Copytrax MONET 5000 Pro User manual

User Manual
MONET 5000 Pro
and
MONET 5000 Pro-Recorder
April 2005 Issue1

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 2
1General................................................................................................................3
1.1 Introduction........................................................................................................4
1.1.1 Front View..................................................................................................4
1.1.2 User Buttons and Status-LED’s..................................................................4
1.1.3 Rear view...................................................................................................7
2Printer driver.......................................................................................................8
2.1 Installation.........................................................................................................8
2.1.1 First Installation (Plug & Play)...................................................................8
2.1.2 Manual Installation...................................................................................10
2.1.3 Uninstalling...............................................................................................17
2.1.4 Driverupdate.............................................................................................19
2.2 Description ......................................................................................................29
2.2.1 Printer Properties.....................................................................................30
2.2.2 Maintenance Dialog .................................................................................34
2.2.3 How to set print quality and mode............................................................38
3Maintenance and Cleaning ..............................................................................40
3.1 Lubrication Of Shafts.......................................................................................40
3.2 Maintenance waste Ink Pad............................................................................41
3.2.1 Required Parts and Tools.........................................................................41
3.2.2 Description Waste Ink Pad Replacement.................................................41
3.3 Maintaining The Printer Body..........................................................................45
3.3.1 Printer Case Exterior................................................................................45
3.3.2 Printer Interior ..........................................................................................45
3.3.3 Printer Cradle Bar ....................................................................................45
3.3.4 Handling And Storage..............................................................................45
4Troubleshooting...............................................................................................46
4.1 The CDP print engine shows an error.............................................................46
4.2 Printer-LED’s are on or flashing ......................................................................47
4.2.1 Functions of LED’s...................................................................................47
4.2.2 Print Cartridge-Status LED on or flashing ................................................47
4.2.3 Resume-LED flashing ..............................................................................47
4.2.4 Power-LED flashing .................................................................................47
4.2.5 All LED’s are flashing...............................................................................47
5Technical Data..................................................................................................48

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 3
1 General
Description:
The CD Printer 5000 Pro & Pro-Recorder is a CD/DVD ink jet printer, based on the HP
DeskJet 5000 series printer technology from Hewlett Packard. The form feed is
replaced by a compact disc printer drawer (Tray).
The CD Printer 5000 Pro & Pro-Recorder prints directly to the surface of printable CDs
or DVDs coated for ink jet colour print.
The CD Printer 5000 pro Recorder, has the added feature of an internal CD / DVD
recorder and as such can simultaneously both print & record CD & DVD discs in
dedicated trays.
System Requirements:
PC
USB port.
Full speed (USB 1.1) or High speed (USB 2.0)
The CD Printer 5000 Pro& Pro-Recorder operates with Windows 2000 or Windows XP
Macintosh
USB port.
Full speed (USB 1.1) or High speed (USB 2.0)
The CD Printer 5000 Pro& Pro-Recorder operates with OS X
Important !!!
Due to the inkjet – technology used in this printer, an aerosolor mist of ink particles can
migrate through the interior of the system. Additional regular maintenance like
lubricating the tray shafts & cleaning the interior of the printer as well as cleaning of the
decoder wheel and the decoder strip is required.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 4
1.1 Introduction
1.1.1 Front View Front cover to
access cartridges
and printer mechanics
Power on switch
and Power LED
User buttons and Media Tray – Print only.
Status LED`s
Optional CD / DVD Recorder
( 5000 Pro – Recorder )
1.1.2 User Buttons and Status-LED’s
With the user buttons, the CD Printer 5000 Pro & Pro-Recorder can be switched on or
off, theprint & record trays can be ejected and inserted.
and a print job can be aborted or restarted.
The Status-LED’s give information about the printer status.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 5
Power on switch
and Power LED
Power Button and - LED
With the Power Button you can switch the printer on and off.
After pressing it takes a couple of seconds until the printer becomes ready.
The Power LED blinks when printing data is being processed.
Caution!
Always use the Power button to turn on or off.
Using a power strip, surge protector, or a wall-mounted switch to turn the printer on and
off may cause printer failure.
Switch for opening and closing the printer tray
Press the Resume Button for 2 sec. ( see page 6 ) to open the tray for putting discs into
the tray or getting discs from the tray. On the same way you can close the tray.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 6
Cancel Button
Print Cartridge Status - LED
Resume Button and LED
Cancel Button
The current print job is aborted by pressing the Cancel Button.
Print Cartridge Status - LED
The Print Cartridge Status LED blinks when a cartridge needs to be replaced or requires
maintenance as well as when the front cover is open.
Resume Button and - LED
The Resume Button blinks in case of a general error, or if no disc is present in the
printing tray.
Put a disc into the drawer and press the resume button to start the printing.
If the resume LED is blinking, you can not use the black switch at the right side,
You have to press the resume button.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 7
1.1.3 Rear view
Power LED ( Green )
Rear cover
Power connector
100 - 230V USB connector
(CDP 5000 Pro & Pro-Recorder)
On / Off Switch

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 8
2 Printer driver
2.1 Installation
2.1.1 First Installation (Plug & Play)
Connect the CD Printer 5000 Pro & Pro-Recorder to the power supply.
Switch-on is not necessary since the personal computer recognizes the printer also in
idle status.
Connect the printer with a USB cable to the PC.
The Plug & Play function recognizes now automatically that a new printer is connected
and starts the installation routine.
Set the options like they are set in the
screen shot on the left.
With the button „Browse“, you can set
the path to the installation file called
„lsf5600k.inf”.
Again, click „Next“ to continue.
Please chose the option „Install from
a list or specific location (Advanced)“.
Only with this option, you have the
full control and you make sure to
install the proper driver.
Click „Next“ to continue.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 9
This dialog field informs you that the
driver is not registered officially with
the manufacturer of the operating
system.
It does not state, however, anything
about the quality of the driver.
You can be sure, that the driver is
programmed and tested with the
latest programs and tools.
You can continue the installation
without any doubt.
Please wait until the driver is installed
and all files were copied.
This can take some minutes.
NOTE : At the end of the installation the personal computer must be
restarted!
Completing the Add Printer Wizard and
starting the installation, by pressing the
button „Finish“.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 10
2.1.2 Manual Installation
Please open the dialog „Printers and
faxes“.
Run the „Add Printer Wizard“ by
pressing the button „Add a printer“.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 11
Click “Next” to continue.
Select the option „Local printer
attached to this computer“ and press
the „Next“ button to continue.
Select a free USB Port.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 12
Again, click „Next“ to continue.
Press the button „Have Disk...“.to
select the path to the installation file
Search the path by clicking on the
button „Browse...“.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 13
Select the installation file.
Select the drive.
Select the path.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 14
Press “OK” to continue.
It is not necessary to print a test
page.
To continue the installation press “Next”.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 15
This dialog field informs you that the
driver is not registered officially with
the manufacturer of the operating
system.
It does not state, however, anything
about the quality of the driver.
You can be sure, that the driver is
programmed and tested with the
latest programs and tools.
You can continue the installation
without any doubt.
In this dialog, you can change the
name of the printer and you can set
the printer as default.
We recommend to use the suggested
name CD PRINTER 5000.
Complete the Add Printer Wizard and start
the installation by pressing the button
„Finish“.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 16
Please wait until the driver is installed
and all files were copied.
This can take some minutes.
NOTE : At the end of the installation the personal computer must be
restarted!

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 17
2.1.3 Uninstalling
In order to uninstall the printer driver,
the personal computer must be restarted first of all.
This is necessary so that all files which are used by the old printer driver are not blocked
by other applications or the operating system.
Blocked files can not be removed during the deinstallation.
This may cause problems, in the case of a later reinstallation..
All programs must be closed before the deinstallation of the printer driver.
1.) Deleting the CD Printer 5000 Pro & Pro-Recorder
printer symbol in the printer status monitor.
2.) To delete the CD Printer 5000 Pro & Pro-Recorder driver files, run the program
“O2uninst.exe” from the
directory „C:\Windows\System32\ and follow the instructions
Start the uninstalling by
pressing the “OK” button.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 18
If no problems occur during the installation, you get
this Information dialog.
The uninstalling is finished after the restart of the
Personal Computer.
This window comes up, when
some files could not deleted
by the Uninstaller.
Please restart the Personal
Computer and run this
uninstaller application again.
NOTE : At the end of the uninstalling the personal computer must be
restarted!

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 19
2.1.4 Driverupdate
At first, download the latest driver from the FTP download server
if the latest driver is available on CD.
Look on www.copytrax.com to find the latest CD PRINTER 5000 PRO driver.
In order to update the printer driver,
the personal computer must first be restarted.
This is necessary so that all files which are used by the old printer driver are not blocked
by other applications or the operating system.
Blocked files can not be removed during the update process.
All programs, which have access to the printer driver, must be closed before the update.
Please disconnect the USB connection of the CDP and the PC.
There are three possible ways to get the printer driver up to date.
a.) Only changed files of the driver will be replaced.
b.) All files of the driver will be replaced.
c.) Windows specific updatesolution, which we not recommend to use,
because you can not be sure that all necessary files are updatet
succesfully.
Update a.) Only changed files of the driver will be replaced.
After restarting the PC and disconnecting the USB connection of the printer,
You have to start the program „O2Update,exe“ gestartet.
This programm is part of the driver and is located in the main directory.
Press OK to start the Update process.

COPYTRAX TECHNOLOGIES MONET 5000 Pro & Pro-Recorder
May 2005 www.copytrax.com 20
If one file can not be deleted,
this dialog box appears.
Press OK to go on with the update.
In this case, take care of the Finish Dialog.
Restart the PC after finishing the program
and run the Update program again.
If one file can not be deleted,
this dialog box appears.
Press OK to go on with the update.
In this case, take care of the Finish Dialog.
Restart the PC after finishing the program
and run the Update program again.
This Dialog appears, when an error
during the update occurs.
Restart the PC after finishing the
program and run the Update program
again.
