copymaster3D Voron User manual

151
WWW.VORONDESIGN.COM
Heat Set Insert
AVAILABLE MOUNTS
We also provide mounts for
other hotends.
They are assembled in a similar
manner.
TOOL CARTRIDGE
www.copymaster3d.com
[e-mail]

152
WWW.VORONDESIGN.COM
E3D V6 Hot End
HEATER AND SENSOR
We do not show the heater and
temperature sensor cartridge in the
drawing. Install them prior to assembling
the toolhead.
TOOL CARTRIDGE
www.copymaster3d.com
[e-mail]

153
WWW.VORONDESIGN.COM
WWW.VORONDESIGN.COM
M3x16 SHCS
PTFE Tube
TOOL CARTRIDGE
DIFFERENT TOOL CARTRIDGES
The mounts for all hotends are designed
to have a piece of PTFE here. It might be
held in place by the printed parts instead.
www.copymaster3d.com
[e-mail]

154
WWW.VORONDESIGN.COM
M3x40 SHCS
PTFE STICKOUT
The PTFE tube should end 10mm above
the surface of the printed part.
The stick out length might vary if you use
an extruder other than the Clockwork.
TOOL CARTRIDGE
www.copymaster3d.com
[e-mail]

155
WWW.VORONDESIGN.COM
CHECK ORIENTATION
The heater block must
point forwards.
WIRING PATH
Guide the wires in the
highlighted path.
TOOL CARTRIDGE
www.copymaster3d.com
[e-mail]

156
WWW.VORONDESIGN.COM
TOOL CARTRIDGE
www.copymaster3d.com
[e-mail]

157
WWW.VORONDESIGN.COM
TOOL CARTRIDGE
INDEXING BOLTS
The bolts are used to index the tool
cartridge. Leave them slightly loose so
that the cartridge can be slid out.
www.copymaster3d.com
[e-mail]

158
WWW.VORONDESIGN.COM
BMG Drive Pinion
MOTOR PLATE
MOTOR ORIENTATION
Rotate the motor in such a way that
the connector/wires are on the left side
when looking at it from the back.
This side will be covered by the cable
cover later.
NEMA 17 Stepper
DRIVE PINION
Make sure the set screw in the drive
pinion is seated on the at of the motor
shaft. Use thread locker.
www.copymaster3d.com
[e-mail]

159
WWW.VORONDESIGN.COM
M3x8 SHCS
ADJUSTABLE MOTOR POSITION
The motor position is adjustable to allow for
a proper meshing of the drive gears.
Start in the topmost position of the slot.
MOTOR PLATE
www.copymaster3d.com
[e-mail]

160
WWW.VORONDESIGN.COM
BMG Drive Gear
MR85 Bearing
CHECK BEARING FIT
The bearings must slip on and off the shaft
easily to allow the gear to self-centre. Do not
shim into position.
Pressing the bearings on the shaft will
damage them.
Lightly sand the shaft if required.
DRIVE GEAR
CHECK PLACEMENT
Make sure the lament drive gear
is fully seated against the drive
shaft gear.
DRIVE GEAR
Make sure the set screw in the lament drive
gear is seated against the notch in the shaft.
Carefully tighten the set screw, the head is easy
to strip.
https://voron.link/p0xac5e
www.copymaster3d.com
[e-mail]

161
WWW.VORONDESIGN.COM
M3x30 SHCS
MAIN BODY
CHECK FOR CLEARANCE
The drive shaft must not touch the motor
housing.
Check if the shaft has sufcient clearance
when fully seated.
Sand the face of shaft if required.
www.copymaster3d.com
[e-mail]

162
WWW.VORONDESIGN.COM
CHECK GEAR PLAY
The gear should have a slight play and
should not be fully tight against the
pinion. Adjust the position of the motor
until you have a faint play.
GEAR LASH CHECK
www.copymaster3d.com
[e-mail]

163
WWW.VORONDESIGN.COM
BMG Idler Assembly
LUBRICATE BEARINGS
A lubrication lm is required to ensure
smooth operation and longevity.
Refer to the BOM for lubricant options -
look for a “light grease”.
GUIDLER
https://voron.link/dncvwdm
www.copymaster3d.com
[e-mail]

164
WWW.VORONDESIGN.COM
M3x30 SHCS
M3x20 SHCS
GUIDLER & LATCH
www.copymaster3d.com
[e-mail]

165
WWW.VORONDESIGN.COM
BMG Thumb Screw
CABLE COVER
REMOVE SCREWS
Carefully remove the screws from the
left side of the motor. They will be
replaced with new bolts in the next
step.
www.copymaster3d.com
[e-mail]

166
WWW.VORONDESIGN.COM
M3x20 SHCS
M3x8 SHCS
OPTION: TOOLHEAD PCB
If you opted to use a toolhead PCB, skip the wire
cover and follow the instructions on page 174.
CLOCKWORK
www.copymaster3d.com
[e-mail]

167
WWW.VORONDESIGN.COM
CLOCKWORK
www.copymaster3d.com
[e-mail]

168
WWW.VORONDESIGN.COM
M3x20 SHCS
M3x30 SHCS
CLOCKWORK
www.copymaster3d.com
[e-mail]

169
WWW.VORONDESIGN.COM
4010 Fan
4020 Blower
REMOVE TOP COVER
Split the fan open by
bending the tabs on the
side.
FAN ASSEMBLY
https://voron.link/vyvtcpa
www.copymaster3d.com
[e-mail]

170
WWW.VORONDESIGN.COM
FAN ASSEMBLY
WIRING PATH
Route the wires through the large opening in the back.
www.copymaster3d.com
