Epson SC-P10000 SERIES Operating manual

MAINTENANCE GUIDE
EPSON SC-P10000 / SC-P20000
oWhy this guide ?
oRegular Printer Maintenance.
•Frequency
•Required Consumables Items
•Print Head Cleaning
•Housing & Platen Cleaning
oSetting & Using the Printer
•Advices of usage
•Control Panel Settings

2
Why this guide ?
Epson SureColor SC-P10000 et SC-P20000 Printers are Products highly
oriented to high productivity & high print quality.
All mechanical aspects have been improved to reach high speed &
quality, reason there are big differents in comparison with Epson Stylus
Pro -11880.
To guarantee continuous print quality and high Speed, we have decided
to create this guide which details all aspects and benefits of a regular
printer maintenance.
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

Periodical Printer Maintenance
MAINTENANCE GUIDE
EPSON SC-P10000 / SC-P20000

4
Operation Frequency
MAINTENANCE Frequency Necessary Tools
Head Maintenance
(Print Head + Caps) 1 per week Cleaning Sticks
Inside the printer and
Platen cleaning 1 per week
- Fiber free cloth*
- Cleaning sticks/swabs
Cleaning the printer
Housing 1 per month - Soft brush - Soft fiber free cloth
Cleaning the Media slot
and path 1 per month Cleaning Sheet
Shaking Ink Cartridge 1 per month -
EPSON SC-P10000/P20000
*recommended Fiber Free Cloth = berkshire SuperPolX 1200, Epson ASP n° 1612238
ETS Prographics –Nov 2017

5
Name Reference
Cleaning Sticks* 1
(50 pieces) C13S090013
Cleaning Sheets
(5 pièces) C13S400045
Berkshire SuperPolX 1200*2
(1 pack=150pieces) 1612238
Necessary EPSON Consummables for maintenance
*11 cleaning stick is delivered with the printer box accessories
*2recommended Fiber Free Cloth = berkshire SuperPolX 1200
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

6
Print Head maintenance
Never use the below items
Air spray Abrasive Sponges Liquid Glass spray Fluffy cloth
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

7
Start the printer in "Head Maintenance" :
Simultaneously press the“maintenance” button ( )
and Power ON ( )
Release the “Maintenance” button when
Control Panel displays "Head Maintenante"
menu.
Press the [Ok] button to allow the Carriage
positionning to Maintenance section (full
side).
If necessary, unload the media and turn the
printer OFF.
1
2
3
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

8
Open the left Ink Cartridge cover and remove the
2 screws with black plastic head.
Slide to the left the cover and pull it out.
Close the Ink Cartridge Cover.
4
5
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

9
Using the Cleaning stick, wipe the four edge of the
head (only) as shown on the pictures below
6
•Never touch the print head surface
•Wipe only the print head edge, even if
you notice dust onto the surface.
Dust and fibers will be removed thanks to the
action of the pump Cap Unit and the the wiper
blade.
You can use a light torch or smart phone light to have a better
visibility of the print head surface.
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

10
If necessary, remove the possible dust surrounding the Maintenance area with a fiber free cloth.
Put back the maintenance front cover and the 2 fixing screws.
7
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

11
Open the top cover and locate the 2 suction caps at the right area of the platen.
Using a cleaning stick, wipe the suctions cap as shown on the picture below to remove
possible dust & fibers.
8
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

12
Cleaning the Head wiper blade
9
A. Wipe inside and
outsilde of the front
wiper blades
B. Wipe inside and
outsilde of the rear wiper
blade
C. Wipe the top surface
of the wiper blades
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

13
After cleaning Print Head & Wipers
10
1. Close the printer maintenance Cover and press the [OK]
button of the control panel.
2. Head is back to home position and a light cleaning
sequence starts immediately.
3. When the cleaning sequence is terminated, the control
panel displays this message (see right picture) :
1. Turn the printer OFF.
Print Head maintenance
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

14
1 Cleaning the Platen & Borderless Porous Pads
Make sure the printer AND control panel are
totally OFF without any warning or Led
activated.
Unplug the power cable and wait 1mn before
any other action. - Open the printer top cover.
Using a fiber free soft cloth,
clean the platen surface from
backward to frontward:
In case of some particles of fiber
or dust inside the platen suction
holes, use a small twizzers or
thooth-peek to remove those
particles
In case of some fibers or dust accumulated
onto the porous pads, use a cleaning stick to
remove those particles.
IMPORTANT:
If you face a very dusty platen, use a fiber free cloth lightly mosturized with water
to remove the dust with more efficiency. Do not hesitate to wring the cloth to
remove the excess of water before use.
IMPORTANT:
Never force wiping the porous pads. They may
get out from the platen.
Cleaning Inside / outside of the printer
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

15
Cleaning Inside / outside of the printer
2 Cleaning the Paper Feed stabilizer
Sensor window :
Clean the Paper Feed Stabilizer sensor
window using a cleaning stick or any cotton
swab.
If the Feed Stabilizer sensor window is very
dusty , moisturize the cotton swab with few
drops of soapy water.
Remove excess of water before wiping the
Feed Stabilizer sensor window.
3 Cleaning the Fan exit surface
It's important to check the fan exit are not obsutrated by
any dust, fibers or other substance. The presence of dust
may reach print head and other sensitive printer part.
When dust are visible onto the Fan exit surface, use a small
vacuum to eliminate all the dust.
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

16
4 Cleaning the Media Insertion Slot
A dust retainer (felt) has been factory added at the media insertion slot along printer
width. The prupose of this felt is to catch media fibers and dust falling down onto
media surface. Reason it's necessary to regularly (1 per month) wipe this felt retainer
using the included cleaning sheet (Ref. 5 sheets Pack : C13S400045).
1. Pull out the protective layer of the cleaning sheet.
The dark side (mark A) is the sticky surface
Do not touch the sticky surface with your fingers and don't let it stick or touch any
other surface than the printer felt.
2. Adhesive side toward you, insert about 1cm of the cleaning sheet inside the media
slot then pull it out. Repeat this operation between 2 or 3 times.
3. Repeat the above step along the full printer width, from left to right. When finished,
dispose the cleaning sheet.
Cleaning Inside / outside of the printer
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

Using the Printer
Printer Configuration Menus
MAINTENANCE GUIDE
EPSON SC-P10000 / SC-P20000

18
1 Close the Media Top Cover
To avoid any dust onto the media roll, it's
important to keep this cover closed during
and after print operation.
2 Shake The Ink Cartridges
To ensure maximum print quality, it's necessary to shake all the ink
cartridges once per month.
Pull out the Ink Cartridges from the Slot and shake horizontaly 30
times during 10 sec with 5cm movements
Usage Advices / Printer Setup Menu
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

19
Usage Advices / Printer Setup Menu
Periodically = every 1/4h
1 cleaning
Pause
Recommended Configuration
Printer Setup Menu
3.a Setting the Auto Nozzle check and Automatic cleaning
Utilisation de l'imprimante / Configuration
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017

20
3.b
On
Light
Recommended Configuration
Administrator Menu
Utilisation de l'imprimante / Configuration
Setting the Auto Nozzle check and Automatic cleaning
Usage Advices / Printer Setup Menu
EPSON SC-P10000/P20000
ETS Prographics –Nov 2017
