Coopers of Stortford F874 User manual

UV Bed Vac F874 Instructions for Use
Please read and retain these instructions for future reference v003:11/09/19
Technical Data
Voltage: 220-240V AC
Frequency: 50-60Hz
Machine Power: 300W
Length of cord: 5m
Noise: ≤ 80db
Vacuity: ≥5Kpa
Dust Collecting Capacity: 180ml
Product Introduction and Precaution
Product Introduction
This product is designed to tackle allergens such as dust mites, bed bugs, bacteria and pollen. The UV light
attacks their DNA preventing them from reproducing and spreading, sterilizing your mattress and soft
furnishings.
Scope of Application
Please do not use this product to clean the following objects:
1. Objects with high temperature.
2. Liquid or semi-liquid, such as water, oil, coal oil, diesel oil, paint, alcohol and detergent.
3. Sharp fragment or dust, such as glass and ironic particles
4. Poisonous and hazardous materials, such as vitriol oil, corrodibility and erodent.
Ultraviolet Rays
Please pay attention to the following during usage:
1. Please do not aim the ultraviolet tube at any part of human body (eye, hand and face), animal or
plant to avoid damage.
2. This product has a three-dotted touch safety design, so please do not modify the device to avoid
reducing the product safety factor or unexpected accidents.
3. Please do not aim the ultraviolet tube at a part for a long time to avoid damage to the object.
4. After ultraviolet tube is open, do not put your hand under the ultraviolet light to avoid skin burning.
5. There are no user serviceable parts. If the ultraviolet tube is dimmed or flashing, stop using the
appliance immediately.
Others
Do not use without all filter components having been installed.

UV Bed Vac F874 Instructions for Use
Please read and retain these instructions for future reference v003:11/09/19
Product Schema
Front Side
Rear / bottom Side
Product Feature and Function
Feature:
1. Provided with high-efficiency (253.7nm) UV-C Silex glass ultraviolet sterilization tube.
2. Provided with 300W rated power, high-efficiency filter system (HEPA) and the vacuum cleaning
function of the ordinary professional vacuum cleaner.
3. Provided with patented design; ergonomic handle design.
4. Provided with three-dotted touch safety design to ensure application safety.
5. Provided with tapping function to kill mite and provide thorough sterilization.

UV Bed Vac F874 Instructions for Use
Please read and retain these instructions for future reference v003:11/09/19
Function:
1. Vibrating and tapping can clear away mites, dust and scurf deeply rooted in textile.
2. After opening ultraviolet tube, the radiation of ultraviolet can kill bacteria, mite and other
microorganisms by damaging its external ribonucleic acid and disabling it.
3. After the vacuum cleaner starts up, the mite, dust and scurf can be cleaned on the surface.
Application
Connect the machine to electricity, toggle switch from “0” to “I”, launch sterilization and dust cleaning
mode, move switch from “I” to “II” to launch tapping function.
Connect power line into mains socket
Toggle switch
(ensure this is switched off before inserting the plug)
Put the machine on object to be cleaned (such as bedding and clothes), toggle switch to operation position,
then the machine will be under pre-operation status to press two running trolleys that are in the front of
the machine bottom, pull and push the machine back and forth to perform cleaning job.
Working status window
Running trolley

UV Bed Vac F874 Instructions for Use
Please read and retain these instructions for future reference v003:11/09/19
Cleaning and Maintenance
Cleaning Dust Collection Box
Switch off the machine, unplug power line and push the fasteners on both sides of the dust box to take out
the dust box. After taking off the filter device, you can pour out the contents or wash with clean water.
Take out the dust box
Wash with clean water
Ventilate and dry
Maintenance and Repair
Daily Cleaning
Any daily cleaning or maintenance work must be performed after turning off and unplugging the UV Bed
Vac.
Regularly empty and clean the dust box, filter cartridge.
Ensure the UV-C ultraviolet tube is kept free from dust, oil stains or others.
The surface of the vacuum cleaner cannot be cleaned with water or other liquids to avoid it entering the
inside parts of the machine. Use a dry cloth or wet wipes for cleaning.
HEPA filter cartridge
UV-C Silex glass ultraviolet sterilization tube

UV Bed Vac F874 Instructions for Use
Please read and retain these instructions for future reference v003:11/09/19
Daily Maintenance, Storage and Trouble Shooting
Storage and Maintenance
If not using machine for a long time, please put the machine in a flannelette bag (not included) and then
locate it in dry and cool place; please do not put machine in direct sunlight or humid environment.
Do not store anything on top of the machine to prevent damage.
If the product (especially the ultraviolet tube) is broken, stop using product immediately.
Simple Trouble Shooting
Failure
Possible Causes
Solution
The vacuum
cleaner is not
working
1. The plug is not properly
connected to the socket.
2. The power socket has no
electricity
3. The vacuum cleaner is not
switched on
1. Reinsert the plug
2. Check the circuit breaker
3. Toggle the switch of the machine
Suction force is
weak
1. The air inlet is blocked
2. Dust box is full
3. Too much dust on the HEPA filter
surface
1. Clean the obstruction
2. Empty the dust box.
3. Clean the dust on the filter surface
Ultraviolet light is
off
1. Running trolley on the bottom of
the machine is not pressed down
2. Light is obscured.
3. The line of the ultraviolet tube is
broken off
4. The ultraviolet tube is broken
1. Press the running trolley down with
slight force
2. Shut down the machine power and wipe
the cleaning tube
3. Contact customer service
4. Contact the customer service
Tapping head
does not move
1. The switch is not pushed to “II”
2. Motor is broken
1. Push the switch to “II”.
2. Contact the customer services
WARNINGS AND SAFETY INSTRUCTIONS:
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED:
READ ALL INSTRUCTIONS BEFORE USE.
FOR DOMESTIC INDOOR USE ONLY.
DO NOT USE OUTDOORS OR FOR COMMERCIAL USE.
BEFORE USE, CHECK THOROUGHLY FOR ANY DEFECTS AND DO NOT USE IF DEFECTS ARE FOUND.
TAKE CARE NOT TO DROP THE APPLIANCE AS HEAVY IMPACTS MAY CAUSE INTERNAL DAMAGE.
BEFORE CONNECTING THE APPLIANCE, CHECK IF THE VOLTAGE INDICATED ON THE BOTTOM OF
THE APPLIANCE IS IN ACCORDANCE WITH THE MAINS VOLTAGE IN YOUR HOME.
CHECK THE APPLIANCE AND POWER CABLE CAREFULLY FOR DAMAGE BEFORE EACH USE.
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8 YEARS AND ABOVE AND PERSONS WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND
KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE
APPLIANCE IN A SAFE WAY AND UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL NOT

UV Bed Vac F874 Instructions for Use
Please read and retain these instructions for future reference v003:11/09/19
PLAY WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY
CHILDREN WITHOUT SUPERVISION.
CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY SUPERVISED.
SOME PARTS OF THIS PRODUCT CAN BECOME VERY HOT AND CAUSE BURNS. PARTICULAR
ATTENTION HAS TO BE GIVEN WHERE CHILDREN AND VULNERABLE PEOPLE ARE PRESENT.
THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD
MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE.
DO NOT LET THE POWER CABLE HANG OVER THE EDGE OF A TABLE OR COUNTER, OR TOUCH HOT
SURFACES.
DO NOT PLACE ON OR NEAR HEAT SOURCES.
USE ON A LEVEL, STABLE SURFACE.
DO NOT COVER THE ITEM IN ANY WAY WHEN IN USE AS THIS MAY CAUSE OVERHEATING.
DO NOT USE THIS APPLIANCE FOR ANY OTHER USE THAN THE INTENDED USE IT IS DESIGNED FOR.
ENSURE THERE IS SUFFICIENT DISTANCE BETWEEN THIS APPLIANCE AND OTHER ITEMS ON THE
WORK SURFACE OR WORK STATION, OR SUFFICIENT DISTANCE BETWEEN THE APPLIANCE AND THE
CONFINES OF THE AREA IN WHICH IT IS SITUATED. WE RECOMMEND A MINIMUM CLEARANCE
AROUND ALL FACES OF AT LEAST 10CM.
TO PROTECT AGAINST ELECTRIC SHOCK, DO NOT IMMERSE POWER CABLE, PLUG OR APPLIANCE, IN
WATER OR ANY OTHER LIQUID.
UNPLUG FROM OUTLET WHEN NOT IN USE AND BEFORE CLEANING.
•DO NOT OPERATE ANY APPLIANCE WITH A DAMAGED POWER CABLE OR PLUG OR AFTER THE
APPLIANCE MALFUNCTIONS, OR HAS BEEN DAMAGED IN ANY MANNER. WE RECOMMEND THAT
THE POWER CABLE IS NOT KINKED OR STORED IN A TWISTED MANNER, AND THAT YOU REGULARLY
CHECK ITS CONDITION.
•ANY REPAIRS MUST BE CONDUCTED BY A QUALIFIED ELECTRICIAN OR ELECTRICAL SERVICE AGENT.
PLUG WIRING (UK & IRELAND)
This appliance is fitted with a moulded BS 1363 13-amp plug. If you have to replace the fuse, only those
that are ASTA or BSI approved to BS1362 and with a rated current of 13-amps should be used.
If there is a fuse cover fitted, this cover must be re-fitted after changing the fuse. If the fuse cover is lost or
damaged the plug must not be used. Spare fuse holders and fuses are available from electrical outlets. If
the socket outlets in your home or office are not suitable for this product’s plug, the plug must be removed
and disposed of safely.
Attempts to insert the plug into the wrong socket is likely to cause electric hazard.
DISPOSAL
•Dispose of all packaging, paper, cartons and plastic, plastic bags in accordance with your local
recycling regulations.
•At the end of the product’s lifespan please dispose of it at an authorised household WEEE waste
recycling centre.
