Coopers of Stortford F916 User manual

Mini Leaf Blower F916 Instructions for Use
Please read and retain these instructions for future reference v002: 13/09/19
Technical Data
Rated voltage:
220-240V
Frequency:
50-60Hz
Power input:
400W
No-load speed:
14000/min
Max blowing rate:
3.0m3/min
Nozzle diameter:
25mm
Insulation class:
Double insulated
Sound pressure level
(according to IEC 60745):
90 dB (A)
Sound power level
according to IEC 60745):
100 dB (A)
Vibration level
(according to IEC 60745):
≤ 2.5 m/s2
Weight:
1.45kg
Parts
1. Nozzle
2. Blast port
3. Trigger Switch
4. Lock-on button
5. Suction port

Mini Leaf Blower F916 Instructions for Use
Please read and retain these instructions for future reference v002: 13/09/19
6. Dust bag
Intended Use
Your blower has been designed for blowing and cleaning applications, as well as light suction purpose.
General Safety Rules
Warning! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire
and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains
operated (corded) power tool or battery operated (cordless) power tool. SAVE THESE INSTRUCTIONS.
1. Work area
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2. Electrical Safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs
with earthed power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use a cord
suitable for outdoor use reduces the risk of electric shock.
3. Personal Safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

Mini Leaf Blower F916 Instructions for Use
Please read and retain these instructions for future reference v002: 13/09/19
c) Avoid accidental starting. Ensure the switch is in the off position before plugging in. Carrying power tools
with your finger on the switch or plugging in power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can reduce dust related hazards.
h) Use clamps or another practical way to secure and support the workpiece to a stable platform. Holding
the work by hand or against your body leaves it unstable and may lead to a loss of control.
4. Power tool use and care
a) DO not force the power tool. Use the correct power tool for your application. The correct power tool will
do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before making any adjustments, changing accessories, or
storing power tools. Such preventative safety measures reduce the risk of starting the power tool
accidentally.
d) Store the idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tools operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions and in the
manner intended for the particular type of power tool, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
Additional Safety Instructions for Blowers
Do not collect still smouldering cigarette ashes, freshly cut metal shavings, screws, nails and the like.
Never block suction inlet and outlet.
Warning Symbols
Read the operation manual and follow all warnings and safety instructions.

Mini Leaf Blower F916 Instructions for Use
Please read and retain these instructions for future reference v002: 13/09/19
Do not use in wet conditions or expose to rain.
Always wear eye protection.
Always wear ear protection.
Switch off and remove plug from mains before cleaning or maintenance.
Disconnect the mains plug if the cord becomes damaged or entangled.
Beware of falling objects
Keep bystanders away.
Do not touch the fan.
Electrical Safety
This tool is double insulated; therefore no earth wire is required. Always check that the
power supply corresponds to the voltage on the rating label.
Assembly
Warning! Before assembly, make sure that the tool is switched off and unplug.
Use
Mounting the nozzle for blowing operations (Fig. A)
Insert the pin located inside the nozzle into the notch provided on the blast port (2).
To lock nozzle in place, turn the
nozzle in the direction
indicated.
To remove nozzle, turn the
nozzle in the opposite
direction.

Mini Leaf Blower F916 Instructions for Use
Please read and retain these instructions for future reference v002: 13/09/19
Mounting the nozzle and dust for dust collection (Fig.
B)
For dust collection, mount the dust bag at the
blast port (2) and nozzle at the suction port (6).
To remove dust bag and nozzle, simply pull out by
first turning in the opposite direction.
Empty the dust bag frequently to ensure
maximum dust collecting efficiency.
Adjust variable speed knob (4) marked with “MIN”
and “MAX” for different speed requirements.
When continuous operation is required, first
depress the switch and then the lock-on button
(5) and release to disengage lock, squeeze and
release switch.(Fig. C).
Warning: Continuous running of machine should not exceed 30 minutes.
Replacing carbon brushes (Fig. D)
Use a screwdriver to remove the brush holder cap.
Take out the worn carbon brush insert the new one and secure the brush hold cap.
Warning! Remove and check the carbon brushes regularly. Replace when they wear down to the limit mark.
Maintenance
Warning
Before performing any maintenance switch off and unplug the tool.
Regularly clean the ventilation slots in your tool using a soft brush or dry cloth.
Regularly clean the motor housing using a damp cloth. Do not use any abrasive or solvent-based cleaner.
PLUG WIRING (UK & IRELAND)
This appliance is fitted with a BS 1363 13-amp plug. If you have to replace the fuse, only those that are ASTA
or BSI approved to BS1362 and with a rated current of 13-amps should be used. If there is a fuse cover fitted,
this cover must be re-fitted after changing the fuse. If the fuse cover is lost or damaged the plug must not be
used. Spare fuse holders and fuses are available from electrical outlets. If the socket outlets in your home or
office are not suitable for this product’s plug, the plug must be removed and disposed of safely. Attempts to
insert the plug into the wrong socket is likely to cause electric hazard. A replacement plug should be wired
according to the following instructions:

Mini Leaf Blower F916 Instructions for Use
Please read and retain these instructions for future reference v002: 13/09/19
The cable
A mains electricity cable contains two or three inner wires. Each has a core of copper and an outer layer of
flexible plastic. This product is double insulated; the wires in the cord set are colour coded in the following
way:
BLUE NEUTRAL
BROWN LIVE
GREEN & YELLOW EARTH
The diagram below shows the key features of a correctly wired three-pin mains plug.
DISPOSAL
•Dispose of all packaging, paper, cartons, plastic and plastic bags in accordance with your local recycling
regulations.
•At the end of the product’s lifespan, please dispose of it at an authorised household waste recycling
centre.
Note:
Double insulated appliances do not
need the green & yellow Earth wire.
They may only have the Brown and
Blue wires.
