DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A...Construction
All aluminum construction with integrated
heat sink.
B ...Light Source
Five 1 watt LEDs in amber, blue, green, red,
or 2800K, 3500K, 4100K or 5100K white.
C ...Power Supply
36” whip with quick connectors at each
end to connect the fixture to the included
external 350mA constant current driver.
Driver comes in an enclosure/junction
box with a knockout for 120V input.
D...Mounting
May be mounted as a recessed fixture
in as little as 1.5” plenum height. Spring
retaining clips secure the recessed trim
in place. May also be surface mounted
using an aluminum extender sleeve.
E ...Lens
Flat or drop glass lens included. White
LEDs use a clear or frosted lens. Colored
LEDs use a corresponding color lens.
F....Finish
Available in white, black or silver powder
coat finish.
Cut-out: 2.75” dia.
RSA LED
PUCKLIGHT
LED10
3.75” O.D.
Recessed
or Surface
Mounted Fixture
Five x 1 Watt LED
ORDERING INFORMATION
Fixture
LED10 =
3.75” Round LED Pucklight
Mounting Type
S =Surface Mount
R =Recessed Mount
Lens Type / Color
FC =Flat Clear
FA =Flat Amber
FB =Flat Blue
FG =Flat Green
FR =Flat Red
DF =Drop Frosted
DA =Drop Amber
DB =Drop Blue
DG =Drop Green
DR =Drop Red
LED Color
28 =White 2800K
35 =White 3500K
41 =White 4100K
51 =White 5100K
AM =Amber
BL =Blue
GR =Green
RD =Red
Finish
W =White
B =Black
S =Silver
3.75” round LED pucklight for recessed or surface mounting. Utilizes
five 1 watt leds in amber, blue, green, or four types of white.
For use in downlighting and task lighting applications such as under
cabinets.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
LED10
0.92”
1.15”
36” leads
3.75”
0.22”
RECESSED MOUNT
SURFACE MOUNT
1.37”
3.75”
1 Watt LED (5x)
Knockout for 120V Input
2.05”
7.16”
Junction Box / Driver Enclosure 2.16”Width
rev. 050808
AVAILABLE
NOVEMBER 2008
