9/16"
[15mm]
CLEAR GLASS LENS (CGL)
Mini, Small, Medium and Large
DECORATIVE FROSTED RING (DFR)
Mini, Small, Medium and Large
FROSTED GLASS LENS (FGS)
Mini, Small, Medium and Large
14"
[356mm]
6-1/2"
[166mm]
11-3/8"
[290mm]
20"
[508mm]
11/16"
[18mm]

MOUNTING OPTIONS
PENDANT
Mini 3/8", Small 1/2",
Medium 1/2" and 3/4", Large 1/2" and 3/4"
CABLE MOUNT
Mini and Small
Straight Cable and Coiled Cable Options
ACRYLIC
Small and Medium
SHROUD*
Mini, Small, Medium and Large
*Standard with Performance Reflector Optional with Glass
14
MEDIUM LARGE
Performance Reflector
and Glass Refractor
17-3/8" [441mm]
Acrylic 18" [457mm]
8-1/8"
[207mm]
14-7/16"
[366mm]
26-5/8"
[676mm]
7/8"
[23mm]
26-7/8"
[682mm]
Performance Reflector
and Glass Refractor
Acrylic
9-1/4"
[235mm]
17"
[432mm]
29-15/16"
[760mm]
7/8"
[23mm]
21-9/32"
[540mm]

Printed in USAADH080966
Cooper Industries, Ltd.
600 Travis, Ste. 5800
Houston, TX 77002-1001
P: 713-209-8400
www.cooperindustries.com
Cooper Lighting and Lumark are valuable trademark of Cooper Industries in the United States and other countries.
You are not permitted to use the Cooper Trademarks without the prior written consent of Cooper Industries.
Cooper Lighting
Customer First Center
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
F: 770-486-4801
www.cooperlighting.com
International Sales, USA
Cooper Lighting
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
F: 770-486-4801
Canada
Cooper Lighting
5925 McLaughlin Road
Mississauga, Ontario L5R 1B8
P: 905-507-4000
F: 905-568-7049
The Cooper Lighting Family
Halo
Metalux
Lumark
Sure-Lites
Neo-Ray
Corelite
Portfolio
Iris
Shaper
io
Lumière
Invue
McGraw-Edison
Streetworks
Fail-Safe
MWS
DLS
RSA
Ametrix
Domestic Facilities
Cranbury, New Jersey
Elk Grove Village, Illinois
Irving, Texas
Ontario, California
Peachtree City, Georgia
Canadian Facility
Calgary, Alberta T2E 7V9
