SPECIFICATION FEATURES
04/15/2007 12:24:03 PM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADC041681
ORDERING INFORMATION
DESCRIPTION
Enclosed and gasketed, rugged construction and three especially selected
shielding elements make this fixture ideally suited for use in various types
of security areas. The housing is a welded completely, enclosed steel
chamber. The door is heavy gauge extruded aluminum with mitered
corners. The door has a continuous aluminum piano hinge and tamper
proof fasteners. The door and shielding are completely gasketed for
minimum maintenance. Fixtures are installed as individual or continuous
runs.
Mounting
Surface
Lamps
By Others.
Ballast
Standard Class P, CBM/ETL ballast.
Housing
20 ga. cold rolled steel.
Shielding
IK12 lexan prismatic lens,
93 tempered glass lens,
KSH25 acrylic prismatic lens.
Finish
Baked on low gloss white powder
coated polyester-epoxy.
MSM
Medical Surface Mount
4 1/4" [108mm]
12" [305mm], 24" [610mm]
LNL= LED Night Light
(50,000 hrs.)
provided by Cooper
12" [305mm] x 48" [1219mm] 24" [610mm] x 48" [1219mm]
24" [610mm] x 24" [610mm]
STANDARD LUMINAIRE SECTION
FAIL-SAFE®

Fail-Safe • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2007 12:24:03 PM
Specifications and Dimensions subject to change without notice.
ADC041681
PHOTOMETRICS
TYPICAL MOUNTING INFORMATION SERIES 3S/T8
SHIELDING
MSM
Coefficients Of Utilization
Effective floor cavity reflectance 20%
rc 80% 50% 30%
rw 70 50 30 10 50 30 10 50 30 10
RCR
1 68 66 64 52 62 61 59 60 59 57
2 64 60 56 53 56 54 51 54 52 50
3 59 54 50 46 51 48 45 49 47 44
4 55 48 44 40 46 42 40 45 42 39
5 50 44 39 35 42 38 35 40 37 34
6 47 39 34 31 38 34 31 37 33 30
7 43 35 31 27 34 30 27 33 30 27
8 40 32 27 24 31 27 24 30 26 23
9 37 29 24 21 28 23 20 27 23 20
10 34 26 21 18 25 21 18 25 21 18
Report No. 393932/3274 for Cat No.3S/2448-S58
Lamp Type: F40T12Rs/WW, 3000 lumens
90˚
0˚
180˚135˚
45
˚
90˚
0˚
Zonal Lumen Summary
Zone Lumens Lamp% Fixt%
0 3160 3160 3160
5 3150 3160 3160
15 3040 3080 3120
25 2820 2940 3000
35 2450 2080 2760
45 1820 1990 2070
55 1180 690 1210
65 484 375 210
75 207 274 210
85 52.8 56 35.1
90 52.8 56 35.1
Total Luminaire Efficiency= 56%
7
/8" DIA. K.O.
3
/8" DIA. K.O.
11/16" x 2" K.O.
TRIPLE 11/16" x 2" K.O.
LEGEND
12"
38"
48" 24" 48"
24"21" 24"21"
9"
S40 Lexan Lens
1/8"thick, clear
hexagonal prisms,
high impact, shatter
proof.
S44 Glass Lens
5/32" thick, clear
square prisms, pattern
#73, controls
brightness, tempered
glass lens, high
impact, shatter proof.
S58 Acrylic Lens
1/8" thick, clear
acrylic prismatic
lens.
