COPLAR EA-LG-01 User manual

- 1 -
O
Op pe er ra at to or r’ ’s s M Ma an nu ua al l o of f
E
Ed dg ge er r A At tt ta ac ch hm me en nt t
EA-LG-01
SAVE THIS MANUALFOR FUTURE REFERENCE

- 2 -
TABLE OF CONTENTS
Safety Rules 4-5
Description 6-7
Assembly 8
Operation 9
Maintenance 10-11

- 3 -

- 4 -
SAFETY RULES
SAVE THESE INSTRUCTIONS
GENERAL SAFETY RULES
1. For safe operation, read and understand all instructions before using this product. Follow safety
instructions. Failure to follow all safety instructions listed below, can result in serious personal
injury.
2. Do not allow children or untrained individuals to use this unit.
3. Wear safety glasses or goggles that are marked to comply with Australian standards and hearing protection when
operating this unit.
4. Wear heavy long pants, boots, and gloves. Do not wear loose fitting clothing, short pants, jewelry of
any kind, or go barefoot.
5. Secure long hair so it is above shoulder level to prevent entanglement in any moving parts.
6. Keep all bystanders, children, and pets at least 50 ft. (15 m) away.
7. Do not operate this unit when you are tired, ill, or under the influence of alcohol, drugs, or
medication.
8. Do not operate in poor lighting.
9. Keep firm footing and balance. Do not overreach. Overreaching can result in loss of balance or
exposure to hot surfaces.
10. Keep all parts of your body away from any moving part.
11. When using the attachment on a trimmer with a gasoline engine, do not touch areas around the
muffler or cylinder of the power head, these parts get hot from operation. Failure to do so could
result in possible serious personal injury.
12. Always stop the engine and remove the spark plug wire or disconnect from power supply before
making any adjustments or repairs except for carburetor adjustments.
13. Inspect unit before each use for loose fasteners, damaged or missing parts. Correct before using the
edger attachment. Failure to do so can cause serious injury.
14. Use only original manufacturer’s replacement parts. Failure to do so, may cause poor performance,
possible injury, and will void your warranty.
15. Do not, under any circumstance, use any attachment or accessory on this product, which was not
provided with the product, or identified as appropriate for use with this product in the Operator’s
Manual.
16. Avoid dangerous environment. Do not use the attachment in damp or wet locations.
17. Do not use in rain.
18. Use the right attachment, do not use attachment for any job except that for which it is intended.
SPECIFIC SAFETY RULES FOR EDGERUSE
1. Clear the work area before each use. Remove all objects such as rocks, broken glass, nails, wire, or
string which can be thrown or become entangled in the edger blade.
2. Be sure all guards are properly and securely attached.
3. Replace dull or worn blade; do not attempt to sharpen.
4. Use this edger for edging along sidewalks, driveways, flower beds, and similar areas. Do not use for
any other purpose.
WARNING:
Read and understand all instructions. Failure to follow all instructions listed below, may
result in electric shock, fire and/or serious personal injury.

- 5 -
SAFETY RULES
5. Be thoroughly familiar with the controls. Know how to stop the unit and disengage the controls
quickly.
6. Do not use edger in rain or wet locations.
7. Do not use the edger on or near graveled surfaces.
8. If the edger strikes any type of foreign object:
⚫Stop the edger and remove the spark plug wire or disconnect from the power supply.
⚫Inspect for damage to the edger attachment.
⚫Correct damage before using the edger attachment. Failure to do so can cause serious injury.
9. Make yourself familiar with the area you are edging. Be aware of uneven sidewalks, holes in the
terrain as well as other similar hazardous conditions. Always push the edger attachment slowly over
rough ground.
10. Always stop the engine and remove the spark plug wire or disconnect from the power supply before
attempting to remove any obstruction caught or jammed in the blade, before installing attachment, or
making any adjustments.
11. Do not attempt to remove cut material nor hold material to be cut when the engine is running or
when the cutting blade is moving.
12. Keep feet away from the cutting area .
13. Always keep the right hand on the rear handle and the left hand on the front handle when the blade is
rotating.
SAFETY RULES WHEN ATTACHMENT IS ATTACHED TO AN ELECTRIC POWERHEAD
1. When this attachment is being used with the
recommended electric power unit, refer to
“Electrical Safety Rules”in the electric power
unit’s Operator’s Manual, in addition to items
contained in this manual.
2. Make sure the cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
stepped on, tripped over, or otherwise subjected to
damage or stress. Keep cord clean of the working
area.
3. Do not abuse the power cord. Never carry the
product by the cord. Never yank the plug out of the
receptacle. Keep the cord away from heat, oil, and
sharp edges.
4. Inspect extension cords for deterioration, cuts, or
cracks in the insulation. Repair or replace the cords
if any defects appear.
WARNING:
A coasting blade can cause injury while it continues to spin after the engine is stopped or throttle
trigger released. Maintain proper control until the blade has completely stopped rotating.
WARNING:
Keep the extension cord clear of the
working area. Position the cord so that it
will not come in contact with the edger
attachment when in use. Failure to do so
can result in serious personal injury.
WARNING:
Check extension cords before each use.
If damaged replace them immediately.
Touching the damaged area could cause
serious injury due to electrical shock.

- 6 -
DESCRIPTION
Before using the Straight Shaft Trimmer Attachment, familiarize yourself with all operating features and safety
requirements.
PART LIST OFTHE EDGERATTACHMENT
1
Blade Kit
21
Hex nut
2
Nut-lock
22
Hex screw
3
Washer-flanged (lower)
23
Flat- washer
4
Blade
24
Guide-curb
5
Washer-flanged
25
Wheel kit
6
Guard kit
26
Washer-flat
7
Screw-Hex
27
Wheel
8
Washer-lock
28
Nut-push
9
Flang
29
Gearhead & screw kit
10
Decal-warning label
30
Hexagon head screw
11
Logo label
31
Flat- washer
12
Guard W/ Hex screw
32
Cap head screw M6X30
13
Flap
33
Gear head Ass'y
14
Washer
34
Boom assembly
15
Nut-hex
35
Shaft flexible
16
Support arm assembly
36
Drives shaft housing ass'y
17
Support plate
37
Dustproof cover
18
Wheel mounting plate
38
Decal-warning label
19
Washer-flat
39
Hanger
20
Knob-adjusting W/ Nut-hex
40
Bar-removal & refitting the blade
WARNING:
Do not allow familiarity with your tool to make you careless. Remember that a careless fraction of a second is
sufficient to inflict severe injury.

- 7 -
DESCRIPTION
Fig.1

- 8 -
ASSEMBLY
The edger attachment is fully assembled at the factory and requires no further assembly.
JONING THE POWER HEAD TO THE EDGERATTACHMENT
See Figure 2.
The edger attachment connects to the power head by means of a coupler device.
1. Loosen the knob on the coupler of the power head shaft and remove the end cap from the edger
shaft.
2. Push in the button located on the edger attachment shaft. Align the button with the guide recess on
the power head coupler and slide the two shafts together. Rotate the edger attachment shaft until the
button locks into the positioning hole.
NOTE: If the button does not release completely in the positioning hole, the shafts are not locked into
place. Slightly rotate from side to side until the button is locked into place.
3. Tighten the knob securely.
REMOVING THEATTACHMENT FROM THE POWER HEAD
For removing or changing the attachment.
1. Loosen the knob.
2. Push in the button and twist the shafts to remove and separate ends.
WARNING:
Never attach or adjust any attachment while power head is running. Always stop the unit and remove the spark
plug wire or disconnect from the power supply. Failure to heed this warning can cause serious personal injury.
WARNING:
Be certain the knob is fully tightened before operating equipment; check it periodically for tightness during use
to avoid serious injury.

- 9 -
OPERATION
OPERATING THE EDGER
See Figure 3.
Hold the edger with the right hand on the rear handle and the left hand on the front handle. The edger
should be held on the right side of the body. Keep a firm grip with both hands while in operation. The
edger should be held at a comfortable position with the rear handle about hip height.
NOTE: When the attachment is being used on a trimmer with a gasoline engine, always operate at full
throttle. Prolonged cutting at partial throttle will result in oil dripping from the muffler.
CUTTING TIPS
See Figure 3.
1. The edger will edge along sidewalks, driveways, flower beds, curbs, and similar areas.
2. Use the arrow guide on the blade guard to align the blade with the edging surface.
3. Cut at steady pace. If the blade begins to bog down, you are edging too fast; slow your pace. Do not
force the blade into ground.
4. Light contact of the blade against the sidewalk edge, curb, etc. is acceptable and will not damage the
edger.
5. Best appearance is obtained when grass is dry. Avoid edging in wet soil or wet grass areas or the
blade guard might clog and result in an uneven edge. If the blade guard becomes clogged, stop the
engine, remove the spark plug wire or disconnect from the power supply, and remove debris from
the blade guard.
TOADJUST THE BLADE DEPTH
See Figures 4 and 5.
Depth of the cut is determined by the distance from the bottom of the wheel to the tip of blade.
1. Stop the engine and remove the spark plug wire or disconnect from the power source.
2. Loosen the adjusting knob and move the wheel arm up to increase the depth and down to decrease
the depth.
3. After adjustment is complete, tighten the adjusting knob securely.
4. Replace the spark plug wire or connect to the power supply and start the unit.
NOTE: Adjust the blade depth from 1/2 in. to 1 in. (1.2 to 2.5 cm) deep initially. Make a shallow cut to
test the cutting depth. If the cutting depth needs adjusting, this should be done progressively until the
desired is reached.
WARNING:
Wear safety glasses or goggles when operating this tool. Failure to do so could result in possible serious injury.

- 10 -
MAINTENANCE
1. Never operate a unit that is damaged, improperly adjusted, or is not completely and securely
assembled.
2. Always stop the engine and remove the spark plug wire or disconnect from the power supply before
making any adjustments or repairs.
3. Inspect the unit before each use for loose fasteners and damaged or missing parts. Replace any parts
that are cracked, chipped, or damaged in any way. Failure to do so can cause serious injury.
4. Make sure all handles are properly and securely attached.
5. Never modify the unit in any way. Do not use for any job except that for which it is intended.
6. For service, contact a service dealer.
NOTE: You can often make adjustments and repairs described here. For other repairs, have the
attachment serviced by an authorized service dealer.
BLADE REPLACEMENT See Figures 6, 7, 8, and 9.
Replace blades that are damaged or worn.
Stop the engine and remove the spark plug wire disconnect from the power supply.
Always make sure the blade is correctly installed and securely fastened before each use.
1. Align the slot in the upper flange washer and gear case with the slot in the flange; place the holding
pin through all three slots to secure in place.
2. Using a 1/2 inch socket wrench, turn the blade nut clockwise to loosen.
3. Remove the blade from the edger shaft.
4. Clean debris from the edger shaft and flange washers.
5. Center the blade on the upper flange washer making sure the blade sits flat.
6. Install the lower flange washer with the cupped hole away from the blade.
7. Install the blade nut onto the edger shaft.
8. Align the slot in the upper flange washer and gear case with the slot in the flange; place the holding
pin through all three slots to secure in place.
9. Using a 1/2 inch socket wrench, turn the blade nut counterclockwise onto the edger shaft and tighten
securely.
DEBRIS FLAP REPLACEMENT
See Figure 10.
Replace the debris flap if it is worn.
1. Using a 10 mm wrench or socket, remove the retaining nuts, washers and debris flap.
2. Install the new debris flap. This replacement part is available from the place of purchase.
3. Replace retaining nuts and washers.
4. Tighten securely.
STORING THE EDGERATTACHMENT
Store the edger attachment in a well ventilated place that is inaccessible to children. Keep away from
corrosive agents such as garden chemicals and de-icing salts.
To remove the edger attachment from the power head for storage:
WARNING:
Use only original manufacturer’s replacement parts, accessories and attachments. Failure to do so may cause
poor performance, possible injury and may void your warranty.

- 11 -
MAINTENANCE
1. Always stop the engine and remove the spark plug wire or disconnect from the power supply before
removing the attachment.
2. Loosen the knob on the coupler device.
3. Push the button in, then twist the shafts to remove and separate the power head from the attachment.
For storing information: Please refer to the operator’s manual of your power head.
ATTACHING THE STORAGE HANGER
See Figure 11.
There are two ways to hang your attachment for storage.
1. To use the hanger cap, push in the button and place the hanger cap over end of the edger attachment
shaft.
2. The secondary hole in the edger attachment shaft can be used for hanging purposes as well.
