Cornelius ED User manual

ED Ice Maker Adapter Kit Installation Instructions Manual
© 2016, Cornelius Inc. - 1 - Publication Number: 629087971TENS
INSTALLATION INSTRUCTIONS
ED ADAPTER KIT FOR FOLLETT ICEMAKERS
SAFETY INSTRUCTIONS
!
WARNING:
Before starting installation, read and understand all safety label and warnings on the machine. Also review and
understand all safety instructions in the owners, installation and service manuals.
Failure to comply could result in serious injury, death or damage to the equipment.
QUALIFIED SERVICE PERSONNEL
!
WARNING:
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit.
All wiring and plumbing must conform to national and local codes. Failure to comply could
result in serious injury, death or equipment damage.
SAFETY PRECAUTIONS
This unit has been specifically designed to provide protection against personal injury. To ensure continued
protection observe the following:
!
WARNING:
Disconnect power to the unit before servicing. Follow all lock out/tag out procedures established by the user. Verify all
power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
CAUTION:
Always be sure to keep area around the unit clean and free of clutter.
Failure to keep this area clean may result in injury or equipment damage.
Revision Date: July 12, 2016 www.cornelius.com Revision: A

ED Ice Maker Adapter Kit Installation Instruction Manual
Publication Number: 629087971TENS - 2 - © 2016, Cornelius Inc.
1. Remove the plastic hopper lid(s) from the top of the dispenser.
2. Install soft ice agitator kit (sold separately) into the dispenser.
NOTE: This soft ice agitator kit is required for proper dispenser operation using “compressed” or
“soft” ice types. Failure to install this kit may result in undesirable beverage quality.
3. Unpack and inspect the adapter kit.
4. Assemble the baffle assembly onto the adapter lid as shown in Figure 1.
Figure 1.
5. Set and secure adapter lid onto the dispenser, as shown in Figure 2.
Figure 2. Dispenser Assembly
ICEMAKER
MOUNTING BRACKET
#8 SELF
DRILLING SCREWS
#8-32 MACHINE
SCREWS (300 ONLY)
OR
#8 SELF TAPPING SCREWS
FOR THE 1XX/2XX LIDS
ADAPTER LID
SCALE 1.000
DRILL Ø9/64 (.140) HOLES
USING BOTTOM OF SLOTTED
HOLES AS A TEMPLATE.
1XX & 2XX ONLY
MANUAL FILL LID
LANYARD

ED Ice Maker Adapter Kit Installation Instructions Manual
© 2016, Cornelius Inc. - 3 - Publication Number: 629087971TENS
6. Remove merchandiser from dispenser by lifting up then pulling out. Set merchandiser aside.
7. Adjust the automatic agitator timing settings (located in the dispenser’s electrical box) to 2 seconds ON, 3 hours
OFF. See Figure 3.
Figure 3.
8. Re-install the merchandiser back onto the dispenser.
9. Set Icemaker onto the adapter kit. See Figure 4 and Figure 5 for location dimensions.
Figure 4. ED/DF 1XX and 2XX
DIM. "A"
REF
DISPENSER ICEMAKER DIM "A"
150 HCD1000RN 1-9/16
150 HCD1400RN 1-9/16
175 HCD1000RN 2-13/16
175 HCD1400RN 2-13/16
2XX HCD1000RN 5-9/16
2XX HCD1400RN 5-9/16
2XX HCC1400AW 3/8
2XX HCC1000AW 1-7/8
REAR OF DISPENSER
LEFT SIDE
OF DISPENSER
TOP VIEW
ICEMAKER MOUNTING DETAILS
ICEMAKER BASE
OUTLINE
ICEMAKER FLUSH WITH
REAR OF ADAPTER KIT
Ø 3.0”

ED Ice Maker Adapter Kit Installation Instruction Manual
Publication Number: 629087971TENS - 4 - © 2016, Cornelius Inc.
Figure 5. ED/DF300
NOTE: FOR ED/DF300 ONLY - Be sure to center the ice drop opening of the Icemaker directly over the
deflector plate. Failure to do so may result in un-even hopper fill.
10. ED/DF300 only – Tighten the four (4) ice deflector mounting screws.
11. Follow the Icemaker manufacturing instructions to complete the installation of the Icemaker.
12. Install Icemaker bin thermostat just underneath ice deflector, see Figure 6 for location area.
Figure 6.
NOTE: Failure to install a bin thermostat correctly may result in inadequate hopper fill, ice dispense
issues, hopper “ice bridging”, and/or possible damage to the Icemaker.
REF
2-1/16
DIM "B"
REF
REF
19-1/2
DISPENSER ICEMAKER DIM "B"
300 HCD1000RN 9-5/16
300 HCD1400RN 9-5/16
300 HCC1000AW 7-5/8
300 HCC1400AW 9-1/8
REAR OF DISPENSER
LEFT SIDE
OF DISPENSER
TOP VIEW
ICEMAKER MOUNTING DETAILS
THESE DIMENSIONS ARE TO AID IN INSTALLATION. ACTUAL LOCATION MAY VARY.
ICEMAKER BASE
OUTLINE
CENTER ICEMAKER ICE DROP
OVER ICE DEFLECTOR
Area to located sensing line
for the bin thermostat -
typical for all installations

ED Ice Maker Adapter Kit Installation Instructions Manual
© 2016, Cornelius Inc. - 5 - Publication Number: 629087971TENS
13. Apply a continuous bead of NSF International (NSF) listed silastic sealant (Dow 732 or equivalent) to seal the ice
maker to the top of the adapter lid. All excess sealant must
be wiped away immediately.
14. Install the ice maker mounting brackets on the back of the ice maker by drilling 9/64” diameter holes, using one of
the two supplied brackets as a template, into the rear of the ice maker and the rear of the adapter lid.
IMPORTANT:
!
Use extreme care no to drill into any ice maker components.
Secure the Icemaker to the adapter lid using the #8 self drilling and mounting brackets provided.
15. Re-connect electrical power to the dispenser.
16. Verify function and operation of both Icemaker and dispenser.
